SAGEMCOM BROANDS FAST3965CV F@st 3965CV Managed Home Router User Manual F st 3965CV Safety sheet ed3 0
SAGEMCOM SAS F@st 3965CV Managed Home Router F st 3965CV Safety sheet ed3 0
User Guide
Safety and Certifications
253509429-B 07 August 2012 1
Important Information about the Sagemcom F@st 3965CV:
Installation and Safe Usage Instructions:
1. Place the gateway in a vertical orientation on a flat surface.
2. Connect the manufacturer supplied AC to DC power adapter. The F@st 3965CV series gateways
require the use of a 12 VDC, 2 A power adapter. Only use a manufacturer supplied and approved
power adapter and Ethernet cable.
3. Connect the F@st 3965CV to the AC Mains in accordance with the installation instructions in this
booklet, and the markings on the identification label (voltage, current, and frequency of electricity
network).
4. Connect the Ethernet cable (provided) to the RJ45 port on the Gateway labeled "1". Then connect the
other end of the Ethernet Cable to the Ethernet port of a computer. Repeat as necessary for the
available Ethernet ports and computers.
5. Connect the Ethernet cable that was provided with the cable modem to the RJ45 port on the Gateway
labeled “WAN”. Then connect the other end of the Ethernet cable to the Ethernet port on the cable
modem.
When using this device, basic safety precautions should always be followed to reduce the risk of
fire, electric shock, and injury to persons including the following:
1. Do not use this product near water and avoid contact with moisture. For example, do not use near a
bathtub, wash bowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool. Care
should be taken so that liquids are not spilled on this equipment.
2. This equipment is for indoor use only, do not place or install in an outdoor location.
3. Place your product on a firm, solid surface, no obstacle at a minimum distance of 20cm (0.65ft). If you
put it on something unsteady, it may fall and be damaged. If you place it on a soft surface, such as rug,
sofa or cushion, the vents may be blocked, causing the product to overheat.
4. Never insert objects into the vents of this equipment as this can result in the risk of electrical shock or
fire.
5. As the power adapter is the only way to connect to the electrical network, the product must be installed
near an easily accessed power outlet.
6. This equipment should only be operated from the type of power supply (Voltage and Current) indicated
on the marking label.
7. Do not overload wall outlets or extension cords. Doing so can result in the risk of fire or electrical
shock.
8. Avoid blocking any vent openings or exhaust exits on this equipment. Do not place equipment in a
built-in installation such as a cabinet that may impede the flow of air through the ventilation openings.
9. The equipment should be situated away from heat sources such as radiators, heat registers, stoves, or
other heat producing appliances and equipment.
10. Care should be taken to ensure that the power cord is routed, so it is not likely to be walked on or
pinched by items placed upon or next to it.
11. Unplug this equipment before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning only.
12. This equipment is not user serviceable and is to be serviced by qualified personnel only. Do not
disassemble this equipment. If service is required, disconnect all power from the equipment and
consult qualified service personnel.
13. To disconnect this equipment from AC power, unplug the power supply from the AC wall socket.
14. Connect only to in house equipment (SELV interface). It is not allowed to connect to public cable
distribution or cable television network.
15. Use the product in the environment specified as below:
- Air temperature between 0°C and +40°C.
- Relative humidity between 20% and 90%.
- Altitude: 2000 meters (6562ft) maximum.
Save these Instructions!
Safety and Certifications
253509429-B 07 August 2012 2
Federal Communications Commission (FCC) Statements
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Modifications:
You are cautioned that changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
FCC Responsible Party: Sagemcom USA
14651 N. Dallas Parkway
Suite 900
Dallas, TX 75254
Phone: 972-674-4100
Radio Frequency Interference Statement
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
This device produces radio frequency energy in the 2.4GHz and 5GHz spectrums. The antenna must be
positioned to keep a minimum distance of 20cm (0.65ft) from the radiating element to any nearby person.
Issued by Sagemcom Broadband SAS
Sagemcom
250, route de l'Empereur - 92500 RUEIL MALMAISON
FRANCE
© Sagemcom Broadband SAS 2012
All rights reserved. Subject to availability.
Rights of modifications reserved.
www.sagemcom.com
Safety and Certifications
253509429-B 07 August 2012 3
Wall Mounting Router (Optional)
While many users place their F@st 3965CV series gateways on their desk, it can be optionally wall
mounted.
1. The unit is wall mounted with the top of the unit facing up.
2. Ensure that the wall you use is smooth, flat, dry, and sturdy.
3. The unit is mounted using two M3x20 screws (20mm length and 3mm in diameter).
4. Install the two screws 135 mm (5.3 inches) apart approximately 20 mm (0.8 inches) below the desired
top of the unit per the following figure.
5. Screw the screws into the wall leaving their heads extending approximately 3.5 to 4.0 mm (0.15 inch)
from the wall surface.
6. Carefully align the screw heads in the keyholes on the back of the unit and gently push it
onto the wall moving it downward to secure it in the narrow portion of the keyhole slots.
135
mm
(5.3 inches)
20
mm
(
0.8
inches)
