Ruckus Wireless
SmartCell Gateway 200
RESTful Interface Reference Guide for
Release 2.5.1
Part Number 800-70700-001 Rev A
Published September 2014
www.ruckuswireless.com
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 2
Copyright Notice and Proprietary Information
Copyright 2014. Ruckus Wireless, Inc. All rights reserved.
No part of this documentation may be used, reproduced, transmitted, or translated, in any form or by any means,
electronic, mechanical, manual, optical, or otherwise, without prior written permission of Ruckus Wireless, Inc.
(“Ruckus”), or as expressly provided by under license from Ruckus.
Destination Control Statement
Technical data contained in this publication may be subject to the export control laws of the United States of America.
Disclosure to nationals of other countries contrary to United States law is prohibited. It is the reader’s responsibility to
determine the applicable regulations and to comply with them.
Disclaimer
THIS DOCUMENTATION AND ALL INFORMATION CONTAINED HEREIN (“MATERIAL”) IS PROVIDED FOR GENERAL
INFORMATION PURPOSES ONLY. RUCKUS AND ITS LICENSORS MAKE NO WARRANTY OF ANY KIND, EXPRESS
OR IMPLIED, WITH REGARD TO THE MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY, NON-INFRINGEMENT AND FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE
MATERIAL IS ERROR-FREE, ACCURATE OR RELIABLE. RUCKUS RESERVES THE RIGHT TO MAKE CHANGES OR
UPDATES TO THE MATERIAL AT ANY TIME.
Limitation of Liability
IN NO EVENT SHALL RUCKUS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUEN-
TIAL DAMAGES, OR DAMAGES FOR LOSS OF PROFITS, REVENUE, DATA OR USE, INCURRED BY YOU OR ANY
THIRD PARTY, WHETHER IN AN ACTION IN CONTRACT OR TORT, ARISING FROM YOUR ACCESS TO, OR USE
OF, THE MATERIAL.
Trademarks
Ruckus Wireless, Ruckus, the bark logo, ZoneFlex, FlexMaster, ZoneDirector, SmartMesh, Channelfly, Smartcell,
Dynamic PSK, and Simply Better Wireless are trademarks of Ruckus Wireless, Inc. in the United States and other
countries. All other product or company names may be trademarks of their respective owners.
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 3
Contents
About This Guide
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Documentation Feedback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1 RESTful Interface Server
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Resource . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
URI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Representation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2REST APIs
GET All Access Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
GET One Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
GET All Radio Records of One Access Point. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
GET One Radio Record of One Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
GET All Radio Records of All Access Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
GET All WLAN Records of One Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
GET One WLAN Record of One Access Point. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
GET All WLAN Records of All Access Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
GET All Mobility Zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
GET One Mobility Zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
GET All Controlblades. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
GET One Controlblade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
GET All Statistics Between Start and End Time for One Access Point . . . . . . . . . . . . . . . 50
GET All Statistics Between Start and End Time for All Radios of One Access Point . . . . . 51
GET All Statistics Between Start and End Time for One Radio of One Access Point . . . . 53
GET All Statistics Between Start and End Time for All WLANs of One Access Point . . . . 54
GET All Statistics Between Start and End Time for One WLAN of One Access Point. . . . 56
GET All Statistics Between Start and End Time for All Mobility Zones . . . . . . . . . . . . . . . 58
Contents
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 4
GET All Statistics Between Start and End Time for One Mobility Zone. . . . . . . . . . . . . . . 59
GET All Statistics Between Start and End Time for All Controlblades. . . . . . . . . . . . . . . . 60
GET All Statistics Between Start and End time for One Controlblade . . . . . . . . . . . . . . . 62
GET All Events Between Start and End Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
GET All Alarms Between Start and End Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Index
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 5
About This Guide
This SmartCell Gateway™ (SCG) 200 RESTful Interface Reference Guide describes
the features provided by the SCG RESTful interface server.
This guide is written for service operators and system administrators who are
responsible for managing, configuring, and troubleshooting Ruckus Wireless
devices. Consequently, it assumes a basic working knowledge of local area
networks, wireless networking, and wireless devices.
NOTE: This guide assumes that the SmartCell Gateway has already been installed
as described in the Getting Started Guide.
Most user guides and release notes are available in Adobe Acrobat Reader Portable
Document Format (PDF) or HTML on the Ruckus Wireless Support Web site at
https://support.ruckuswireless.com/documents.
About This Guide
Document Conventions
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 6
Document Conventions
Tab l e 1 and Table 2 list the text and notice conventions that are used throughout
this guide.
Terminology
Tab l e 3 lists the terms used in this guide.
Table 1. Text conventions
Convention Description Example
monospace Represents information as it
appears on screen [Device name]>
monospace bold Represents information that
you enter
[Device name]> set
ipaddr 10.0.0.12
default font bold Keyboard keys, software
buttons, and field names
On the Start menu, click All
Programs.
italics Screen or page names Click Advanced Settings.
The Advanced Settings page
appears.
Table 2. Notice conventions
Notice Type Description
NOTE Information that describes important features or instructions
CAUTION! Information that alerts you to potential loss of data or potential
damage to an application, system, or device
WARNING! Information that alerts you to potential personal injury
Table 3. Terms used in this guide
Terms Description
AP Access Point
CP Captive Portal
NBI Northbound Interface
RADIUS Remote Authentication Dial-Up Service
SCG Smart Cell Gateway
SSL Secure Socket Layer
About This Guide
Related Documentation
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 7
Related Documentation
For a complete list of documents that accompany this release, refer to the Release
Notes.
Documentation Feedback
Ruckus Wireless is interested in improving its documentation and welcomes your
comments and suggestions. You can email your comments to Ruckus Wireless at:
docs@ruckuswireless.com
When contacting us, please include the following information:
Document title
Document part number (on the cover page)
Page number (if appropriate)
For example:
Ruckus Wireless SmartCell Gateway 200 Administrator Guide (Release 2.5.1)
Part number: 800-70670-001
Page 88
TCP Transmission Control Protocol
UE User Equipment
UE-IP User Equipment - IP Address
UE-MAC User Equipment - MAC Address
Table 3. Terms used in this guide
Terms Description
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 8
1
RESTful Interface Server
In this chapter:
Overview
Host
Resource
URI
Security
Representation
RESTful Interface Server
Overview
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 9
Overview
This reference guide describes the features provided by the SCG 200 RESTful
Interface Server, as well as its internal design considerations. The SCG RESTful
interface server is responsible for providing access to certain SCG resources, such
that external clients (that pass authentication) can pull information by means of
simple RESTful operations. Currently, only GET operation is supported.
NOTE: A separate document describing the DB Importer Client Application (which
makes use of this RESTful API) to retrieve and make that information persistent into
the RDBMS will be made available later.
NOTE: Refer to About This Guide chapter for conventions used in this guide.
Host
The SCG RESTful API is available from any SCG node, specifically control plane
(SCG-CBlade) in a cluster.
Resource
The API defines the resources of certain core objects such as AP, AP radio, AP
WLan, mobility zone, controlblade, as well as collections of these core objects. It
also defines the data resources for accessing the statistics of the corresponding
core objects, as well as events and alarms.
NOTE: Additional resources, such as datablade, tunnel, user equipment is planned
for future releases.
URI
There are multiple ways for accessing and querying each resource and, therefore,
there is multiple URIs for each resource. The URI format is intuitive and the
information is human-readable.
