SDI Technologies IBT15N Splashproof Wireless Speaker with Speakerphone User Manual iBT15 EN IB 62317
SDI Technologies Inc. Splashproof Wireless Speaker with Speakerphone iBT15 EN IB 62317
User Manual
Thank you for purchasing the iHome iBT15. This product is designed to provide high quality wireless
sound for your iPad, iPhone, iPod, computer, PDA or other Bluetooth audio device.
This instruction booklet explains the basic operation and care of the unit. Please read them carefully and
keep for future reference.
IMPORTANT INFORMATION ABOUT SPLASH PROOF USE
For proper splash-proof operation, make sure the seal on the left side of the unit is completely flush with
the unit by pressing along the entire edge of the seal until it is completely and securely in place.
• The unit is IPX5 rated, meaning it will repel a stream of water for up to 5 minutes.
• DO NOT immerse the unit in water.
• Make sure seal and surrounding surfaces are completely dry before opening seal to prevent moisture
from damaging the internal electronics.
• Keep seal free of dirt, sand, or other objects that can interfere with proper sealing. If for any reason
the seal is not making a tight seal, water may enter the unit.
• DO NOT clean unit with oily soaps or use chemicals or solvents. Clean with damp cloth.
Maintenance
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other
protective material should be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents,
such as benzene, thinner or similar materials can damage the surface of the unit.
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free from defects
in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original
purchase. Should this product fail to function in a satisfactory manner, it is best to first return it to the store where it was originally
purchased. Should this fail to resolve the matter and service still be required by reason of any defect or malfunction during
the warranty period, SDI will repair or, at its discretion, replace this product without charge. This decision is subject to
verification of the defect or malfunction upon delivery of this product to the Factory Service Center authorized by Customer
Service.
If service is required, please call Customer Service at 1-800-288-2792 to obtain a Return Authorization Number and shipping
instructions. A copy of the sales receipt is required to validate in-warranty coverage.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not cover (i) products
which have been damaged by negligence or willful actions, misuse or accident, or which have been modified or repaired
by unauthorized persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii) damage to digital media
players, CD’s or tape cassettes (if applicable); (iv) the cost of shipping this product to the Factory Service Center and its return
to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the product other than to the
original purchaser. In no event will SDI or any of its affiliates, contractors, resellers, their officers, directors, shareholders,
members or agents be liable to you or any third party for any consequential or incidental damages, any lost profits, actual,
exemplary or punitive damages. (Some states do not allow limitations on implied warranties or exclusion of consequential
damages, so these restrictions may not apply to you.) This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
Your acknowledgement and agreement to fully and completely abide by the above mentioned disclaimer of warranty is
contractually binding to you upon your transfer of currency (money order, cashier's check, or credit card) for purchase of your
SDI product.
© 2017 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free from defects
in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original
purchase. Should this product fail to function in a satisfactory manner, it is best to first return it to the store where it was originally
purchased. Should this fail to resolve the matter and service still be required by reason of any defect or malfunction during
the warranty period, SDI will repair or, at its discretion, replace this product without charge. This decision is subject to
verification of the defect or malfunction upon delivery of this product to the Factory Service Center authorized by Customer
Service.
If service is required, please call Customer Service at 1-800-288-2792 to obtain a Return Authorization Number and shipping
instructions. A copy of the sales receipt is required to validate in-warranty coverage.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not cover (i) products
which have been damaged by negligence or willful actions, misuse or accident, or which have been modified or repaired
by unauthorized persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii) damage to digital media
players, CD’s or tape cassettes (if applicable); (iv) the cost of shipping this product to the Factory Service Center and its return
to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the product other than to the
original purchaser. In no event will SDI or any of its affiliates, contractors, resellers, their officers, directors, shareholders,
members or agents be liable to you or any third party for any consequential or incidental damages, any lost profits, actual,
exemplary or punitive damages. (Some states do not allow limitations on implied warranties or exclusion of consequential
damages, so these restrictions may not apply to you.) This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
Your acknowledgement and agreement to fully and completely abide by the above mentioned disclaimer of warranty is
contractually binding to you upon your transfer of currency (money order, cashier's check, or credit card) for purchase of your
SDI product.
