SEGI A1000-2WSP Keyless Entry System User Manual
SEGI LIMITED Keyless Entry System Users Manual
SEGI >
Users Manual
Remote & Antenna FCC ID Number (US Only) IC ID Number (International Only)
2W902R-SP VA5REC500-2WSP 7087A-2WREC500SP
ANT-2WSP VA5A1000-2WSP 7087A-2WA1000SP
User Manual
By Firstech LLC, Version: 1.0
Applicable to the following remote(s);
2W902R-SP 2 Way 5 Button LED Remote
&
ANT-2WSP 2Way Antenna
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions;
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following conditions;
(1) This device may not cause harmful interference.
(2) This device may accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate this device.
WWW.COMPUSTAR.COM
2
Introduction ..................................................................................................................................................3
Warranty Coverage ......................................................................................................................................3
Quick Reference ...........................................................................................................................................4
Button Lock .................................................................................................................................................4
Full or Half Paging Mode ............................................................................................................................4
Valet Mode..................................................................................................................................................4
Remote Maintenance – Battery Replacement ...........................................................................................4
2 Way Remote Button Functions ...............................................................................................................5
Function Button Menu ................................................................................................................................6
Remote Option Menu Table .......................................................................................................................6
Remote LED Functions and Descriptions .................................................................................................6
Alarm LED Notifications ..............................................................................................................................7
1 Way Remote Button Functions ...............................................................................................................7
General System Functions .........................................................................................................................8
Sending Commands ...................................................................................................................................8
Receiving Commands .................................................................................................................................8
Active Lock/Arm and Unlock/Disarm ..........................................................................................................8
Passive Lock/Arm .......................................................................................................................................8
Automatic Transmission Remote Start Function .......................................................................................9
Manual Transmission Remote Start Function (Reservation Mode) ..........................................................9
Trunk Release ......................................................................................................................................... 10
Auxiliary Outputs/Window Roll-Down/Sliding Doors............................................................................... 10
Silent Arm/Disarm.................................................................................................................................... 10
Remote Mute ........................................................................................................................................... 11
Shock Sensor On/Off .............................................................................................................................. 11
Automatic Button Lock ............................................................................................................................ 11
Advanced System Functions ................................................................................................................... 12
Drive Lock/Ignition Controlled Door Locks .............................................................................................. 12
Turbo Timer Mode ................................................................................................................................... 12
2nd Car Mode (Multiple Vehicle Control) ................................................................................................. 12
RPS Touch and RPS (Remote Paging Sensor) ..................................................................................... 12
Secure Valet Switch ................................................................................................................................ 15
Timer Start Mode ..................................................................................................................................... 15
Cold/Hot Start Mode ................................................................................................................................ 15
Remote Coding / Programming Routine ................................................................................................ 16
Programming 2 Way 5 Button Remotes: ................................................................................................ 16
Remote Start Error Diagnostic ................................................................................................................ 16
Alarm Diagnostic ....................................................................................................................................... 17
Limited Lifetime Warranty ........................................................................................................................ 18
3
Introduction
Thank you for purchasing a Firstech system for your vehicle. In order to truly enjoy the benefits of this
system, we recommend that you thoroughly review the following manual. Please note that this manual
applies to the 2 Way 5 Button LED Remote (2W902R-SP) Regardless of whether you purchased the
ALARM IT, START IT, or MAX IT system. This manual also supports the 1WG7R-SP that is included in
your new RF Kit. Please note that there are certain features listed in this manual that may not be
available for your system. There may also be features listed in this manual that require additional
installation or programming before they become active. If you have any questions or concerns please
contact the original place of purchase. For further information you may also contact our customer support
center at 888-820-3690.
Warranty Coverage
Caution: The Manufacturer’s warranty will be voided if this product is installed by anyone other than an
Authorized Firstech dealer. For complete warranty details visit www.compustar.com or the last page of
this manual. Firstech remotes carry a 1 year warranty from original date of purchase. CompuStar Pro
remotes carry a 2 year warranty.
Warranty registration can be completed online by visiting www.compustar.com. Please complete the
registration form within 10 days of purchase. We do not include a mail in warranty registration card with
each unit – registration must be done online. To verify that an authorized dealer installed your system,
we highly recommend that you keep a copy of the original proof of purchase, such as the dealer invoice
in a safe place.
4
Quick Reference
Button Lock
The 2W902R-SP comes equipped with automatic button lock. This requires you to tap any button to
wake your remote up then tap the button for the function you are trying to activate. Button lock can be
turned off in your remote’s option menu.