Typically, the path is used to represent the resource. Query parameters are used to
describe the query, whenever applicable. In this release, there are 25 different URIs,
which are described in the chapter - REST APIs.
RESTful Interface Server
Security
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 10
Security
The SCG RESTful API is protected by the same security facility as the SCG Web
interface. Therefore, the client must first pass authentication before any REST API
access is allowed. In this release, only user accounts with super administrator role
have REST access capability.
To log on, the client can perform a HTTPS PUT operation towards the log on URI
and pass a JSON object with the attributes of username and password. The client
also has to provide the correct information for these corresponding fields.
For example to logon, {“userName”:”admin”, “password”:””user12#”}
can be:
URI
HTTPS: https://SCG_Management_IP: 8443/wsg/api/scg/session/login
Curl Command
curl -k -i -H "Accept: application/json" -H "Content-type:
application/json" -H "GMTOffset:12" -H "TimezoneOffset:
12" -c cookies.txt -X PUT -d '{"userName":"admin",
"password":"admin123!"}' https://10.150.0.40:8443/wsg/
api/scg/session/login
Example
HTTP/1.1 200 OK
Server: Apache-Coyote/1.1
Set-Cookie: JSESSIONID=C116A5694435A1963B4FD791BDACD34D;
Path=/wsg; Secure
Content-Type: application/json;charset=UTF-8
Transfer-Encoding: chunked
Date: Sat, 14 Dec 2013 03:02:22 GMT
Representation
The response information is represented in JSON format, and is passed back to the
client through HTTPS. The system supports multiple representations, since single
data representation is not ideal for every client. It is only natural that in future, more
SCG customers may require support of other formats such as XML, Atom, etc.
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 11
2
REST APIs
This chapter lists the following REST APIs:
GET All Access Points
GET One Access Point
GET All Radio Records of One Access Point
GET One Radio Record of One Access Point
GET All Radio Records of All Access Points
GET All WLAN Records of One Access Point
GET One WLAN Record of One Access Point
GET All WLAN Records of All Access Points
GET All Mobility Zones
GET One Mobility Zone
GET All Controlblades
GET One Controlblade
GET All Statistics Between Start and End Time for One Access Point
GET All Statistics Between Start and End Time for All Radios of One Access Point
GET All Statistics Between Start and End Time for One Radio of One Access
Point
GET All Statistics Between Start and End Time for All WLANs of One Access
Point
GET All Statistics Between Start and End Time for One WLAN of One Access
Point
GET All Statistics Between Start and End Time for All Mobility Zones
GET All Statistics Between Start and End Time for One Mobility Zone
GET All Statistics Between Start and End Time for All Controlblades
GET All Statistics Between Start and End time for One Controlblade
GET All Events Between Start and End Time
GET All Alarms Between Start and End Time
REST APIs
GET All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 12
GET All Access Points
This resource URI retrieves a list of all access point records from the SCG.
URI
~/api/rest/aps
Verb
GET
Parameters
N/A
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/aps
Response
Lists the access point records in JSON format
Example
{
"aps": [
{
"apMac": "C0:C5:20:26:95:D0",
"serial": "101102000507",
"model": "ZF7025",
"deviceName": "RuckusAP",
"description": null,
"bladeId": "a30429f2-5f94-46aa-8068-d88d72e95896",
"mobilityZoneUUID": "11a87f70-fada-4938-9fcb-
a26edb1504d0",
"lastSeen": 1364895872029,
"uptime": 303,
"ip": "192.168.0.101",
"hops": 0,
"fwVersion": "2.1.0.0.31",
"gpsInfo": "",
REST APIs
GET One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 13
"gpsSource": null,
"connectionStatus": "Disconnect",
"registrationState": "1",
"approvedTime": 1364895541135,
"registrationTime": 1364895541135,
}
]
}
GET One Access Point
This resource URI retrieves a single access point record from the SCG based on
the MAC address of the access point.
URI
~/api/rest/ap/{macaddress}
Verb
GET
Parameters
macaddress - MAC address of the access point
Request Example
: https://SCG_Management_IP:8443/wsg/api/rest/ap/
00:22:68:00:00:A1
Response
Lists the access point record in JSON format.
Example:
{
"apMac": "00:22:68:00:00:A1",
"serial": "101102000507",
"model": "ZF7025",
"deviceName": "RuckusAP",
"description": null,
REST APIs
GET All Radio Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 14
"bladeId": "a30429f2-5f94-46aa-8068-d88d72e95896",
"mobilityZoneUUID": "11a87f70-fada-4938-9fcb-
a26edb1504d0",
"lastSeen": 1364895872029,
"uptime": 303,
"ip": "192.168.0.101",
"hops": 0,
"fwVersion": "2.1.0.0.31",
"gpsInfo": "",
"gpsSource": null,
"connectionStatus": "Disconnect",
"registrationState": "1",
"approvedTime": 1364895541135,
}
GET All Radio Records of One Access Point
This resource URI retrieves all radio records of a single access point from the SCG,
using the MAC address of the access point.
URI
: ~/api/rest/ap/{macaddress}/radios
Verb
GET
Parameters
macaddress - MAC address of the access point
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/ap/
00:22:68:00:00:A1/radios
Response
Lists the access point radio records in JSON format.
REST APIs
GET All Radio Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 15
Example
{
"radios": [
{
"apMac": "00:22:68:00:00:A1",
"radioId": "0",
"channel": "0",
"mode": "11ng",
"phyError": 0,
"channelBlacklist": "",
"channelList": null,
"numOfAuthorizedClients": 0,
"noiseFloor": -50,
"rxBytes": 0,
"rxFrames": 0,
"txBytes": 0,
"txFrames": 0,
"retry": 33,
"drop": 0,
"rxMulticast": 0,
"txMulticast": 0,
}
]
}
{
"radios": [
{
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "1",
"channel": "132",
"mode": "11na",
REST APIs
GET All Radio Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 16
"phyError": 66,
"channelBlacklist": "",
"channelList": null,
"numOfAuthorizedClients": 0,
"noiseFloor": -99,
"rxBytes": 3213381,
"rxFrames": 25709,
"txBytes": 4827994,
"txFrames": 28045,
"retry": 1726,
"drop": 0,
"rxMulticast": 16252,
"txMulticast": 0,
"total": 0,
"busy": 0,
"rx": 0,
"tx": 0,
"backgroundScan": true,
"txPower": "max",
"channelWidth": 2,
"clientCount": 0,
"wlanGroupId": "87b24ac3-acd6-48d4-850f-21c837d53d50",
"wlanGroupName": "default",
"deployedWlanNum": 0,
"maxWlanNum": 0,
"wlanGroupWlanNum": 0,
"key": "8C:0C:90:02:F4:F0_1",
"columns": {
"total": "0",
"wlanGroupId": "87b24ac3-acd6-48d4-850f-21c837d53d50",
"drop": "0",
REST APIs
GET All Radio Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 17
"busy": "0",
"clientCount": "0",
"mode": "11na",
"channelBlacklist": "",
"rxFrames": "25709",
"channelWidth": "2",
"radioId": "1",
"txMulticast": "0",
"wlanGroupName": "default",
"txFrames": "28045",
"txPower": "max",
"rxMulticast": "16252",
"txBytes": "4827994",
"rxBytes": "3213381",
"numOfAuthorizedClients": "0",
"tx": "0",
"noiseFloor": "-99",
"backgroundScan": "true",
"retry": "1726",
"channel": "132",
"apMac": "8C:0C:90:02:F4:F0",
"rx": "0",
"phyError": "66"
}
},
{
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "0",
"channel": "11",
"mode": "11ng",
"phyError": 440,
REST APIs
GET All Radio Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 18
"channelBlacklist": "",
"channelList": null,
"numOfAuthorizedClients": 2,
"noiseFloor": -88,
"rxBytes": 15574519,
"rxFrames": 197036,
"txBytes": 309672593,
"txFrames": 270885,
"retry": 73504,
"drop": 0,
"rxMulticast": 10701,
"txMulticast": 0,
"total": 78,
"busy": 22,
"rx": 53,
"tx": 4,
"backgroundScan": true,
"txPower": "max",
"channelWidth": 0,
"clientCount": 2,
"wlanGroupId": "87b24ac3-acd6-48d4-850f-21c837d53d50",
"wlanGroupName": "default",
"deployedWlanNum": 0,
"maxWlanNum": 0,
"wlanGroupWlanNum": 0,
"key": "8C:0C:90:02:F4:F0_0",
"columns": {
"total": "78",
"wlanGroupId": "87b24ac3-acd6-48d4-850f-21c837d53d50",
"drop": "0",
"busy": "22",
REST APIs
GET All Radio Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 19
"clientCount": "2",
"mode": "11ng",
"channelBlacklist": "",
"rxFrames": "197036",
"channelWidth": "0",
"radioId": "0",
"txMulticast": "0",
"wlanGroupName": "default",
"txFrames": "270885",
"txPower": "max",
"rxMulticast": "10701",
"txBytes": "309672593",
"rxBytes": "15574519",
"numOfAuthorizedClients": "2",
"tx": "4",
"noiseFloor": "-88",
"backgroundScan": "true",
"retry": "73504",
"channel": "11",
"apMac": "8C:0C:90:02:F4:F0",
"rx": "53",
"phyError": "440"
}
}
]
}
REST APIs
GET One Radio Record of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 20
GET One Radio Record of One Access Point
This resource URI retrieves a specific radio record of a single access point from the
SCG, based on the MAC address and radio ID of the access point.
