SDI Technologies HBH34 Bluetooth stereo audio system with Bluetooth 4.0 User Manual HBH34 QSG 121316ai ai
SDI Technologies Inc. Bluetooth stereo audio system with Bluetooth 4.0 HBH34 QSG 121316ai ai
User Manual
HBH34
Staff Quick Start Guide
Included
• HBH34 system
• Security tether
Set Up
Setting the Time Zone and Clock
(Factory Preset Clock)
Connect AC plug
to a working outlet
that is not controlled
by an On/Off switch.
Press Time Zone Button again to confirm.
Set the Volume Limiter Switch on the
back of the unit (Off for large rooms,
On for smaller rooms).
Security tether
2 SECS
HBH34 Quick Start Guide - Front
Size: 432 x 140 mm
Printing Color: Black
Mat’l: 100 gsm WF paper
Nov 11, 2016
Daylight Saving Time
The unit ships with the Daylight Saving Time (DST)
switch in Auto position, and will automatically adjust
when the time changes in March and November. If
Daylight Saving Time is NOT observed in your loca-
tion, move the DST switch from AUTO to -1 or +1
BEFORE setting time.
Bluetooth Pairing
1. Press and hold the Bluetooth Button. Unit will enter
pairing mode.
2. Select “HBH34” on your device’s Bluetooth menu.
outlet
1
2
3
4
o on
volume limit
+1 -1 auto
dst
time zone
Remove thumbscrew
and remove back cover
to access staff controls.
The first time you connect your new preset clock to
the AC outlet, the unit will automatically show the
correct Eastern Standard time, which is the default
setting. If you are not in the Eastern time zone, you
must change the default setting to match your time
zone (see Time Zone Setting below). Once the
correct time zone is set, if the time displayed is not
correct, follow steps under Manual Clock Setting to
set the correct time, year and date.
Time Zone Setting
Make sure unit is in Power OFF mode.
Press and hold the Time Zone Button on the
back of the unit for 2 seconds. The time zone
will flash.
Press the – or + Button to cycle to local time zone.
Secure the attached Security Tether to a wall
or other permanent surface.
CAUTION: DO NOT attach to an AC outlet or
cause it to become entangled with anything
that can create a hazardous situation.
FCC ID: EMOHBH34
IC: 986B-HBH34
Remove pull tab from Backup Battery Compartment
located on bottom of theunit.
When Low Battery Icon appears on display,
replace backup batteries with 2 fresh AA
batteries. Make sure polarity (+/–) markings match
illustration.
Manual Clock Setting
Press the Time Set Button to confirm the time. The year
will flash.
Press the Time Set Button to confirm the year.
The date will flash.
Press the Time Set Button to confirm the date
and exit clock setting.
Press the - or + button to set the time.
Press the - or + button to set the year.
Press the - or + button to set the date. Hold for
rapid adjustment.
Backup Batteries Reset Button
Press and hold the Time Set Button
for 2 seconds to enter clock setting mode.
2 SECS
HBH34 Quick Start Guide - Inside
Size: 432 x 140 mm
Printing Color: Black
Mat’l: 100 gsm WF paper
HBH34QSG-103116-A © 2016 HTI Industries, LLC. All rights reserved Printed in China
reset
The courtesy plug on top of the unit is rated for 15
amps. If a guest connects a device that overloads the
outlet, the built in circuit breaker will prevent damage
to the unit. The Reset Button on the back of the unit
will pop out to indicate the outlet was overloaded.
Press and release the Reset Button to reset the circuit
breaker and restore the courtesy plug to operation.
time set
time set
time set
time set
Keep unit connected to AC power when
replacing batteries or you will lose settings.
Once staff has completed setup, replace security
cover on back of unit and tighten thumbscrew.
√
Maintenance
• Place the unit on a level surface away from sources of direct
sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural
wood and lacquered finish. A cloth or other protective
material should be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild
soap and water. Stronger cleaning agents, such as thinner or
similar materials can damage the surface of the unit.
IMPORTANT SAFETY INSTRUCTIONS
When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety.
However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating
instructions carefully before installation and use, and keep these instructions handy for future reference. Take special
note of all warnings listed in these instructions and on the unit.