Full or Half Paging Mode
The 2W902R-SP is shipped in Half Paging Mode. This means that the remote will only receive 2 Way
LED confirmations for remote start and lock and unlock. It will not receive 2 Way LED confirmations
when the alarm is triggered. To turn this feature on hold the buttons for 2.5 seconds to
enter the Remote Programming Menu. Tap the Lock <insert lock button icon> button to turn Full Paging
on. The remote will beep twice and LED flash red. You are now in Full Alarm and Starter Mode.
Valet Mode
When servicing or loaning your vehicle to others, the system should be placed in Valet Mode. Valet
Mode prevents the system from remote starting and disables all alarm functions. IMPORTANT: While in
Valet mode the remote will still control power lock and unlock systems. The parking lights will not flash.
The system can be put into valet one of three ways:
1. Turn the vehicle’s key to the ignition “on” position, tap the Function and Trunk buttons
<insert function + trunk button icons> at the same time for a half second. The parking lights
will flash once and/or siren chirp once to confirm the system is in valet mode. Repeat this process to take
the system out of valet mode. The parking lights will flash twice and/or siren chirp once to confirm the
system is out of valet mode. Please note the confirmation chirps from the 2 Way remote will be quieter in
Valet Mode.
2. If you do not have your remote control, you can put the system into valet by turning the ignition key
“on” and then “off” five times within 7 seconds. The parking lights will flash once to confirm the system is
in valet mode. Shortly after the first flash, the parking lights will flash twice. A remote control is required
to take the system out of valet mode.
3. If your system is set up for a secure valet option (optional), you will not be able to put the system into
valet until the proper code has been entered using the secure valet switch. The secure valet switch is the
small button with bright blue LED on the front and if installed is the only way to override the alarm and/or
remote start. Until programmed, the default code is (3, 3).
Removing System Out of Valet:
Tap the<insert function + trunk button icons> for a half second to remove the system out of Valet. On
starter and alarm/starter systems, you can turn the key to the Ignition On position and tap the foot brake
10 times. This will take your system out of Valet Mode. If this does not work you can also reprogram your
remote(s). See Remote Coding/Programming Routine section for details.
Remote Maintenance – Battery Replacement
The only regular maintenance this system requires is remote control battery replacement. No
programming is required when replacing the battery.
5
2W902R-SP:
Turn the remote over and unlock the battery cover by sliding the clear tab up. Slide the battery cover off,
revealing the AAA battery. IMPORTANT: Be sure to observe correct polarity when installing the battery.
1WG7R-SP:
Use a quarter or flat head screwdriver to pry the back cover off of the remote. You can insert the quarter
or flat head in the small slot at the bottom of the remote by the keychain loop. Carefully pry off the back
cover using caution that you do not damage the circuit board. Your battery size should be listed on the
battery. Battery size: Two (2) CR2016) Replacements can be purchased from your local Firstech dealer
or an electronics store.
2 Way Remote Button Functions
Button Duration Function / Description
<Insert
Lock
Icon>
Half
second Locks doors and if equipped, arms the alarm.
4
seconds Panic/vehicle locater (flashes vehicle’s parking lights and sounds siren and horn).
<Insert
Unlock
Icon>
Half
second Unlocks doors and if equipped, disarms the alarm.
2.5
seconds Run time extender. Resets the run time for Turbo Timer or Remote Start.
<Insert
Trunk
Icon>
2.5
seconds Trunk release. Triggers the trunk release output and opens the vehicle’s trunk.
<Insert
Key
Icon>
Half
second Car Check (updates vehicle status on remote) / Secure Auxiliary
2.5
seconds Holding this button will start your vehicle. Repeat and this will shut your vehicle down.
<Insert
Function
Icon>
This button activates and deactivates multiple features. See the Function Button Menu table below for
complete details.
<Insert
Lock +
Unlock
Icon>
Half
second Turns siren chirps on/off (Note: With the siren chirps off, it will still sound in the event the
alarm is triggered).
2.5
seconds Turns the shock sensor on/off. (ALARM IT or MAX IT systems only)
<Insert
Function
and
Trunk
Icon>
Half
second Valet mode (see Valet Mode Section for details)
2.5
seconds Option programming menu 1. For use during installation.
<Insert
Function
and Key
Icon>
Half
second Activates timer start mode. Timer start mode has multiple programmable settings: duration
settings, temperature settings and self start settings.
2.5
seconds Option programming menu 2. For use during installation.
<Insert
Trunk Half
second Activates passive arming (vehicle will arm/lock 30 seconds after the vehicle is disarmed)
6
and Key
Icon> 2.5
seconds Accesses Remote Option Menu. See Remote Option Menu Table for details.
