User manual

HBH88
Sta Quick Start Guide
Included
HBH88 system
Security tether
Set Up
Setting the Time Zone and Clock
(Factory Preset Clock)
Connect AC plug
to a working outlet
that is not controlled
by an On/O switch.
Press Time Zone Button again to confirm.
Set the Volume Limiter Switch on the
bottom of the unit (High for large rooms,
Low for smaller rooms).
When Low Battery Icon appears on display,
replace backup batteries with 2 fresh AA batteries.
Make sure polarity (+/–) markings match
illustration.
Security tether
Manual Clock Setting
Press the Time Set Button to confirm the time. The year
will flash.
Press the Time Set Button to confirm the year.
The date will flash.
Press the Time Set Button to confirm the date
and exit clock setting.
Press the or button to set the time. Make sure to set
the correct AM/PM hour (indicator to left of time).
Press the or button to set the year.
Press the or button to set the date. Hold for
rapid adjustment.
Backup Batteries Reset Button
Press and hold the Time Set Buttonfor 2 seconds to
enter clock setting mode.
2 SECS
2 SECS
HBH88 Quick Start Guide - Front
Size: 540 x 140 mm
Printing Color: Black
Mat’l: 100 gsm WF paper
Dec 19, 2017
HBH88 Quick Start Guide - Inside
Size: 540 x 140 mm
Printing Color: Black
Mat’l: 100 gsm WF paper
HBH88QSG-103116-A © 2017 HTI Industries, LLC. All rights reserved Printed in China
Daylight Saving Time
The unit ships with the Daylight Saving Time (DST)
switch in Auto position, and will automatically adjust
when the time changes in March and November. If
Daylight Saving Time is NOT observed in your loca-
tion, move the DST switch from AUTO to -1 or +1
BEFORE setting time.
Bluetooth Pairing
1. Press and hold the Bluetooth Button. Unit will enter
pairing mode.
2. Select “HBH88” on your device’s Bluetooth menu.
outlet
2
1
3
hi lo
volume limit
-1 +1 auto
dst
time zone
The total ouput current of both courtesy plugs (one
on each side of the unit) is 10 amps 1250 watts. If a
guest connects a device that overloads the outlet(s),
the built in circuit breaker will prevent damage to the
unit. The Reset Button on the back of the unit will pop
out to indicate the outlet was overloaded.
Press and release the Reset Button to reset the circuit
breaker and restore the courtesy plug to operation.
reset
time set
time set
time set
time set
Keep unit connected to AC power when
replacing batteries or you will lose settings.
The first time you connect your new preset clock to
the AC outlet, the unit will automatically show the
correct Eastern Standard time, which is the default
setting. If you are not in the Eastern time zone, you
must change the default setting to match your time
zone (see Time Zone Setting below). Once the
correct time zone is set, if the time displayed is not
correct, follow steps under Manual Clock Setting to
set the correct time, year and date.
Time Zone Setting
Make sure unit is in Power OFF mode.
Press and hold the Time Zone Button on the
back of the unit for 2 seconds. The time zone
will flash.
Press the or button to cycle to local time zone.
Secure the attached Security Tether to a wall
or other permanent surface.
CAUTION: DO NOT attach to an AC outlet or
cause it to become entangled with anything
that can create a hazardous situation.
Maintenance
Place the unit on a level surface away from sources of direct
sunlight or excessive heat.
Protect your furniture when placing your unit on a natural
wood and lacquered finish. A cloth or other protective
material should be placed between it and the furniture.
FCC ID: EMOHBH88
IC: 986B-HBH88
TIP: Press the Alarm Set Button when display is
flashing during clock setting to toggle between 12
hour and 24 hour display modes.
The apparatus shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on apparatus.
L'appareil ne doit pas être exposé aux écoulements ou aux éclaboussures et aucun
objet ne contenant de liquide, tel qu'un vase, ne doit être placé sur l'objet.
Mains plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the
mains plug should be disconnected form the mains socket outlet completely.
La prise du secteur est utilisé pour déconnecter le système. La prise du secteur ne
doit pas être obstruée ou doit être facilement accessible pendant son utilisation. Pour
être complètement déconnecté de l'alimentation d'entrée, la prise doit être
débranchée du secteur.
Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu'à la lumière du soleil,
au feu ou autres choses de semblable.
An appliance with a protective earth terminal should be connected to a mains outlet
with a protective earth connection
Un appareil avec la borne de terre de protection doit être connecté au secteur avec
la connexion de terre de protection.
Minimum distances 10 cm around the apparatus for sucient ventilations.
10cm de distance minimale autour de l’appareil pour une ventilation susante.
The ventilation should not be impeded by covering the ventilation openings with
items such as newspaper, table-cloths, curtains etc.
Ne pas recouvrir les entrées d’aérations avec des objets tel qu’un journal, une nappe,
un rideau, etc…
No naked flame sources such as lighted candles should be placed on the apparatus.
Aucune source de flamme nue, tel qu’une bougie, ne doit être placée sur l’appareil.
Attention should be drawn to the environmental aspects of battery disposal.
Les piles usages doivent être jetées en respectant l’environnement.
