User Manual 1
Safety and Certifications
007-2864-001 Rev. 1.0 27 October 2010 4
identifier that has the format US:AAAEQ##TXXXX. The digits represented by ## are the REN without a
decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is separately shown on the label.
If this equipment causes harm to the telephone network, the telephone company will notify you in
advance that temporary discontinuance of service may be required. But if advance notice isn't practical,
the Telephone Company will notify the customer as soon as possible. Also, you will be advised of your
right to file a complaint with the FCC if you believe it is necessary.
The Telephone Company may make changes to its facilities, equipment, operations or procedures that
could affect the operation of the equipment. If this happens the Telephone Company will provide
advance notice so you can make the necessary modifications to maintain uninterrupted service.
This equipment is not user serviceable. If trouble is experienced with this equipment, for repair or
warranty information, please contact Sagemcom at:
Via USA Telephone: +1 (972) 674-4100
Or Via Mail:
Sagemcom USA LLC
14651 N. Dallas Parkway
Suite 900
Dallas, TX 75254
If the equipment is causing harm to the telephone network, the Telephone Company may request that
you disconnect the equipment until the problem is resolved.
Connection to party line service is subject to state tariffs. (Contact the state public utility commission,
public service commission or corporation commission for information.)
If your home has specially wired alarm equipment connected to the telephone line, ensure the installation
of this equipment does not disable your alarm equipment. If you have questions about what will disable
alarm equipment, consult your telephone company or a qualified installer.
This equipment connects to the telephone network that can be vulnerable to electrical surges as a result
of lightning strikes and other events. Such events can be very destructive to equipment connected to
both the telephone network and to AC power sources. It is strongly recommended that a surge arrestor
be used to connect this equipment to AC power in order to reduce the possibility of damage resulting from
such events.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
This device produces radio frequency energy in the 2.4 GHz spectrum. The antenna should be
positioned to keep a minimum distance of 20cm from the radiating element to any nearby person.
Issued by Sagemcom Broadband SAS
Sagemcom
250, route de l'Empereur - 92500 RUEIL MALMAISON
© Sagemcom Broadband SAS 2010
All rights reserved. Subject to availability.
Rights of modifications reserved.
www.sagemcom.com
Safety and Certifications
007-2864-001 Rev. 1.0 27 October 2010 1
Important Information about the Sagemcom F@ST 2864:
Installation and Safe Usage Instructions:
1. Place the VDSL router in a vertical orientation on a flat surface.
2. Connect the manufacturer supplied AC to DC power adapter. The F@ST 2864 router requires the use
of a 12 VDC, 2500 mA power adapter. Only use a manufacturer supplied and approved power
adapter.
3. Connect the F@ST 2864 to the AC Mains in accordance with the installation instructions in this
booklet, and the markings on the identification label (voltage, current, and frequency of electricity
network).
4. Connect the Ethernet cable (provided) to one of the RJ45 ports on the VDSL Router labeled "LAN1",
"LAN2", "LAN3", or "LAN4". Then connect the other end of the Ethernet Cable to the Ethernet port of a
computer. Repeat as necessary for the other available Ethernet ports.
5. For an Ethernet WAN configuration, connect the RJ45 port labeled “WAN ETH” to the connection
provided by your ISP.
6.
For a VDSL configuration, connect the provided DSL Cable to the port on the VDSL Router labeled
"DSL". Connect the other end of the DSL Cable to a standard Phone Jack. CAUTION:
To reduce
the risk of fire, always and only use a UL Listed or CSA Certified Telecommunication Line
Cord (DSL cable) with a minimum wire gauge of 26AWG (0.4 mm dia. minimum, or 0.129
mm² minimum) or larger (e.g., 24AWG).
When using this device, basic safety precautions should always be followed to reduce the risk of
fire, electric shock, and injury to persons including the following:
1. Do not use this product near water and avoid contact with moisture. For example, do not use near a
bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool. Care
should be taken so that liquids are not spilled on this equipment.
2. This equipment is for indoor use only, do not place or install in an outdoor location.
3. Never insert objects into the vents of this equipment as this can result in the risk of electrical shock or
fire.
4. This equipment should only be operated from the type of power supply (Voltage and Current)
indicated on the marking label.
5. Do not overload wall outlets or extension cords. Doing so can result in the risk of fire or electrical
shock.