Function Button Menu
Button Duration <Insert Lock
Icon> <Insert Unlock Icon> <Insert
Trunk
Icon>
<Insert
Key/Start
Icon>
<Insert
Function
Icon>
One Tap Drive Lock
On/Off Turbo Timer On/Off Auxiliary 1 Auxiliary 2
Remote Option Menu Table
Feature Turns Feature
On or Off Button
Duration Remote
Chirp(s) Function / Description
Enter and Exit
Remote Menu
<insert Trunk
+ Key button
icon>
2.5
Seconds Three On |
Three Off Enters and Exits Remote Option Menu. The LED will flash purple.
2 Way Paging
Display <insert Lock
icon> Half
second
One-Half
Paging | Two-
Full Paging
Determines whether your remote is used for Alarm or Start Only
system. Set it to FULL for ALARM IT and MAX IT features. Set to
HALF for START IT ONLY systems. If on, LED will flash blue.
When turned off, the LED will flash red twice.
Important: The 2W902R-SP is defaulted in HALF for START IT
systems. It must be changed to FULL for alarm systems.
Silent <insert Unlock
icon> Half
second One On | Two
Off Turns the silent mode on or off. If on, LED will flash blue. When
turned off, the LED will flash red twice.
2nd Car Mode <insert Trunk
icon> Half
second One On | Two
Off
Puts your remote into 2nd Car Mode. You can control another
vehicle with the same remote as long as it has the same RF Kit
installed. If on, LED will flash blue. When turned off, the LED will
flash red twice.
Automatic Button
Lock
<insert
Key/Start
icon>
Half
second One On | Two
Off
Locks all buttons on the remote automatically after one minute.
Tap any button then the button(s) you would like to use to send a
command from the remote to your vehicle. If on, LED will flash
blue. When turned off, the LED will flash red twice.
Remote LED Functions and Descriptions
Your remote will communicate to and from your vehicle while in range. The LED will change colors
indicating transmission, confirmation, remote start run time and error confirmations.
Event LED Color LED Duration Chirp(s)
Runtime Remaining:
100 Percent Blue Once every 5 seconds Six times
Runtime Remaining:
66 Percent Purple Once every 5 seconds N/A
Runtime Remaining:
33 Percent Red Once every 5 seconds N/A
All command
confirmations Blue Once or Twice depending on function Once or Twice
depending on
function
All error
confirmations Red Three LED flashes Three chirps
7
Alarm LED Notifications
In the event that your alarm has been triggered, your remote will receive notifications based on what
zone has been violated. Please see the following table for details and a short description of each
notification. Please note that these notifications are only available with MAX IT and ALARM IT systems.
`
1 Way Remote Button Functions
<please use 1WG7R-SP icons below>
Button Duration Additional
Programming
Required Function / Description
Half second no Locks doors and/or arms alarm.
3.5 seconds no Panic/vehicle locater (flashes vehicle’s parking lights and sounds siren and horn).
Half second no Unlocks doors and/or disarms alarm.
Half second no Aux 1. Triggers the auxiliary 1 output (most commonly used for rear defrost or window
roll-down).
2.5 seconds no Trunk release. Triggers the trunk release output and opens the vehicle’s trunk.
Half second no Aux 2. Triggers the auxiliary 2 output (most commonly used for rear defrost or window
roll-down).
2.5 seconds no Activates the remote start. Repeat and remote start will shut off.
Half second no Turns siren chirps on/off (Note: With the siren chirps off, it will still sound in the event the
alarm is triggered).
2.5 seconds no Option programming menu 1 - Installers Only.
Half second no Valet mode (see Valet Mode Section for details)
2.5 seconds no Turns the shock sensor on/off. (Alarm or Alarm/Starter systems only)
Half second yes Drive lock. Activates ignition controlled door locks.
Zone LED Color Chirp(s) Description
Door Trigger(s) Purple and Red Chirps for 30 seconds or until
button tapped on remote One of more of your door trigger
zones have been violated.
Trunk Trigger Purple and Red Chirps for 30 seconds or until
button tapped on remote Your trunk trigger zone has been
violated.
Hood Trigger Purple and Red Chirps for 30 seconds or until
button tapped on remote Your hood trigger zone has been
violated.
Ignition On Trigger Purple and Red Chirps for 30 seconds or until
button tapped on remote Your alarm is triggered when your
vehicle’s ignition is turned on.
DAS Tilt Trigger Purple and Red Chirps for 30 seconds or until
button tapped on remote Your alarm is triggered when your
DAS detects tilt motion
Prewarn Shock Sensor Blue and Red 8 Chirps Your prewarn shock sensor zone
has been violated.
Full Shock Sensor Purple and Red Chirps for 30 seconds or until
button tapped on remote Your full trigger shock sensor zone
has been violated.
8
2.5 seconds no Option programming menu 2 - Installers Only.