URI
~/api/rest/ap/{macaddress}/radio/{radioid}
Verb
GET
Parameters
macaddress - MAC address of the access point
radioid - Radio ID, for example - 0 or 1
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/ap/
00:22:68:00:00:A1/radio/0
Response
Specifies the AP radio record in JSON format.
Example
{
"apMac": "00:22:68:00:00:A1",
"radioId": "0",
"channel": "0",
"mode": "11ng",
"phyError": 0,
"channelBlacklist": "",
"channelList": null,
"numOfAuthorizedClients": null,
"noiseFloor": -50,
"rxBytes": 0,
"rxFrames": 0,
"txBytes": 0,
"txFrames": 0,
REST APIs
GET All Radio Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 21
"retry": 33,
"drop": 0,
"rxMulticast": 0,
"txMulticast": 0,
}
GET All Radio Records of All Access Points
This resource URI retrieves a list of all radio records for all access points that are
managed by the SCG.
URI
~/api/rest/aps/radios
Verb
GET
Parameters
N/A
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/aps/radios
Response
Lists the AP radios records in JSON format.
Example
{
"radios": [
{
"apMac": "C0:C5:20:26:95:D0",
"radioId": "0",
"channel": "0",
"mode": "11ng",
"phyError": 0,
"channelBlacklist": "",
"channelList": null,
REST APIs
GET All Radio Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 22
"numOfAuthorizedClients": null,
"noiseFloor": -50,
"rxBytes": 0,
"rxFrames": 0,
"txBytes": 0,
"txFrames": 0,
"retry": 33,
"drop": 0,
}
]
}
{
"radios": [
{
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "1",
"channel": "132",
"mode": "11na",
"phyError": 66,
"channelBlacklist": "",
"channelList": null,
"numOfAuthorizedClients": 0,
"noiseFloor": -99,
"rxBytes": 3213381,
"rxFrames": 25709,
"txBytes": 4827994,
"txFrames": 28045,
"retry": 1726,
"drop": 0,
"rxMulticast": 16252,
"txMulticast": 0,
REST APIs
GET All Radio Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 23
"total": 0,
"busy": 0,
"rx": 0,
"tx": 0,
"backgroundScan": true,
"txPower": "max",
"channelWidth": 2,
"clientCount": 0,
"wlanGroupId": "87b24ac3-acd6-48d4-850f-21c837d53d50",
"wlanGroupName": "default",
"deployedWlanNum": 0,
"maxWlanNum": 0,
"wlanGroupWlanNum": 0,
"key": "8C:0C:90:02:F4:F0_1",
"columns": {
"total": "0",
"wlanGroupId": "87b24ac3-acd6-48d4-850f-21c837d53d50",
"drop": "0",
"busy": "0",
"clientCount": "0",
"mode": "11na",
"channelBlacklist": "",
"rxFrames": "25709",
"channelWidth": "2",
"radioId": "1",
"txMulticast": "0",
"wlanGroupName": "default",
"txFrames": "28045",
"txPower": "max",
"rxMulticast": "16252",
"txBytes": "4827994",
REST APIs
GET All Radio Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 24
"rxBytes": "3213381",
"numOfAuthorizedClients": "0",
"tx": "0",
"noiseFloor": "-99",
"backgroundScan": "true",
"retry": "1726",
"channel": "132",
"apMac": "8C:0C:90:02:F4:F0",
"rx": "0",
"phyError": "66"
}
},
{
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "0",
"channel": "11",
"mode": "11ng",
"phyError": 440,
"channelBlacklist": "",
"channelList": null,
"numOfAuthorizedClients": 2,
"noiseFloor": -88,
"rxBytes": 15574519,
"rxFrames": 197036,
"txBytes": 309672593,
"txFrames": 270885,
"retry": 73504,
"drop": 0,
"rxMulticast": 10701,
"txMulticast": 0,
"total": 78,
REST APIs
GET All Radio Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 25
"busy": 22,
"rx": 53,
"tx": 4,
"backgroundScan": true,
"txPower": "max",
"channelWidth": 0,
"clientCount": 2,
"wlanGroupId": "87b24ac3-acd6-48d4-850f-21c837d53d50",
"wlanGroupName": "default",
"deployedWlanNum": 0,
"maxWlanNum": 0,
"wlanGroupWlanNum": 0,
"key": "8C:0C:90:02:F4:F0_0",
"columns": {
"total": "78",
"wlanGroupId": "87b24ac3-acd6-48d4-850f-21c837d53d50",
"drop": "0",
"busy": "22",
"clientCount": "2",
"mode": "11ng",
"channelBlacklist": "",
"rxFrames": "197036",
"channelWidth": "0",
"radioId": "0",
"txMulticast": "0",
"wlanGroupName": "default",
"txFrames": "270885",
"txPower": "max",
"rxMulticast": "10701",
"txBytes": "309672593",
"rxBytes": "15574519",
REST APIs
GET All WLAN Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 26
"numOfAuthorizedClients": "2",
"tx": "4",
"noiseFloor": "-88",
"backgroundScan": "true",
"retry": "73504",
"channel": "11",
"apMac": "8C:0C:90:02:F4:F0",
"rx": "53",
"phyError": "440"
}
}
]
}
GET All WLAN Records of One Access Point
This resource URI retrieves all WLAN records of a single access point, which is
managed by the SCG, based on the MAC address of the access point.
