User Manual
Setup
1.
2.
Front
Back
Motion Sensor QSG
Troubleshooting
1.
2.
3.
Connect button
Placement
Revised 05/18. Copyright 2018.
SmartThings, Inc. All rights reserved.
Make sure the Motion Sensor is
within 15 feet (4.5 meters) of your
SmartThings Hub or SmartThings
Wifi (or compatible device with
SmartThings Hub functionality)
during setup.
Use the SmartThings mobile app to
select the “Add device” card and
then select the “Motion sensor”
category.
Remove the tab on the Motion
Sensor marked “Remove When
Connecting” and follow the
on-screen instructions in the
SmartThings app to complete setup.
The Motion Sensor can detect motion up
to 15 feet (4.5 meters) away with a 100
degree field of view.
Simply place the Motion Sensor facing
the area that you’d like to monitor and
make sure there are no objects
blocking its view.
The Motion Sensor can also monitor
temperature.
Hold the “Connect” button with a
paperclip or similar tool for 5
seconds, and release it when the
LED starts blinking red.
Use the SmartThings mobile app to
select “Add device” card and then
follow the on-screen instructions to
complete setup.
If you’re still having trouble connecting
the Motion Sensor, please visit
Support.SmartThings.com for assistance.