© 2017 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
Limited 1 Year Warranty
iBT15 EN-IB -
Size: 214mm x 336mm
Printing color: Black
June 23, 2017
100gsm2 WF (書紙)
9
Consumer Product Safety Guide
8
When used in the directed manner, this unit has been designed and manufactured to ensure your personal
safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety
and operating instructions carefully before installation and use, and keep these instructions handy for future
reference. Take special note of all warnings listed in these instructions and on the unit.
1. Water and Moisture – DO NOT immerse unit in water. Make sure the seal and surrounding surfaces
are completely dry before opening seal to prevent moisture from damaging the internal electronics.
Keep seal free of dirt, sand, or other objects that can interfere with proper sealing. If for any reason
the seal is not making a tight seal, water may enter the unit.
2. Ventilation – The unit should be situated so that its location or position does not interfere with its proper
ventilation. For example, it should not be situated on a bed, sofa, rug or similar surface that may block
ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators, heat registers, stoves or
other appliances (including amplifiers) that produce heat.
4. Power Sources – The unit should be connected to a power supply only of the type described in the
operating instructions or as marked on the appliance.
5. Cleaning – The unit should be cleaned only using a warm damp cloth. Do not use solvents, etc.
6. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled
into any openings or vents located on the product.
7. Attachments – Do not use attachments not recommended by the product manufacturer.
8. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect the
antenna or cable system during a lightning storm or when it is left unattended and unused for long
periods of time. This will prevent damage to the product due to lightning and power-line surges.
9. Overloading – Do not overload wall sockets, extension cords, or integral convenience receptacles as
this can result in a risk of fire or electric shock.
10. Damage Requiring Service – The unit should be serviced by qualified service personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
12. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as a month
or longer, fully charge the unit before storing.
13. Servicing – The user should not attempt to service the unit beyond those methods described in the
user’s operating instructions. Service methods not covered in the operating instructions should be
referred to qualified service personnel.
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
IMPORTANT SAFETY INSTRUCTIONS
Internal Rechargeable Lithium-ion Battery
This device uses an internal rechargeable lithium-ion battery that should last the lifetime of the device. If you
suspect your battery may be dead, try charging it several times. If the battery does not recharge, please contact
us for repair information.
WARNING/DISPOSAL OF UNIT
Please do NOT attempt to change the battery yourself. If the battery has died and you do not want us to replace
your battery, you should follow the disposal instructions below:
• Never dispose of used batteries/electronics with ordinary solid wastes, since they contain toxic substances.
• Always dispose of used batteries/electronics in accordance with the prevailing community regulations that apply
to the disposal of batteries/electronics. If there are no local regulations concerning battery/electronics disposal,
please dispose of the device in a waste bin for electronic devices.
• Many electronics retailers now recycle batteries and other electronic components at no charge. Check to see
which ones in your area do so.
CAUTION
The battery used in this device may present a risk of fire, explosion or chemical burn if
mistreated
• Never use or charge the battery if it appears to be leaking, discolored, deformed, or in any way abnormal.
• Never disassemble the unit or attempt to remove battery as that could cause leakage of alkaline solution or other
electrolytic substance.
• Always confirm that the temperature is 5°C – 35° C (41° - 95° Fahrenheit) before you charge the battery.
Leakage or deterioration of the battery may occur if this warning is not heeded.
• Never expose the battery to any liquid.
• Never expose the battery to excessive heat such as direct sunlight or fire. Never use the battery pack in an
unventilated vehicle where excessive internal temperatures may be encountered.
• Always keep the battery out of the reach of infants and small children.
