SDI Technologies T332 Bluetooth Dual Alarm AM/FM Clock Radio User Manual T332 IB 012216
SDI Technologies Inc. Bluetooth Dual Alarm AM/FM Clock Radio T332 IB 012216
User Manual
T332 IB_US version
Size: 178 x 178 mm (16 pages)
Color: Black text on white paper
Material: 90gsm book paper
Jan. 22, 2016 P1
Model T332
Bluetooth Dual Alarm
AM/FM Clock Radio
For additional information, online registration,
and exclusive special offers visit our website:
Questions? Contact Customer Service at 1-800-888-4491
BT
BT
1
Table of Contents
What’s in the Box
What’s in the Box................................................................................................................................................................1
Product Care ......................................................................................................................................................................1
Controls Overview..............................................................................................................................................................2
Display................................................................................................................................................................................3
Installing and Replacing Backup Batteries .........................................................................................................................3
Set Up ................................................................................................................................................................................4
Setting the Time ..............................................................................................................................................................4-5
Setting and Using Alarms ................................................................................................................................................6-8
Setting Up and Using Bluetooth ......................................................................................................................................8-9
Setting and Using the Radio........................................................................................................................................10-12
Using in Aux-in Audio ..................................................................................................................................................12-13
Sleep Mode ......................................................................................................................................................................13
Dimmer.............................................................................................................................................................................14
Battery Information ...........................................................................................................................................................14
Safety Information ............................................................................................................................................................15
Troubleshooting................................................................................................................................................................16
Warranty Information ........................................................................................................................................................17
P2
Product Care
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective
material should be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzene,
thinner or similar materials can damage the surface of the unit.
This product ships with the following items. Make sure all are present.
1. T332 Alarm Clock 2. Instruction book
BT
BT
2
Controls Overview
Rear Panel
Top Panel
P3
Power/Mode/
Alarm Reset
Button
Alarm 1
Button
Snooze/Sleep
Display Dimmer
Button
Alarm 2
Button
Volume – /
Volume +
Buttons
Minute/FWD
Button
Hour/REV
Button
Clock/Preset
Button
Bluetooth
Pairing
Button
Aux-in jack
(Power cord not shown)
P
R
E
S
E
T
H
O
U
R
M
I
N
A
L
M
1
A
L
M
2
V
O
L
U
M
E
A
L
M
R
E
S
E
T
C
L
O
C
K
/
M
O
D
E
SNOOZE/SLEEP
BT PAIR
*
FM Antenna
BT BT
3
P4
Display
Installing and Replacing Backup Batteries
When lit,
indicates
Buzzer, Radio or
Bluetooth
as Alarm 2
source.
If neither is lit,
Alarm 2 is not
armed
When lit,
indicates
Buzzer, Radio or
Bluetooth
as Alarm 1
source.
If neither is lit,
Alarm 1 is not
armed When lit, indicates backup
batteries should be replaced
When lit, indicates linked
Bluetooth device. Fast ashing
indicates pairing attempt,
slower ashing for linking attempt
When lit,
indicates time
displayed is PM
Time display
Press
Your new Timex Clock Radio includes a battery backup system that will maintain the
time and alarm settings during a temporary power interruption.
1. Keep unit connected to AC power when changing batteries to avoid losing your
settings.
2. Press on the battery door locking tab to open and remove the battery door.
3. Check the correct polarity (+/ - ) markings in the battery compartment and install two
“AAA”batteries (not included).
4. Replace the battery door.
NOTE: With batteries installed, the display will turn off during a power failure but the
clock will continue to run and maintain your alarm settings.
21 3
Set Up
Connecting to Power Source
Connect the AC plug into a working wall outlet that is not controlled by a wall switch.
The unit does not operate on batteries (the battery back up system maintains clock
settings during power failures).
Turning the Unit ON or OFF
Make sure unit is OFF. To confirm unit is off, press and hold the Power/Alarm Reset
/Mode Button for 2 seconds until OFF appears on the display.
4
P5
Setting the Time
1
2 SECS
2 SECS
• Press and release the Power/Alarm Reset/
Mode Button on the unit at any time to turn the
unit On.
• Press and hold the Power/Alarm Reset /Mode
Button to turn the unit Off.
MODE
ALM RESET
MODE
ALM RESET
ON
MODE
ALM RESET
OFF
BT BT
BT BT
BT PAIR
*
AUX IN
5
P6
2 SECS
5
Press and release the Presets/Clock Button to complete time setting.