Half second no Activates passive arming (vehicle will arm/lock 30 seconds after the vehicle is disarmed)
Half second yes Activates timer start mode. Timer start mode has multiple programmable settings:
duration settings, temperature settings and self start settings.
Half second yes Activates the built in Turbo Timer function. Additional installation is required when using
this feature on automatic transmission vehicle’s.
2.5 seconds no Car Check / Secure Auxiliary
If you would like additional information on the functionality of your 1 Way companion remote, please visit
the support page at www.compustar.com to download the full user manual.
General System Functions
The remote transmitter functions are predetermined and programmed from the factory. The five button
configuration allows for many functions to be performed through a series of tapping and/or holding
buttons.
Sending Commands
When in range and a command has been sent the remote will beep and unique LED will flash blue or red.
For example, to send a remote start command from the pager, hold the Key/Start button for 2.5
seconds. The remote will beep confirming the command has been sent and that the remote is in range.
Once the vehicle has successfully remote started, the remote will receive a three beep and LED
command indicating the vehicle is running.
Receiving Commands
The remote pager will receive commands indicating the status of the vehicle, confirmation of sending
commands and remote start notifications. For example, after sending the lock command, the pager will
receive LED and chirp signals confirming that the vehicle has been successfully locked/armed. To see if
your pager is in range, tap the button for a half second – if the remote receives an audible and LED
confirmation then it is in range.
Active Lock/Arm and Unlock/Disarm
Tap the Lock button for a half second to lock/arm your vehicle. Tap the Unlock button
to unlock/disarm your vehicle. If equipped this will also activate your starter kill and anti grind
feature. Also you will not be able to start your vehicle with the key until unlock/disarm.
IMPORTANT: If the alarm has been triggered (Siren is sounding, parking lights flashing, and horn
honking), you must wait until the remote pager has been paged before disarming the alarm – the first
button tap will shut off the alarm and the second will unlock/disarm the system.
Passive Lock/Arm
The system can be configured to passively lock and arm the vehicle. Put the system in
passive by tapping the Trunk + Key Start buttons button for a half second.
The remote will beep once and the LEDs will illuminate to indicate the system is in passive lock and
9
arming mode.
While in passive mode, the system will lock and arm the alarm 30 seconds after the last door is closed.
As an indicator that the vehicle is going to passively lock and arm, the remote and siren will chirp once
and the parking lights will flash once at both 10 and 20 seconds prior to passively locking and arming. If
you want the system to passively arm and not passively lock, ask your local Firstech dealer to turn
Option 1-8 to setting II.
Automatic Transmission Remote Start Function
Hold the Key/Start button for 2.5 seconds to remote start an automatic transmission vehicle. If you
are in range and the vehicle is ready to remote start, the remote will beep once and LED flash blue
indicating that the remote start command has been successfully transmitted.
If you are in range and the remote beeps three times, there is a remote start error. Refer to the “remote
start error diagnostic” on the last page of this manual for details.
Upon receiving confirmation that your vehicle is running, the remote LED will flash the and
remote beep to show the run time. The remote start run time can be programmed for 3, 15, 25,
or 45 minutes - ask your local Firstech dealer to adjust Option 2-7 if you would like a run
time other than 15 minutes (default).
IMPORTANT: Your vehicle’s key must be inserted into the ignition and turned to the “on” position prior
to driving your vehicle. If the foot brake is depressed prior to the key being in the “on” position, the
vehicle will shut off.
Manual Transmission Remote Start Function (Reservation Mode)
In order to remote start a manual transmission vehicle, the system must first be set in Reservation Mode.
Reservation Mode must be set each and every time you want to remote start a manual transmission
vehicle. The purpose of Reservation Mode is to leave the transmission in neutral before exiting the
vehicle.
IMPORANT:
The transmission must be left in the neutral position.
The vehicle’s windows must be rolled up.
The vehicle’s door pins must be in working order.
Do not install this remote start on a manual transmission vehicle that has a convertible or
removable top.
Do not set reservation mode or remote start with people in the vehicle.
Activating Reservation Mode
STEP 1: While the vehicle is running, place the transmission in neutral, set the emergency / parking
brake, and remove pressure from the foot brake.
STEP 2: Remove the key from the vehicle’s ignition. The vehicle’s engine should remain running even
after the key has been removed. If the vehicle does not remain running visit your local authorized
Firstech dealer for service.
STEP 3: Exit the vehicle and close the door. The vehicle’s doors will lock/arm and then engine will shut
down. If the vehicle’s engine does not shut off, your door trigger may be functioning improperly. Do not
use the remote start feature and take your vehicle to a local authorized Firstech dealer for service.