URI
~/api/rest/ap/{macaddress}/wlans
Verb
GET
Parameters
macaddress - MAC address of the access point
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/ap/
00:22:68:00:00:A1/wlans
Response
Lists the AP WLAN records in JSON format.
REST APIs
GET All WLAN Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 27
Example
{
"wlans": [
{
"key": "C0:C5:20:26:95:D8",
"bssid": "C0:C5:20:26:95:D8",
"apMac": "00:22:68:00:00:A1",
"radioId": "0",
"radioType": null,
"rxBytes": "2208536",
"ssid": "kkkwlan1",
"totalNumClients": "0",
"txBytes": "19761",
"wlanId": "0",
"authmethod": "NONE",
"wsgWlanId": "1",
"columns": {
}
]
}
{
"wlans": [
{
"key": "8C:0C:90:82:F4:F8",
"bssid": "8C:0C:90:82:F4:F8",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "0",
"radioType": null,
"rxBytes": "111408",
"ssid": "w3",
"totalNumClients": "0",
"txBytes": "648",
REST APIs
GET All WLAN Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 28
"wlanId": "2",
"authmethod": "OPEN",
"wsgWlanId": "3",
"columns": {
"wsgWlanId": "3",
"bssid": "8C:0C:90:82:F4:F8",
"authmethod": "OPEN",
"totalNumClients": "0",
"wlanId": "2",
"radioId": "0",
"ssid": "w3",
"txBytes": "648",
"rxBytes": "111408",
"apMac": "8C:0C:90:02:F4:F0"
}
},
{
"key": "8C:0C:90:42:F4:F8",
"bssid": "8C:0C:90:42:F4:F8",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "0",
"radioType": null,
"rxBytes": "120535",
"ssid": "w2",
"totalNumClients": "0",
"txBytes": "2592",
"wlanId": "1",
"authmethod": "OPEN",
"wsgWlanId": "2",
"columns": {
"wsgWlanId": "2",
REST APIs
GET All WLAN Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 29
"bssid": "8C:0C:90:42:F4:F8",
"authmethod": "OPEN",
"totalNumClients": "0",
"wlanId": "1",
"radioId": "0",
"ssid": "w2",
"txBytes": "2592",
"rxBytes": "120535",
"apMac": "8C:0C:90:02:F4:F0"
}
},
{
"key": "8C:0C:90:02:F4:F8",
"bssid": "8C:0C:90:02:F4:F8",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "0",
"radioType": null,
"rxBytes": "11493936237",
"ssid": "w21",
"totalNumClients": "2",
"txBytes": "338023205",
"wlanId": "0",
"authmethod": "OPEN",
"wsgWlanId": "1",
"columns": {
"wsgWlanId": "1",
"bssid": "8C:0C:90:02:F4:F8",
"authmethod": "OPEN",
"totalNumClients": "2",
"wlanId": "0",
"radioId": "0",
REST APIs
GET All WLAN Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 30
"ssid": "w21",
"txBytes": "338023205",
"rxBytes": "11493936237",
"apMac": "8C:0C:90:02:F4:F0"
}
},
{
"key": "8C:0C:90:02:F4:FC",
"bssid": "8C:0C:90:02:F4:FC",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "1",
"radioType": null,
"rxBytes": "476104347",
"ssid": "w21",
"totalNumClients": "0",
"txBytes": "36246953",
"wlanId": "32",
"authmethod": "OPEN",
"wsgWlanId": "1",
"columns": {
"wsgWlanId": "1",
"bssid": "8C:0C:90:02:F4:FC",
"authmethod": "OPEN",
"totalNumClients": "0",
"wlanId": "32",
"radioId": "1",
"ssid": "w21",
"txBytes": "36246953",
"rxBytes": "476104347",
"apMac": "8C:0C:90:02:F4:F0"
}
REST APIs
GET All WLAN Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 31
},
{
"key": "8C:0C:90:42:F4:FC",
"bssid": "8C:0C:90:42:F4:FC",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "1",
"radioType": null,
"rxBytes": "10116",
"ssid": "w2",
"totalNumClients": "0",
"txBytes": "908",
"wlanId": "33",
"authmethod": "OPEN",
"wsgWlanId": "2",
"columns": {
"wsgWlanId": "2",
"bssid": "8C:0C:90:42:F4:FC",
"authmethod": "OPEN",
"totalNumClients": "0",
"wlanId": "33",
"radioId": "1",
"ssid": "w2",
"txBytes": "908",
"rxBytes": "10116",
"apMac": "8C:0C:90:02:F4:F0"
}
},
{
"key": "8C:0C:90:82:F4:FC",
"bssid": "8C:0C:90:82:F4:FC",
"apMac": "8C:0C:90:02:F4:F0",
REST APIs
GET All WLAN Records of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 32
"radioId": "1",
"radioType": null,
"rxBytes": "7998",
"ssid": "w3",
"totalNumClients": "0",
"txBytes": "0",
"wlanId": "34",
"authmethod": "OPEN",
"wsgWlanId": "3",
"columns": {
"wsgWlanId": "3",
"bssid": "8C:0C:90:82:F4:FC",
"authmethod": "OPEN",
"totalNumClients": "0",
"wlanId": "34",
"radioId": "1",
"ssid": "w3",
"txBytes": "0",
"rxBytes": "7998",
"apMac": "8C:0C:90:02:F4:F0"
}
}
]
}
REST APIs
GET One WLAN Record of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 33
GET One WLAN Record of One Access Point
This resource URI retrieves a specific WLAN record of a single access point, based
on its MAC address and WLAN ID.
URI
~/api/rest/ap/{macaddress}/wlan/{wlanid}
Verb
GET
Parameters
macaddress - MAC address of the access point
wlanid - WLAN ID, for example, 0 or 1
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/ap/
00:22:68:00:00:A1/wlan/0
Response
Lists the specific AP WLAN record in JSON format.
Example
{
"key": "C0:C5:20:26:95:D8",
"bssid": "C0:C5:20:26:95:D8",
"apMac": "00:22:68:00:00:A1",
"radioId": "0",
"radioType": null,
"rxBytes": "2208536",
"ssid": "kkkwlan1",
"totalNumClients": "0",
"txBytes": "19761",
"wlanId": "0",
"authmethod": "NONE",
"wsgWlanId": "1",
"columns":{
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 34
}
GET All WLAN Records of All Access Points
This resource URI retrieves a list of all WLAN records for all access points managed
by the SCG.
URI
~/api/rest/aps/wlans
Verb
GET
Parameters
N/A
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/aps/wlans
Response
Lists theAP WLAN records in JSON format.
