Users Manual
SA-29G
Installation Instructions Supervised Wireless Repeater
1 0706-0960080+01
1. General Description
The SA-29G is a high performance, supervised, wireless
repeater for Rosslare's Millennium Wireless Security
product line. SA-29G is compatible with a wide variety of
wireless control panels, universal receivers, RF sensors,
and remote controls.
Note 1: This product must be installed professionally, and
has only one available channel.
Note 2: Pursuant to FCC §15.21 [54FR 17714, Apr. 25,
1989, as amended at 68 FR 68545, Dec. 9, 2003), changes
or modifications made to equipment which are not
expressly approved by Rosslare Enterprises, Ltd., may void
the user’s authority to operate the quipment.
1.1. Standard Features
1) Integral rechargeable battery - provides up to 10 hours
(UPS) backup power with up to 10 years standby
battery life.
2) Supervision signal - transmitted every 20 minutes.
3) Case Tamper and optional Back Tamper.
4) Advanced microelectronics for ultra-low current
consumption.
2. Technical Specifications
2.1. Electrical Characteristics
Primary Power Supply: +12V DC (+) Linear regulated; (-)
GND: two terminal blocks.
Backup Power Supply: UPS Rechargeable Lithium-Ion
Battery: 4.2 Volt 1600 mAh
Current Consumption: DC Powered Standby - 14.5 mA
DC Powered Transmit - 29 mA
Battery Powered Standby - 7.5 mA
Battery Powered Transmit - 20 mA
2.2. Environmental Characteristics
Operating Temperature: -5°C to +50°C (-23°F to +122°F)
Operating Humidity: Up to 95% non-condensing (max.)
RF Receiving Sensitivity: The integrated wireless receiver is
rated at -111 dBm sensitivity for receiving incoming RF
signals; 180 meters- Open Field
RF Transmission Output Power: SA-29G - up to 10 mW or 10
dBm; 200 m (approx 600 feet) - Open Field
RF Transmission Frequency: 433.92 or 868.35 MHz
Cover Tamper Switch: Detects the removal of the SA-29G
front cover.
Back Tamper Switch: Detects the removal of the SA-29G
from the wall (optional using Jumper).
Supervisor: The supervisory signal is routinely transmitted to
the control panel every 20 minutes, advising the Tamper
Status, Battery Status, and Event Activation Status.
2.3. Physical Characteristics
Dimensions: 100mm x 76mm x 27mm (3.93in. X 2.99in x
1.062in)
Weight: 116 grams (4.09 oz)
3. Installation – General Information
The SA-29G Repeater detects the RF transmissions from
the Rosslare sensors and remote controls in its vicinity,
and re-transmits them to the main control unit.
Caution: AVOID mounting on or near large metal
surfaces or reinforced concrete walls which may interfere
or block the wireless signals. Test the range from the
desired location using the RF test procedure described in
section 0.
Caution: To prevent false tamper signals, make sure that
after enrolling the repeater, the Case and Back Tamper
are secure.
Caution: BATTERY WARNING!!! DO NOT REMOVE, DE-
SOLDER, SHORT-CIRCUIT OR BURN THE BATTERY ON THE
UNIT. THIS MAY CAUSE PERMANENT DAMAGE TO THE
BATTERY.
4. Installation Instructions
4.1. Recharging the Battery
Recharge the battery the first time you operate the SA-
29G, or if you are using the unit after it has been out of
service for a prolonged period of time.
Recharge the UPS battery for at least 7 hours, to make it
fully functional.
4.2. Enrolling to the Host Control Panel
1) In the appropriate RF zone, enter the programming
menu of the host. Go to the Repeater Zone and select
the RF device.
2) When prompted, generate a transmission from the SA-
29G Repeater unit using the cover Tamper Switch (the
SA-29G must be connected to DC power).
