SDI Technologies IB75 Bluetooth Wireless Earbuds User Manual iB75 Eng IB 07 12 2013

SDI Technologies Inc. Bluetooth Wireless Earbuds iB75 Eng IB 07 12 2013

User Manual

Model: iB75 (Front)
Print color : Black text on white paper
Size of manual: 180W x 270H (mm)
Date: Jul 12, 2013
The two earpieces are marked ‘L’ and ‘R’. All of the controls and the Mini 8-pin USB
charging port are located on the ‘R’ earpiece. Place the ‘R’ earpiece in your right ear and
the ‘L’ earpiece in your left ear. The cable connecting the two earpieces should be behind
your neck.
Using Your Headphones
Note: Some of the functions described below may not be supported on your specific
smartphone. Check with your smartphone owner’s manual to confirm the features
supported by your phone.
Your headphones must be paired with your phone and turned on to perform any of the
following operations.
Receiving/Ending A Call
When you receive an incoming call, press the Multi-function button once to answer the
call through the headphones. When you are finished speaking press the Multi-function
button once more to end the call.
Making A Call
When you make a call on your smartphone the call may be automatically transferred to
the headphones if your smartphone supports this automatic transfer function. If not,
press the Multi-function button once to transfer the call to the headphones.
Voice Activated Calling
If your smartphone supports this feature with the headphones, press and hold the
Multi-function button for about 2 seconds to initiate the voice activated calling function,
then follow the instructions supplied with your phone.
Last Number Redial
If your phone supports this feature, press the Multi-function twice to redial the last
number you called.
Declining A Call
If you receive a call that you would rather not accept (indicated by the caller ID on your
phone) press the Multi-function button twice to decline the call.
Volume Control
Press the Volume “ + ” or “ ” to adjust the volume of the incoming calls or the music
volume level.
Introduction
Your new iHome Bluetooth stereo headphones are designed to link with your Bluetooth
enabled smartphone or music player to allow you to wirelessly listen to music and answer
phone calls within the normal 10 meter (30 feet) Bluetooth operating range.
What’s Included
Specifications
Bluetooth specification: Supports V2.1 + EDR with Handsfree Profile 1.5,
Headset Profile 1.1 and A2DP profile 1.2 (Class ll)
Standby time: 100 hours (with fully charged battery)
Talk time: 8 hours (with fully charged battery)
Music Playing Time: 7 hours (with fully charged battery)
Operating Distance: up to 10 meters / 30 feet
Weight: 16 grams
Certifications: CE, FCC, RoHS, BQB
Switching the Power On and Off
1. Press and hold the Multi-function button for approximately 3 seconds until a ‘beep’ is
heard. The LED indicator turns blue and begins flashing slowly. This indicates that the
power is ‘On’.
2. When the power is ‘On’ press and hold the Multi-function button for approximately 3
seconds until a ‘beep’ is heard. The LED indicator turns red, flashes for a few seconds
and then shuts off. This indicates that the power is ‘Off’.
Pairing With a Bluetooth Enabled Smartphone or Music Player
If your smartphone or music player, such as the iPod touch, is Bluetooth enabled
(supports the A2DP Bluetooth Profile) you may pair these iHome headphones with your
phone or music player to listen to music and make or receive calls as long as the two
devices are within the Bluetooth operating range of approximately 33-feet of each other.
1. Make sure that your iHome iB75 headphones are in the Power Off mode. Make sure
that your smartphone or music player is ‘On’.
2. Press and hold the Multi-function button on your iB75 headphones for about 5
seconds until the LED indicator alternately flashes red and blue to indicate it is trying to
pair with a compatible device.
3. If necessary, turn on the Bluetooth function of your phone or music player so that it
begins searching for a compatible device.
4. “iHome iB75” should appear on your phone or music player’s compatible devices list.
You may also see a message such as “Not Paired”. Tap on that message to complete
the pairing process. If your phone or music player asks for a ‘password’ to complete
the pairing process, enter ‘0000’ on the keypad of your phone or music player.
5. When pairing is successful the screen on your phone should show “iHome iB75
Connected” or similar message and the blue LED indicator on the iB75 headphones
should flash repeatedly. Your headphones are now ready for use.