Example
{
"wlans": [
{
"key": "C0:C5:20:26:95:D8",
"bssid": "C0:C5:20:26:95:D8",
"apMac": "C0:C5:20:26:95:D0",
"radioId": "0",
"radioType": null,
"rxBytes": "2208536",
"ssid": "kkkwlan1",
"totalNumClients": "0",
"txBytes": "19761",
"wlanId": "0",
"authmethod": null,
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 35
"wsgWlanId": "1",
"columns": {
"bssid": "C0:C5:20:26:95:D8",
"wsgWlanId": "1",
"totalNumClients": "0"
}
}
]
}
{
"wlans": [
{
"key": "8C:0C:90:05:87:BC",
"bssid": "8C:0C:90:05:87:BC",
"apMac": "8C:0C:90:05:87:B0",
"radioId": "1",
"radioType": null,
"rxBytes": "86340",
"ssid": "w21",
"totalNumClients": "0",
"txBytes": "19477",
"wlanId": "32",
"authmethod": null,
"wsgWlanId": "1",
"columns": {
"wsgWlanId": "1",
"bssid": "8C:0C:90:05:87:BC",
"totalNumClients": "0",
"wlanId": "32",
"radioId": "1",
"ssid": "w21",
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 36
"txBytes": "19477",
"rxBytes": "86340",
"apMac": "8C:0C:90:05:87:B0"
}
},
{
"key": "8C:0C:90:42:F4:FC",
"bssid": "8C:0C:90:42:F4:FC",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "1",
"radioType": null,
"rxBytes": "2367996",
"ssid": "w2",
"totalNumClients": "0",
"txBytes": "130752",
"wlanId": "33",
"authmethod": null,
"wsgWlanId": "2",
"columns": {
"wsgWlanId": "2",
"bssid": "8C:0C:90:42:F4:FC",
"totalNumClients": "0",
"wlanId": "33",
"radioId": "1",
"ssid": "w2",
"txBytes": "130752",
"rxBytes": "2367996",
"apMac": "8C:0C:90:02:F4:F0"
}
},
{
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 37
"key": "8C:0C:90:82:F4:FC",
"bssid": "8C:0C:90:82:F4:FC",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "1",
"radioType": null,
"rxBytes": "2365878",
"ssid": "w3",
"totalNumClients": "0",
"txBytes": "129844",
"wlanId": "34",
"authmethod": null,
"wsgWlanId": "3",
"columns": {
"wsgWlanId": "3",
"bssid": "8C:0C:90:82:F4:FC",
"totalNumClients": "0",
"wlanId": "34",
"radioId": "1",
"ssid": "w3",
"txBytes": "129844",
"rxBytes": "2365878",
"apMac": "8C:0C:90:02:F4:F0"
}
},
{
"key": "8C:0C:90:45:87:BC",
"bssid": "8C:0C:90:45:87:BC",
"apMac": "8C:0C:90:05:87:B0",
"radioId": "1",
"radioType": null,
"rxBytes": "75718",
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 38
"ssid": "w2",
"totalNumClients": "0",
"txBytes": "18387",
"wlanId": "33",
"authmethod": null,
"wsgWlanId": "2",
"columns": {
"wsgWlanId": "2",
"bssid": "8C:0C:90:45:87:BC",
"totalNumClients": "0",
"wlanId": "33",
"radioId": "1",
"ssid": "w2",
"txBytes": "18387",
"rxBytes": "75718",
"apMac": "8C:0C:90:05:87:B0"
}
},
{
"key": "8C:0C:90:85:87:B8",
"bssid": "8C:0C:90:85:87:B8",
"apMac": "8C:0C:90:05:87:B0",
"radioId": "0",
"radioType": null,
"rxBytes": "2892711",
"ssid": "w3",
"totalNumClients": "0",
"txBytes": "69552",
"wlanId": "2",
"authmethod": null,
"wsgWlanId": "3",
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 39
"columns": {
"wsgWlanId": "3",
"bssid": "8C:0C:90:85:87:B8",
"totalNumClients": "0",
"wlanId": "2",
"radioId": "0",
"ssid": "w3",
"txBytes": "69552",
"rxBytes": "2892711",
"apMac": "8C:0C:90:05:87:B0"
}
},
{
"key": "8C:0C:90:05:87:B8",
"bssid": "8C:0C:90:05:87:B8",
"apMac": "8C:0C:90:05:87:B0",
"radioId": "0",
"radioType": null,
"rxBytes": "2895895",
"ssid": "w21",
"totalNumClients": "0",
"txBytes": "72689",
"wlanId": "0",
"authmethod": null,
"wsgWlanId": "1",
"columns": {
"wsgWlanId": "1",
"bssid": "8C:0C:90:05:87:B8",
"totalNumClients": "0",
"wlanId": "0",
"radioId": "0",
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 40
"ssid": "w21",
"txBytes": "72689",
"rxBytes": "2895895",
"apMac": "8C:0C:90:05:87:B0"
}
},
{
"key": "8C:0C:90:45:87:B8",
"bssid": "8C:0C:90:45:87:B8",
"apMac": "8C:0C:90:05:87:B0",
"radioId": "0",
"radioType": null,
"rxBytes": "2894169",
"ssid": "w2",
"totalNumClients": "0",
"txBytes": "69552",
"wlanId": "1",
"authmethod": null,
"wsgWlanId": "2",
"columns": {
"wsgWlanId": "2",
"bssid": "8C:0C:90:45:87:B8",
"totalNumClients": "0",
"wlanId": "1",
"radioId": "0",
"ssid": "w2",
"txBytes": "69552",
"rxBytes": "2894169",
"apMac": "8C:0C:90:05:87:B0"
}
},
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 41
{
"key": "8C:0C:90:02:F4:F8",
"bssid": "8C:0C:90:02:F4:F8",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "0",
"radioType": null,
"rxBytes": "11543828139",
"ssid": "w21",
"totalNumClients": "1",
"txBytes": "338349994",
"wlanId": "0",
"authmethod": null,
"wsgWlanId": "1",
"columns": {
"wsgWlanId": "1",
"bssid": "8C:0C:90:02:F4:F8",
"totalNumClients": "1",
"wlanId": "0",
"radioId": "0",
"ssid": "w21",
"txBytes": "338349994",
"rxBytes": "11543828139",
"apMac": "8C:0C:90:02:F4:F0"
}
},
{
"key": "8C:0C:90:82:F4:F8",
"bssid": "8C:0C:90:82:F4:F8",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "0",
"radioType": null,
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 42
"rxBytes": "49943881",
"ssid": "w3",
"totalNumClients": "0",
"txBytes": "282096",
"wlanId": "2",
"authmethod": null,
"wsgWlanId": "3",
"columns": {
"wsgWlanId": "3",
"bssid": "8C:0C:90:82:F4:F8",
"totalNumClients": "0",
"wlanId": "2",
"radioId": "0",
"ssid": "w3",
"txBytes": "282096",
"rxBytes": "49943881",
"apMac": "8C:0C:90:02:F4:F0"
}
},
{
"key": "8C:0C:90:85:87:BC",
"bssid": "8C:0C:90:85:87:BC",
"apMac": "8C:0C:90:05:87:B0",
"radioId": "1",
"radioType": null,
"rxBytes": "75387",
"ssid": "w3",
"totalNumClients": "0",
"txBytes": "18387",
"wlanId": "34",
"authmethod": null,
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 43
"wsgWlanId": "3",
"columns": {
"wsgWlanId": "3",
"bssid": "8C:0C:90:85:87:BC",
"totalNumClients": "0",
"wlanId": "34",
"radioId": "1",
"ssid": "w3",
"txBytes": "18387",
"rxBytes": "75387",
"apMac": "8C:0C:90:05:87:B0"
}
},
{
"key": "8C:0C:90:02:F4:FC",
"bssid": "8C:0C:90:02:F4:FC",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "1",
"radioType": null,
"rxBytes": "478493255",
"ssid": "w21",
"totalNumClients": "0",
"txBytes": "36381500",
"wlanId": "32",
"authmethod": null,
"wsgWlanId": "1",
"columns": {
"wsgWlanId": "1",
"bssid": "8C:0C:90:02:F4:FC",
"totalNumClients": "0",
"wlanId": "32",
REST APIs
GET All WLAN Records of All Access Points
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 44
"radioId": "1",
"ssid": "w21",
"txBytes": "36381500",
"rxBytes": "478493255",
"apMac": "8C:0C:90:02:F4:F0"
}
},
{
"key": "8C:0C:90:42:F4:F8",
"bssid": "8C:0C:90:42:F4:F8",
"apMac": "8C:0C:90:02:F4:F0",
"radioId": "0",
"radioType": null,
"rxBytes": "49953268",
"ssid": "w2",
"totalNumClients": "0",
"txBytes": "284040",
"wlanId": "1",
"authmethod": null,
"wsgWlanId": "2",
"columns": {
"wsgWlanId": "2",
"bssid": "8C:0C:90:42:F4:F8",
"totalNumClients": "0",
"wlanId": "1",
"radioId": "0",
"ssid": "w2",
"txBytes": "284040",
"rxBytes": "49953268",
"apMac": "8C:0C:90:02:F4:F0"
}
REST APIs
GET All Mobility Zones
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 45
}
]
}
GET All Mobility Zones
This resource URI retrieves a list of all mobility zone records from SCG.