10
Once the vehicle shuts off your system is in reservation mode and the vehicle is ready to safely remote
start.
IMPORTANT: By default, the system will lock/arm the vehicle upon setting reservation mode. Take care
to not lock your keys inside the vehicle.
Cancelling Reservation Mode
Reservation mode will be cancelled for the following reasons;
You did not activate the parking brake prior to turning off the ignition.
You pressed the foot brake after the key was removed from the ignition.
You released the parking brake after the key was removed from the ignition.
You entered valet mode, opened the vehicle’s door, hood, trunk or set off the alarm.
Reservation Mode Settings
Reservation mode settings can be programmed with Option 1-6. It is recommended that reservation
mode settings are programmed by your local authorized Firstech dealer.
Default 1: Locks doors when Reservation Mode is set.
Option 2: Hold Key/Start button to initiate Reservation Mode
Option 3: Reservation mode sets 10 seconds after the last door is closed, as opposed to immediately.
This option will allow you to access the vehicle’s rear doors, trunk or hatch prior to the system setting
reservation and passively locking/arming.
Option 4: Shuts motor off before locking doors.
Trunk Release
Hold button for 2.5 seconds to release the trunk or hatch. If you are in range, the
remote will beep twice and the LEDs will flash indicating that the trunk release command has
been successfully transmitted. IMPORTANT: Trunk release is an optional vehicle feature that may
require additional parts and labor.
Auxiliary Outputs/Window Roll-Down/Sliding Doors
Your system is equipped with two additional outputs that can be configured to control windows, open
power sliding doors, open a power sliding moon roof, or even turn on a rear defroster. These outputs can
be configured for pulsed, timed or latched settings. Your authorized Firstech dealer can set these outputs
up accordingly. Using auxiliary outputs to control additional vehicle functions will require additional parts
and can be rather labor extensive.
Tap the Function <insert icon> button for a half second followed by the Trunk button to
trigger auxiliary output 1. Tap the Function <insert icon> button for a half second followed by
the Key/Start <insert icon> button to trigger auxiliary output 2. The remote will beep once and parking
lights flash, indicating that the auxiliary output(s) have been triggered.
By default, the system is in secure auxiliary mode, which requires you to tap the Key/Start button
for a half second prior to triggering auxiliary 1 or 2. To turn off secure auxiliary, ask your authorized
Firstech dealer to turn on Option 4-5 to setting II
.
Silent Arm/Disarm
Upon lock/arm and unlock/disarm, you can eliminate vehicle’s audible confirmation by muting
the siren. Normally, the siren will chirp once to indicate the system is locked/armed and twice to
indicate the system is unlocked/disarmed. To mute the siren tap buttons
11
simultaneously for a half second.
IMPORTANT: Even when the siren is muted, it will still go off in the event the alarm is triggered.
Remote Mute
To silent your remote you must turn on Remote Mute on;
STEP 1: Enter remote programming mode by holding the Trunk and Key/Start buttons
simultaneously for 2.5 seconds. The remote will beep 3 times and the LED
will flash purple indicating that you have successfully entered programming mode.
STEP 2 : Tap the Unlock button. The LED will flash blue indicating that silent mode is on. Tap the
Unlock button again to turn Remote Mute off. Two chirps and red LED flashes indicates Remote Mute is
off.
STEP 3: Exit remote programming by holding down the Trunk and Key/Start buttons
simultaneously for 2.5 seconds. The remote will beep indicating that you have successfully exited
programming. Your remote’s LED will still illuminate.
Shock Sensor On/Off
Hold the Lock and Unlock buttons simultaneously for 2.5 seconds to turn the
shock sensor on and off. The remote will beep twice and LED flash twice to confirm the shock
sensor is off. The remote will beep once and LED flash once to confirm the shock sensor is on.
IMPORTANT: Turning off the shock sensor also turns off any optional sensors.
Adjusting the shock sensor sensitivity is done at the actual sensor, which is generally mounted
somewhere under the vehicle’s dashboard. The higher the number on the dial means greater sensitivity
to impact. The recommended dial setting for most vehicles is somewhere between 2 & 4. If you are
testing your sensor, please note that the shock sensor does not recognize impact for 30 seconds after
the system has been armed.
Automatic Button Lock
Your remote comes with an automatic button lock feature. This feature automatically locks all four
buttons on your remote after one minute. To unlock just tap any button then tap or hold the button(s) for
the command you would like to send. This feature must be turned on in the Remote Option Menu.
STEP 1: Enter remote programming mode by holding the Trunk and Key/Start buttons
simultaneously for 2.5 seconds. The remote will beep 3 times and the LEDs will flash purple on your
remote indicating that you have successfully entered programming mode.
