S E M SEM-SP1501 Mini Speaker User Manual SP 1501 BTHF S02 FCC STD ENGLISH IM V0 140110

S.E.M. INDUSTRIES Mini Speaker SP 1501 BTHF S02 FCC STD ENGLISH IM V0 140110

User Manual_2AANA-SEM-SP1501

E-2
WAR NI NG : To reduce
the risk of electric shock, do
not remove cover (or back).
N o u s e r - s e r v i c e a b l e
p a r t s i n s i d e . R e f e r
s e r v i c i n g t o q u a l i f i e d
service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
T he excl am at i on
poi nt w i t hi n t he
triangle is a warning
sign alerting you of
important instructions
accompanying the
product.
The lightning flash
a n d a r r o w h e a d
within the triangle
i s a w a r n i n g
sign alerting you of
"dangerous voltage"
inside the product.
NOTE: CAUTION SYMBOLS ARE PRINTED ON REAR OF UNIT.
PLEASE REFER TO INSTRUCTION MANUAL.
WARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO DRIPPING OR SPLASHING LIQUIDS.
THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING OR SPLASHING AND
NO OBJECTS FILLED WITH LIQ UIDS SHOULD BE PLACED ON THE APPARATUS.
THE MARKING AND RATING LABEL IS LOCATED AT REAR ENCLOSURE OF THE APPARATUS.
UNDER THE INFLUENCE OF ELECTROSTATIC PHENOMENON,
THE PRODUCT MAY MALFUNCTION AND USER TO POWER RESET.
BATTERY SHOULD NOT BE EXPOSED TO EXCESSIVE HEAT SUCH AS SUNSHINE, FIRE OR THE LIKE.
Model : SP-1501-BTHF
USER MANUAL
High Power Mini Speaker System
The device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the product.
NOTE: This product has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This product generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If the product does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures : -Reorient or relocate the
receiving antenna. -Increase the separation between the product and receiver. -
Connect the product into an outlet on a circuit different from that to which the receiver
is connected. -Consult the dealer or an experienced radio/TV technician for help.
CAUTION
DO NOT EXPOSE TO DRIPPING
OR SPLASHING LIQUIDS!
PLEASE NOTE: YOU WILL FIND THE
RATING LABEL FOR THIS PRODUCT
LOCATED ON THE REAR OF THE UNIT.
BLUETOOTH® WIRELESS PLAYBACK
THE UNIT CAN WIRELESSLY STREAM AUDIO FROM ANY BLUETOOTH® DEVICE WITHIN
30 FEET. SIMPLY PAIR THE DEVICE AND ENJOY WIRELESS PLAYBACK AND CONTROL
FROM YOUR BLUETOOTH® DEVICE.
PREPARE THE UNIT:
- SWITCH THE ON/OFF SWITCH TO TURN THE UNIT ON.
- THE BLUETOOTH LED INDICATOR WILL FLASH TO INDICATE THE UNIT IS ON AND WAITING
FOR PARING.
- THE LED INDICATOR WILL REMAIN LIT ON WHEN PAIRED.
*NOTE ONLY ONE DEVICE CAN BE PAIRED AT ANY GIVEN TIME.
PREPARE YOUR PHONE OR OTHER BLUETOOTH® DEVICE:
- TURN ON THE BLUETOOTH® FUNCTION, THIS IS USUALLY FOUND UNDER GENERAL
SETTINGS OR OPTIONS.
*PLEASE REFER TO YOUR DEVICE’S MANUAL FOR FURTHER BLUETOOTH® DETAILS.
MAKE THE CONNECTION:
- GO TO YOUR DEVICE’S BLUETOOTH® SETTINGS
- ADD OR SEARCH FOR DEVICES
- IF ASKED FOR A PASS CODE, ENTER “0000”
*THIS IS A ONE-TIME EVENT PER DEVICE. TO PAIR YOUR UNIT TO ANOTHER DEVICE,
REPEAT THE ABOVE PREPARATION AND CONNECTION STEPS.