Note: The SA-29G will identify any Rosslare wireless
product, by protocol. It will repeat any transmission it
receives so the transmission reaches other devices that
are part of the setup (e.g., Wireless Keypads, Control
Panels and/or Wireless Sirens).
4.3. Mounting the SA-29G onto the Wall
1) Remove the plastic screw cover from the SA-29G front
cover (see Figure 1), to reveal the case-locking screw.
2) Unscrew the case locking screw and remove the front
cover.
CAUTION: Do not touch any of the circuitry.
3) Using the back case as a template, mark the locations
of the holes on the wall, and then drill the desired
holes. It is recommended to install the unit in a high
position to prevent tampering.
Figure 1: SA-29G Front Cover
Screw Cover
4.4. Connecting the Power and Setting the Back Tamper
Operation Logic.
1) While wiring the power, remove the power supply from
the mains.
2) Run the two power wires (+12V DC) and (-) through
the hole provided in the back case, and connect to
the terminal blocks for Vin (see Figure 2); Connect the
Ground (-), and then the (+12Volts DC).
3) Use the jumper to enable or disable the back tamper:
Jumper In-Place -> Back Tamper Disabled
Jumper Removed -> Back Tamper Enabled
(see Figure 2).
Caution: Make sure the casing is mounted flush onto the
mounting surface to prevent false Back Tamper signals.
Figure 2: Connecting 12Vdc Power
4.5. Testing the Installation:
4) Perform the RF test by entering the Host's RF test
feature, and transmitting to the Host using the SA-29G
cover tamper switch.
5) Perform a visual test using the LED of the SA-29G to see
that the unit's repeating function is functioning
properly; The LED flashes each time the SA-29G
transmits.
4.6. Finishing the installation:
6) When all the above instructions have been followed,
and the unit is functioning, replace the tap cover and
screw (a security screw may be used for additional
protection).
7) Replace the plastic screw cover.
5. Limited Warranty
ROSSLARE ENTERPRISES LIMITED S (Rosslare) TWO YEAR LIMITED
WARRANTY is applicable worldwide. This warranty supersedes any other
warranty. Rosslare's TWO YEAR LIMITED WARRANTY is subject to the
following conditions:
Warranty
Warranty of Rosslare's products extends to the original purchaser (Customer) of
the Rosslare product and is not transferable.
Products Covered By This Warranty and Duration
ROSSLARE ENTERPRISES LTD. AND / OR SUBSIDIARIES (ROSSLARE)
warrants that the SA-29G Supervised Wireless Magnetic Contact Sensor is free
from defects in materials and assembly in the course of normal use and service.
The warranty period commences with the date of shipment to the original
purchaser and extends for a period of 2 years (24 months).
Warranty Remedy Coverage
In the event of a breach of warranty, ROSSLARE will credit Customer with the
price of the Product paid by Customer, provided that the warranty claim is
delivered to ROSSLARE by the Customer during the warranty period in
accordance with the terms of this warranty. Unless otherwise requested by
ROSSLARE ENTERPRISES LTD. AND / OR SUBSIDIARIES representative,
return of the failed product(s) is not immediately required.
If ROSSLARE has not contacted the Customer within a sixty (60) day holding
period following the delivery of the warranty claim, Customer will not be required
to return the failed product(s). All returned Product(s), as may be requested at
ROSSLARE ENTERPRISES LTD. AND / OR SUBSIDIARY’S sole discretion,
shall become the property of ROSSLARE ENTERPRISES LTD. AND / OR
SUBSIDIARIES.
To exercise the warranty, the user must contact Rosslare Enterprises Ltd. to
obtain an RMA number after which, the product must be returned to the
Manufacturer freight prepaid and insured.
In the event ROSSLARE chooses to perform a product evaluation within the
sixty (60) day holding period and no defect is found, a minimum US$ 50.00 or
equivalent charge will be applied to each Product for labor required in the
evaluation.
Rosslare will repair or replace, at its discretion, any product that under normal
conditions of use and service proves to be defective in material or
workmanship. No charge will be applied for labor or parts with respect to
defects covered by this warranty, provided that the work is done by Rosslare or
a Rosslare authorized service center.