STEP 2 : Tap the Start button. One chirp and LED flash indicates that Automatic Button Lock is on.
Tap the Start button again to turn Auto Button Lock off. Two chirps and LED flashes indicates the
feature is off.
STEP 3: Exit remote programming by holding down the Trunk and Key/Start buttons
simultaneously for 2.5 seconds. The remote will beep indicating that you have successfully exited
programming.
12
Advanced System Functions
The following section reviews advanced system functions. Many of these functions require multiple steps
or additional programming by your local authorized Firstech dealer to be active.
Drive Lock/Ignition Controlled Door Locks
Tap the Function button <insert icon> once followed by the Lock button to turn the
Drive Lock on and off. (also known as ignition controlled door locks) The remote will beep
once and the LED flash once to confirm that drive lock mode is activated. The remote will beep twice and
LED flash twice to to confirm drive lock is off.
IMPORTANT: Drive lock mode requires the dealer turn on Option 1-9. Drive lock has two settings;
Default 1: Off
Option 2: Locks the doors when the ignition is on and after the brake is depressed.
Option 3: locks the doors when the RPM’s have reached two times that of idle speed (this setting
requires that a tachometer wire is connected).
With both settings, the doors will unlock when the ignition is turned off. If using this feature on a manual
transmission vehicle, the doors will unlock upon setting the emergency / parking brake.
Turbo Timer Mode
The built in turbo timer keeps the vehicle’s engine running for either 1, 2, or 4 minutes
(programmable from dealer) after the vehicle key has been removed from the ignition. This
feature will keep oil running through the turbo system to allow for appropriate cooling time.
Tap the Function button <insert icon> once followed by the Unlock button to turn turbo mode on or off.
The remote will beep once and LED flash once to confirm that turbo mode is activated. Repeat to turn
turbo timer off. The remote will beep twice and LED flash twice to confirm turbo mode is off.
IMPORTANT: To utilize this feature, the emergency / parking brake wire must be connected to the
Firstech system. Consult your local authorized dealer for installation.
2nd Car Mode (Multiple Vehicle Control)
This remote has the ability to operate a 2nd vehicle with the same system. Note: When in 2nd
Car Mode that your LED will flash blue when the buttons are tapped. Hold buttons
for 2.5 seconds to enter the Remote Option Menu. Tap the Trunk Button to turn
2nd Car Mode on. Your remote will chirp once for on and twice for off. The remote’s LED will illuminate
blue confirming that 2nd car mode is activated. The remote will remain in 2nd Car Mode until you hold the
buttons for 2.5 seconds, enter the Remote Option Menu and tap the Trunk
Button. The remote will beep twice and you must hold the Trunk and Key/Start buttons
to save the Remote Option Menu changes.
IMPORTANT: 2nd car mode requires the remote to be programmed to a 2nd vehicle that is equipped with
the same remote kit.
13
RPS Touch and RPS (Remote Paging Sensor)
The RPS is an optional feature. The car call/RPS feature uses a small sensor that is mounted
on the inside of your windshield.
RPS Touch (Remote Paging Sensor)
The new RPS touch has multiple features including: remote paging, 4 digit pin unlock/disarm, and
arm/lock. All features are operated with a simple touch of the sensor.
Please have your installer program Option 3-16 to Setting 2.
RPS Touch and car call functions do not require programming, however in order to unlock/disarm your
vehicle you must program a 4 digit passcode using the instructions below:
STEP 1: Choose your RPS Touch 4 digit code. ‘0’ is not available.
STEP 2: Turn ignition to the ‘ON’ position and leave driver’s door open.
STEP 3: Hold your finger over the ‘Red Circle’ icon for 2.5 seconds.
STEP 4: When the siren chirps and LEDs flash in a circular pattern, tap on your first number. (Hold the
number for 2.5 seconds to choose 6 through 10.) After choosing your first number you will get one siren
chirp and LEDs will flash in a circular pattern.
STEP 5: Repeat Step 4 until all four digits are set. You will get 1 siren chirp and 1 parking light flash.
Repeat Steps 2 - 5 if you get 3 chirps and light flashes. Your RPS Touch is now programmed.
Alarm rearm and lock
To rearm hold your finger on the ‘Red Circle’ for 2.5 seconds.
Alarm disarm and unlock
To disarm hold your finger over the ‘Red Circle’ for 2.5 seconds. Once the LEDs start their circular
pattern, enter your 4 digit code. (Refer to Step 4 above.) Two seconds after entering the 4th digit, your
system will disarm.
2 Way LCD remote paging
To page a 2 Way LCD remote just tap the ‘Red Circle’ twice.
