SDI Technologies IHV310 Bluetooth Speaker User Manual iHv310 QSG v6

SDI Technologies Inc. Bluetooth Speaker iHv310 QSG v6

User Manual

Front CoverBack Cover
Inside page
Model: iHv310
Quick Start Guide
FCC ID: EMOIHV310
Questions? Visit www.iHome.com/support
or call 1-800-288-2792 Toll Free
Printed in ChinaiHv310-051718-A
iHV310 - QSG (English only)
Size: 260 x 160 mm (unfold), 130 x 160 mm (folded)
Color: 1C + 1C
Material: white Art paper
Jun. 4, 2018
iHV310 - QSG (English only)
GETTING STARTED BLUETOOTH
AUX-IN
Basic Controls & Functions
Charging your speaker
Speaker must be charged before use (about 3 hours).
• Connect small plug of the included USB charging cable to
USB port located on the left bottom side of the speaker
and connect the other end to a powered USB port.
• Indicator will glow red while charging and turn off once charged.
• Speaker should provide about 4 hours of audio when fully charged.
iHome iHv310
Pairing establishes a unique communication connection between your Bluetooth
device and the speaker. Once paired, you will be able to stream audio wirelessly to
your Bluetooth Wireless Speaker.
1
When the speaker is powered ON it enters auto-link mode,
searching for a previously connected Bluetooth device. If none is
found, the unit switches to auto-pairing mode. The LED indicator
beside the USB port will flash blue and tones will sound.
Connect a standard 3.5 mm audio cable (not included) to the aux-in
jack located at the left bottom of the speaker under the water
resistant cover and connect the other end to the headphone jack on
your audio device. Power on the speaker. The LED indicator will
slowly flash blue. Press the Mode Button as needed to switch
from Bluetooth to Aux mode. NOTE: While using Aux-in, Bluetooth
connection is disabled and media playback and volume adjustment
must be controlled using your audio device.
SPEAKERPHONE
Press the Play/Pause/Call Button to answer or end a call.
Press and hold for 2 seconds to decline/ignore an incoming call.
2
Turn on Bluetooth mode on your device (under Settings,
Connections or similar).
3 Select “iHv310” on your device’s menu of Bluetooth devices. When
pairing is successful, the LED will turn solid blue. If prompted for a
password, enter “0000” on your device. You can now begin to
stream audio and calls from your device. The LED will slowly flash
blue when audio is playing.
4 Press Play/Pause/Call Button to play/pause/resume Bluetooth
audio.
Press and hold << or >> Buttons to adjust speaker volume.
5 To pair other devices, press and hold the M Mode Button for 3
seconds to disconnect current device. Pair the new device per
steps above.
Front
Cover
BC
CHARGE
BEFORE
USE
• Bluetooth Wireless Speaker
• USB Charging Cable
What’s Included:
Bluetooth Wireless Speaker
Right Side
ON/OFF
switch
Charging indicator
USB Charging Port
Aux-in jack
Short press
next track
Long press
raise volume
Short press
previous track
Long press
lower volume
Short press
Switch between Bluetooth
and Aux-in modes
Press and hold 6 seconds
clear Bluetooth pairing record
Left Side
Short press
play/pause/resume audio
Short press
answer/end calls
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT SAFETY INSTRUCTIONS
When used in the directed manner, this unit has been designed and manufactured to ensure your personal
safety. However, improper use can result in potential electrical shock or fire hazards. Please read and follow all
safety and operating instructions carefully before installation and use, and keep these instructions handy for
future reference. Take special note of all warnings listed in these instructions and on the unit.
Water and Moisture – The unit should not be used near water. For example: near a bathtub, washbowl, kitchen
sink, laundry tub, swimming pool or in a wet basement.
Cleaning – The unit should be cleaned only with dry cloth. Do not use solvents, etc
Ventilation The unit should be situated so that its location or position does not interfere with its proper
ventilation. For example, it should not be situated on a bed, sofa, rug or similar surface that may block ventilation
openings. Also, it should not be placed in a built-in installation, such as a bookcase or cabinet, which may
impede the flow of air through the ventilation openings.
“Heat – The unit should be situated away from heat sources such as radiators, heat registers, stoves or other
appliances (including amplifiers) that produce heat.”
“Damage Requiring Service – The unit should be serviced by qualified service personnel when:
A. objects have fallen into or liquid has been spilled into the enclosure.
B. the unit has been exposed to rain.
C. the unit has been dropped or the enclosure damaged.
D.. the unit exhibits a marked change in performance or does not operate normally”
Only use attachments/accessories specified by the manufacturer.
This device complies with Part 15 of the FCC Rules, operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This device complies with Industry Canada’s licence-exempt RSSs.
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
FCC Information
For warranty information:
visit https://www.ihome.com/support
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device can be used
in public exposure condition without restriction.