Exclusions and Limitations
ROSSLARE shall not be responsible or liable for any damage or loss resulting
from the operation or performance of any Product or any systems in which a
Product is incorporated. This warranty shall not extend to any ancillary
equipment not furnished by ROSSLARE, which is attached to or used in
conjunction with a Product, nor to any Product that is used with any ancillary
equipment, which is not furnished by ROSSLARE.
This warranty does not cover expenses incurred in the transportation, freight
cost to the repair center, removal or reinstallation of the product, whether or not
proven defective.
Specifically excluded from this warranty are any failures resulting from
Customer's improper testing, operation, installation, or damage resulting from
use of the Product in other than its normal and customary manner, or any
maintenance, modification, alteration, or adjustment or any type of abuse,
neglect, accident, misuse, improper operation, normal wear, defects or damage
due to lightning or other electrical discharge. This warranty does not cover
repair or replacement where normal use has exhausted the life of a part or
instrument, or any modification, abuse of, or tampering with the Product, if
Product disassembled or repaired in such a manner as to adversely affect
performance or prevent adequate inspection and testing to verify any warranty
claim.
ROSSLARE does not warrant the installation, maintenance, or service of the
Product. Service life of the product is dependent upon the care it receives and
the conditions under which it has to operate.
In no event shall Rosslare be liable for incidental or consequential damages.
2 0706-0960080+01
Limited Warranty Terms
THIS WARRANTY SETS FORTH THE FULL EXTENT OF ROSSLARE ENTERPRISES LTD. AND ITS
SUBSIDIARIES’ WARRANTY.
THE TERMS OF THIS WARRANTY MAY NOT BE VARIED BY ANY PERSON, WHETHER OR NOT
PURPORTING TO REPRESENT OR ACT ON BEHALF OF ROSSLARE.
THIS LIMITED WARRANTY IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES. ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMITATION, IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE
SPECIFICALLY EXCLUDED.
IN NO EVENT SHALL ROSSLARE BE LIABLE FOR DAMAGES IN EXCESS OF THE PURCHASE
PRICE OF THE PRODUCT, OR FOR ANY OTHER INCIDENTAL, CONSEQUENTIAL OR SPECIAL
DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF USE, LOSS OF TIME, COMMERCIAL
LOSS, INCONVENIENCE, AND LOSS OF PROFITS, ARISING OUT OF THE INSTALLATION, USE,
OR INABILITY TO USE SUCH PRODUCT, TO THE FULLEST EXTENT THAT ANY SUCH LOSS OR
DAMAGE MAY BE DISCLAIMED BY LAW.
THIS WARRANTY SHALL BECOME NULL AND VOID IN THE EVENT OF A VIOLATION OF THE
PROVISIONS OF THIS LIMITED WARRANTY.
6. Technical Support
Asia Pacific, Middle East, Africa
Headquarters:
905-912 Wing Fat Industrial Bldg, 12 Wang Tai Road, Kowloon Bay Hong
Kong
Tel: +852 2795-5630 Fax: +852 2795-1508 E-mail:
support.apac@rosslaresecurity.com
United States and Canada
1600 Hart Court, Suite 103 Southlake, TX, USA 76092
Toll Free: +1-866-632-1101 Local: +1-817-305-0006 Fax: +1-817-305-0069
E-mail: support.na@rosslaresecurity.com
Europe
Global Technical Support & Training Center:
HaMelecha 22 Rosh HaAyin, Israel 48091
Tel: +972 3 938-6838 Fax: +972 3 938-6830 E-mail:
support.eu@rosslaresecurity.com
South America
Pringles 868, 1640 Martinez Buenos Aires Argentina Tel: +54 11 4798-
0095 Fax: +54 11 4798-2228
Web Site: www.rosslaresecurity.c
3 0706-0960080+01
