SAM JIN STS-MLT-250 Multipurpose Sensor User Manual SJ QSGMultipurpose US 1 0
SAM JIN CO., LTD Multipurpose Sensor SJ QSGMultipurpose US 1 0
SAM JIN >
User Manual
Meet your
Multipurpose Sensor
The most versatile device in the Samsung SmartThings™
family, the Multipurpose Sensor acts as an open/closed,
vibration, orientation, and temperature sensor all in one.
Multipurpose Sensor components
Multipurpose Sensor Magnet
Magnet Alignment Mark
Wall Plate
Magnet
Wall
Plate
MAX 0.4in
10mm
Template for wall mounting:
Multipurpose Sensor
Installation Tips
The Multipurpose Sensor works best if it’s within 15 feet
(4.5 meters) of the SmartThings Hub when you connect it.
If your device doesn’t connect:
If your device doesn’t connect after removing the "Remove
to Pair" tab, hold the “Connect” button while inserting the
battery. Release the button when the LED is lit. The LED will
blink blue while attempting to connect. Then select
“Connect New Device” in the SmartThings app.
How to connect a Multipurpose Sensor
Select “Connect New Device” in the free SmartThings
mobile app and then remove the “Remove to Pair” tab found
in the Multipurpose Sensor.
REMOVE
TO PAIR
Connect Button
LED Light
Use your Multipurpose Sensor to know if doors
are open or closed:
The SmartThings Multi Sensor can monitor whether doors,
windows, cabinets or your garage are open, closed or have
been left open after you leave home. To start, mount one
part of your Multipurpose Sensor on a doorframe, window
frame, or the fixed part of a cabinet or drawer, and place the
other part next to it on the door, window, or part that opens.
Use your Multipurpose Sensor to monitor
temperature:
The Multipurpose Sensor can detect the temperature in the
room where it's located. By placing the Multipurpose Sensor
on a door, window, or cabinet, you can monitor the
temperature and receive alerts if the room gets too hot
or cold.
Multipurpose Sensor
Door or Window
Magnet
Quick-Start
Guide
USE CARE when
replacing the battery
to avoid damaging
the device.
Cover
CR2450
Bottom
Replacing the battery
To replace the battery in your Multipurpose Sensor, use a
flat tool to carefully remove the battery from the device. Then
add a new battery and close the cover back into place.
CR2450
Wichtige Sicherheitshinweise
• Lesen, behalten und folgen Sie diesen Anweisungen
• Beachten Sie alle Warnhinweise
• Verwenden Sie das Produkt nicht in der Nähe von Wasser und
vermeiden Sie Tropfen oder Spritzer von Flüssigkeiten jeder Art
• Säubern Sie das Gerät ausschliesslich mit einem trockenen Tuch
• Vermeiden Sie die Installation in der Nähe von Wärmequellen wie
Heizungen, Öfen oder anderen Geräten (inkl. Verstärkern), die Hitze
produzieren
• Verwenden Sie nur Hersteller zertifiziertes Zubehör
Règles de sécurité:
• Lire, conserver et suivre ces instructions
• Respecter toutes les consignes de sécurité
• Nettoyer l'appareil uniquement avec un chiffon sec
• Ne pas utiliser à proximité et éviter tout contact avec l’eau ou un
quelconque liquide
• Ne pas installer a proximité d une source de chaleur telle que
radiateur, poêle ou autres appareils (incluant les amplificateurs) qui
produisent de la chaleur
• Utiliser uniquement des accessoires recommandées par le fabricant
Certifications
Hereby, SmartThings Inc. declares that this product is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
The original Declaration of Conformity may be found at
smartthings.com/eu/compliance.
Certified under FCC Part 15.
Certified in Canada by IC to RSS-247.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
This device should not be installed or operated within 20cm (8 inches) of
persons or other radio emitting devices.
Multipurpose Sensor FCC ID : 2AF4S-STS-MLT-250, IC : 20753-STSMLT250.
FCC Statement
Operation of this device is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the
device.
Tested to Comply With FCC Standards
FOR HOME OR OFFICE USE
Canada Statement
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Le present appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est aurorisee aux deux
conditions suivantes: (1) l’appareil ne doit pas pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter toute brouillage radioelectrique
subi, meme si le brouillage est susceptible d’en compromettre le
fonctionnement.
Information to the User
Changes or modifications not expressly approved by the manufacturer could
void your authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Correct disposal of batteries in this product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates
that the product and its electronic accessories (e.g. charger,
headset, USB cable) should not be disposed of with other household
waste.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from other types
of waste and recycle them responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer where they purchased
this product, or their local government office, for details of where and how
they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
(Applicable in countries with separate collection systems)
This marking on the battery, manual or packaging indicates that the
batteries in this product should not be disposed of with other household
waste. Where marked, the chemical symbols Hg, Cd or Pb indicate that the
battery contains mercury, cadmium or lead above the reference levels in EC
Directive 2006/66. If batteries are not properly disposed of, these
substances can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please separate
batteries from other types of waste and recycle them through your local,
free battery return system.
Disclaimer
Some content and services accessible through this device belong to third
parties and are protected by copyright, patent, trademark and/or other
intellectual property laws. Such content and services are provided solely for
your personal non-commercial use. You may not use any content or services
in a manner that has not been authorised by the content owner or service
provider.
