SEGI JR961-1WSS CAR Alarm transmitter User Manual Compu 1W 4B all E MR961

SEGI LIMITED CAR Alarm transmitter Compu 1W 4B all E MR961

Users Manual

www.compustar.comwww.firstechllc.com
Applicable to the following remote(s):
All 1Way 4Button Remote
Remote FCC ID Number (US Only) IC ID Number (International Only)
1WAMR-Fiance O44J1WAM4R 5532A-J1WAM4R
1WAMR-1600 O44JR1600 5532A-JR1600
1WAMR-1800 O44JR1800A433 7087A-R1800AM
1WAMR-1900 O44JR5120AMSH 7087A-R5120AM
1WAMR-762 VA5JR762A433 7087A-R762A433
1WAMR-763 VA5JR763AM433 7087A-R763A433
NU1000R O44JR1700A433 7087A-R150A433
NU2000R N/A 7087A-R150F433
1WFMR-Fiance O44J1WFM4R 7087A-1WFM4R
1W900FMR N99J1WPLL4R 5532A-J1WPLL4R
1W900FMR-Pro VA5JR762F907 7087A-762F907
1W900SHR-961 VA5JR961AM 7087A-R961AM
1WSS-25 VA5JR762WSS 7087A-R762WSS
1WG5R-SS VA5JR961-1WSS 7087A-R961WSS
VZ1WAMR-960 N/A 7087A-R960A433
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions;
(1) This device may not cause harmful interference.
(2) This device may accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate this device.
To maintain compliance with RF energy exposure guidelines, the antenna used for this transmitter must be maintained a separation distance of at least 20cm
from the user body when transmitting. Co-located or operated in conjunction with any other antenna or transmitter is prohibited.
Statement : The term ICbefore the radio certification number only signifies that Industry Canada technical specifications were met.
CAUTION: The User that modifications to the unit may void the users authority to operate the unit
Toll Free : 888-820-3690
8102REUSC000902 / CS-1W-ES By Firstech LLC Version 1.1
By Firstech, LLC 2
t@o@c
i S
w@c S
q@r T
g@s@f W
v@m T
r@m@M@b@r U
Q@w@r@b@f U
a@lOa@@uOd W
a@t@r@s@f W
m@t@r@s@f@Hr@mI X
a@r@m X
c@r@m Y
t@r Y
s@aOd Y
s@s@oOo Y
r@c@O@p@rHI QP
p@Qw@Tb@r QP
a@d
QR
r@s@e@d
QQ
l@l@w
QT
a@s@f
QP
By Firstech, LLC 2 3 By Firstech, LLC
Introduction
Thank you for purchasing a Firstech system for your vehicle. In order to truly enjoy the benefits of this system, we recommend that you
thoroughly review the following manual. Please note that this manual applies to the 1 Way-4 Button Non Liquid Crystal Display Remotes,
regardless of whether you purchased the alarm only, starter only or alarm/starter combination. There are certain features listed in this manual
that may not be available for your system. There may also be features listed in this manual that require additional installation or programming
before they are active. If you have any questions, please contact the original place of purchase. For further information you may also contact our
customer support center by calling 888-820-3690.
Warranty Coverage
Caution: The Manufacture’s warranty will be voided if this product is installed by anyone other than an authorized Firstech dealer. For complete
warranty details visit www.compustar.com or the last page of this manual. Firstech remotes carry a 1 year warranty from original date of purchase.
Warranty registration can be completed online by visiting www.compustar.com. Please complete the registration form within 10 days of purchase.
We do not include a mail in warranty registration card with each unit. Registration must be done online. To verify that an authorized dealer
installed your system, we highly recommend that you keep a copy of the original proof of purchase, such as the dealer invoice in a safe place.
5 By Firstech, LLC By Firstech, LLC 4
Quick Reference
When servicing or loaning your vehicle to others, the system should be in Valet mode. Valet mode prevents the system from remote starting and
disables all alarm functions.
IMPORTANT: While in Valet mode the remote will still control power lock and unlock systems. The parking lights will not flash.
The system can be put into valet one of three ways:
1. Turn the vehicle’s key to the ignition “on” position and tap buttons simultaneously for 0.5 seconds. The parking lights
will flash once and/or siren chirp once to confirm the system is in valet mode. Repeat this process to take the system out of valet mode.
