SDI Technologies IAV5 Color Changing Bluetooth Rechargeable Stereo Speaker System for Amazon Echo Dot User Manual iAV5 QSG IB 2018 01 11

SDI Technologies Inc. Color Changing Bluetooth Rechargeable Stereo Speaker System for Amazon Echo Dot iAV5 QSG IB 2018 01 11

User Manual

» Connect the built-in USB cable to the Echo Dot USB Port. Connect the iAV5 to USB
power source via USB cable (not included).
» The iAV5 powers the Echo Dot. Once fully charged, you can operate
both the iAV5 and the Echo Dot portably.
» A voice will automatically announce when the battery level is very low
» Press and hold the Color Mode Button to hear current
battery level voice announcement
FCC Information
This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
• Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
le dispositif a été évalué à satisfaire l'exigence générale de l'exposition aux rf.
l'appareil peut être utilisé dans des conditions d'exposition portatif sans restriction.
WARNING/DISPOSAL OF UNIT
Do NOT attempt to change the battery. Doing so will void the warranty and could cause injury and damage to your device.
To dispose of the unit, follow the instructions below:
• Never dispose of used batteries/electronics with ordinary solid wastes, since they contain toxic substances.
• Always dispose of used batteries/electronics in accordance with the prevailing community regulations.
• Many electronics retailers now recycle batteries and other electronic components at no charge.
GENERAL BATTERY PRECAUTIONS
• Never use or charge a battery if it appears to be leaking, discolored, deformed, or in any way abnormal.
• Never disassemble the unit or attempt to remove battery as that could cause leakage of alkaline solution or other
electrolytic substances.
• Avoid charging a rechargeable battery when the temperature is not within 5°C - 35°C (41° - 95° Fahrenheit).
• Never expose a battery to any liquid.
• Never expose a battery to excessive heat such as direct sunlight or fire. Never use a battery pack in an unventilated vehicle
where excessive internal temperatures may be encountered.
• Always keep batteries out of the reach of infants and small children.
Printed in ChinaiAV5-171024-A
Model: iAV5
FCC ID: EMOIAV5
IC: 986B-IAV5
FRONT
BACK
INTERIOR
CONNECTING YOUR AMAZON ECHO DOT
Docking Your Amazon Echo Dot
Color Changing Bluetooth Rechargeable
Stereo Speaker System
for Amazon Echo Dot
™
Model: iAV5
QUICK START GUIDE
» iAV5 » USB cable »
7
» Align the rear of the Echo Dot (the side with the USB port and Aux Jack) with the
opening in the iAV5 dock well and place with the ports facing the back.
» Press and hold the Power Button for 2 seconds to power on the iAV5.
» Press and hold the Bluetooth Button for 2 seconds to enter pairing mode.
» Open the Alexa app and select Settings. Select your Echo Dot, then select Bluetooth >
Pair a New Device or ask Alexa to do so. Select “iHome iAV5” on the menu. You will
hear a “Connected” announcement once the Echo Dot is paired with the iAV5.
iAV5 QSG (English)
Size: 280 x 160 mm (folded: 140 x 160 mm)
Color: print Black and
Material: 260gsm Art Card, 4C + 4C
Jan 11, 2018
BACK
“Alexa, stop”
“Alexa, mute” or “Alexa, unmute”
“Alexa, set volume to 5”
“Alexa, turn up/down the volume”
Contact Us: 1•800•288•2792
For full warranty and full instructions
visit: www.ihome.com/support
VOLUME CONTROL
BATTERY LEVEL
» If the unit “freezes up” or otherwise fails to respond properly,
insert a paper clip or similar into the Reset Port on the back
of the unit
RESET PORT
» TIP: Insert the end of a small screw driver or simliar beside the built-in USB cable
when it is connected and gently pry to release USB connector from Amazon Dot
UNDOCKING THE DOT
» Use the volume control on the Amazon Echo Dot to
adjust the volume to your desired level.
» TIP: You can use Alexa voice commands to change volume
or stop/pause playback.
1 Power Button
Press and hold for 2 seconds
to power unit ON or OFF.
2 Battery/Charge indicator
Solid red = charging
Solid green = fully charged
3 USB Charge Port
Connect a standard USB cable
(such as the one included with
your Amazon Echo Dot) to
charge iAV5 for portable use.
4 Bluetooth Indicator
Fast blinking blue = pairing
Slow blinking blue = linking
Solid blue = paired to device
5 Bluetooth Button
Press and hold for 2 seconds
to pair a device with the iAV5
Press to answer incoming call
Press and hold for 2 seconds
to end or decline call.
6 Color Change Button
Press and release to cycle
through color change modes:
slow fade, fast change,
favorite color, pulse to music,
preset pulse mode and o.
Powering Amazon Echo Dot
Amazon, Alexa, Echo Dot and all
related logos are trademarks of
Amazon.com, Inc. or its aliates.
BACK
reset
3
4
7
6
Pairing and Playing Amazon Echo Dot Audio or Bluetooth Device
7 Dock cover/Built-in USB for Dot™
Remove back cover to connect
built-in USB cable to power your Amazon Dot™
CHARGE UNIT
BEFORE USE
ABOUT 7 HOURS
5
2
1
reset
Connect other buletooth device:Turn on Bluetooth mode on your device,select
“iHome iAV5” on the menu.when pairing successful,you will hear a “Connected”
» You can now “Ask Alexa” to access all the functions of Echo Dot and hear the audio
through the iAV5.
you can now begin to stream audio and calls from your device.
Press the Bluetooth Button to answer incoming call.Press and hold to ignore/end call.