Wearing Your Headphones
Your iHome Bluetooth headphones are supplied with 3 different
sizes of silicon ear cushions (tips) and three different sizes of soft
rubber stabilizer ‘fins’ designed to prevent the headphones from
falling out of your ears during periods of strenuous physical
activity. Refer to the following illustration showing the proper way
to fit the headphones in your ears with the stabilizer fins installed.
Although you must use the headphones with the silicon cushions to
form a proper seal in your ear canals, using the stabilizer fins is optional.
The medium (M) size cushions and ‘fins’ were installed at our factory. If you find that the
M size cushions and fins are either too big or too small for you, you may change to the S
or L size cushions and fins. Start by removing the cushions simply by pulling them off the
plastic tubes. Then remove the rubber ‘fins’ from the speaker housing. Install either the S
of L fins on the speaker housings first, then install either the S or L cushions by pushing
them onto the plastic posts as far as they will go. Make sure that the cushions are
securely fixed on the posts so that a cushion does not remain in your ear when you
remove the headphones.
Model: iB75
Bluetooth wireless earbuds
with mic + remote and pouch
iB75 Bluetooth
Wireless Headphones
USB Cable
Silicon Tips
Stabilizer Fins
Lx 2
SIZE Mx 2
SIZE Sx 2
SIZE
Lx 1set
SIZE Mx 1set
SIZE Sx 1set
SIZE
Controls and Indicators
1. Multi-function button: Power On/Off,
Answer/End, Pair, Play, and Pause
2. Speakers
3. Back button
4. Forward button
5. Mini 8-pin USB Charging Port
(under water resistant cover)
6. Microphone
7. Volume + button
8. Volume
-
button
9. Power On, Charging, Pairing LED Indicator
+
-
1
9
2
7
8
2
3
4
5
6
Charging Your Headphones
IMPORTANT: Your headphones operates on a built-in rechargeable lithium-ion battery.
You should charge the battery for a full 4 hours before first time use.
1. Lift up the water resistant cover to expose the Mini 8-pin USB charging port.
2. Connect the Mini 8-pin USB plug on the charging cable to the Mini 8-pin USB port on
the headphones.
3. Connect the standard USB plug on the charging cable to any standard USB power
port such as found on a notebook computer, or the charging adapter for an iPod,
iPhone, etc.
4. The Power/Charging/Pairing indicator will glow RED while the headphones is charging.
The indicator will turn Off when the battery is fully charged.
Reminder: Allow the battery to charge for 4 hours before first time use. Normal recharge
time after first use should take about 2 hours. When full charged the battery will provide
up to 8 hours of talk time, 7 hours of music playing time, or 100 hours of standby time.
Model: iB75 (Back)
Print color : Black text on white paper
Size of manual: 180W x 270H (mm)
Date: Jul 12, 2013
Listening to Music
To listen to music your headphones must be paired and connected to a smartphone or
music player that supports the A2DP Bluetooth profile (see “Pairing With a Bluetooth
Enabled Smartphone or Music Player” above). To play music, use the playback controls
on the connected device. If you answer or make a call while listening to music, the music
will pause automatically until you end the call.
You may also use the buttons on the ‘R’ earpiece to control the music as follows:
Play or Pause – Press the Multi-function button once to start playback; press again to
pause; press once more to resume playback.
Track Controls – Press the button during playback to skip the beginning of the next
track. Press the button once during playback to skip back to the beginning of the
current track. Press twice to skip back to the beginning of the previous track.
Volume Controls – Press the “ + ” or “ ” buttons to control the music playback volume.
Troubleshooting
Reception is noisy or intermittent.
Make sure that the headphones and the paired device are within the Bluetooth operating
range of approximately 30-feet.
Make sure that your headphones are properly paired and
connected with your Bluetooth enabled smartphone or
music player. Refer to the “Pairing” instructions on this
manual and in the manual supplied with your phone or
music player if necessary.
The rechargeable battery in your headphones may be
exhausted and need to be recharged. Refer to the
“Charging Your Headphones” instructions in this manual.
The pairing settings between the headphones and your
smartphone or music player may have been erased or
deleted. Follow the “Pairing” instructions in this manual to
repair and reconnect the devices.
Your specific model of smartphone may not support some
of the functions described in this manual. Refer to the
manual supplied with your phone for further information.
Care and Maintenance
Always remember to turn your headphones off if they will not be used for a long period of
time. Do not expose your headphones to extremely hot or cold temperatures for
extended periods. Do not expose them to direct sunlight or leave them in places such as
the dashboard of your car on a hot day. Prevent water or any other liquids from entering
the cabinets of your headphones.