Touch Panel Sensitivity
To change touch sensitivity open the driver’s door, hold the button on the back of the RPS Touch until
the LEDs go out. Release button and tap again. The number of solid LEDs represent sensitivity of touch,
1 being the lowest, 5 the highest.
RPS Touch On or Off
You can turn the RPS Touch off from your remote. Just follow the instructions below:
14
STEP 1: Enter remote programming mode by holding down the Trunk and Key/Start buttons <insert
icon> simultaneously for 2.5 seconds. The remote will beep once and the LCD will read “REMOTE
MENU” indicating that you have entered programming mode.
STEP 2 : Scroll through the remote options by taping the Function button <insert icon>. Once the LCD
reads “RPS-ON” tap the Lock button <insert icon> to turn this feature on. The LCD will read “RPS-OFF”
STEP 3: Exit remote programming by holding down the Trunk and Key/Start buttons <insert icon>
simultaneously for 2.5 seconds. The remote will beep indicating that you have successfully exited
programming. The vibration icon will remain illuminated on the LCD indicating the remote is in remote
mute/vibration mode.
RPS (Remote Paging Sensor) Unlock/Disarm
RPS and car call functions do not require programming, however in order to unlock/disarm your vehicle
you must program a 4 digit passcode using the instructions below:
STEP 1: Disarm/unlock the alarm (remote must be programmed first) and choose a 4 digit code. You can
not have zeros.
STEP 2: Turn ignition key to the “on” position and leave the driver’s door open.
STEP 3: Knock on the windshield in front of the RPS a total of 5 times (each time you knock the LED on
the RPS will flash RED). The LED will begin to flash rapidly in BLUE with successful completion of this
step.
STEP 4: Enter the first digit of the desired four digit pass code by knocking on the windshield in front of
the RPS the desired number of times. For example, to enter 3, knock on the sensor 3 times (each time
you knock the LED will flash RED) then wait.
STEP 5: The LED on the RPS will confirm your first number by flashing BLUE slowly. Once the LED
begins to flash rapidly in BLUE, enter your second number by repeating step 4.
STEP 6: Repeat steps 4 & 5 to enter all four numbers.
STEP 7: Turn the ignition OFF - the RPS disarm/unlock passcode is now programmed. Follow steps 3 –
5 to enter your disarm/unlock code.
Alarm rearm and lock
To rearm, knock on your sensor 5 times.
Alarm disarm and unlock
To disarm, knock on your sensor 5 times. Wait for the Blue LEDs to flash rapidly. Follow STEP 4 and 5
above to enter your 4 digit passcode.
2 Way LCD remote paging
To page a 2 Way LCD remote just knock on the RPS twice.
Knock Panel Sensitivity
To change knock sensitivity, disarm the system and adjust the switch on the rear of the RPS. The larger
the circle, the more sensitive the knock sensor is.
15
Secure Valet Switch
The optional Secure Valet Switch prevents the alarm from being put into valet mode through cycling the
ignition on/off five times. The Secure Valet Switch is more secure than traditional toggle / valet switches
because it requires a two digit code. IMPORTANT: The first two digits of the RPS unlock/disarm pass
code will be the default pass code for the secure valet – you do not need to program them independently.
If you are not using the RPS unlock, following the below procedures to program your secure valet pass
code;
STEP 1: Turn on Option 3-10-III. (Dealer programmed option)
STEP 2: Turn ignition key to the “on” position.
STEP 3: Hold down the valet switch for 1.5 seconds. The LED on the valet switch will begin to flash
rapidly with successful completion of this step.
STEP 4: Enter the first digit of the desired two digit pass code by depressing the switch the number of
times that coordinates with the desired first number. For example, to enter 3, depress the switch 3 times,
then wait.
STEP 5: The LED will confirm the first number by flashing BLUE slowly. Once the LED begins to flash
rapidly, enter your second number by repeating step 4.
STEP 6: Turn the ignition off - the Secure Valet Switch is now programmed. Follow steps 3 – 5 to enter
your Secure Valet code.
Timer Start Mode
Timer start mode is used to cool or warm the vehicle automatically without use of the key or
the remote. While engaged, timer start will activate even while the remote is out of range.
Tap the Function + Key/Start buttons <insert icons> for a half second to activate timer start mode. The
remote will beep once and LED flash once. Repeat the same step to turn off timer start mode. Timer start
mode will be cancelled any time the vehicle is started manually or remotely. To change from the default
setting to optional settings, see your place of purchase.
Cold/Hot Start Mode
Cold/hot start mode works in conjunction with timer start mode (see above) and the temperature sensor.
It allows you to configure your timer start feature to check the vehicle’s temperature prior to starting. All
of these options require programming from your local dealer.
