SDI Technologies IHV110 Bluetooth Sport Earbuds User Manual iHv115 QSG 062018
SDI Technologies Inc. Bluetooth Sport Earbuds iHv115 QSG 062018
user manual
Inside pageInside page
Model: iHv115
Quick Start Guide
BC
Questions? Visit www.ihome.com/support
or call 1-800-288-2792 Toll Free
iHv115 - QSG (English Only)
Bluetooth Wireless
Sport Earbuds
R
• Bluetooth Wireless Sport
Earbuds with control dongle
• Silicon Ear Cushions
• USB Charging Cable
What’s Included:
Front CoverBack Cover
FCC ID: EMOIHV110
Printed in China
iHv115-062018-A
iHv115 - QSG (English only)
Size: 260 x 160 mm (unfold), 130 x 160 mm (folded)
Color: 1C + 1C
Material: 100gsm Wood free Paper
Jun. 20, 2018
GETTING STARTED BLUETOOTH
EAR CUSHIONS
Basic Controls
Charging your earbuds
Earbuds must be charged before use.
• Connect small plug of USB charging cable to USB port and
connect the other end to a powered USB port.
• Indicator will glow red while charging and turn off once charged.
• Earbuds should provide about 4 hours of audio when fully charged.
MultiFunction (MF) Button
Plus Button
•Press and hold 2-3 seconds
power earbuds ON or OFF
•Press and hold 7 seconds
power ON and enter pairing
mode (blue and red LEDs flash)
•Short press
play/pause/resume audio
•Short press
answer/end calls
•Short press
next track
•Press and hold
increase volume
iHv110
Note: Noise isolation ear buds like the Bluetooth Wireless Sport Earbuds are
designed to provide a good seal in your ears and block outside sounds. You
should not use noise isolation ear buds in situations that require you to hear
outside warning sounds.
Pairing establishes a unique communication connection between your Bluetooth
device and the earbuds. Once paired, you will be able to stream audio wirelessly to
your Bluetooth Wireless Sport Earbuds.
1
The FIRST TIME EARBUDS ARE POWERED ON they enter
auto-pairing mode. The LED indicator on the dongle will flash blue
and red.
The Bluetooth Wireless Sport Earbuds come with 3 sets of ear
cushions to ensure a satisfying fit. If the current ear cushions do not
suit you, remove them and replace with smaller or larger ear
cushions.
SPEAKERPHONE
Press the MultiFunction Button to answer or end a call.
Press and hold for 2 seconds to decline/ignore an incoming call.
2
Turn on Bluetooth mode on your device (under Settings,
Connections or similar).
3 Select “iHv115” on your device’s menu of Bluetooth devices. When
pairing is successful, the LED will glow solid blue. If prompted for
a password, enter “0000” on your device. You can now begin to
stream audio and calls from your device.
4 For manual pairing or to pair other devices, press and hold the
MultiFunction Button for 7 seconds. The earbuds will power on,
attempt to autolink to a previously paired device, then enter
pairing mode. Pair your device per step 3 above.
Front
Cover
2-3s
LED Indicators
Microphone (on back side of dongle)
USB Charging Port
7s
For warranty information:
visit https://www.ihome.com/support
FCC Information
• Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT SAFETY INSTRUCTIONS
When used in the directed manner, this unit has been designed and manufactured to ensure your
personal safety. However, improper use can result in potential electrical shock or fire hazards. Please
read and follow all safety and operating instructions carefully before installation and use, and keep
these instructions handy for future reference. Take special note of all warnings listed in these instructions
and on the unit.
Water and Moisture – The unit should not be used near water. For example: near a bathtub, washbowl,
kitchen sink, laundry tub, swimming pool or in a wet basement.
Cleaning – The unit should be cleaned only with dry cloth. Do not use solvents, etc
Heat – The unit should be situated away from heat sources such as radiators, heat registers, stoves or
other appliances (including amplifiers) that produce heat.
Only use attachments/accessories specified by the manufacturer.
Damage Requiring Service – The unit should be serviced by qualified service personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
Attention should be drawn to the environmental aspects of battery disposal.
This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This device complies with Industry Canada’s licence-exempt RSSs.
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of
the device.
Minus Button
•Short press
restart track
•Short press x2
previous track
•Press and hold
lower volume
•Press and hold
for 3 seconds
during pairing
mode to reset
Bluetooth
iHome
