Ruoey Lung Enterprise N8-FM N8-FM Remote Control User Manual Layout 4
Ruoey Lung Enterprise Corp. N8-FM Remote Control Layout 4
Users Manual
Wireless Hand
Remote Operation
Contouring
“Head Tilt”
Feature now with
Power “Lumbar“
Adjustability
8
FOR YOUR SAFETY, READ THE OWNER’S MANUAL CAREFULLY AND COMPLETELY BEFORE OPERATING THIS PRODUCT. ELECTRIC
SHOCK MAY OCCUR IF ELECTRICAL COMPONENTS ARE NOT INSTALLED OR OPERATED ACCORDING TO THESE GUIDELINES.
Head and Foot Position Adjustments (A, B, C, D)
• Use to raise or lower the head and foot sections of your adjustable bed. The premium “Wall-Glide”
feature will automatically synchronize with all Head & Foot adjustments.
LED Signal Light (E)
• Indicates signal is being sent for operating function.
Bed “Flat” Button (F)
• Press down and hold for 3 seconds to return bed to the flat position.
Pre-Programmed Memory Position (G)
• These 3 program function keys allow you to select the most popular positions with one touch.
Head and Foot Massage Adjustments (H, I, J, K)
•
Use to activate the massage feature on the head and foot of the bed (starting at intensity 4 of 8).
Gradually increase or decrease intensity of massage vibration by pressing the appropriate button. The
lowest setting on each massage unit will turn off the respective vibration. The massage feature is
programmed with an Auto Shut-Off Timer that will automatically turn off the massage after 15 minutes
of continuous use. A 5 minute cool down is required before initiating an additional massage sequence.
E. LED Signal Light
A. Raises the Head of the Bed
B. Lowers the Head of the Bed C. Raises the Foot of the Bed
D.Lowers the Foot of the Bed
F. Returns Head & Foot to FLAT
Position (hold 3 seconds)
H. Increases the Intensity
of Vibration (Head)
J. Increases the Intensity
of Vibration (Foot)
I. Decreases the Intensity
of Vibration (Head)
N. Turns on Massage
Wave 1,2 or 3
K. Decreases the Intensity
of Vibration (Foot)
G. Pre-Programmed
Memory Positions
Q. Decreases
Lumbar Support
P. Increases Lumbar Support
L. Stops Massage
M. Full Body Massage
O. Under
Bed Light
Advanced Wireless Adjustable Bed
with Bluetooth Sound System
& Power Lumbar Adjustability
The
REVOLUTION
Wireless Hand
Remote Operation
9
NOTE:
This bed may show minor intermittent performance because of typical RF interference.This is normal in the operation of the bed, not a defect.
Continued
Advanced Wireless Adjustable Bed with
Bluetooth Sound System & Power Lumbar Adjustability
The
REVOLUTION
Stop Button (L)
• Hold down for 2 seconds to stop massage.
Full Body Massage (M)
• Press to activate both the head and foot massages at the same time.
Wave Massage Adjustments (N)
• Activates both units to wave mode massage. NOTE: You must stop the massage in order to activate another
massage setting such as full body or another wave massage.
REMEMBER: YOU MUST STOP MASSAGE BEFORE ALTERNATING BETWEEN MASSAGE FUNCTIONS.
Under Bed Light (O)
• Press the button to turn on or off the under bed light. (Button on back of Hand Wand)
Lumbar Adjustments (P,Q)
• Activates the power Lumbar System which gently increases or decreases lower back support
REMOTE FEATURES
• The Adjustable Bed uses a RF (Radio Frequency) hand control system.
• The buttons are backlit, when pressed, to aid in the visibility of the remote in low light environments.
• It is not necessary to face the receiver to operate the remote control. Remote signal is best transmitted within
9 feet (3 meters) of the receiver.
SAFETY
• In the case that an overload of weight is placed on the head or foot mechanism, the control unit will automatically stop all
functions. The control unit will automatically resume all functions 30 seconds after excess weight is removed.
• Massage motors will automatically shut off after running continuously for 15 minutes. All massage functions will be
operational again after 5 minutes.
• The input transformer voltage is AC120V 60HZ, the output voltage is DC24V 3A. In the case of a short-circuit, a fuse on the
transformer will blow to protect the electrical equipment (Fuse: 1A~1.5A.). Should this occur, you MUST seek professional
assistance to replace the fuse. Call Customer Care at: 1-877-826-8757
Notice: The changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Important Note: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device
is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and
void user’s authority to operate the device.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT
ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
