SAGEMCOM BROANDS FAST2704R Wireless ADSL Router User Manual QIG 253500583A Fast 2704R EN
SAGEMCOM SAS Wireless ADSL Router QIG 253500583A Fast 2704R EN
Users Manual
Quick Installation Guide
F@ST 2704R
QIG 253500583A Fast 2704R_EN.book Page 1 Mardi, 21. août 2012 8:48 08
F@ST 2704R
2
Sagemcom thanks you for choosing the F@ST 2704R series routers and hope that it will
provide you with full satisfaction.
F@ST 2704R products provide full ADSL functionality on POTS (ITU G.992.1/3/5 -
Appendix A) and on ISDN (ITU G.992.1/3/5 - Appendix B).
F@ST 2704R routers include four ethernet interfaces (LAN1 to LAN4).
Copyright © Sagemcom Broadband SAS
All rights reserved.
Sagemcom is a registered trademark.
Windows® is a registered trademark of Microsoft Corporation.
QIG 253500583A Fast 2704R_EN.book Page 2 Mardi, 21. août 2012 8:48 08
3
F@ST 2704R
Contents of the pack
Before you carry out the installation, make sure that the pack contains the following
elements:
Item Description
1F@ST 2704 router
2Mains adapter
3ADSL line cable used to connect your router to your
telephone line
4Ethernet cable used to connect your router to the
Ethernet port of your computer
5Quick Installation Guide
6Filter/Splitter used to connect one phone set and your
router to your telephone line*
7Microfilter used to connect another phone set to your
telephone line*
* Option depending on pack content requested
5
4
3
2
1
7
6
QIG 253500583A Fast 2704R_EN.book Page 3 Mardi, 21. août 2012 8:48 08
F@ST 2704R
4
Safety instructions
Power supply source
• Do not cover the router’s power adapter.
• The router comes with its own power adapter. Do not use another adapter.
• This class II adapter does not need to be grounded (earthed). The connection to the
electrical network should comply with the indications given on the label.
• Use a readily accessible AC power outlet located near the router. The power supply cord is
1.5 m long.
• Care should be taken to ensure that the power cord is routed, so it is not likely to be walked
on or pinched by items placed upon or next to it.
• The router is designed to be connected to a GG- (ground-to-ground) or GN-
(ground-to-neutral) type power supply network.
• The router is not designed to be connected to an electrical installation with IT type diagram
(neutral connected to earth through an impedance).
• Protection against short-circuits and leaks between the phase, neutral and earth should be
provided by the building’s electrical installation. The power supply circuit for this equipment
should be fitted with 16 A overcurrent protection and differential protection.
• Connect the router to the AC power via a readily accessible wall socket providing the electric
protection.
Location conditions
By choosing an appropriate location, you will preserve the longevity of the device. Ensure that
the selected location has the following characteristics:
• Install and use the router inside a building.
• The room temperature must not exceed 40 °C.
• Solar radiation: 700 w/m².
• Relative humidity: 5 to 85 % without condensation.
• The router can be placed on a desktop or fixed vertically in its wall mounting.
• Do not expose the router to strong sunlight or place it near a substantial source of heat.
• Do not place the router in an environment where it could be subjected to considerable steam
condensation.
QIG 253500583A Fast 2704R_EN.book Page 4 Mardi, 21. août 2012 8:48 08
5
F@ST 2704R
• Do not expose the router to splashes of water.
• Avoid blocking any vent openings or exhaust exits on this equipment. Do not place
equipment in a built-in installation such as a cabinet that may impede the flow of air through
the ventilation openings.
• Do not use the router or its peripherals for outdoor transmissions.
Maintenance
• This equipment is not user serviceable and is to be serviced by qualified personnel only.
• Do not disassemble this equipment. If service is required, disconnect all power and phones
lines from the equipment and consult qualified service personnel.
• Do not use liquid or aerosol cleaning agents.
Environment
Never dispose of your product with other household waste. Please inform
yourself about the local rules on the separate collection of electrical and
electronic products. The correct disposal of your old product helps prevent
potentially negative consequences on the environment and human health.
QIG 253500583A Fast 2704R_EN.book Page 5 Mardi, 21. août 2012 8:48 08
F@ST 2704R
6
For North America
IMPORTANT SAFETY INSTRUCTIONS
When using this equipment, basic safety precautions should always be followed to
reduce the risk of fire, electric shock and injury to persons, including the following:
• The equipment is for indoor use in dry locations.
• Operate the equipment on maximum ambient temperature 40 °C, without any cover.
• Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or
laundry tub, in a wet basement or near a swimming pool.
• Avoid using a telephone (other than a cordless type) during an electrical storm. There may
be a remote risk of electric shock from lightning.
• Do not use the telephone to report a gas leak in the vicinity of the leak.
• To reduce the risk of fire, use only No. 26 AWG or larger (e.g., 24 AWG) UL Listed or CSA
Certified Telecommunication Line Cord.".
