User Manual
Model: iBN350
NFC Bluetooth Stereo Dual
Alarm Clock with Dual
QUESTIONS? Visit www.ihome.com
Wireless USB Charging
1
1 2
WELCOME
Thank you for choosing the iBN350 from iHome. This user guide will
get you up and running quickly and provide helpful hints to
maximize enjoyment. For more information about this and other
iHome products, please visit www.ihome.com
GETTING STARTED
This unit ships with the following items. Please check to see that all
items are present.
1 iBN350 speaker system
2 100-240V Universal AC power adaptor
FEATURES & FUNCTIONS
Mode Button
Power On/O
Button
Sleep Button
Alarm 1/Alarm 2
Buttons
Talk/End Call
Button
Snooze/Dimmer
Button
2
Back panel
Display
Top panel
Play/Pause Button
Volume
Control
Buttons +/– Settings
Buttons
Bluetooth
Pairing
Button
Aux-in jack
USB
charging
port
Clock
Button
DST
Switch
DC jack
Time Display
Alarm Time/Date Display
PM Indicator
AM Indicator
Bluetooth Indicator
Wireless Charging
Indicator
Sleep Mode Indicator
Wake-To/Mode Indicators
(Tone/BT/(Bluetooth)Aux)
Alarm
Indicators
Low Backup
Battery Indicator
Wireless charging pad NFC charging
area
(on right side of unit)
p
a
i
r
i
n
g
t
a
l
k
/
e
n
d
DC 9V 3A
DC 9V 3A
BACKUP BATTERY
The iBN350 ships with a CR2450 battery installed for backup to provide
continuous alarm operation and clock settings in the event of a power failure.
Remove the pull tab from the battery compartment on the bottom of the unit
before use. If a power failure occurs or the AC cord is accidentally
disconnected, the display backlight will not remain lit, but current time and
alarm time settings will be temporarily maintained. Otherwise, you must reset
the time and alarm settings.
Note: The Battery Low icon is located at the lower left side of the clock
display. When the backup battery is low and needs to be replaced, the
Battery Low icon will flash. To replace, follow steps on next page.
3
CONNECTING AC ADAPTER
This unit operates on AC power
using the included 100V-240V
universal AC adaptor. Place unit on
a stable surface. Plug the power
adaptor into the DC jack on back
of the unit and the other end into a
working wall socket. The Power
Button will glow red.
RESET
RESET
TEST
TEST
verify adaptor type
4
BACKUP BATTERY (CONTINUED)
1. Please make sure the AC adaptor is connected. Otherwise all settings
may be lost during battery replacement.
2. Use a Phillips screwdriver to open the backup battery compartment
door located on the bottom of the unit.
3. Remove the exhausted battery. Insert
a new CR2450 battery by easing it
under the tabs in the battery well and
pressing down. Make sure the side
marked + is facing up.
4. Close the battery compartment door and tighten the battery door screw.
Note: Make sure you dispose of battery properly (see your local
regulations).
WARNING: Lithium batteries can explode or cause burns if disassembled,
shorted, recharged, exposed to water, fire, or high temperatures.
Do not place loose batteries in a pocket, purse, or other container
containing metal objects, mix with used or other battery types, or
store with hazardous or combustible materials. Store in cool, dry,
ventilated area. Follow applicable laws and regulations for
transport and disposal.
show iBN350
battery compartment
5
SETTING THE TIME
1. Press and hold the Clock Button. The TIME will flash on the display.
Press the + or – Buttons to set the correct time (hold for rapid
adjustment). Make sure to set the correct AM or PM time. (The PM/AM
indicators appear to the left of the time display.)
NOTE: The display can be set to standard 12 hour time (AM and PM) or to
24 hour time. To toggle between 12 and 24 modes, press and release the
Alarm 1 or Alarm 2 Button at any time while display is flashing
during time setting mode.
3. Press and release the Clock Button to confirm the current time setting.
The YEAR will flash on the display. Press the + or – Buttons to set the
correct year.
4. Press and release the Clock Button to confirm the current year setting.
The DATE will flash on the display. Press the + or – Buttons to set the
correct month and day (hold for rapid adjustment).
5. Press and release the Clock Button to confirm the current date setting.
Two beeps will sound to indicate time setting mode is complete.
SETTING THE DAYLIGHT SAVING TIME (DST) SWITCH
This unit has a DST switch on the back of the unit to adjust the time for
daylight saving time and standard time. By default, it is set to Auto and will
automatically adjust the time at the start and end of daylight saving time. If
you are located in an area that does not observe daylight saving time or
otherwise wish to adjust manually, slide the switch to +1 to add one hour or
to –1 to subtract an hour.