Press and hold the Presets/Clock Button until the time flashes on the
display.
3
2
Press and release the Hour/ Button to adjust the HOUR.
NOTE: The PM indicator will light when the hour is set for PM. There is no
AM indicator.
Press and release the Minute/ Button to adjust the MINUTES.
PM indicator
4
CLOCK/
PRESET
CLOCK/
PRESET
HOUR
MIN
BT BT
BT BT
BT BT
BT BT
P7
6
Setting and Using Alarms
1
Press and hold the Alarm 1 Button until “6:00” flashes on the display.
This unit has two independent alarms, Alarm 1 and Alarm 2. Each is set and
operates in the same way. Instructions below show Alarm 1. Follow the same
method to set Alarm 2.
2
Press and release the Hour/ Button to adjust the HOUR.
NOTE: The PM indicator will light when the hour is set for PM. There is no
AM indicator.
Press and release the Minutes/ Button to adjust the MINUTES.
3
2 SECS
HOUR
MIN
PM indicator
BT BT
BT BT
BT BT
P8
7
4
OR OR
Press and release the Alarm 1 Button to complete alarm time setting.
Disarm alarm
Set alarm to Bluetooth
Set alarm to Radio
Set alarm to Buzzer
Press and release the Alarm 1 Button repeatedly as needed to cycle
to desired alarm mode: Buzzer (default), Radio (last AM or FM station
played), Bluetooth or Off (alarm is no longer active). Note that the last
radio volume listened to will be the radio alarm volume.
To silence any sounding alarm and reset it come on the next day at the
same time, press and release either the Power/Alarm Reset /Mode
Button, Alarm 1 Button or Alarm 2 Button.
SELECTING YOUR ALARM SOURCE/DISARMING THE ALARM
RESETTING AN ALARM TO COME ON THE NEXT DAY
BT BT
Alarm set to Buzzer
Alarm set to Radio
Alarm set to Bluetooth
Alarm OFF
(no indicator)
BT
BT
BT
BT
SNOOZE/SLEEP
8
Press and release the Snooze/Sleep
Button when the alarm sounds to silence it
for 9 minutes. Snooze can be used several
times during alarm.
Press and release the Power/Alarm Reset/Mode Button as needed to
turn unit On and select Bluetooth mode.
Make sure your Bluetooth-enabled device is turned on and “discoverable”
(see your device’s manual for details). When “Timex T332” appears on your
device’s display along with “Not Paired” or similar message, tap on the
message to complete pairing. The message should change to “Timex T332
Connected”, indicating your device is paired and the Bluetooth indicator on
the display will change to solid.
2
3
Press and release the BT (Bluetooth) Pairing Button located on the back
of the unit. The indicator next to the Bluetooth icon will flash quickly on the
display.
Setting Up and Using Bluetooth
PAIRING A BLUETOOTH DEVICE
SNOOZE
1
BT BT
BT BT
BT PAIR
MUST FIRST ENTER
BT MODE TO PAIR
*
For iPhone
Timex T332 Timex T332
Timex T332 Timex T332
For other
9
P10
If needed, press and release the Volume - Button or Volume + Button to
adjust volume on the unit.
OR
Once your device is paired, it will link with the device when within range
(about 30 feet).
PLAYING BLUETOOTH AUDIO
PAIRING WITH A DIFFERENT DEVICE
3
CLOCK/
PRESET
To pair the unit with a different Bluetooth enabled device while your original
device is still within range, you may need to go to the Bluetooth screen on
your phone, select the original device and then select “Forget This Device”,
“Disconnect”, “Cancel”, etc. to un-pair the original device.
2
Use the controls on your Bluetooth device to select music, control playback
and adjust volume. You can also press and release the Presets/Clock
Button as needed to Play and Pause Bluetooth audio from your device.
1
Press and release the Power/Alarm Reset/Mode Button as needed to
turn unit On and select Bluetooth mode.
BT BT
10
P11
OR
AM
FM
Press and release the Power/Alarm Reset/Mode Button as needed to
turn unit On and select AM or FM radio band.
Press and release the Volume - Button or Volume + Button to adjust
radio volume.
TIP: Extend FM antenna for best reception.