Without limiting the foregoing, unless expressly authorised by the applicable
content owner or service provider, you may not modify, copy, republish,
upload, post, transmit, translate, sell, create derivative works, exploit, or
distribute in any manner or medium any content or services displayed
through this device.
One (1) Year Limited Warranty
SmartThings, Inc. warrants this product (the “Product”) against defects in
materials and/or workmanship under normal use for a period of ONE (1)
YEAR from the date of purchase by the original purchaser (“Warranty
Period”). If a defect arises and a valid claim is received within the Warranty
Period, then as your sole remedy (and SmartThings’ sole liability),
SmartThings will at its option either 1) repair the defect at no charge, using
new or refurbished replacement parts, or 2) replace the Product with a new
product that is functionally equivalent to the original, in each case within 30
days following receipt of the returned Product. A replacement product or
part, assumes the remaining warranty of the original Product. When a
Product or part is exchanged, any replacement item becomes your property
and the replaced Product or part becomes SmartThings’ property.
Obtaining Service: To obtain warranty service, visit
support.smartthings.com to speak with a service agent or open a service
request. Please be prepared to describe the Product that needs service and
the nature of the problem. A purchase receipt is required. The Product must
be insured, and shipped freight prepaid and securely packaged. You must
contact support for a Return Material Authorization Number (“RMA
Number”) before shipping any Product, and include the RMA Number, a
copy of your purchase receipt and a description of the problem you are
experiencing with the Product. Any claim under this Limited Warranty must
be submitted to SmartThings before the end of the Warranty Period.
Exclusions: This warranty does not apply to: a) damage caused by failure to
follow instructions relating to the Product’s use or the installation of
components; b) damage caused by accident, abuse, misuse, transport,
neglect, fire, floods, earthquake or other external causes; c) damage
caused by service performed by anyone who is not an authorized
representative of SmartThings; d) accessories used in conjunction with a
covered Product; e) a Product or part that has been modified to alter
functionality or capability; f) items intended to be periodically replaced by
the purchaser during the normal life of the Product, including, without
limitation, batteries, bulbs or cables; g) a Product that is used commercially
or for a commercial purpose, in each case as determined by SmartThings.
EXCEPT FOR BODILY INJURY, SMARTTHINGS SHALL NOT BE LIABLE
FOR (I) ANY LOST PROFITS, COST OF PROCUREMENT OF SUBSTITUTE
PRODUCTS, OR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR
(II) ANY AMOUNTS IN EXCESS OF THE PURCHASE PRICE FOR THE
PRODUCT, IN EACH CASE WHETHER RESULTING FROM THE USE OF OR
INABILITY TO USE THIS PRODUCT, OR ARISING OUT OF ANY BREACH
OF THIS WARRANTY, EVEN IF COMPANY HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. SOME STATES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION AND EXCLUSIONS MAY NOT
APPLY TO YOU.
TO THE EXTENT PERMITTED BY APPLICABLE LAW, SMARTTHINGS
DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED WARRANTIES,
INCLUDING WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND WARRANTIES AGAINST
HIDDEN OR LATENT DEFECTS. IF SMARTTHINGS CANNOT LAWFULLY
DISCLAIM STATUTORY OR IMPLIED WARRANTIES, THEN TO THE EXTENT
PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL BE LIMITED IN
DURATION TO THE WARRANTY PERIOD. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
This warranty gives you specific legal rights and you may also have other
rights, which vary from state to state. To exercise your rights under this
warranty, please follow the instructions above under the heading “Obtaining
Service”, or contact SmartThings at SmartThings, Inc., 456 University Ave.
Suite 200, Palo Alto, CA 94301, USA.
Samsung is a registered trademark of Samsung Electronics Co., Ltd.
This ZigBee Certified Product works with ZigBee networks supporting the
Home Automation Profile.
Global 2.4 GHz wireless use.
ZigBee® Certified is a registered trademark of the ZigBee Alliance.
Safety Instructions
WARNING: No user-serviceable parts inside. Refer all servicing to
qualified service personnel.
IMPORTANT CONSUMER INFORMATION: Please read before
activating or using the Arrival Sensor.
WARNING: This product contains chemicals known to the State of California to
cause cancer and reproductive toxicity. For more information, please call
1-800-SAMSUNG (726-7864).
• Read, keep and follow
these instructions
• Heed all warnings
• Do not use this product near
water or expose the product to
dripping or splashing of any
water or liquid.
• Clean only with a dry cloth
• Do not install near any heat
sources such as radiators, heat
registers, stoves or other
apparatus (including amplifiers)
that produce heat
• Only use attachments and
accessories specified by the
manufacturer
• Read our Product Usage
Guidelines at:
http://SmartThings.com/guidelines
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. VORSICHT.
EXPLOSIONSGEFAHR WENN BATTERIEN EINES FALSCHEN TYPS VERWENDET
WERDEN. ENTSORGEN SIE BATTERIEN ENTSPRECHEND DER ANWEISUNGEN.
ATTENTION. RISQUE D'EXPLOSION SI LA BATTERIE EST REMPLACÉE PAR UN
MODÈLE INCORRECT. JETEZ LES BATTERIES USAGÉES SELON LES INSTRUCTIONS
S’Y RÉFÉRANT.