DISABLING THE CONNECTION TO UNPAIR A BLUETOOTH® DEVICE THAT IS ALREADY
PAIRED, PRESS AND HOLD THE PAIR KEY FOR A FEW SECONDS.
VOLUME CONTROL:
INCREASE AND DECREASE VOLUME USING THE VOLUME UP AND VOLUME DOWN KEYS
ON THE UNIT OR USING THE VOLUME CONTROLS ON YOUR BLUETOOTH® ENABLED
DEVICE.
*NOTE THAT IF THERE IS NO PLAYBACK, ENSURE THAT NEITHER THE UNIT NOR YOUR
BLUETOOTH® DEVICE ARE SET TO ZERO VOLUME AND THE CORRECT DEVICE FOR
PLAYBACK IS PAIRED.
LOCATION OF CONTROLS
E-3
1. SPEAKER
2. VOLUME UP KEY
3. PAIR/ PLAY/ PAUSE/ HANDS FREE KEY
4. VOLUME DOWN KEY
5. MICRO USB CHARGING SOCKET
6. CHARGING LED INDICATOR
7. BLUETOOTH LED INDICATOR
8. AUX INPUT SOCKET
9. MICROPHONE (FOR HANDS FREE)
10. ON/ OFF SWITCH (BOTTOM OF UNIT)
E-4
BACK VIEW:
FOR BEST RESULTS, FULLY CHARGE YOUR SPEAKE R SYSTEM BEFORE USE. USING THE AUDIO LINE IN CONNECTION (AUX-INPUT)
- YOU CAN CONNECT THE AUDIO OUTPUT OF AN EXTERNAL DEVICE SUCH AS A MP3
PLAYER TO THIS UNIT, TO LISTEN TO THE SOUND OF THAT DEVICE THROUGH
THE HIGH QUALITY AMPLIFIER OF THIS MUSIC SYSTEM.
- TO CONNECT THE EXTERNAL DEVICE PLEASE USE A STANDARD STEREO HEADPHONE
(3.5MM TO 3.5MM PLUGS) CABLE TO CONNECT THE "HEADPHONE-OUT OR AUDIO
LINE-OUT" OF THE DEVICE TO THE AUX-INPUT SOCKET OF THIS UNIT.
- SWITCH ON THE EXTERNAL DEVICE (eg. MP3-PLAYER).
- START PLAYBACK OF THE EXTERNAL DEVICE AND ADJUST THE VOLUME CONTROL
OF THE UNIT TO THE DESIRED LEVEL.
- REMEMBER TO SWITCH OFF THE UNIT AND THE EXTERNAL DEVICE WHEN YOU ARE
FINISHED USING THE EXTERNAL DEVICE.
- REMEMBER TO UNPLUG THE 3.5MM AUX-IN PLUG FROM THE UNIT WHEN YOU ARE
FINISHED USING THE EXTERNAL DEVICE, TO SWITCH BACK TO BLUETOOTH® MODE.
POWER SUPPLY : ................... RECHARGEABLE LITHIUM BATTERY 3.7V/800mAh x 1PC
RECHARGE POWER: USB DC 5V, 500mA (OR HIGHER)
SPECIFICATIONS
SPEAKER OPERATION
- AT ANYTIME DURING PLAYBACK, PRESS THE PLAY/PAUSE KEY TO PAUSE
OPERATION. PRESS AGAIN TO RESUME OPERATION AT THE SAME TRACK & POSITION.
- AT ANYTIME DURING PLAYBACK, “PRESS AND RELEASE” THE NEXT OR BACK KEY :
OR TO SKIP BACKWARDS OR FORWARDS BY ONE TRACK, AS DESIRED.
- PRESS THE PLAY/PAUSE KEY TO START PLAYBACK.
- THE UNIT INCLUDES A VERY USEFUL HANDS-FREE FUNCTION WHICH ENABLES YOU
TO USE IT AS A SPEAKER PHONE.
- MAKE SURE THE UNIT IS ON AND PAIRED WITH YOUR PHONE DEVICE AS DESCRIBED.
TO RECEIVE A CALL: PRESS THE HANDS-FREE KEY (3) ONCE.
TO END A CALL: PRESS THE HANDS-FREE KEY (3) AGAIN WHEN THE CALL IS FINISHED.
HANDS-FREE OPERATION
SPEAKER CHARGING
USB 5V
1
2
3
4
5
6
7
8
9
10
FRONT VIEW:
THIS UNIT COMES WITH A MICRO USB PORT FOR CHARGING.
USE THE SUPPLIED MICRO USB CABLE TO CONNECT THE UNIT TO ANY STANDARD USB
PORT. CHARGING TIME DEPENDS ON THE OUTPUT CAPACITY OF THE USB PORT,
BUT IT WILL TAKE AVERAGELY 2 HOURS FOR A FULL CHARGE
(BASED ON A 1000MA USB PORT). PLAYBACK TIME DEPENDS ON THE TYPE
OF MUSIC YOU ARE LISTENING TO AND THE VOLUME LEVEL, BUT IT CAN PLAY UP
TO 6 HOURS UNDER NORMAL CONDITIONS.
WHEN IT IS SUCCESSFULLY BEING CHARGED, THE LED INDICATOR WILL TURN RED
TO INDICATE IT IS IN CHARGING MODE.
PLUG-IN TO CHANGE TO AUX-IN MODE UNPLUG TO CHANGE TO BLUETOOTH® MODE