WARNING
To prevent fire or shock hazard. do not expose this appliance to rain or moisture.
This lightning flash with arrowhead symbol, within an equilateral triangle is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product’s enclosure that may be of sufficient magnitude.
The exclamation point within an equilateral is intended to alert the user to
presence of important operating and maintenance (servicing) instructions in
the informations accompanying the appliance.
CAUTION - RISK OF ELECTRIC SHOCK - DO NOT OPEN
Warning: To reduce the risk of electric shock, do not remove cover (or back) no user
serviceable parts inside. refer servicing to qualified service personnel.
QIG 253500583A Fast 2704R_EN.book Page 6 Mardi, 21. août 2012 8:48 08
7
F@ST 2704R
USA
FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE:
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
QIG 253500583A Fast 2704R_EN.book Page 7 Mardi, 21. août 2012 8:48 08
F@ST 2704R
8
FCC Radiation Exposure Statement
This device complies with FCC radiation exposure limits set forth for an uncontrolled
environment and it also complies with Part 15 of the FCC RF Rules. This transmitter
must not be co-located or operating in conjunction with any other antenna or transmitter.
Operation is subject to the following two conditions:
• this device may not cause harmful interference, and
• this device must accept any interference received, including interference that may cause
undesired operation.
This device produces radio frequency energy in the 2.4 GHz spectrum. The antenna
must be positioned to keep a minimum distance of 20 cm (0.65 ft) from the radiating
element to any nearby person.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user
authority to operate the equipment.
FCC Terminal Equipment Statements
This equipment complies with Part 68 of the FCC rules and the requirements adopted by
the ACTA. On the back of this equipment is a label that contains, among other
information, a product identifier in the format US:AAAEQ##TXXXX. If requested, this
number must be provided to the telephone company.
This equipment has a Universal Service Order Code (USOC) of RJ11C, a Facility
Interface Code (FIC) of METALLIC. The Telephone Company may request this
information when ordering service for this equipment.
QIG 253500583A Fast 2704R_EN.book Page 8 Mardi, 21. août 2012 8:48 08
9
F@ST 2704R
A plug and jack used to connect this equipment to the premises wiring and telephone
network must comply with the applicable FCC Part 68 rules and requirements adopted
by the ACTA. A compliant telephone cord and modular plug is provided with this product.
It is designed to be connected to a compatible modular jack that is also compliant.
The REN is used to determine the number of devices that may be connected to a
telephone line. Excessive RENs on a telephone line may result in the devices not ringing
in response to an incoming call. In most but not all areas, the sum of RENs should not
exceed five (5.0). To be certain of the number of devices that may be connected to a line,
as determined by the total RENs, contact the local telephone company. For products
approved after July 23, 2001, the REN for this product is part of the product identifier that
has the format US:AAAEQ##TXXXX. The digits represented by ## are the REN without
a decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is separately
shown on the label.
If this equipment causes harm to the telephone network, the telephone company will
notify you in advance that temporary discontinuance of service may be required. But if
advance notice isn't practical, the Telephone Company will notify the customer as soon
as possible. Also, you will be advised of your right to file a complaint with the FCC if you
believe it is necessary.
The Telephone Company may make changes to its facilities, equipment, operations or
procedures that could affect the operation of the equipment. If this happens the
Telephone Company will provide advance notice so you can make the necessary
modifications to maintain uninterrupted service.
This equipment is not user serviceable. If trouble is experienced with this equipment, for
repair or warranty information, please contact your Service Provider, or Sagemcom at:
QIG 253500583A Fast 2704R_EN.book Page 9 Mardi, 21. août 2012 8:48 08
F@ST 2704R
10
+1 (972) 674-4100, or Sagemcom USA, 14651 N. Dallas Parkway, Suite 900, Dallas, TX
75254. If the equipment is causing harm to the telephone network, the Telephone
Company may request that you disconnect the equipment until the problem is resolved.
Connection to party line service is subject to state tariffs. Contact the state public utility
commission, public service commission or corporation commission for information.
If your home has specially wired alarm equipment connected to the telephone line,
ensure the installation of this equipment does not disable your alarm equipment. If you
have questions about what will disable alarm equipment, consult your telephone
company or a qualified installer.
This equipment connects to the telephone network that can be vulnerable to electrical
surges as a result of lightning strikes and other events. Such events can be very
destructive to equipment connected to both the telephone network and to AC power
sources. It is strongly recommended that a surge arrestor be used to connect this
equipment to AC power in order to reduce the possibility of damage resulting from such
events.
Canada
IC Warning
CS03:
This product meets the applicable Industry Canada technical specifications.
Le présent matériel est conforme aux spécifications techniques applicables dans
l'Industrie au Canada.
QIG 253500583A Fast 2704R_EN.book Page 10 Mardi, 21. août 2012 8:48 08
11
F@ST 2704R
The Ringer Equivalence Number is an indication of the maximum number of devices
allowed to be connected to a telephone interface. The termination on an interface may
consist of any combination of devices subject only to the requirement that the sum of the
RENs of all the devices does not exceed five.