1
Introduction
iBT15-170623-D (EN) Printed in China
Splashproof
Wireless Speaker
with Speakerphone
instruction manual
CHARGE
BEFORE
USE
iBT15
FCC Information
This device complies with Part 15 of the FCC Rules, operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC Radiation Exposure Statement
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
• Warning: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil
ne doit pas produire de brouillage; (2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and
compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure
and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de
RSS 102 et la conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information
canadienne sur l'exposition et la conformité de rf.
FCC ID: EMOIBT15N
IC: 986B-IBT15N
Declaration ID D024962
iBT15 EN-IB
Size: 214mm x 336mm
Printing color: Black
June 20, 2017
100gsm2 WF (書紙)
What’s Included
• iBT15 speaker
• micro USB charging cable
• carry strap
micro USB charging cableiBT15 speaker carry strap
Playing Audio via Aux In
1. Connect one end of a 3.5mm audio cable (not
included) to the Aux-in jack on the left side of the
unit and connect the other end to the headphone or
line-out jack on your audio device.
2.
Press the
Power/End Call
Button on the unit
to turn
it on.
3. Power on the audio device and use the controls on
the device to play or pause audio, and navigate
tracks.
4. Press t
he – or + Button to adjust the system
volume
. You can also adjust volume on your device.
5. When done listening, press the Power/End Call
Button to turn the unit OFF. Remember to turn off
your device, too.
NOTE: Make sure no Bluetooth device is playing when
you want to listen to Aux-in or you will hear Bluetooth
instead of Aux-in. Pause the Bluetooth source and Aux-in
audio will be heard in a moment.
Pairing is the set-up process to introduce your Bluetooth-capable device to the iBT15. Once your device is paired,
the iBT15 can recognize it and you can play your audio through it.
1. Make sure your Bluetooth device is fully charged. Turn on your Bluetooth device and make it
“discoverable” by turning on Bluetooth mode (check in Options or Settings).
2. Press the
Power/End Call Button to turn on the iBT15. The first time the unit is powered
on, it will enter auto-pairing mode and attempt to connect to a Bluetooth device. Otherwise,
follow step 3 to begin pairing.
3. Press and hold the Talk/Bluetooth/Play/Pause Button on the right of the unit for 2
seconds. The unit will beep twice and the status indicator LED will flash blue, indicating the
unit is in pairing mode.
4.
“iHome iBT15” should appear in your device’s Bluetooth menu. If “Not Paired”, “Not Connected” or similar
message appears, select “iHome iBT15” to connect it. If prompted for a passcode, enter “1234” on your
device’s keypad.
9
7
8
6
2
3
4
5
iBT15
Meet Your iBT15
Aux-in Jack
Left Side
Splash-resistant Cover
Reset Button
(insert
paperclip to
reset unit)
USB Charging
Port
Right Side
Power/End Call
Button
Talk/Bluetooth Pairing/
Play/Pause Button
– Volume Button
+ Volume Button
iBT15
Microphone
Status indicator LED
Status indicator Status
Solid red LED
Solid blue LED
Flashing red LED
Quickly flashing blue LED
Slowly flashing blue LED
Unit is charging
Unit needs charging
Active Bluetooth connection / Aux mode
Unit is attempting to pair with Bluetooth device
Unit is attempting to auto link to already
paired Bluetooth device
Top
Getting Started: Carabiner & Carry Strap
The iBT15 has a built-in carbiner clip and comes with a carry strap for easy
carrying or attaching to a backpack, shower head, etc.
To attach the carry strap, form a small loop in one end of the strap. Insert this
loop through the carabiner on top of the unit, then pull the loop back through
the larger loop formed in the carry strap to tighten.
Getting Started: Charging the Unit
Charge unit before use. For first time charge, charge for at least 4
hours.
Pull back splash-proof seal and connect the included micro USB cable to the
USB Charging Port on the left side of the unit and connect the other standard
USB plug to a computer, USB AC adaptor (not included) or other USB power
source. The status indicator glows solid red while charging and turns off once
charged.