1. Water and Moisture – The unit should not be used near water. For example: near a bathtub, washbowl, kitchen sink,
laundry tub, swimming pool or in a wet basement.
2. Ventilation – The unit should be situated so that its location or position does not interfere with its proper ventilation.
For example, it should not be situated on a bed, sofa, rug or similar surface that may block ventilation openings. Also,
it should not be placed in a built-in installation, such as a bookcase or cabinet, which may impede the flow of air
through the ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators, heat registers, stoves or other appliances
(including amplifiers) that produce heat.
4. Power Sources – The unit should be connected to a power supply only of the type described in the operating instructions
or as marked on the appliance.
5. Power-Cable Protection – Power supply cables should be routed so that they are not likely to be walked on or pinched
by items placed upon or against them. It is always best to have a clear area from where the cable exits the unit to
where it is plugged into an AC socket.
6. Cleaning – The unit should be cleaned only as recommended. See the Maintenance section of this manual for
cleaning instructions.
7. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled into any
openings or vents located on the product.
8. Attachments – Do not use attachments not recommended by the product manufacturer.
9. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect the antenna or cable
system during a lightning storm or when it is left unattended and unused for long periods of time. This will prevent
damage to the product due to lightning and power-line surges.
10. Overloading – Do not overload wall sockets, extension cords, or integral convenience receptacles as this can result
in a risk of fire or electric shock.
11. Damage Requiring Service – The unit should be serviced by qualified service personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
12. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as a month or longer, the
power cable should be unplugged from the unit to prevent damage or corrosion.
13. Servicing – The user should not attempt to service the unit beyond those methods described in the user’s operating
instructions. Service methods not covered in the operating instructions should be referred to qualified service
personnel.
Hotel Technologies, a division of HTI Industries LLC, (hereafter referred to as Hotel Technologies), warrants
this product to be free from defects in workmanship and materials, under normal use and conditions, for a
period of 30 days from the date of receipt of the item.
Should service be required by reason of any defect or malfunction during the warranty period, Hotel
Technologies will repair or, at its discretion, replace this product without charge. This decision is subject to
verification of the defect or malfunction upon delivery of this product to the Factory Service Center listed below.
Before returning this product for service, please first replace the batteries (if applicable) with fresh ones, as
exhausted or defective batteries are the most common cause of problems encountered.
If service is still required:
1. Fax a representative at 915.633.1388 with a Return Authorization request including proof of purchase date
(i.e., invoice number and date from distributor or HTI) to receive a Return Authorization Number. Issuance of
Return Authorization Number is subject to review prior to granting.
NO ITEM CAN BE ACCEPTED WITHOUT A RETURN AUTHORIZATION NUMBER.
2. Remove batteries (if applicable) and pack the unit in a well-padded, heavy corrugated box.
3. Send the unit by method agreed to with your representative to the Factory Service Center listed below:
Consumer Repair Department
Hotel Technologies Inc.
1330 Goodyear Drive
El Paso TX 79936-6420
NOTE: Improperly packed items or Items received without an RA # cannot receive credit.
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not
cover (i) products which have been damaged by negligence, misuse or accident, or which have been modified
or repaired by unauthorized persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii)
damage to tape cassettes (if applicable); (iv) the cost of shipping this product to the Factory Service Center
and its return to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the product
subsequent to the original purchaser. Any applicable implied warranties are also limited to 30 days, and Hotel
Technologies will not be liable for consequential damages. (Some states do not allow limitations on implied
warranties or exclusion of consequential damages, so these restrictions may not apply to you.) This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state.
LIMITED 30 DAY WARRANTY
(valid in contiguous U.S.A. only: not valid in Hawaii or Alaska)
please contact the appropriate distributor for their warranty terms
FCC Information
This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
• Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
Questions? visit www.hoteltech.com or call 1-888-744-6835 Toll Free
IC Statement for RF Device
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF
exposure, users can obtain Canadian information on RF exposure and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la conformité à l'exposition
de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et la conformité de rf.
HBN21-150425-A © 2015 HTI Industries, LLC. All rights reserved Printed in China
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Generic Legal Sheet for all Hotel model items - Front
Size: 108 x 140 mm
Color: 1C + 1C (Black)
Material: 100 gsm WF paper
Aug. 04, 2015
Generic Legal Sheet for all Hotel model items - Back
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