Apparatus should only be used in moderate climates.
EI aparato debe usarse en climas moderados.
IMPORTANT SAFETY INSTRUCTIONS
This lightning flash with arrowhead symbol within an equilateral
triangle, is intended to alert the user to the presence of
non-insulated “dangerous voltage” within the product’s
enclosure that may be of sucient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
Portable Cart
Warning
CAUTION - TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE
PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
CAUTION:
Use of controls or adjustments or performance of procedures other than those specified may result in
hazardous radiation exposure.
WARNING:
To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
Ce symbole à éclair avec une pointe de flèche dans un triangle
équilatéral est pour indiquer à l'utilisateur la présence d'une
«tension dangereuse» non-isolée dans le boîtier du produit qui
pourrait créer un risque de choc électrique aux personnes.
Le point d'exclamation dans un triangle équilatéral est pour
alerter l'utilisateur à la présence d'instructions importantes
d'utilisation et d'entretien dans la documentation accompagnant
l'appareil.
Avertissement
portatif de chariot
AVERTISSEMENT - POUR RÉDUIRE LE RISQUE DE CHOC
ÉLECTRIQUE, NE RETIREZ PAS LE COUVERCLE (OU L'ARRIÈRE)
AUCUN USER-SERVICING AU PERSONNEL DE SERVICE QUALIFIÉ.
ATTENTION :
L'utilisation des commandes ou des ajustements ou l'exécution des procédures autres que ceux spécifiques
peut avoir comme conséquence l'exposition de rayonnement dangereuse.
* Caution Marking was located at bottom enclosure of the apparatus
Les marquages sont inscrits en bas de l’appareil.
AVERTISSEMENT :
POUR ÉVITER LE RISQUE D’INCENDIE OU DE CHOCS ÉLECTRIQUES, NE PAS EXPOSER CET APPAREIL À
LA PLUIE OU À L’HUMIDITÈ.
IMPORTANTES INSTRUCTIONS DE SÉCURITÉ
ATTENTION
1. Read these instructions. 2. Keep these instructions. 3. Heed all warning. 4. Follow all instructions.
5. Do not use this apparatus near water. 6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacture’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with one wider than the other.
A grounding plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and at the point where they
exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart or rack is
used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug the apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way. Examples of damage include: Power supply cord or plug
is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
1. Lisez la présente notice. 2. Conservez cette notice. 3. Tenez compte des avertissements. 4. Suivez l'ensemble des consignes.
5. N'utilisez jamais cet appareil à proximité d'eau. 6. Le nettoyage doit s'eectuer uniquement à l'aide d'un chion sec.
7. Veillez à ne pas obturer les ouvertures permettant la ventilation. Veillez à installer le produit conformément aux exigences du fabricant.
8. N'installez pas l'appareil près de sources de chaleur telles que les radiateurs, les bouches de chaleur, les cuisinières ou autres appareils
(amplificateurs inclus) produisant de la chaleur.
9. Ne rendez pas inecace la prise de mise à la terre ou la fiche polarisée servant à la sécurité. Une fiche polarisée comporte deux broches
; l'une est plus large que l'autre. Une prise de mise à la terre comporte deux broches, plus une troisième broche de mise à la terre. Cette
troisième broche, plus large, est prévue pour la sécurité de l'utilisateur. Si l'introduction de cette broche dans votre prise de courant s'avère
impossible, contactez un électricien qui eectuera le remplacement de la prise obsolète.
10. Protégez le cordon d'alimentation électrique des piétinements ou des tiraillements, en particulier à hauteur des prises ou des fiches
d'alimentation électriques, et à leur sortie des appareils.
11. Utilisez uniquement les accessoires préconisés par le fabricant.
12. Utilisez l'appareil uniquement avec le chariot, le socle, le tripode, le support ou la table préconisés par le fabricant ou vendus avec
l'appareil. Si un chariot ou un présentoir est utilisé, exercez la plus grande prudence pour éviter toute blessure provoquée par un renversement accidentel.
13. Débranchez l'appareil durant un orage ou lorsque l'appareil ne sera pas utilisé pendant de longues périodes.
14. Reportez toute réparation à un personnel qualifié. Les réparations sont exigées lorsque l'appareil a été endommagé d'une manière quelconque. Voici des exemples de
dommages : le cordon d'alimentation ou la fiche est endommagé(e), du liquide a été déversé ou des objets sont tombés dans l'appareil, l'appareil a été exposé à la pluie ou à
l'humidité, l'appareil ne fonctionne pas normalement ou a été échappé.
Clock Backup: DC 3V, AA x 2
Service Number: HBH88-A-A
USB: DC 5V 2.4A x 2
HBH88
Serviced by Hotel Technologies Inc.
www.hoteltech.com
Made in China
Patents: www.ihome.com/patents
Toll Free: 1-888-744-6835
4008427
CONFORMS TO
UL STD. 60065
CERTIFIED TO CSA
STD. C22.2 No.60065
Power Source: AC~125V 60Hz, 1300W
AC Outlet: AC~125V 60Hz, 10A Total
FCC ID: EMOHBH88 IC: 986B-HBH88
Bottom of unit
Bas de l'unité
Model plate
Plaque modèle
IMPORTANT SAFETY INSTRUCTIONS
When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety.