Using the iBT15
Computer USB port
Computer
connected to
working outlet
USB AC adaptor
(not included) USB AC adaptor
connected to
working outlet
OR
5. Once pairing is successful, a tone will sound and the Bluetooth indicator light will glow solid, indicating the
iBT15 is ready to play music. There should also be an indication on your device. If no device is successfully
paired within 3 minutes the iBT15 will default to previous mode. Once the iBT15 is paired to a device, it will
attempt to autolink when the device is within range (about 30 feet).
Pairing Your Device
For iPhone
iHome iBT15 iHome iBT15
iHome iBT15 iHome iBT15
For other
Using the iBT15
Pairing with a Different Device
When you power ON the speaker, it will automatically link with the previously paired Bluetooth device
as long as that device is still within range (approx. 30 feet). To pair with a different device follow steps
1 - 4 under ”Pairing Your Device” on previous page.
Playing Audio Via Bluetooth
1.
Press the
Power/End Call
Button
to turn on the unit. The status indicator will glow solid blue when
a linked device is in range and detected. You can then listen to audio streamed wirelessly from your
paired iPad, iPhone, iPod or other Bluetooth device.
2. Press the Talk/Bluetooth/Play/Pause Button to play audio from your device. Press again to pause
play and once more to resume play. When Bluetooth audio is active, the status indicator will glow
solid blue.
3. Use menu and track controls on your Bluetooth device to navigate tracks.
4. Press the – or + Button to adjust the iBT15 volume. A confirmation tone will sound when minimum or
maximum volume is reached. You can also adjust volume on your device.
5. When done listening, press the Power/End Call Button to turn the unit OFF. Remember to turn off
your device, too.
Speakerphone Operation
NOTE: The unit must be powered and linked to a Bluetooth phone to receive a call.
1. When a call is received, playing music is muted to hear the ring tone. Press the Talk/
Bluetooth/Play/Pause Button to answer the call, or press the Power/End Call Button to ignore it.
For call waiting function, use phone controls on your device.
2. When a call is completed, press the Power/End Call Button to end the call and resume previous
function.
Using the iBT15
Mobile Phone Game Devices iPod Laptop
PC/Tablet MP3/MP4
Using the iBT15
Unit doesn’t respond (no power)
• Check that unit is fully charged.
• Make sure your device is properly paired with the iBT15.
• Make sure the Power is ON.
Unit doesn’t respond (locked up or frozen)
If the unit does not respond, insert the end of a paperclip or similar into the Reset Button located under
the splash proof cover to reset the unit.
Resetting Bluetooth
If Bluetooth function is not operating properly, you may wish to reset Bluetooth. To do so, press and hold
the Power/End Call Button for 10 seconds. You will hear a long high tone. You will need to re-pair
your paired devices.
Trouble pairing device/computer with iBT15
Bluetooth implementation varies depending on your device’s hardware and operating system. Please see
our website for updates on pairing.
• Make sure you have the latest firmware for your device.
• Make sure your device is working properly. Check your device’s manual for details on Bluetooth
pairing and linking.
• When you power ON the speaker, it will automatically link with the last previously paired Bluetooth
device if the device is still within range (approx.30 feet). To pair with a different device press and hold
the Talk/Pairing/Play/Pause Button for 2-3 seconds.
For further information and to see the latest instructions, visit www.ihome.com/support
8
Troubleshooting
TIP: On some iOS (Apple) devices,
you can view the iBT15 battery
status on your deviceʼs screen.
When device is paired and
connected, look for a vertical
battery icon next to
the Bluetooth icon on
the upper right corner
of the deviceʼs screen.
Press the
Power/End Call
Button
to turn ON or OFF.
The unit will respond in a moment.
Drop+
6/20/2107
6/20/2107
6/23/2107
6/23/2107
Model: iBT15(USA)
Model: iBT15N(CANADA)
6/23/2107
