SDI Technologies IBT5880 Rechargeable Bluetooth Color Changing Speaker User Manual iBT5880 draft QSG ENG 060818
SDI Technologies Inc. Rechargeable Bluetooth Color Changing Speaker iBT5880 draft QSG ENG 060818
User Manual
Color: print Black and PMS 7694C (2C + 1C) in white card
iBT5880 QSG (English)
Size: 280 x 160 mm (folded: 140 x 160 mm)
Material: 260gsm Art Card
June 8, 2018
FRONT
Back
QUICK START GUIDE
In the Box » iBT5880 speaker
» » USB Charging cable USB AC adaptor
Rechargeable Bluetooth
Color Changing Speaker
Model: iBT5880
iHome
iBT5880
BLUETOOTH: PAIRING & PLAYING
Manual Pairing
Pairing the First Time
iHome
iBT5880
2s
2s
FRONT BACK
CHARGE UNIT
BEFORE USE
ABOUT 5 HOURS
Power
Button
(press to power on,
press and hold to power o)
Charge Indicator
Red = charging
Green = charged
Bluetooth Indicator
Solid = Bluetooth
Flashing = pairing
Play/Pause/
Bluetooth
Button
Color Mode
Button
Back/Forward
Buttons
Talk/End
Button
For full warranty
visit: www.ihome.com/support
USING SPEAKERPHONE
Answer Call End/Decline Call
BLUE LIGHT RED LIGHT GREEN LIGHT
FLASHING COLORS (speed depends on volume) OFF
Aux-in
Jack
Charge via USB AC adapter (included)
or other powered USB port
Raise/Lower
Volume Buttons
USB in
Charging Port
Reset Port
(insert paper clip or
similar to reset unit)
» Make your Bluetooth device “discoverable”
» Press the Power Button to turn on speaker. The unit will attempt to link to a paired
device. If none found, the speaker enters pairing mode.
» Select “iHome iBT5880” on your device’s Bluetooth menu to complete pairing.
» To manually pair, power on speaker then press and hold Bluetooth Button for 2 seconds.
» Select “iHome iBT5880” on your device’s Bluetooth menu to complete pairing.
» Press Play/Pause Button to play or pause Bluetooth audio.
» Press Button to skip to next track. Press Button to return to start of current track
or go to previous track
» Press +/– Buttons to adjust speaker volume
» The speaker must be on and connected with a paired Bluetooth device to recieve calls.
» Press the Talk/End Button to answer incoming call. Press again to end/decline call.
Press and hold to redial the previous call.
AUX-IN
» To play aux audio, connect a standard audio cable (not included) to the headphone jack
of your audio device and connect the other end to the aux-in jack on iBT5880.
» Press the Power Button to turn on speaker.
» Use controls on your device to listen to audio.
» Bluetooth audio will be disabled while aux-in audio cable is connected
COLOR CHANGING MODE
» Press and hold the Power Button to power on the iBT5880.
» Press the Color Mode Button as needed to cycle through the below modes:
Contact Us: 1• 800• 288•2792
FCC Information
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.
• Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following
two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts
de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
le dispositif a été évalué à satisfaire l'exigence générale de l'exposition aux rf.
l'appareil peut être utilisé dans des conditions d'exposition portatif sans restriction.
Model: iBT5880
FCC ID:EMOIBT5880
IC:986B-IBT5880
Printed in China
iBT5880-180611-A
Internal Rechargeable Lithium-ion Battery
inside pageinside page
This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. WARNING/DISPOSAL OF UNIT
Do NOT attempt to change the battery. Doing so will void the warranty and could cause
injury and damage to your device.
To dispose of the unit, follow the instructions below:
• Never dispose of used batteries/electronics with ordinary solid wastes, since they
contain toxic substances.
• Always dispose of used batteries/electronics in accordance with the prevailing
community regulations.
• Many electronics retailers now recycle batteries and other electronic components at no
charge.
GENERAL BATTERY PRECAUTIONS
• Never use or charge a battery if it appears to be leaking, discolored, deformed, or in any
way abnormal.
• Never disassemble the unit or attempt to remove battery as that could cause leakage of
alkaline solution or other electrolytic substances.
• Avoid charging a rechargeable battery when the temperature is not within 5°C - 35°C
(41° - 95° Fahrenheit).
• Never expose a battery to any liquid.
• Never expose a battery to excessive heat such as direct sunlight or fire. Never use a
battery pack in an unventilated vehicle where excessive internal temperatures may be
encountered.
• Always keep batteries out of the reach of infants and small children.
This device uses an internal non-replaceable rechargeable lithium-ion battery that should
last the lifetime of the device. If you suspect your battery may be dead, try charging it for
an extended period of time and try resetting the unit. If this fails, contact Customer
Service at 1-800-288-2792.
IMPORTANT SAFETY INSTRUCTIONS
When used in the directed manner, this unit has been designed and manufactured to ensure your personal
safety. However, improper use can result in potential electrical shock or fire hazards. Please read and follow
all safety and operating instructions carefully before installation and use, and keep these instructions handy
for future reference. Take special note of all warnings listed in these instructions and on the unit.
1. Water and Moisture – The unit should not be used near water. For example: near a bathtub, washbowl,
kitchen sink, laundry tub, swimming pool or in a wet basement.
2. Ventilation – The unit should be situated so that its location or position does not interfere with its proper
ventilation. For example, it should not be situated on a bed, sofa, rug or similar surface that may block
ventilation openings. Also, it should not be placed in a built-in installation, such as a bookcase or cabinet,
which may impede the flow of air through the ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators, heat registers, stoves or
other appliances (including amplifiers) that produce heat.
4. Power Sources – The unit should be connected to a power supply only of the type described in the
operating instructions or as marked on the appliance. Only use the AC adapter that came with the unit.
5. Power-Cable Protection – Power supply cables should be routed so that they are not likely to be walked
on or pinched by items placed upon or against them. It is always best to have a clear area from where
the cable exits the unit to where it is plugged into an AC socket.
6. Cleaning – The unit should be cleaned only using a warm damp cloth. Do not use solvents, etc.
7. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled
into any openings or vents located on the product.
8. Attachments – Do not use attachments not recommended by the product manufacturer.
9. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect the antenna
or cable system during a lightning storm or when it is left unattended and unused for long periods of
time. This will prevent damage to the product due to lightning and power-line surges.
10. Overloading – Do not overload wall sockets, extension cords, or integral convenience receptacles as
this can result in a risk of fire or electric shock.
11. Damage Requiring Service – The unit should be serviced by qualified service personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
12. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as a month or
longer, the backup battery should be removed from the unit to prevent damage or corrosion.
13. Servicing – The user should not attempt to service the unit beyond those methods described in the
user’s operating instructions. Service methods not covered in the operating instructions should be
referred to qualified service personnel.
14. Magnetic Interference: This product’s speakers contain powerful magnets which could cause interference
or damage to sensitive equipment such as hard drives, CRT televisions and monitors, as well as medical,
scientific, and navigational devices. Keep this unit away from these products at all times.
Bluetooth is a registered trademarks of Bluetooth SIG Inc.
Bluetooth technology is incorporated under license from Bluetooth SIG Inc.