2
OR
3
Press and release the Hour/ Button or Minute/ Button to tune radio
to a desired station. Press and hold to seek the next clear station.
Setting and Using the Radio
BASIC RADIO OPERATION
1
HOUR MIN
BT BT
BT BT
11
P12
AM
FM
This unit will store up to 20 station presets, 10 AM and 10 FM.
SETTING RADIO PRESETS
PRESET RADIO SETTING AND OPERATION
2 SECS
3
4
Press and hold the Presets/Clock Button to enter presetting mode.
CLOCK/
PRESET
OR
Press and release the Hour/ Button or Minute/ Button to select the
preset number you wish to assign (P01 - P10).
MIN
OR
2
Press and release the Hour/ Button or Minute/ Button to tune radio
to a station you want to assign to a preset. Press and hold to seek the next
clear station.
HOUR
HOUR
MIN
Press and release the Power/Alarm Reset/Mode Button as needed to
turn unit On and select AM or FM radio band.
1BT BT
BT BT
BT BT
12
P13
AUX IN
PRESET RADIO OPERATION
2
Press and release the Power/Alarm Reset/Mode Button as needed to
turn unit On and select AUX mode.
1
Connect a standard audio cable with 3.5mm plug (not included) to the AUX
IN jack located on the back of the unit and to the output/headphone jack of
your audio device.
Using Aux In Audio
5 Press and release the Presets/Clock
Button to confirm the preset number
(P01 - P10) you want to assign to the
current station. Continue steps 1- 4 to
set all desired presets.
To listen to a preset at any time, press and release the Presets/Clock
Button as needed to select the desired preset station.
Mobile Phone Game Devices iPod Laptop
PC/Tablet MP3/MP4
CLOCK/
PRESET
BT BT
13
P14
SNOOZE/SLEEP
OR
Sleep mode allows you to set the unit to turn off after a selected time
interval. It allows you to fall asleep while listening to the radio or a device
that is connected to the Aux In Jack.
NOTE: It will power off the Timex unit, but it will not power off your AUX
device.
Press and release the Snooze/Sleep Button in AM, FM, AUX or Bluetooth
mode to select the desired sleep interval: 90, 80, 70, 60, 50, 40, 30, 20, 10
minutes or OFF (turns unit off right away).
Sleep Mode
3
Control audio playback on your device, making sure output volume is
turned up. If needed, press the Volume - Button or Volume + Button to
adjust volume on the unit.
14
P15
SNOOZE/SLEEP
Press and hold the Snooze/Sleep Button to toggle display brightness between
high and low settings. Dimmer cannot be adjusted when alarm is sounding.
Dimmer
Battery Cautions and Tips
• Only use the recommended/supplied batteries or equivalent.
• Use alkaline batteries for longer life.
•
Do not mix old and new batteries, and do not mix alkaline, carbon-zinc or rechargeable
nickel-cadmium batteries.
• Insert batteries with proper polarity (+/–) as indicated.
• Remove exhausted batteries from product.
• Recharge rechargeable batteries under adult supervision.
• Do not attempt to recharge non-rechargeable batteries.
• Do not open batteries or heat them beyond normal ambient temperatures.
• To prevent battery leakage or damage remove batteries from a product if it will not be used for a
month or longer.
• Use extreme caution handling leaking batteries (avoid direct contact with eyes and skin). If battery
leakage comes in contact with eyes, IMMEDIATELY flush the eye with lukewarm and gently flowing
water for at least 30 minutes. If skin contact occurs, wash skin with clear water for at least 15
minutes. Seek medical attention if any symptoms occur.
• Store in cool, dry, ventilated area away from hazardous or combustible material.
• Do not dispose of batteries in the household trash or fire.
• Follow applicable laws and local regulations for the disposal and transportation of batteries.
2 SECS
When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety.
However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating
instructions carefully before installation and use, and keep these instructions handy for future reference. Take special
note of all warnings listed in these instructions and on the unit.
1. Water and Moisture – The unit should not be used near water. For example: near a bathtub, washbowl, kitchen sink,
laundry tub, swimming pool or in a wet basement.
2. Ventilation – The unit should be situated so that its location or position does not interfere with its proper ventilation.
For example, it should not be situated on a bed, sofa, rug or similar surface that may block ventilation openings. Also,
it should not be placed in a built-in installation, such as a bookcase or cabinet, which may impede the flow of air
through the ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators, heat registers, stoves or other appliances
(including amplifiers) that produce heat.