Anti Jacking Mode
Your system has a mode that requires you to keep your remote separate from your key chain. This
feature also requires additional labor. Please consult your installer for more details. The Anti Jacking
mode allows you to safely disable your vehicle once a thief has driven off with your property. If you are
car jacked and still have your remote, you can panic the system by holding the Lock button <insert icon>
down for 4 seconds. The siren will sound for 30 seconds and the vehicle will shut down.
More Optional Sensors
If you purchased an Alarm or Alarm and Remote Start system you have the ability to add optional
sensors from Firstech. You have the ability to protect your investment by adding a battery back up
system to protect main power to your alarm or a tilt sensor to protect expensive rims and tires.
16
Remote Coding / Programming Routine
IMPORTANT: Every Firstech remote must be coded to the system prior to performing any operations. All
remotes must be coded at the same time.
Programming 2 Way 5 Button Remotes:
STEP 1: Activate Valet/Programming mode by manually turning the ignition key on and off (between the
Acc & On positions) five times within 7 seconds. The vehicle’s parking lights will flash once with the
successful completion of this step.
STEP 2: Within 2 seconds after cycling the ignition for the 5th time, tap the Lock button on 2 way
remotes or the (lock) button on 1 way remotes for a half second. The parking lights will flash once to
confirm the transmitter has been coded.
Exiting Programming: Programming is a timed sequence. The parking
lights will flash twice signaling the end of programming mode.
Programming Multiple Remotes: After the confirmation flash given in
step 2, code additional remotes by pressing button on 2 way
remotes or the (lock) button on 1 way remotes. The parking lights will
flash once confirming each additional remote. All systems can
recognize up to three remotes.
Remote Start Error Diagnostic
If the remote start fails to start the vehicle, the parking lights will flash three times immediately. Following
those three flashes the parking lights will flash again corresponding to the error table.
Number of
Parking Light
Flashes Remote Start Error
1 Motor running
2 Key in ignition on position
3 Door open (manual transmission only)
5 Foot brake on
6 Hood open
7 Reservation off (manual transmission only)
8 Tach or voltage sensing failure
9 DAS sensor movement
10 System is in Valet Mode
We recommend that you do not attempt any repairs on your remote starter. Contact your dealer or call us
directly.
17
Alarm Diagnostic
While the alarm is armed, the LED will blink slowly. While the siren is going off, the LED will indicate
which specific zone was triggered.
Upon disarming the alarm after it has been triggered, the amount of siren chirps will indicate the specific
zone.
Priority Situation LED On Duty
1 Door/Hood/Trunk/Key Triggered 2 flash, rest, then repeat
2 2nd Shock Triggered 3 flash, rest, then repeat
3 Optional Sensor Triggered 4 flash, rest, then repeat
4 PANIC 5 flash , rest, then repeat
# of
Chirps Situation
4 Optional Sensor Triggered
5 2nd Shock Triggered
6 Door/Hood/Trunk/Key Triggered
18
Limited Lifetime Warranty
Firstech, LLC Warrants to the original purchaser that this product shall be free of defects in material and
workmanship under normal use and circumstances for the period of time that the original owner of this
product owns the vehicle in which it is installed; except that the remote controller unit for the period of
one year from the date of installation to the original owner of this product. When the original purchaser
returns the product to the retail store where it was purchased or prepaid postal to Firstech, LLC., 21903
68th Avenue South, Kent, WA 98032, USA within the warranty period, and if the product is defective,
Firstech, LLC, will at its option repair or replace such.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUDED BY
THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COMMERCE
THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO, THE EXCLUSION OF ANY
AND ALL WARRANTY OF MERCHANTAPILITY AND/OR ANY AND ALL WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OR
PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD. NEITHER THE
MANUFACTURER OF ANY ENTITIES CONNECTED THEREWITH SHALL BE RESPONSIBLE OR
LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY
CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR LOSS OF TIME, LOSS OF
EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE.
NOTWITHSTANDING THE ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO
REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE.
Some states do not allow limitations on how long an implied warranty will last or the exclusion or
limitation on how long an implied warranty will last or the exclusion or limitation of incidental or
consequential damages. This warranty gives you specific legal rights, and you may also have other rights,
which vary State to State.
Firstech, LLC. is not RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING
BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES
FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC
OPPORTUNITY AND THE LIKE that may or may not resulted from the operation of Compustar,
Compustar Pro, Arctic Start, Vizion, or NuStart. NOT WITH STANDING THE ABOVE, MANUFACTURER
DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE AS
DESCRIBED ABOVE.
Your Warranty
The product's warranty is automatically void if the date code or serial number is defaced, missing or
altered. This warranty will not be valid unless you have completed the registration card at
www.compustar.com within 10 days of purchase.