6
SETTING AND USING THE ALARMS
SETTING THE ALARMS
This unit has two alarms which are set the same way. Instructions below are
for setting alarm 1. Substitute the Alarm 2 Button to set alarm 2. You can
wake to your Bluetooth device or to the built-in tones. The alarm will sound
for 60 minutes or until reset/turned o.
1. Press and hold the Alarm Button until the alarm time display flashes and
one beep sounds.
2. Press the + or – Buttons to adjust the display to the desired alarm time (hold
for rapid adjustment). Remember to set the correct AM or PM alarm time.
3. Press the Alarm Button to confirm the alarm time. The wake to schedule
will flash.
4. Press the + or – Buttons to set the desired alarm schedule: 7 Days (every
day), 5 Days (week days only) or 2 Days (weekends only).
5. Press the Alarm Button to confirm the alarm schedule. The wake source
indicator will flash on the display. Press the + or – Buttons to select BT
(Bluetooth) or Tone, then press the Alarm Button to access preferences
and volume setting for the selected alarm source.
Wake to BT: If wake to Bluetooth (BT) is selected, press the + or – Buttons
to set the BT volume (can be set from 5–40). The alarm will
wake you to the last track played on the last linked Bluetooth
device. Note: if Bluetooth is not detected at alarm time,
alarm will default to tone.
Wake to Tone: Select to wake to one of the 4 built-in alarm tones. Press
the + or – Buttons to listen to and select the desired tone.
Confirm with the Alarm Button, then press the + or –
Buttons to set the alarm volume (can be set from 5–40).
6. Press the Alarm Button to exit and confirm alarm settings. An alarm
icon will appear on the display, indicating that the alarm is set and armed.
NOTE: alarm volume is independent from normal volume.
7
SETTING AND USING THE ALARMS
(Continued)
REVIEWING, ARMING/DISARMING AND RESETTING THE ALARM
Press and release the Alarm Button at any time to review the current alarm
settings. To toggle the alarm on or o, press the Alarm Button as needed.
When the alarm icon is displayed, the alarm is armed/on.
Press the Power Button or Alarm Button when the alarm is sounding to
reset it to come on again at the same time the next scheduled day. (For
example, if your alarm schedule is set to Wake Weekday and you reset the
alarm on Friday, it will come on again on Monday, not on Saturday.)
SNOOZE/DIMMER OPERATION
1. To program a custom snooze duration, during normal operation (when
alarm is not sounding) press and hold the Snooze/Dimmer Button until
the display flashes, then press the + and – Buttons on the unit to adjust
the snooze time to 1 - 29 minutes.
2. Press the Snooze/Dimmer Button on the iBN350 after the alarm sounds.
The alarm will be silenced and will come on again in about 9 minutes
(default). You may repeat this cycle several times during the one hour
alarm cycle.
3. During normal operation (when alarm is not sounding), press the
Snooze/Dimmer Button to control the brightness level (8 steps, high to
DIMMER 1 and DIMMER OFF settings) of the LCD display and buttons.
SLEEP MODE
Sleep mode lets you sleep to your playing docked iPhone or iPod or to FM
radio for the set sleep duration, then turns the unit o. Press the Sleep
Button as needed to cycle to the desired sleep duration: 120, 90, 60, 30 or
15 minutes or OFF (turns sleep mode o). Press the or Button on the
unit to adjust sleep listening level (sleep level volume is independent from
normal volume levels). Press the Sleep Button during sleep to view the
remaining sleep time; press again to set sleep to next (lower) sleep
duration.
8
USING WIRELESS CHARGING
This unit supports Qi wireless charging; PMA wireless charging is not
supported.
Wireless charging is only for compatible devices. Remove metal case
from device before charging. Do not place metal or magnetic-striped
objects on the charger. Doing so could damage the object or this unit.
Center Qi compatible device with back side down on marked charging
target circle. Check the wireless charging indicator toward the bottom left
of the display.
Rapid blinking icon: Device is not charging properly. Reposition device.
Slow blinking icon: Device is charging properly.
Solid icon: Device is charged (some devices do not support this
feature).
USING THE USB CHARGING PORT
A 1 Amp USB port is located on the back of the unit for charging devices
while the unit is connected to AC power. Connect one end of a compatible
USB cable (not included) into the standard USB port on the unit and the
other end into the device you wish to charge. Some devices require higher
amperage USB charging ports. Monitor the charging status of your device.
If the device does not charge, you will need to use the charger that came
with your device.
USING BLUETOOTH
Pairing Your Device Using NFC
Pairing is the set-up process to introduce your Bluetooth-capable device to the
iBN350. Once your device is paired, the iBN350 can recognize it and you can
play your audio through it.
This device features wireless NFC pairing, which allows playing NFC-enabled
devices to play and pair instantly. For non-NFC devices, please see the following
section “Pairing Your Device Using Standard Bluetooth.”
