SECURITY DOOR CONTROLS
Price & Installation
The 290 Micro Cabinet Lock is designed to electronically
secure cabinets and drawers. The need for keys is eliminated
and the addition of a keypad or remote control of your choice
provides true access control and convenience of use.
• Pharmaceutical cabinets and drawers
• Retail display cases and drawers
• Gun cabinets
• File cabinets
• Utility cabinets and drawers
• Museum display cases
• For swinging or sliding doors
• Failsecure continuous duty
• Field reversible solenoid for failsafe operation
• Dual 12/24VDC
• Nonhanded
• 600lbs of holding force
290 Micro cabinet lock
290LS Micro cabinet lock with lock status switch
Dual Voltage 250-130mA @ 12/24VDC
Dimensions 3-1/4"L x 1-1/8"W x 1-1/8D"
(82.5 x 28.5 x 28.5mm)
Applications
Features
Models
Specifications
Side entry Side entry Slide entry
Front entry
Strike can enter lock from any
of 3 sides and also sliding
from the side
Drawer Sliding Door Swinging Door
290 Micro Cabinet Lock
SECURITY DOOR CONTROLS
www.sdcsecurity.com service@sdcsecurity.com
[t] 800.413.8783 805.494.0622 [f] 805.494.8861
801 Avenida Acaso, Camarillo CA 93012 • PO Box 3670, Camarillo CA 93011-3670
SECURITY DOOR CONTROLS
sdcsecurity.com service@sdcsecurity.com
© 2012 Security Door Controls LIT-290CabinetLock 09/12
For Cabinets, Electrical Cases, Display Cases and Drawers (Sliding or Swinging)
Keypad or Card Reader (Lock/Unlock All)
290 Micro Cabinet Lock Failsecure
(Reversible for Failsafe)
XX
X
X
X
X
Display Cases
Metal/Electrical Enclosure
Cabinets & Drawers
End View Sliding Swinging
Keypad or
Card Reader
(Lock/Unlock All)
Display Cases
