SDI Technologies IBT33V3 Portable Rechargeable Bluetooth Stereo Speaker User Manual iBT33V3 IB EN 1014
SDI Technologies Inc. Portable Rechargeable Bluetooth Stereo Speaker iBT33V3 IB EN 1014
User Manual
Model: iBT33(USA)
iBT33V3 (CANADA)
instruction manual
iBT33v3 IB (English) water proof
Size: 153mm x 120mm
Printing color: Black
Oct 14, 2016 P1
Waterproof Rechargeable
Bluetooth Stereo Speaker
CHARGE
BEFORE
USE
Questions? Contact Customer Service at 1-800-288-2792
Limited 1 Year Warranty
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free from defects in
workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original purchase.
Should this product fail to function in a satisfactory manner, it is best to first return it to the store where it was originally purchased. Should
this fail to resolve the matter and service still be required by reason of any defect or malfunction during the warranty period, SDI will
repair or, at its discretion, replace this product without charge. This decision is subject to verification of the defect or malfunction upon
delivery of this product to the Factory Service Center authorized by Customer Service.
If service is required, please call Customer Service at 1-800-288-2792 to obtain a Return Authorization Number and shipping
instructions. A copy of the sales receipt is required to validate in-warranty coverage.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not cover (i) products which
have been damaged by negligence or willful actions, misuse or accident, or which have been modified or repaired by unauthorized
persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii) damage to digital media players, CD’s or tape cassettes
(if applicable); (iv) the cost of shipping this product to the Factory Service Center and its return to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the product other than to the original
purchaser. In no event will SDI or any of its affiliates, contractors, resellers, their officers, directors, shareholders, members or agents be
liable to you or any third party for any consequential or incidental damages, any lost profits, actual, exemplary or punitive damages.
(Some states do not allow limitations on implied warranties or exclusion of consequential damages, so these restrictions may not apply
to you.) This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Your acknowledgment and agreement to fully and completely abide by the above mentioned disclaimer of warranty is contractually
binding to you upon your transfer of currency (money order, cashier's check, or credit card) for purchase of your SDI product.
© 2016 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
iBT33V3-161014-B Printed in China
P17
9/19/2016
10/14/2016
10/14/2016
1
iBT33
IMPORTANT INFORMATION ABOUT WATERPROOF OPERATION
For proper waterproof operation, make sure the waterproof cover on back of the unit is completely
flush with the unit by pressing along the entire edge of the cover until it is completely and securely in
place
• The unit is IP67 waterproof rated, meaning it is immersible for up to 30 minutes at a depth of 1 meter
(3 feet). It will typically withstand rain, snow and being submersed in shallow water. Longer duration or
deeper immersion that exceeds the tested limits may cause product failure and void the warranty.
• DO NOT immerse the unit in water for extended periods.
• DO NOT immerse the unit in water deeper than 1 meter (about 3 feet).
• Make sure cover and surrounding surfaces are completely dry before opening cover to prevent moisture
from damaging the internal electronics.
• Keep rubber cover free of dirt, sand, or other objects that can interfere with proper sealing. If for any
reason the waterproof cover is not making a tight waterproof seal water may enter the unit.
• Rinse with tap water after immersion in salt water or swimming pool.
• DO NOT clean unit with oily soaps or use chemicals or solvents. Clean with damp cloth.
water
tight
not
water
tight
iBT33
Introduction
2
Thank you for purchasing the iHome iBT33. This product is designed to provide high quality wireless
sound for your Bluetooth audio device and for waterproof, dustproof and shock proof operation.
This instruction booklet explains the basic operation and care of the unit. Please read carefully and keep
for future reference.
Maintenance
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other
protective material should be placed between it and the furniture.
• Clean your unit with a damp cloth only. Strong cleaning agents, such as thinner or similar materials can
damage the surface of the unit.
iBT33
Table of Contents
3
Included ............................................................................................................................ 4
Meet Your iBT33................................................................................................................. 5
Charging the Unit................................................................................................................ 6
Pairing Your Device.............................................................................................................. 7
Pairing with a Different Device ............................................................................................... 8
Playing Audio Via Bluetooth................................................................................................... 8
Speakerphone Operation...................................................................................................... 9
Playing Audio Via Aux In .................................................................................................... 10
Internal Rechargeable Lithium-ion Battery................................................................................ 11
Consumer Product Safety Guide.......................................................................................12-13
FCC Information................................................................................................................ 14
Troubleshooting................................................................................................................. 15
Warranty......................................................................................................................... 16
iBT33
4
Included
• iBT33 unit
• USB charging cable
• Audio cable
iBT33 USB charging cable audio cable
Meet Your iBT33
iBT33
5
Back
Top Panel
Front
Volume – /Volume + Buttons
Battery Level Meter
Microphone
(behind grille)
Power Button
REV/FWD
End/Answer Call Buttons
Play/Pause/Pairing Button
Bluetooth Status
Indicator Light
Aux-in Jack Reset port
Waterproof cover
Micro USB Charging/
Audio-in Port
Charging the Unit
CHARGE UNIT BEFORE USE
1. Connect the micro USB plug to the micro USB charging port on the back of the unit.
2. Connect the standard USB plug end of the cable to a power USB port on a computer or other USB
charging device. For first time use, charge unit for about 8 hours.