USB Cable
This iHome Bluetooth headphone uses a "Mini 8-pin USB" cable for charging. You cannot
charge this model with a standard mini or micro USB cable. If you misplace or lose the
original Mini 8-pin USB charging cable supplied with this headphone, contact iHome
Customer Service to order a replacement Mini 8-pin USB cable.
Protect Your Hearing
Using these, or any headphones at high volume levels for long periods can result in
permanent hearing damage. Always start listening with volume controls on your
headphones and your paired smartphone or music player at a low level and then
gradually increase the volume controls to a comfortable listening level.
Important Notes
It is dangerous and illegal (in some jurisdictions) to use headphones when you are driving
a car, riding a bike or motorcycle, or operating a watercraft. Be aware of local laws and
regulations.
Do not use these headphones in situations where they might cause distractions or
prevent you from hearing warning sounds.
These headphones contain small parts and should be kept out of reach of small children.
There are no user serviceable parts in these headphones. Do not attempt any service or
repairs on your own. Refer to the warranty for service, repair or replacement information.
Limited One-Year Warranty Information
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this
product to be free from defects in workmanship and materials, under normal use and conditions,
for one year of the product from the date of original purchase.
Should this product fail to function in a satisfactory manner, it is best to first return it to the store
where it was originally purchased. Should this fail to resolve the matter and service still be required
by reason of any defect or malfunction during the warranty period, SDI will repair or, at its
discretion, replace this product without charge. This decision is subject to verification of the
defect or malfunction upon delivery of this product to the Factory Service Center authorized by
SDI Customer Service. The product must include proof of purchase, including date of purchase.
An out-of-warranty fee for service will be charged for units that are received without proof of
purchase.
Before returning this product for service, please first replace the batteries (if applicable) with fresh
ones, as exhausted or defective batteries are the most common cause of problems encountered.
If service is still required:
1. Call SDI Customer Service at 1-800-288-2792 for Return Authorization and for the address of
the Factory Service Center.
2. Remove the batteries (if applicable) and pack the unit in a well padded, heavy corrugated box.
SDI is not responsible for damage that occurs during shipping to the Factory Service Center.
3. Enclose a photocopy of your sales receipt, credit card statement, or other proof of the date of
purchase, if within the warranty period. Also include your name and address information, a
brief description for why the unit is being returned, and the return authorization number. No
unit can be processed without a return authorization number.
4. Write the return authorization number on the side of the shipping package and send the unit
prepaid and insured to the Factory Service Center address authorized by SDI Customer
Service.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed.
It does not cover (i) products which have been damaged by negligence or willful actions, misuse
or accident, or which have been modified or repaired by unauthorized persons; (ii) cracked or
broken cabinets, or units damaged by excessive heat; (iii) damage to digital media players, CD’s
or tape cassettes (if applicable); (iv) the cost of shipping this product to the Factory Service Center
and its return to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the
product other than to the original purchaser. In no event will SDI or any of its affiliates, contractors,
resellers, their officers, directors,
shareholders, members or agents be liable to you or any third party for any consequential or
incidental damages, any lost profits, actual, exemplary or punitive damages. (Some states do not
allow limitations on implied warranties or exclusion of consequential damages, so these
restrictions may not apply to you.) This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
Your acknowledgement and agreement to fully and completely abide by the above mentioned
disclaimer of warranty is contractually binding to you upon your transfer of currency (money order,
cashier's check, or credit card) for purchase of your SDI product.
© 2013 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihomeaudio.com or call 1-800-288-2792 Toll Free.
i
B75-07122013-1(ENG) Printed in China
FCC Information
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment.
This Device complies with RSS-210 of the IC Rules; Operation is subject to the following
two conditions:
(1) This device may not cause interference and
(2) This device must accept any interference received, including interference that may
cause undesired operation
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS
102 and compliance with RSS-102 RF exposure, users can obtain Canadian information
on RF exposure and compliance.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio RSS-210. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil
ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre
le fonctionnement.
This device complies with Part 15 of the FCC Rules, operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
No Sound
Unable to Pair/Connect
Some Functions
Do Not Work
FCC ID: EMOIB75
IC: 986B-IB75

Navigation menu