URI
~/api/rest/mobilityzones
Verb
GET
Parameters
N/A
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/mobilityzones
Response
Lists the mobility zone records in JSON format.
Example
{
"mobilityzones": [
{
"key": "b4187899-38ae-4ace-8e40-0bc444455156",
"mobilityZoneName": "Staging Zone",
"description": "Staging Zone",
"meshSSID": null,
"creatorUUID": "92cc1b65-c3cd-4f26-8c9b-3e7b055c7c25",
"createDatetime": 1363766599388,
"fwMaxRebootWait": null,
"switchoverCluster": null,
"switchoverClusterEnable": false,
REST APIs
GET One Mobility Zone
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 46
"domainUUID": null,
"columns": {
"creatorUUID": "92cc1b65-c3cd-4f26-8c9b-3e7b055c7c25",
"mobilityZoneName": "Staging Zone",
"description": "Staging Zone”,
}
}
]
}
GET One Mobility Zone
This resource URI retrieves one mobility zone record from the SCG, based on the
zone UUID.
URI
~/api/rest/mobilityzone/{zoneuuid}
Verb
GET
Parameters
zoneuuid - Zone UUID
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/mobilityzone/
cee71896-241e-4fbf-a3e2-62cb47d63573
Response
Lists the mobility zone record in JSON format.
Example
Key is the {zoneuuid}
{
"key": "cee71896-241e-4fbf-a3e2-62cb47d63573",
"mobilityZoneName": "zone1",
REST APIs
GET All Controlblades
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 47
"description": "",
"meshSSID": null,
"creatorUUID": "92cc1b65-c3cd-4f26-8c9b-3e7b055c7c25",
"createDatetime": 1364362756320,
"fwMaxRebootWait": null,
"switchoverCluster": null,
"switchoverClusterEnable": false,
"domainUUID": null,
"columns": {
"creatorUUID": "92cc1b65-c3cd-4f26-8c9b-3e7b055c7c25",
"mobilityZoneName": "zone1",
"description": "",
}
}
GET All Controlblades
This resource URI retrieves a list of all controlblade records from the SCG.
URI
~/api/rest/controlblades
Verb
GET
Parameters
N/A
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/controlblades
Response
Lists the controlblade records in JSON format.
Example
{
"controlBlades": [
REST APIs
GET One Controlblade
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 48
{
"key": "a30429f2-5f94-46aa-8068-d88d72e95896",
"healthEnum": "Online",
"bladeStateEnum": "In_Service",
"description": "ctrldesc112",
"statistics": null,
"hostName": "cblade",
"mac": "00:00:00:00:00:00",
"ip": "172.18.114.61",
"firmware": null,
"model": "SCG112020",
"serialNumber": "000000112020",
"removalStatus": null,
"start-time": 1364894071654,
"role": null,
"bindingIps": {
"br2": "172.18.114.63",
"br1": "172.18.114.61",
}
}
]
}
GET One Controlblade
This resource URI retrieves one controlblade record from SCG, based on the zone
UUID.
URI
~/api/rest/controlblade/{bladeuuid}
Verb
GET
REST APIs
GET One Controlblade
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 49
Parameters
bladeuuid - Blade UUID
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/controlblade/
380d2ff8-dfde-46c2-85cd- 493ed5b7b920
Response
Lists the controlblade record in JSON format.
Example
Key is the {bladeuuid}
{
"key": "a30429f2-5f94-46aa-8068-d88d72e95896",
"healthEnum": "Online",
"bladeStateEnum": "In_Service",
"description": "ctrldesc112",
"statistics": null,
"hostName": "cblade",
"mac": "00:00:00:00:00:00",
"ip": "172.18.114.61",
"firmware": null,
"model": "SCG112020",
"serialNumber": "000000112020",
"removalStatus": null,
"start-time": 1364894071654,
"role": null,
"bindingIps": {
"br2": "172.18.114.63",
"br1": "172.18.114.61",
"br0": "172.18.114.60",
}
}
REST APIs
GET All Statistics Between Start and End Time for One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 50
GET All Statistics Between Start and End
Time for One Access Point
This resource URI retrieves statistical records between the specified start and end
time of one access point from SCG, based on MAC address. of the access point.
URI
~/api/rest/ap/{macaddress}/stats?starttime={start-
Time}&endtime={endTime}
Verb
GET
Parameters
macaddress - MAC address of the access point
start-Time - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/ap/
00:22:68:00:00:A1/stats?start-
time=2011-12-31%2023:59:59%20pst&endtime=2012-01-
08%2000:00:00%20pst
Response
Lists the AP statistical records in JSON format.
Example
{
"apstats": [
{
"macAddress": "00:22:68:00:00:A1",
"timestamp": 1364905800000,
"txBytes": 0,
"rxBytes": 0,
REST APIs
GET All Statistics Between Start and End Time for All Radios of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 51
"airtime": 0,
"minNumClients": 0,
"txRateKbps": 0,
"rxRateKbps": 0,
"rxDataFrames": 0,
"uptime": null,
"avgNumClients": 0,
"txDataFrames": 0,
}
]
}
GET All Statistics Between Start and End
Time for All Radios of One Access Point
This resource URI retrieves statistical records between the specified start and end
time of all radios on one access point from the SCG. This is based on the MAC
addressof the access point.
URI
~/api/rest/ap/{macaddress}/radios/stats?starttime={start-
Time}&endtime={endTime}
Verb
GET
Parameters
macaddress - MAC address of the access point
startTime - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
REST APIs
GET All Statistics Between Start and End Time for All Radios of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 52
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/ap/
00:22:68:00:00:A1/radios/stats?start-time=2011-12-
31%2023:59:59%20pst&endtime=2012-01-08%2000:00:00%20pst
Response
Lists the AP radio statistical records in JSON format.