3. The Battery Level Meter on the front of the unit flashes while the unit is charging and turns solid
once the unit is fully charged. See table above for charge status information.
6
Using the iBT33
NOTE: The white, 4 segment Battery Level Meter on the front of the unit is activated when the unit
is ON or when connected to a charging source via the USB cable.
iHome iBT33 USB port
Charge via computer USB port, USB AC adaptor or other powered USB port
Computer connected
to working outlet Computer USB port
USB AC adaptor (not included)
Battery Charge Status
100% charged
dead, needs charge
low, needs charge
60 - 99% charged
46 - 60% charged
Pairing is the set-up process to introduce your Bluetooth-capable device to the iBT33. Once your device is
paired, the iBT33 can recognize it and you can play your audio through it.
1. Make sure your Bluetooth device is fully charged. Turn on your Bluetooth device and
make it “discoverable” by turning on Bluetooth mode (check in Options or Settings).
2. Press the Power Button to turn on the iBT33. The first time the unit is powered
on, it will enter auto-pairing mode and attempt to connect to a Bluetooth device (if
so, skip to step 4). Otherwise, follow step 3 to begin pairing.
3. Press and hold the Play/Pause/Pairing Button for 2 seconds. The iBT33 will
beep and the Bluetooth status indicator light on front of the unit will flash quickly.
4. “iHome iBT33” should appear in your device’s Bluetooth menu. If “Not Paired”, “Not Connected” or
similar message appears, select “iHome iBT33” to connect it. If prompted for a passcode, enter
“1234” on your device’s keypad.
Using the iBT33
7
5. If pairing is successful, 1 beep will sound and the Bluetooth status indicator light will appear solid blue,
indicating the iBT33 is ready to play music. There should also be an indication on your device. If no
device is successfully paired within 3 minutes the iBT33 will default to previous mode. Once the iBT33 is
paired to a device, it will attempt to autolink when the device is within range (about 30 feet).
Pairing Your Device
For iPhone
iHome iBT33 iHome iBT33 iHome iBT33 iHome iBT33
For other
Pairing with a Different Device
When you power ON the unit, it will automatically link with the previously paired Bluetooth device as long
as that device is still within range (approx. 30 feet). To pair with a different device follow steps 1 - 4 under
”Pairing Your Device” on previous page.
Playing Audio Via Bluetooth
1. Press the Power Button to turn on the unit. The status indicator will glow solid blue when a linked
device is in range and detected. You can then listen to audio streamed wirelessly from your paired
Bluetooth device.
2. Press the Play/Pause/Pairing Button to play audio from your device. Press again to pause play
and once more to resume play. When Bluetooth audio is active, the status indicator will glow solid
blue.
3. Press the << REV or >> FWD Buttons to go to the beginning or end of the current track. Press again to
go to the previous or next track. You can also use menu and track controls on your Bluetooth device to
navigate tracks.
4. Press t
he – or + Button to adjust
the iBT33 volume. You can also adjust volume on your device.
5. When done listening,
press the Power Button
to turn the unit OFF.
Using the iBT33
8
NOTE: The unit must be powered on and linked to a Bluetooth phone to receive a call.
1. When a call is received, playing music is muted to hear the ring tone. Press
thexxxxxxFWD/Answer Call Button to answer the call, or press the REV/End Call Button
to ignore it. For call waiting function, use phone controls on your device.
2. When a call is completed, press the REV/End Call Button to end the call and resume
previous function.
Using the iBT33
9
Speakerphone Operation
Playing Audio via Aux In
1. Connect one end of the included 3.5mm stereo
audio cable to the Aux-in jack on the back of the unit
and connect the other end to the headphone or
line-out jack on your audio device.
2. Press the Button on the unit to turn it on.
3. Power on the audio device and use the controls on
the device to play or pause audio, and navigate
tracks.
4. Press t
he – or + Button to adjust the system volume
.
You can also adjust volume on your device.
5. When done listening, press the Button to turn the
unit OFF. Remember to turn off your device, too.