1. Turn on yourBluetooth-enabled/NFC-enabled device and turn on Bluetooth
and NFC capability as described in the device’s user manual.
2. Place your NFC-enabled device in play mode.
3. Touch the NFC area of your playing device against the NFC antenna area
located on the right side of the unit. The unit will turn on and enter
automatic pairing mode. The Bluetooth icon and “BT” will flash on the
display, indicating pairing attempt.
4. “iHome iBN350” should on appear on your device’s Bluetooth menu.
Select “iHome iBN350” to complete pairing.
5. You are now ready to play audio from your device.
Pairing Your Device Using Standard Bluetooth
1. Press and hold the Bluetooth Pairing Button located on the front of the
unit for 3 seconds. The Bluetooth icon and “BT” will flash on the display
and notes will sound indicating pairing mode.
2. “iHome iBN350” will appear on your device’s Bluetooth menu. Select “iHome
iBN350” to complete pairing.
If prompted for a passcode, enter “1234” on
your device’s keypad.
“Connected” or similar should appear on your device.
3.
Tones will sound and the Bluetooth icon will appear solid indicating the
iBN350 is paired and ready to play music. If no device is successfully paired
within 3 minutes the unit will default to previous mode.
4.
Once the unit is paired to a device, it will attempt to autolink when the
device is within range (about 33 feet)
9
USING BLUETOOTH
(Continued)
Listening to Bluetooth Audio
1. Press and release the Power Button to turn on the unit, then press and
release the Mode Button as needed to cycle through BT and AUX modes.
2. When BT mode is selected, press the + or – Buttons to navigate to the
desired tracks. Press and hold to search within the current track.
Adjust the volume on your BT device to maximum output.
4. Press the or Button on the unit to adjust the system volume. Press
the Button to pause Bluetooth audio, and again to unpause.
Using the Speakerphone
Unit must be ON and paired to a Bluetooth device to use Speakerphone mode.
1. When a call is received, playing music is muted to hear the ring tone and “CALL”
appears on the display. Press the Talk/End Call Button to answer the call, or press
and hold to reject the call. For call waiting function, press the button again to
answer a second call, and once more to return to the original call. Press and hold to
end the current call and return to a remaining call.
2. When a call is completed, press the Talk/End Call Button to end the call and
resume previous function.
10
LISTENING TO AUX DEVICES
1. Connect a standard audio cable with 3.5mm plug to the headphone or
line-out jack on your AUX device and the other end to the AUX IN jack
located on the back of the iBN350.
2. Press and release the Power Button to turn on the unit, then press and
release the Mode Button as needed to cycle through BT and AUX modes.
3. When AUX mode is selected, turn on your AUX device and use its controls
to play, pause and navigate audio tracks. Adjust the volume on your AUX
device to maximum output.
4. Press the or Button on the unit to adjust the system volume. Press
the Button to mute aux audio, and again to unmute.
5. Press and release the Power Button to turn o the unit when through
listening. Remember to turn o your AUX device, too.
MAINTENANCE
• Place the unit on a level surface away from sources of direct sunlight or
excessive heat.
• Protect your furniture when placing your unit on a natural wood and
lacquered finish. A cloth or other protective material should be placed
between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water.
Stronger cleaning agents such as thinner or similar materials can damage
the surface of the unit.
11
TROUBLESHOOTING
Symptom Possible reason Solution
Unit won’t turn on
Device does not
respond to the
unit and/or
device is playing
but no sound
comes out
AC adaptor isn't plugged
into a working wall socket
or not plugged into the
power jack on back of the
unit
Unit is not properly
connected to power
source and/or Power
Button is not ON/device is
paused/device is not
connected properly
Plug the AC adaptor into a
working wall socket and plug the
connector into the supply jack on
the unit. Make sure any associated
wall switch that controls the outlet
is ON.
Make sure the unit is properly
connected to AC power source.
Check that the unit is ON. Try
adjusting volume on unit and
audio device. Press the Mode
Button to select BT or AUX mode.
Also try pressing the Play/Pause
Button.
Erratic
performance
No sound
Sound distorted
Device doesn’t
charge up
External interference
Volume is too low
Volume is too high
Sound source is distorted
Unit is not properly
connected to AC power
Device is not connected
properly/ USB cable is bad
Device is not capable of Qi
wireless charging
Move unit away from potential
sources of external interference such
as computers, modems, wireless
devices (routers) or fluorescent light.
Turn volume up on your device
Turn volume down on your device
If the original sound file (MP3) is old
or of poor quality, distortion and noise
are easily noticed with high-power
speakers. Try upgrading file from a
trusted source such as iTunes.
Please make sure the unit is
connected to a working power outlet.
The unit will not charge devices while
operating on backup battery.
Make sure USB cables are good and
properly connected.
Check that device works with Qi
wireless charging. Adjust placement
on wireless charging pad.
