S E M SEM-HP2020 Stereo Bluetooth Headphone User Manual HP 2020 BTHF S01 FCCstd ENGLISH IM V3 131104a
S.E.M. INDUSTRIES Stereo Bluetooth Headphone HP 2020 BTHF S01 FCCstd ENGLISH IM V3 131104a
S E M >
User manual_2AANA-SEM-HP2020
OPERATING INSTRUCTIONS
1
3
4
8 9
5
7
Front view Back view
Side view
1. Volume + key
2. Volume - key
3. On/ off switch
4. Adjustable & foldable headband
5. Skip + key
6. Skip - key
7. Micro USB charging socket
8. LED indicator
9. Multi-function key
10. Microphone
26
Location of controls
Welcome to HP-2020
A stylish headphone with Bluetooth & Hands free function. Adjustable & foldable headband design for extra comfort.
Basic playback control is included at the side of the headphone: Volume +/- and Skip +/- (forward/ backward) of one song.
To begin with, switch ON the headphone. The LED indicator will flash in blue rapidly repeatedly to indicate pairing mode.
Steps for Bluetooth® Connection
1. Switch on the Bluetooth® function of the device you would like to pair with.
2. On your device's Bluetooth® settings, add or search for a new Bluetooth®
device, and locate this device.
3. Press the "Connect" button on your device to start the pairing process.
4. When it is successfully paired, the LED indicator will flash twice.
5. Playback control can be done directly through your device:
SKIP +: To go to next song / SKIP - : To go to pervious song
(Multi-function key): Press once & release to pause, press again &
release to resume playback.
(Note: If you press & hold this key for more than 2 seconds, it will unpair
the headphone from your device).
6. To unpair a Bluetooth® device that has already been paired, press & hold
the Multi-function key.
Hands free function
At anytime during playback, you can pick up phone a call by simply
pressing the “Multi-function” key.
You can press the key again to hang up.
Charging the headphone
This device comes with a micro USB port for charging.
Use the supplied micro USB cable to connect the headphone to any standard
USB port. Charging time depends on the output capacity of the USB port,
but it will take averagely 2 hours for a full charge (based on a 1000mA USB
port). Playback time depends on the type of music you are listening to and
the volume level, but it can play up to 10 hours under normal conditions.
When it is successfully being charged, the LED indicator will turn red
to indicate it is in charging mode.
10
THE DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION. CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S AUTHORITY
TO OPERATE THE PRODUCT.
NOTE: THIS PRODUCT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR
A CLASS B DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL
INTERFERENCE IN A RESIDENTIAL INSTALLATION. THIS PRODUCT GENERATES, USES AND CAN RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND
USED IN ACCORDANCE WITH THE INSTRUCTIONS, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. HOWEVER, THERE IS NO GUARANTEE THAT
INTERFERENCE WILL NOT OCCUR IN A PARTICULAR INSTALLATION. IF THE PRODUCT DOES CAUSE HARMFUL INTERFERENCE TO RADIO OR TELEVISION RECEPTION,
WHICH CAN BE DETERMINED BY TURNING THE EQUIPMENT OFF AND ON, THE USER IS ENCOURAGED TO TRY TO CORRECT THE INTERFERENCE BY ONE OR MORE OF
THE FOLLOWING MEASURES : -REORIENT OR RELOCATE THE RECEIVING ANTENNA. -INCREASE THE SEPARATION BETWEEN THE PRODUCT AND RECEIVER.
-CONNECT THE PRODUCT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM THAT TO WHICH THE RECEIVER IS CONNECTED. -CONSULT THE DEALER OR AN
EXPERIENCED RADIO/TV TECHNICIAN FOR HELP.
