Ruoey Lung Enterprise N7-MP REMOTE CONTROL User Manual
Ruoey Lung Enterprise Corp. REMOTE CONTROL
User Manual
TEMPUR-Ergo™ Basic
RADIO FREQUENCY IS 433 MHz.
FCC COMPLIANCE
THIS device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
TO comply with the FCC RF exposure
compliance requirements, no change to the
antenna or the device is permitted. Any change
to the antenna or the device could result in the
device exceeding the RF exposure requirements
and void user’s authority to operate the device.
PRODUCT RATINGS
The lift motors in your TEMPUR-Ergo™ Basic are NOT
designed for continuous use. Reliable operation and
full life expectancy will be attained as long as the lift
motors do not operate more than two (2) minutes
over an 20-minute period, or approximately 10%
duty cycle. Any attempt to circumvent or exceed this
rating will shorten the life expectancy of this product
and may void the warranty. The recommended weight
restrictions on our TEMPUR-Ergo Basic systems
are as follows: Twin, Twin Long, Double, Queen, and
Split/Dual CA King bases – up to 650 lbs. each. This
TEMPUR-Ergo Basic will structurally support the
recommended weight distributed evenly across the
head and foot sections. This product is not designed to
support or lift this amount of weight in the head or foot
sections alone.
NOTE: Exceeding the recommended weight
restrictions could damage your TEMPUR-Ergo
Basic and void your warranty.
For best performance, you should enter and exit
the TEMPUR-Ergo Basic while it is in the at or fully
lowered position.
INTENDED USAGE
The electric adjustable bed should be installed with
the Headboard Bracket and/or the head of the frame
should be positioned close to a wall.
8
Customer serviCe: 1–800–821–6621
1. HEAD UP (HU) 3. LEG UP (LU)
6. MEMORY PRESET 1
2. HEAD DOWN (HD)
7. MEMORY PRESET 2
Wireless Remote Control Features
READ ADVISORY INFORMATION IN THE SAFETY PRECAUTIONS SECTION OF THIS GUIDE CAREFULLY BEFORE
USING THIS PRODUCT. THE POTENTIAL FOR ELECTRIC SHOCk EXISTS IF ELECTRICAL COMPONENTS ARE NOT
INSTALLED OR OPERATED PROPERLY.
5. FLAT (F)
4. LEG DOWN (LD)
17
CUSTOMER SERVICE: 1–800–821–6621
Operation
TEMPUR-Ergo™ Basic
Operating Instructions
MANUAL ADjUSTMENT OF HEAD AND FOOT
Head (1,2)
This function adjusts the Head section to
the desired position.
Press the HEAD UP button (1).
Keep pressing the button until the desired
height is reached.
Press the HEAD DOWN button (2).
Keep pressing the button until the desired height is
reached.
Leg (3,4)
This function adjusts the Leg section to the
desired position.
Press the LEG UP button (3).
Keep pressing the button until the desired
height is reached.
Press the LEG DOWN button (4).
Keep pressing the button until the desired height is
reached.
Flat (5)
Press and hold the FLAT button (5) for 3
seconds, and the bed frame will
automatically move to its complete at position.
NOTE: Ensure all obstructions are clear of the
base’s undercarriage when lifting or lowering
the base’s head and leg sections to avoid risk
of pinching or damage.
NOTE: When the movement to the flat position
is active it is possible to interrupt the movement
with ANY button at any time during movement
for safety reasons.
Preset Memory Positions (6,7)
The system offers two (2) Preset
Memory Positions.
Hold either button for 5 seconds, until the lights
ash 3 times. When they stop, memory is stored.
NOTE: When the new position of the head is
higher than the current position of the head,
first the head section and then the leg section
move to the corresponding memory position.
NOTE: If the new position of the head is equal
or lower than the current position of the head,
first the leg section and then the head section
move to the corresponding memory position.
NOTE: When the movement to a memory
position is active it is possible to interrupt the
movement with ANY button, at any time during
movement for safety reasons.
To ensure safe operation of the system, please observe the following safety instructions:
CAUTION: Keep children away from electrically adjustable beds and control units. There is risk of injury
and electric shock.
CAUTION: Unplug the power cord during a thunderstorm or if you do not intend to use the system for an
extended period of time.
NOTE: Do not put the remote control button-side down.
NOTE: The actuators will continue moving until you release button or the maximum height is reached.
18
Customer serviCe: 1–800–821–6621