L’indice d’équivalence de la sonnerie (IES) sert à indiquer le nombre maximal de
terminaux qui peuvent être raccordés à une interface téléphonique. La terminaison d’une
interface peut consister en une combinaison quelconque de dispositifs, à la seule
condition que la somme d’indices d’équivalence de la sonnerie de tous les dispositifs
n’excède pas 5.
RSS(Category I Equipment):
This device complies with Industry Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause
undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication.
Radio apparatus containing digital circuitry which can function separately from the
operation of a transmitter or an associated transmitter, shall comply with ICES-003.
In such cases, the labeling requirements of the applicable RSS apply, rather than the
labeling requirements in ICES-003.
QIG 253500583A Fast 2704R_EN.book Page 11 Mardi, 21. août 2012 8:48 08
12
F@ST 2704R
This Class B digital apparatus complies with Canadian ICES-003.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS
102 and compliance with RSS-102 RF exposure, users can obtain Canadian information
on RF exposure and compliance.
Cet appareil est conforme aux normes d'exemption de licence RSS d'Industry Canada.
Son fonctionnement est soumis aux deux conditions suivantes :
1. cet appareil ne doit pas causer d'interférence et
2. cet appareil doit accepter toute interférence, notamment les interférences qui
peuvent affecter son fonctionnement.
Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé
pour l’émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l’intention des autres utilisateurs, il faut choisir le type d’antenne et son
gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l’intensité nécessaire à l’établissement d’une communication satisfaisante.
Les appareils radio contenant des circuits numériques qui peuvent fonctionner
indépendamment d'un émetteur ou d'un émetteur connexe doivent être conformes aux
exigences de la NMB-003. Ce sont alors les exigences d'étiquetage du CNR pertinent,
plutôt que les exigences d'étiquetage de la NMB-003, qui s'appliquent à ces appareils.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5
de RSS 102 et la conformité à l'exposition de RSS-102 RF, utilisateurs peut obtenir
l'information canadienne sur l'exposition et la conformité de RF.
QIG 253500583A Fast 2704R_EN.book Page 12 Mardi, 21. août 2012 8:48 08
13
F@ST 2704R
Connection
Connecting your router
Make the connections as shown in the diagram below.
Connecting additional telephones
Make the connections as shown in this diagram.
ETH4 PWR
ETH3ETH2ETH1
LINE
PHONE
Filter/Spitter
LINE
MODEM
Line
wall socket
PWR
Phone set
Mains Adapter
with its lead
Mains
wall socket
Line cord
QIG 253500583A Fast 2704R_EN.book Page 13 Mardi, 21. août 2012 8:48 08
F@ST 2704R
14
Router supervision
You can monitor the router’s activity and status using the following sources:
• status of the LEDs on the front and left panels of the router,
• using the router’s built-in "DSL Router" HTTP controller, available in the HTTP configuration
tool, accessible at http://myrouter or http://192.168.1.1.
Status of the LEDs on the front panel
LED Status Meaning
Power
Off Power Off
Green Power On
Red Router in rescue mode
ADSL
Green steady ADSL Up
Green blinking
• ADSL Synchronisation in progress
or
•down
Internet
Off
•Power Off
or
• The Internet account must be configured
or
• Bridge mode
Green steady The Internet account is configured
Green blinking Tx/Rx traffic
Red Invalid or unauthorised Internet account
QIG 253500583A Fast 2704R_EN.book Page 14 Mardi, 21. août 2012 8:48 08
15
F@ST 2704R
WLAN
Off Wi-Fi deactivated
Green steady Wi-Fi activated
Green blinking Wi-Fi Tx/Rx traffic
LAN x
(1 to 4)
Off No link detected on the Ethernet port
Green steady Ethernet port has detected a link with 100 Mbps device
Green blinking Tx/Rx traffic at 100 Mbps
USB
Off No USB connection
Green steady USB connection available
Green blinking USB connection reading in progress
WPS Off No WPS connection
Green blinking WPS connection reading in progress
LED Status Meaning
QIG 253500583A Fast 2704R_EN.book Page 15 Mardi, 21. août 2012 8:48 08
Sagemcom Broadband SAS
Headquarters: 250, route de l’Empereur
92848 Rueil-Malmaison Cedex - FRANCE
Tel : +33 (0)1 57 61 10 00 - Fax : +33 (0)1 57 61 10 01
www.sagemcom.com
All rights reserved. The information and specifications included are subject to change without prior
notice. Sagemcom Broadband SAS tries to ensure that all information in this document is correct, but
does not accept liability for error or omission.
Non contractual document. All trademarks are registered by their respective owners. Simplified joint
stock company - Capital 35 703 000 Euros - 518 250 360 RCS NANTERRE.
253500583-A - 08/12
QIG 253500583A Fast 2704R_EN.book Page 16 Mardi, 21. août 2012 8:48 08
