R610 Wave 2 AP - Preliminary Specications
CAPACIT Y
CONCURRENT STATIONS • Up to 512 clients per AP
SIMULTANEOUS VoIP CLIENTS • Up to 30
WI-FI
STANDARDS • I E EE 802.11a/ b /g /n /a c
• 2.4GHz and 5GHz
SUPPORTED
DATA RATES
• 802.11n/ac: 6.5Mbps – 260Mbps (20MHz)
• 13.5Mbps – 600Mbps (40MHz)
• 29.3Mbps – 1300Mbps (80MHz)
• 802.11a: 54, 48, 36, 24, 18, 12, 9 and 6Mbps
• 802.11b: 11, 5.5, 2 and 1 Mbps
• 802.11g: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
RADIO CHAINS • 3 x 3
MIMO • SU-MIMO - Up to 3 streams
• MU-MIMO - Up to 3 streams
RF POWER OUTPUT
(Aggregate)
• 28 dBm for 2.4GHz†
• 27 dBm for 5GHz†
CHANNELIZATION • 20MHz, 40MHz, 80MHz, 160MHz
FREQUENCY BAND • IEEE 802.11 b/g/n: 2.4 – 2.484 GHz
• IEEE 802.11a/ac: 5.15 – 5.25 GHz; 5.25 –
5.35 GHz; 5.47 – 5.725 GHz; 5.725 – 5.85
GHz
OPERATING
CHANNELS
• US/Canada: 1-11, Europe ( ETSI X30): 1-13,
Japan X41: 1-13
• 5 GHz channels: Country dependent
POWER SAVE • Supported
WIRELESS SECURITY • WPA-PSK, WPA-TKIP, WPA2
AES , 8 0 2.11i
• Authentication via 802.1X with the
ZoneDirector, local authentication database,
support for RADIUS, LDAP, and
ActiveDirectory
CERTIFICATIONS* • U.S., Europe, Australia, Brazil, Canada,
Chile, China, Colombia, Costa Rica, Hong
Kong, India, Indonesia, Israel, Japan, Korea,
Malaysia, Mexico, New Zealand, Peru,
Philippines, Saudi Arabia, Singapore, South
Africa, Taiwan, Thailand, UAE, Vietnam
• WEEE/RoHS compliance
• EN-60601-1-2 (Medical)
• Wi-Fi Alliance
• EN50121-1 Railway EMC
• EN50121-4 Railway Immunity
• IEC 61373 Railway Shock & Vibration
• UL 2043 plenum rated
• 5GHz UNII-1 (2014)
† Maximum power varies by country
*See price list for latest country certication listing
PHYSICAL CHARACTERISTICS
POWER • DC Input: 12 VDC 1.0A
• Power over Ethernet 802.3 af
PHYSICAL SIZE • TBD
WEIGHT • TBD
ETHERNET PORTS • 2 auto MDX, auto-sensing
10/100/1000 Mbps, RJ-45,
POE port (on one port)
LOCK OPTIONS • Hidden latching mechanism
• Kensington Lock Hole
• T-bar Torx
• Bracket (902-0108-0000) Torx
screw & padlock (sold separately)
ENVIRONMENTAL
CONDITIONS
• Operating Temperature: 0°C - 40°C
• Operating Humidity: 10% - 95%
non-condensing
POWER DRAW • TBD
USB PORT • Yes
PLEASE NOTE: When ordering ZoneFlex Indoor APs, you must specify the
destination region by indicating -US, -IL, or -WW instead of XX. When ordering
PoE injectors or power supplies, you must specify the destination region by in-
dicating -US, -EU, -AU, -BR, -CN, -IN, -JP, -KR, -SA, -UK, or -UN instead of -XX.
*Specications subject to change without notice.
Product Ordering Information
MODEL DESCRIPTION
ZoneFlex R600 Smart Wi-Fi 802.11ac Access Point
901-R610-XX00 Concurrent dual band 802.11ac AP, no power
adapter
Optional Accessories
902-0108-0000 Spare, Accessory Mounting Bracket
902-0173-XXYY Power Adapter, AC/DC wall plug,100-240Vac
50/60Hz
902-0162-XXYY PoE injector (sold in quantities of 10 or 100)
MANAGEMENT
DEPLOYMENT OPTIONS • Standalone (individually managed)
• Managed by ZoneDirector
• Managed by SmartZone
• Managed by FlexMaster
• Managed by SmartCell Gateway 200
CONFIGURATION • Web User Interface (HTTP/S)
• CLI (Telnet/SSH), SNMP v1, 2, 3
• TR-069 vis FlexMaster
AUTO AP SOFTWARE UPDATES • FTP or TFTP, remote auto available
RF
ANTENNA • Adaptive antenna that provides up
to 512 unique antenna patterns per
radio
• Full omnidirectional polarization
diversity
PHYSICAL ANTENNA GAIN • Up to 3 dBi
BEAMFLEX* SINR TX GAIN • Up to 6 dB
BEAMFLEX* SINR RX GAIN • 3-5 dB (PD-MRC)
INTERFERENCE MITIGATION • Up to 15 dB
MINIMUM RX SENSITIVITY • Up to -101 dBm
* BeamFlex gains are statistical system level effects translated to enhanced
SINR based on observations over time in real-world conditions with multiple
APs and many clients