Example
{
"apradioStats": [
{
"macAddress": "00:22:68:00:00:A1",
"radioId": "0",
"timestamp": 1364905800000,
"num11nClients": 0,
"txFrames": null,
"airtime": 0,
"rxBytes": null,
"minNumClients": 0,
"rxFrames": null,
"txBytes": null,
"numNon11nClients": 0,
"maxNumClients": 0
}
{
"macAddress": "00:22:68:00:00:A1",
"radioId": "0",
"timestamp": 1364906700000,
"num11nClients": 0,
"txFrames": null,
"airtime": 65,
REST APIs
GET All Statistics Between Start and End Time for One Radio of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 53
}
]
}
GET All Statistics Between Start and End
Time for One Radio of One Access Point
This resource URI retrieves statistical records between the input start and end time
for all radios of one access point from SCG. This is based on the MAC address of
access points.
URI
~/api/rest/ap/{macaddress}/radio/{radioid}/stats?start-
time={start-Time}&endtime={endTime}
Verb
GET
Parameters
macaddress - MAC address of the access point
radioid - Radio ID, for example - 0 or 1
startTime - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/ap/
00:22:68:00:00:A1/radio/0/stats?start-time=2011-12-
31%2023:59:59%20pst&endtime=2012-01-08%2000:00:00%20pst
Response
Lists the AP radio statistical records in JSON format.
Example
{
"apradioStats": [
REST APIs
GET All Statistics Between Start and End Time for All WLANs of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 54
{
"macAddress": "00:22:68:00:00:A1",
"radioId": "0",
"timestamp": 1364905800000,
"num11nClients": 0,
"txFrames": null,
"airtime": 0,
"rxBytes": null,
"minNumClients": 0,
"rxFrames": null,
"txBytes": null,
"numNon11nClients": 0,
"maxNumClients": 0
}
{
"macAddress": "00:22:68:00:00:A1",
"radioId": "0",
"timestamp": 1364906700000,
"num11nClients": 0,
"txFrames": null,
"airtime": 65,
}
]
}
GET All Statistics Between Start and End
Time for All WLANs of One Access Point
This resource URI retrieves statistical records between the specified start and end
time for all WLANs on one access point from the SCG. This is based, on the MAC
address of access points.
REST APIs
GET All Statistics Between Start and End Time for All WLANs of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 55
URI
~/api/rest/ap/{macaddress}/wlans/stats?starttime={start-
Time}&endtime={endTime}
Verb
GET
Parameters
macaddress - MAC address of the access point
startTime - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/ap/
00:22:68:00:00:A1/wlans/stats?start-time=2011-12-
31%2023:59:59%20pst&endtime=2012-01-08%2000:00:00%20pst
Response
Lists the AP WLAN statistical records in JSON format.
Example
{
"apwlanStats": [
{
"macAddress": "00:22:68:00:00:A1",
"timestamp": 1364906700000,
"radioId": "0",
"wlanId": "0",
"ssid": "kkkwlan1",
"bssid": "c0:c5:20:26:95:d8",
"txBytes": null,
"rxBytes": null,
"txRateKbps": 0,
REST APIs
GET All Statistics Between Start and End Time for One WLAN of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 56
"rxRateKbps": 0,
"minNumClients": 0,
"avgNumClients": 0,
"maxNumClients": 0
}
{
"macAddress": "00:22:68:00:00:A1",
"timestamp": 1364907600000,
"radioId": "0",
"wlanId": "0",
}
]
}
GET All Statistics Between Start and End
Time for One WLAN of One Access Point
This resource URI retrieves statistical records between the specified start and end
time for one WLAN pertaining to one access point from the SCG. This is based on
the MAC address and WLAN ID, respectively.
URI
~/api/rest/ap/{macaddress}/wlan/{wlanid}/stats?start-
time={start-Time}&endtime={endTime}
Verb
GET
Parameters
macaddress - MAC address of the access point
wlanid - WLAN ID, for example - 0,1
startTime - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
REST APIs
GET All Statistics Between Start and End Time for One WLAN of One Access Point
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 57
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/ap/
00:22:68:00:00:A1/wlan/0/stats?start-time=2011-12-
31%2023:59:59%20pst&endtime=2012-01-08%2000:00:00%20pst
Response
Lists the AP WLAN statistical records in JSON format.
Example
{
"apwlanStats": [
{
"macAddress": "00:22:68:00:00:A1",
"timestamp": 1364906700000,
"radioId": "0",
"wlanId": "0",
"ssid": "kkkwlan1",
"bssid": "c0:c5:20:26:95:d8",
"txBytes": null,
"rxBytes": null,
"txRateKbps": 0,
"rxRateKbps": 0,
"minNumClients": 0,
}
]
}
REST APIs
GET All Statistics Between Start and End Time for All Mobility Zones
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 58
GET All Statistics Between Start and End
Time for All Mobility Zones
This resource URI retrieves statistical records between the specified start and end
time for all mobility zones from the SCG.
URI
~/api/rest/mobilityzones/stats?starttime={start-
Time}&endtime={endTime}
Verb
GET
Parameters
startTime - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/mobilityzones/
stats?start-time=2011-12-31%2023:59:59%20pst&endtime=2012-
01-08%2000:00:00%20pst
Response
Lists the mobility zone statistical records in JSON format.
Example
{
"mobilityZoneStats": [
{
"zoneUUID": "11a87f70-fada-4938-9fcb-a26edb1504d0",
"timestamp": 1364905800000,
"txBytes": 0,
"rxBytes": 0,
"airtime": 0,
"minNumClients": 0,
"txRateKbps": 0,
REST APIs
GET All Statistics Between Start and End Time for One Mobility Zone
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 59
"rxRateKbps": 0,
"rxDataFrames": 0,
"uptime": null,
"avgNumClients": 0,
"txDataFrames": 0,
"maxNumClients": 0
}
{
"zoneUUID": "11a87f70-fada-4938-9fcb-a26edb1504d0",
"timestamp": 1364906700000,
"txBytes": 0,
}
]
}
GET All Statistics Between Start and End
Time for One Mobility Zone
This resource URI retrieves statistical records between the specified start and end
time for one mobility zone from the SCG, based on the Zone UUID.
URI
~/api/rest/mobilityzone/{zoneuuid}/stats?starttime={start-
Time}&endtime={endTime}
Verb
GET
Parameters
zoneuuid - Zone UUID
startTime - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
REST APIs
GET All Statistics Between Start and End Time for All Controlblades
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 60
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/mobilityzone/
cee71896-241e-4fbf-a3e2-62cb47d63573/stats?start-
time=2011-12-31%2023:59:59%20pst&endtime=2012-01-
08%2000:00:00%20pst
Response
Lists the mobility zone statistical records in JSON format.
Example
{
"mobilityZoneStats": [
{
"zoneUUID": "cee71896-241e-4fbf-a3e2-62cb47d63573",
"timestamp": 1364905800000,
"txBytes": 0,
"rxBytes": 0,
"airtime": 0,
"minNumClients": 0,
"txRateKbps": 0,
"rxRateKbps": 0,
"rxDataFrames": 0,
"uptime": null,
}
]
}
GET All Statistics Between Start and End
Time for All Controlblades
This resource URI retrieves statistical records between the specified start and end
time for all controlblades from the SCG.
REST APIs
GET All Statistics Between Start and End Time for All Controlblades
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 61
NOTE: The statistical data of controlblade is available only for 2 days. RESTful API
can retrieve only the last two days of the controlblade statistical data from the SCG.
Access to older data will not return any values.
URI
~/api/rest/controlblades/stats?starttime={start-
Time}&endtime={endTime}
Verb
GET
Parameters
startTime - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/controlblades/
stats?start-time=2011-12-31%2023:59:59%20pst&endtime=2012-
01-08%2000:00:00%20pst
Response
Lists the controlblade statistical records in JSON format.