6. Avoid blocking any vent openings or exhaust exits on this equipment. Do not place equipment in a
built-in installation such as a cabinet that may impede the flow of air through the ventilation openings.
7. The equipment should be situated away from heat sources such as radiators, heat registers, stoves,
or other heat producing appliances and equipment.
8. Care should be taken to ensure that the power cord is routed, so it is not likely to be walked on or
pinched by items placed upon or next to it.
9. Unplug this equipment before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning only.
10. This equipment is not user serviceable and is to be serviced by qualified personnel only. Do not
disassemble this equipment. If service is required, disconnect all power and phones lines from the
equipment and consult qualified service personnel.
11. To disconnect this equipment from AC power, unplug the power supply from the AC wall socket.
12. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a
remote risk of electric shock from lightning.
13. Do not use the telephone to report a gas leak in the vicinity of the leak.
14. Connect only to in house equipment (SELV interface). It is not allowed to connect the coax port to
public cable distribution or cable television network.
Save these Instructions!
Safety and Certifications
007-2864-001 Rev. 1.0 27 October 2010 2
Industry Canada Statements
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This product meets the applicable Industry Canada technical specifications/Le présent materiel est
conforme aux specifications techniques applicables d’Industrie Canada.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities
of the local Telecommunications Company. The equipment must also be installed using an acceptable
method of connection. The customer should be aware that compliance with the above conditions may not
prevent degradation of service in some situations. Repairs to certified equipment should be coordinated
by a representative designated by the supplier. Any repairs or alterations made by the user to this
equipment, or equipment malfunctions, may give the telecommunications company cause to request the
user to disconnect the equipment. Users should ensure for their own protection that the electrical ground
connections of the power utility, telephone lines, and internal metallic water pipe system, if present, are
connected together. This precaution may be particularly important in rural areas. Caution: Users should
not attempt to make such connections themselves, but should contact the appropriate electric inspection
authority, or electrician, as appropriate.
The Ringer Equivalence Number is an indication of the maximum number of devices allowed to be
connected to a telephone interface. The termination on an interface may consist of any combination of
devices subject only to the requirement that the sum of the RENs of all the devices does not exceed five.
The REN of this device is 0.1B.
L’indice d’équivalence de la sonnerie (IES) sert à indiquer le nombre maximal de terminaux qui peuvent
être raccordés à une interface téléphonique. La terminaison d’une interface peut consister en une
combinaison quelconque de dispositifs, à la seule condition que la somme d’indices d’équivalence de la
sonnerie de tous les dispositifs n’excède pas 5.
Le REN de ce dispositif est 0.1B.
The Sagemcom F@ST 2864 complies with Canadian RSS-210.
NOTICE: To prevent radio interference to the licensed service, this device must be operated indoors only
and should be kept away from windows to provide maximum shielding. Equipment (or its transmit
antenna) that is installed outdoors is subject to licensing by Industry Canada. Modification of antenna
gain or transmit power may require a radio license from Industry Canada.
Safety and Certifications
007-2864-001 Rev. 1.0 27 October 2010 3
Federal Communications Commission (FCC) Statements
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Modifications:
You are cautioned that changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
FCC Responsible Party: Sagemcom USA
14651 N. Dallas Parkway
Suite 900
Dallas, TX 75254
Phone: 972-674-4100
Radio Frequency Interference Statement
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
FCC Terminal Equipment Statements
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On
the bottom side of this equipment is a label that contains, among other information, a product identifier in
the format US:NS3DL01BFAST2864. If requested, this number must be provided to the Telephone
Company. A copy of the TCB Certificate or Suppliers Declaration of Conformity to the FCC Part 68 and
ACTA requirements can be found at:
http://www.part68.org
This equipment has a Universal Service Order Code (USOC) of RJ11C, a Facility Interface Code (FIC) of
METALLIC, and the Service Order Code (SOC) is N/A. The Telephone Company may request this
information when ordering service for this equipment.
A plug and jack used to connect this equipment to the premises wiring and telephone network must
comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant
telephone cord and modular plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant.
The REN is used to determine the number of devices that may be connected to a telephone line.
Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call.
In most but not all areas, the sum of RENs should not exceed five (5.0). To be certain of the number of
devices that may be connected to a line, as determined by the total RENs,
contact the local telephone
company. For products approved after July 23, 2001, the REN for this product is part of the product
This device complies with RSS-210 of the Industry CanadaRules.
Operation is subject to the following twoconditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with Canada/FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
