User Manual
Page 1 of 5
Model NAME : 2.4G Wireless Mouse
MODEL NO. : MA-ERGW10
VERSION : 0.1
DATE : 2017.5.5
USER MANUAL
GMAERGW10
Page 2 of 5
Version.
#
Revised Date PIC Remark
0.1 5/5/2017 Bob Preliminary
Page 3 of 5
Electrical Specification
1. Operating Voltage
Mouse supply voltage: 3V (2AAA battery)
2. Current Consumption
Current use :< 10mA
3. Sleep Mode
3.1 Electrical Current: ＜1mA;
3.2 Wake Up: Press any button
5. Mouse Pointer Performance
5.1 Resolution：800/1200 (default) /1600DPI
5.2 Speed： 25inches/sec （Max）
5.3 Acceleration：8G
6. LED Indicating Functions
When the battery power is low (battery voltage reduce to <2.2V) the LED will
glisten at the frequency of 1Hz
Page 4 of 5
7. Wireless specifications
2.408-2.474GHz frequency coverage.
GFSK RF transceiver
High Speed RF link data rate Max. 1M bit/s
Button Functions
1. Left Button: Mouse left button standard function
2. Right Button: Mouse right button standard function
3. Middle Button: Mouse middle button standard function
4. Wheel: Mouse scroll wheel standard function
5. 4 Button: IE Forward function
6. 5 Button: IE Back function
7. DPI Button: DPI regulate function
Page 5 of 5
Operation Process
Step 1
Open the battery cover which in the back of the Mouse.
Insert 2AAA battery which is environment-friendly and safety
Close the battery cover.
Step 2
Place the mouse on a desk or other plane surface. The surface material isn’t metal is better
for wireless distance.
Step 3
Insert a Transceiver in a USB port of PC. The Transceiver is pairing with the mouse.
Step 4
Use the mouse freely.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