Using the iBT33
10
Mobile Phone Game Devices iPod Laptop
PC/Tablet MP3/MP4
11
Internal Rechargeable Lithium-ion Battery
This device uses an internal non-replaceable rechargeable lithium-ion battery that should last the lifetime of the device. If you
suspect your battery may be dead, try charging it for an extended period of time and try resetting the unit. If this fails, contact
Customer Service at 1-800-288-2792
.
WARNING/DISPOSAL OF UNIT
Do NOT attempt to change the battery. Doing so will void the warranty and could cause injury and damage to your device.
To dispose of the unit, follow the instructions below:
• Never dispose of used batteries/electronics with ordinary solid wastes, since they contain toxic substances.
• Always dispose of used batteries/electronics in accordance with the prevailing community regulations.
• Many electronics retailers now recycle batteries and other electronic components at no charge
GENERAL BATTERY PRECAUTIONS
• Never use or charge a battery if it appears to be leaking, discolored, deformed, or in any way abnormal.
• Never disassemble the unit or attempt to remove battery as that could cause leakage of alkaline solution or other electrolytic
substances.
• Avoid charging a rechargeable battery when the temperature is not within 5°C - 35° C (41° - 95° Fahrenheit).
• Never expose a battery to any liquid.
• Never expose a battery to excessive heat such as direct sunlight or fire. Never use a battery pack in an unventilated vehicle where
excessive internal temperatures may be encountered.
• Always keep batteries out of the reach of infants and small children.
When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result
in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these
instructions handy for future reference. Take special note of all warnings listed in these instructions and on the unit.
1. Water and Moisture – This unit is rated iP67 (will withstand submersion for 30 minutes at a depth of 1 meter (3 feet)), but should not be operated
under water. It is also dustproof.
• Waterproof door cover must be properly sealed before use near water.
• Dry unit completely before opening waterproof door cover.
• Do NOT open waterproof door cover if wet or in a wet environment.
2. Ventilation – The unit should be situated so that its location or position does not interfere with its proper ventilation. For example, it should not be
situated on a bed, sofa, rug or similar surface that may block ventilation openings. Also, it should not be placed in a built-in installation, such as
a bookcase or cabinet, which may impede the flow of air through the ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators, heat registers, stoves or other appliances (including amplifiers) that
produce heat.
4. Power Sources – The unit should be connected to a power supply only of the type described in the operating instructions or as marked on the
appliance.
5. Power-Cable Protection – Power supply cables should be routed so that they are not likely to be walked on or pinched by items placed upon or
against them.
6. Cleaning – The unit should be cleaned only using a warm damp cloth. Do not use solvents, etc.
7. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled into any openings or vents located on the
product.
8. Attachments – Do not use attachments not recommended by the product manufacturer.
9. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect the antenna or cable system during a lightning
storm or when it is left unattended and unused for long periods of time. This will prevent damage to the product due to lightning and power-line
surges.
10. Overloading – Do not overload wall sockets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric
shock.
11. Damage Requiring Service – The unit should be serviced by qualified service personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure..
C. the unit has been dropped or the enclosure damaged.
D. the unit exhibits a marked change in performance or does not operate normally.
12. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as a month or longer, make sure to charge the unit before
storing and periodically during storage to maintain battery
13. Servicing – The user should not attempt to service the unit beyond those methods described in the user’s operating instructions. Service methods
not covered in the operating instructions should be referred to qualified service personnel.
Consumer Product Safety Guide
12
IMPORTANT SAFETY INSTRUCTIONS
iBT33
FCC Information
This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Radiation Exposure Statement
• Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
FCC ID:EMOIBT33V3
IC:986B-IBT33V3
14 Declaration ID:D025616
This equipment should be installed and operated with a minumum distance of 20 cm between the radiator and your body.
Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre corps.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Unit doesn’t respond (no power)
• Make sure unit is completely charged.
• Check that all connections are correct and properly plugged in.
• Make sure your device is properly paired with the iBT33.
• Make sure the unit is on
Unit doesn’t respond (locked up/ “frozen”)
If the unit does not respond, try resetting the unit. Insert a paperclip or similar into the Reset port located
on back of the unit for about 10 seconds. Note that doing so will clear settings, and any Bluetooth devices
will need to be re-paired.
Trouble pairing device/computer with iBT33
Bluetooth implementation varies depending on your device’s hardware and operating system. Please see
our website for updates on pairing.
• When you power ON the speaker, it will automatically link with the last previously paired Bluetooth
device if the device is still within range (approx. 30 feet). To pair with a different device you must turn
off Bluetooth capability on the already paired device, or take it out of range.
• If your device does not auto-link when within range, re-pair the device. To do so, first delete the iBT33
from your Bluetooth devices menu.
• Make sure your device is working properly. Check your device’s manual for details on Bluetooth pairing
and linking.
For further information and to see the latest instructions, visit www.ihome.com/support
15
Troubleshooting