Example
{
"controlBladeStats": [
{
"bladeUUID": "a30429f2-5f94-46aa-8068-d88d72e95896",
"timestamp": 1364787600000,
"cpu_perc": null,
"cpu_perc_min": null,
"cpu_perc_max": null,
"memory_perc": null,
"memory_perc_min": null,
"memory_perc_max": null
REST APIs
GET All Statistics Between Start and End time for One Controlblade
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 62
}
{
"bladeUUID": "a30429f2-5f94-46aa-8068-d88d72e95896",
"timestamp": 1364787900000,
"cpu_perc": null,
"cpu_perc_min": null,
"cpu_perc_max": null,
"memory_perc": null
}
]
}
GET All Statistics Between Start and End time
for One Controlblade
This resource URI retrieves statistical records between the specified start and end
time of a single controlblade from the SCG. This is based on the Zone UUID.
NOTE: The statistical data of controlblade is available only for 2 days. RESTful API
can retrieve only the last two days of the controlblade statistical data from the SCG.
Access to older data will not return any values.
URI
~/api/rest/controlblade/{bladeuuid}/stats?start-
time={start-Time}&endtime={endTime}
Verb
GET
Parameters
bladeuuid - Blade UUID
startTime - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
REST APIs
GET All Statistics Between Start and End time for One Controlblade
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 63
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/controlblade/
380d2ff8-dfde-46c2-85cd-493ed5b7b920/stats?start-
time=2011-12-31%2023:59:59%20pst&endtime=2012-01-
08%2000:00:00%20pst
Response
Lists the controlblade statistical records in JSON format.
Example
{
"controlBladeStats": [
{
"bladeUUID": "380d2ff8-dfde-46c2-85cd-493ed5b7b920",
"timestamp": 1364787600000,
"cpu_perc": null,
"cpu_perc_min": null,
"cpu_perc_max": null,
"memory_perc": null,
"memory_perc_min": null,
"memory_perc_max": null
}
{
"bladeUUID": "380d2ff8-dfde-46c2-85cd-493ed5b7b920",
"timestamp": 1364787900000,
"cpu_perc": null,
"cpu_perc_min": null,
"cpu_perc_max": null,
"memory_perc": null
}
]
}
REST APIs
GET All Events Between Start and End Time
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 64
GET All Events Between Start and End Time
This resource URI retrieves event records between the specified start (including) and
end time from the SCG using the attribute insertion time for comparison.
URI
~/api/rest/events?starttime={startTime}&endtime={endTime}
Verb
GET
Parameters
startTime - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
Request Example
https://SCG_Management_IP:84433/wsg/api/rest/events?start-
time=2011-12-31%2023:59:59%20pst&endtime=2012-01-
08%2000:00:00%20pst
Response
Lists event records in JSON format.
Example
{
"events": [
{
"ap": null,
"eventCode": 826,
"category": "Cluster",
"severity": "Major",
"zoneUUID": null,
"eventType": "nodeRebooted",
"model": null,
"apMac": null,
REST APIs
GET All Alarms Between Start and End Time
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 65
"wsgIP": null,
"configID": null,
"timestamp": 1363766861123
}
]
}
GET All Alarms Between Start and End Time
This resource URI retrieves alarm records between the specified start (including) and
end time from the SCG using insertion time for comparison.
URI
~/api/rest/alarms?starttime={startTime}&endtime={endTime}
Verb
GET
Parameters
startTime - Start time format is - “yyyy-mm-dd hh:mi:ss timezone”. For example,
“2011-12-10 11:22:33 pst”
endTime - End time format is similar to the start time format.
Request Example
https://SCG_Management_IP:8443/wsg/api/rest/alarms? start-
time=2011-12-31%2023:59:59%20pst&endtime=2012-01-
08%2000:00:00%20pst
Response
Lists the alarm records in JSON format.
Example
{
"alarms": [
{
"key": "39246a08-6b96-4e54-a8c0-b2cb338acc17",
REST APIs
GET All Alarms Between Start and End Time
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 66
"alarmCode": 811,
"alarmUUID": "39246a08-6b96-4e54-a8c0-b2cb338acc17",
"ackUserUUID": null,
"ackTimestamp": null,
"timestamp": 1364356298241,
"zoneUUID": null,
"alarmType": "nodeRebooted",
"alarmState": "Outstanding",
"alarmSeverity": "Major",
"acknowledged": "No",
"clearEventCode": null,
"all": "",
"event": {
"ap": null,
"eventCode": 826,
"category": "Cluster",
"severity": "Major",
"zoneUUID": null,
}
]
}
{
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 67
Index
A
alarms between start and end time 65
all access points 12
all controlblades 47
all events between start and end time 64
all mobility zones 45
all radio records of all access points 21
all radio records of one access point 14
all statistics for all controlblades 60
all statistics for all mobility zones 58
all statistics for all radios of one access
point 51
all statistics for all WLans of one access
point 54
all statistics for one access point 50
all statistics for one controlblade 62
all statistics for one mobility zone 59
all statistics for one radio of one access
point 53
all statistics for one WLan of one access
point 56
all WLan records of all access points 34
all WLan records of one access point 26
authentication 10
B
bladeuuid 49, 62
C
core objects 9
D
data resources 9
E
endTime 50, 51, 53, 55, 56, 58, 59,
61, 62, 64, 65
example 12, 13, 15, 20, 21, 27, 33, 34,
45, 46, 47, 49, 50, 52, 53, 55, 57, 58,
60, 61, 63, 64, 65
H
host 9
M
macaddress 13, 14, 20, 26, 33, 50, 51,
53, 55, 56
multiple representations 10
O
one access point 13
one controlblade 48
one mobility zone 46
one radio record of one access point 20
one WLan record of one access point 33
overview 9
P
parameters 12, 13, 14, 20, 21, 26, 33,
34, 45, 46, 47, 49, 50, 51, 53, 55, 56,
58, 59, 61, 62, 64, 65
Q
query parameters 9
R
radioid 20, 53
representation 10
request example 12, 13, 14, 20, 21, 26,
33, 34, 45, 46, 47, 49, 50, 52, 53, 55,
57, 58, 60, 61, 63, 64, 65
resource 9
response 12, 13, 14, 20, 21, 26, 33,
34, 45, 46, 47, 49, 50, 52, 53, 55, 57,
58, 60, 61, 63, 64, 65
S
security 10
security facility 10
start-Time 50
Index
SmartCell Gateway 200 RESTful Interface Reference Guide for Release 2.5.1, 800-70700-001 Rev A 68
startTime 51, 53, 55, 56, 58, 59, 61,
62, 64, 65
statistics 9
super administrator 10
U
uRI 9, 10, 12, 13, 14, 20, 21, 26, 33,
34, 45, 46, 47, 48, 50, 51, 53, 55, 56,
58, 59, 61, 62, 64, 65
user accounts 10
V
verb 12, 13, 14, 20, 21, 26, 33, 34,
45, 46, 47, 48, 50, 51, 53, 55, 56, 58,
59, 61, 62, 64, 65
W
wlanid 33, 56
Z
zoneuuid 46, 59
Copyright © 2006-2014. Ruckus Wireless, Inc.
350 West Java Dr. Sunnyvale, CA 94089. USA
www.ruckuswireless.com

Navigation menu