4. Power Sources – The unit should be connected to a power supply only of the type described in the operating
instructions or as marked on the appliance.
5. Power-Cable Protection – Power supply cables should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them. It is always best to have a clear area from where the cable exits the
unit to where it is plugged into an AC socket.
6. Cleaning – The unit should be cleaned only as recommended. See the Maintenance section of this manual for
cleaning instructions.
7. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled into any
openings or vents located on the product.
8. Attachments – Do not use attachments not recommended by the product manufacturer.
9. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect the antenna or cable
system during a lightning storm or when it is left unattended and unused for long periods of time. This will prevent
damage to the product due to lightning and power-line surges.
10. Overloading – Do not overload wall sockets, extension cords, or integral convenience receptacles as this can result
in a risk of fire or electric shock.
11. Damage Requiring Service – The unit should be serviced by qualified service personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
12. Antenna – Do not connect an external antenna to the unit (other than that provided).
13. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as a month or longer, the
power cable should be unplugged from the unit to prevent damage or corrosion.
14. Servicing – The user should not attempt to service the unit beyond those methods described in the user’s operating
instructions. Service methods not covered in the operating instructions should be referred to qualified service personnel.
15
P16
IMPORTANT SAFETY INSTRUCTIONS
16
FCC/IC Information
Troubleshooting
This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. This device complies with FCC radiation exposure limits set forth
for an uncontrolled environment.
• Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
P17
1. The unit does not power ON.
The unit is not connected to AC outlet, the AC outlet has no power, or is controlled by a wall switch that
is “OFF”. Check AC outlet and wall switch.
2. Alarm does not come on.
The alarm time AM or PM incorrectly set, Alarm was OFF, etc. Check alarm settings.
3. Low battery indicator is on.
Batteries have not been installed correctly in the battery compartment or the batteries may be weak or
exhausted. Try replacing batteries.
4. Poor FM Radio reception on certain stations.
Weak or distant station. Try adjusting the direction of the FM wire antenna.
5. Poor AM Radio reception on certain stations.
Weak or distant station. Rotate the unit to improve reception.
6. Unit shuts “Off” unexpectedly.
The unit is in Sleep Mode instead of the power ON mode, the unit was turned ON by an alarm and the
alarm time ended, or the AC outlet unit is connected to is controlled by a wall switch that is turned
OFF. Check mode on unit. Check wall switch. Turn unit on with Power Button.
17
P18
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102
RF exposure, users can obtain Canadian information on RF exposure and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la conformité à
l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et la conformité de rf.
Limited 90 Day Warranty Information
Timex Audio Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free
from defects in workmanship and materials, under normal use and conditions, for a period of ninety (90) days from the
date of original purchase.
Should this product fail to function in a satisfactory manner, it is best to first return it to the store where it was originally
purchased. Should this fail to resolve the matter and service still be required by reason of any defect or malfunction
during the warranty period, SDI will repair or, at its discretion, replace this product without charge. This decision is
subject to verification of the defect or malfunction upon delivery of this product to the Factory Service Center authorized
by Customer Service.
If service is required, please call Customer Service at 1-800-888-4491 for Return Authorization and shipping
instructions.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not cover (i)
products which have been damaged by negligence or willful actions, misuse or accident, or which have been modified
or repaired by unauthorized persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii) damage
to digital media players, CD’s or tape cassettes (if applicable); (iv) the cost of shipping this product to the Factory
Service Center and its return to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the product other than to
the original purchaser. In no event will SDI or any of its affiliates, contractors, resellers, their officers, directors,
shareholders, members or agents be liable to you or any third party for any consequential or incidental damages, any
lost profits, actual, exemplary or punitive damages. (Some states do not allow limitations on implied warranties or
exclusion of consequential damages, so these restrictions may not apply to you.) This warranty gives you specific legal
rights, and you may also have other rights which vary from state to state.
Your acknowledgment and agreement to fully and completely abide by the above mentioned disclaimer of warranty is
contractually binding to you upon your transfer of currency (money order, cashier's check, or credit card) for purchase
of your SDI product. © 2016 SDI Technologies, Inc. All rights reserved.
Questions? Visit www.timexaudio.com
or call 1-800-888-4491 Toll Free
TIMEX is a registered trademark of Timex Corporation in the United States and other countries
T332_012216-A