However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating
instructions carefully before installation and use, and keep these instructions handy for future reference. Take special
note of all warnings listed in these instructions and on the unit.
1. Water and MoistureThe unit should not be used near water. For example: near a bathtub, washbowl, kitchen sink,
laundry tub, swimming pool or in a wet basement.
2. Ventilation – The unit should be situated so that its location or position does not interfere with its proper ventilation.
For example, it should not be situated on a bed, sofa, rug or similar surface that may block ventilation openings. Also,
it should not be placed in a built-in installation, such as a bookcase or cabinet, which may impede the flow of air
through the ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators, heat registers, stoves or other appliances
(including amplifiers) that produce heat.
4. Power Sources – The unit should be connected to a power supply only of the type described in the operating instructions
or as marked on the appliance.
5. Power-Cable Protection – Power supply cables should be routed so that they are not likely to be walked on or pinched
by items placed upon or against them. It is always best to have a clear area from where the cable exits the unit to
where it is plugged into an AC socket.
6. Cleaning – The unit should be cleaned only as recommended. See the Maintenance section of this manual for
cleaning instructions.
7. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled into any
openings or vents located on the product.
8. Attachments – Do not use attachments not recommended by the product manufacturer.
9. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect the antenna or cable
system during a lightning storm or when it is left unattended and unused for long periods of time. This will prevent
damage to the product due to lightning and power-line surges.
10. Overloading – Do not overload wall sockets, extension cords, or integral convenience receptacles as this can result
in a risk of fire or electric shock.
11. Damage Requiring Service – The unit should be serviced by qualified service personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
12. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as a month or longer, the
power cable should be unplugged from the unit to prevent damage or corrosion.
13. Servicing – The user should not attempt to service the unit beyond those methods described in the user’s operating
instructions. Service methods not covered in the operating instructions should be referred to qualified service
personnel.
Hotel Technologies, a division of HTI Industries LLC, (hereafter referred to as Hotel Technologies), warrants this product to be free
from defects in workmanship and materials, under normal use and conditions, for a period of 30 days from the date of receipt of the
item.
Should service be required by reason of any defect or malfunction during the warranty period, Hotel Technologies will repair or, at
its discretion, replace this product without charge. This decision is subject to verification of the defect or malfunction upon delivery of
this product to the Factory Service Center listed below.
Before returning this product for service, please first replace the batteries (if applicable) with fresh ones, as exhausted or defective
batteries are the most common cause of problems encountered.
If service is still required:
1. Fax a representative at 915.633.1388 with a Return Authorization request including proof of purchase date (i.e., invoice number
and date from distributor or HTI) to receive a Return Authorization Number. Issuance of Return Authorization Number is subject to
review prior to granting.
NO ITEM CAN BE ACCEPTED WITHOUT A RETURN AUTHORIZATION NUMBER.
2. Remove batteries (if applicable) and pack the unit in a well-padded, heavy corrugated box.
3. Send the unit by method agreed to with your representative to the Factory Service Center listed below:
Consumer Repair Department
Hotel Technologies Inc.
1330 Goodyear Drive
El Paso TX 79936-6420
NOTE: Improperly packed items or Items received without an RA # cannot receive credit.
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not cover (i) products which
have been damaged by negligence, misuse or accident, or which have been modified or repaired by unauthorized persons; (ii)
cracked or broken cabinets, or units damaged by excessive heat; (iii) damage to tape cassettes (if applicable); (iv) the cost of
shipping this product to the Factory Service Center and its return to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the product subsequent to the original
purchaser. Any applicable implied warranties are also limited to 30 days, and Hotel Technologies will not be liable for consequential
damages. (Some states do not allow limitations on implied warranties or exclusion of consequential damages, so these restrictions
may not apply to you.) This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
LIMITED 30 DAY WARRANTY
(valid in contiguous U.S.A. only: not valid in Hawaii or Alaska)
If you did not purchase this product directly from Hotel Technologies,
please contact the appropriate distributor for their warranty terms
FCC Information
This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
Questions? visit www.hoteltech.com or call 1-888-744-6835 Toll Free
IC Statement for RF Device
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain
Canadian information on RF exposure and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la conformité à l'exposition de RSS-102 rf, utilisateurs
peut obtenir l'information canadienne sur l'exposition et la conformité de rf.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with
a minimum distance of 20 centimeters between the radiator and your body.
Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune autre antenne ou émetteur. Cet équipement devrait être installé et actionné
avec une distance minimum de 20 centimètres entre le radiateur et votre corps
Legal Sheet w/ic-110317-C © 2017 HTI Industries, LLC. All rights reserved Printed in China
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Generic Legal Sheet for all Hotel model items - Front
Size: 108 x 140 mm
Color: 1C + 1C (Black)
Material: 100 gsm WF paper
JAN 18 , 2018
Generic Legal Sheet for all Hotel model items - Back
FCC Radiation Exposure Statement
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of
the FCC RF Rules. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for
this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation
instructions and consider removing the no-collocation statement.

Navigation menu