12
13
IMPORTANT SAFETY TIPS
When used in the directed manner, this unit has been designed and
manufactured to ensure your personal safety. However, improper use can
result in potential electrical shock or fire hazards. Please read all safety and
operating instructions carefully before installation and use, and keep these
instructions handy for future reference. Take special note of all warnings
listed in these instructions and on the unit.
1. Water and Moisture – The unit should not be used near water. For
example: near a bathtub, washbowl, kitchen sink, laundry tub, swimming
pool or in a wet basement.
2. Ventilation – The unit should be situated so that its location or position
does not interfere with its proper ventilation. For example, it should not
be situated on a bed, sofa, rug or similar surface that may block ventila-
tion openings. Also, it should not be placed in a built-in installation, such
as a bookcase or cabinet, which may impede the flow of air through the
ventilation openings.
3. Heat – The unit should be situated away from heat sources such as
radiators, heat registers, stoves or other appliances (including amplifiers)
that produce heat.
4. Power Sources – The unit should be connected to a power supply only of
the type described in the operating instructions or as marked on the
appliance. Only use the AC adapter that came with the unit.
5. Power-Cable Protection – Power supply cables should be routed so that
they are not likely to be walked on or pinched by items placed upon or
against them. It is always best to have a clear area from where the cable
exits the unit to where it is plugged into an AC socket.
6. Cleaning – The unit should be cleaned only as recommended. See the
Maintenance section of this manual for cleaning instructions.
7. Objects and Liquid Entry – Care should be taken so that objects do not
fall and liquids are not spilled into any openings or vents located on the
product.
8. Attachments – Do not use attachments not recommended by the
product manufacturer.
9. Lightning and Power Surge Protection – Unplug the unit from the wall
socket and disconnect the antenna or cable system during a lightning
storm or when it is left unattended and unused for long periods of time.
This will prevent damage to the product due to lightning and power-line
surges.
10. Overloading – Do not overload wall sockets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric
shock.
11. Damage Requiring Service – The unit should be serviced by qualified
service personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not
operate normally.
14
IMPORTANT SAFETY TIPS
(CONTINUED)
12. Servicing – The user should not attempt to service the unit beyond those
methods described in the user’s operating instructions. Service methods
not covered in the operating instructions should be referred to qualified
service personnel.
13. Magnetic Interference: This product’s speakers contain powerful
magnets which could cause interference or damage to sensitive
equipment such as hard drives, CRT televisions and monitors, as well as
medical, scientific, and navigational devices. Keep this unit away from
these products at all times.
A GUIDE TO PRODUCT SAFETY
This device complies with Part 15 of the FCC Rules, operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interfer-
ence that may cause undesired operation.
• Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate
the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B) This device complies with Industry Canada licence-ex-
empt RSS standard(s). Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le fonctionnement
iBN350-062016-A Printed in China
LIMITED 1 YEAR WARRANTY
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as
SDI), warrants this product to be free from defects in workmanship and
materials, under normal use and conditions, for a period of one (1) year from
the date of original purchase.
Should this product fail to function in a satisfactory manner, it is best to first
return it to the store where it was originally purchased. Should this fail to
resolve the matter and service still be required by reason of any defect or
malfunction during the warranty period, SDI will repair or, at its discretion,
replace this product without charge. This decision is subject to verification
of the defect or malfunction upon delivery of this product to the Factory
Service Center authorized by Customer Service.
If service is required, please call Customer Service at 1-800-288-2792 to
obtain a Return Authorization Number and shipping instructions. A copy of
the sales receipt is required to validate in-warranty coverage.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for
which it was designed. It does not cover (i) products which have been
damaged by negligence or willful actions, misuse or accident, or which have
been modified or repaired by unauthorized persons; (ii) cracked or broken
cabinets, or units damaged by excessive heat; (iii) damage to digital media
players, CD’s or tape cassettes (if applicable); (iv) the cost of shipping this
product to the Factory Service Center and its return to the owner.
This warranty is valid only in the United States of America and does not
extend to owners of the product other than to the original purchaser. In no
event will SDI or any of its aliates, contractors, resellers, their ocers,
directors, shareholders, members or agents be liable to you or any third
party for any consequential or incidental damages, any lost profits, actual,
exemplary or punitive damages. (Some states do not allow limitations on
implied warranties or exclusion of consequential damages, so these
restrictions may not apply to you.) This warranty gives you specific legal
rights, and you may also have other rights which vary from state to state.
Your acknowledgment and agreement to fully and completely abide by the
above mentioned disclaimer of warranty is contractually binding to you
upon your transfer of currency (money order, cashier's check, or credit card)
for purchase of your SDI product.
© 2016 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
This equipment should be installed and operated with a minumum distance of
20 cm between the radiator and your body.