The parking lights will flash twice and/or siren chirp once to confirm the system is out of valet mode.
2. If you don’t have your remote control, you can put the system into valet by turning the ignition key “on” and then “off” five times within 7
seconds. The parking lights will flash once to confirm the system is in valet mode. Shortly after the first flash, the parking lights will flash twice. A
remote control is required to take the system out of valet mode. IMPORTANT: If your system is set up for a secure valet option, you will not be able
to put the system into valet until the proper code has been entered to the secure valet switch.
3. If your system is set up with the secure valet switch (optional), you will not be able to put the system into valet until the proper code has been
entered to the secure valet switch. The secure valet switch is the small button with bright blue LED on the front and if installed is the only way to
override the alarm and/or remote start. The default code is (3, 3).
v@m The only regular maintenance this system requires is remote control battery replacement. No programming is required when replacing
the battery.
First, remove the small Phillips screw located on the back of the remote. Once the screw has been removed, gently pull the remote apart taking care
to not damage the circuit board. 1 Way remote batteries differ among the models. Your battery size should be listed on the battery. Replacements
can be purchased from your local Firstech dealer or an electronics store.
r@mMb@r
Q@w@r@b@f
Button Duration Additional Function / Description
Programming Required
0.5 seconds no Locks doors and/or arms alarm.
3.5 seconds no Panic/vehicle locater (flashes vehicle’s parking lights and sounds siren and horn).
0.5 seconds no Unlocks doors and/or disarms alarm.
0.5 seconds no Aux 1. Triggers the auxiliary 1 output
(most commonly used for rear defrost or window roll-down)
2.5 seconds no Trunk pop. Triggers the trunk release output and opens the vehicle’s trunk.
7 By Firstech, LLC By Firstech, LLC 6
The remote transmitter functions have been predetermined and programmed from the factory. The four button configuration allows for many
functions to be performed through a series of tapping, holding and / or multiple presses of buttons. Although Firstech remotes have numerous
button functions and capabilities, please keep in mind that the most common functions are performed in one simple step. There are advanced
features not described in this manual. Please go to www.compustar.com for more details.
Tap button for 0.5 seconds to lock/arm and unlock/disarm. The LED will flash on your remote. If your vehicle is locked, tap
button to unlock; if your vehicle is unlocked, tap button to lock.
IMPORTANT: If the alarm has been triggered (Siren is going off), you must wait up to 5 seconds before disarming the alarm - the
first button tap will shut off the alarm and the second will unlock/disarm the system.
a@lOa@@uOd
Press the button for 2.5 seconds to remote start an automatic transmission vehicle. If you are in range and if the vehicle is ready to remote
start, the parking lights will flash once and/or siren chirp once to indicate that the remote start command has been successfully transmitted.
If you are in range and the parking lights flash and/or vehicle’s siren chirps three times, there is a remote start error. Refer to the “remote start error
diagnostic” at the end of this manual for details.
The remote start run time can be programmed for 3, 15, 25, or 45 minutes - ask your local Firstech dealer to adjust Option 2-7 if you
would like a run time other than 15 minutes (default).
IMPORTANT: Your vehicle’s key must be inserted into the ignition and turned to the “on” position prior to driving your vehicle. If the foot brake
is depressed prior to the key being in the “on” position, the vehicle will shut off.
a@t@r@@f
General System Functions
Additional
Programming Required
0.5 seconds no Aux 2. Triggers the auxiliary 2 output (most commonly used for rear defrost or window roll-down)
2.5 seconds no Activates the remote start. Repeat and remote start will shut off.
0.5 seconds no Turns siren on/off (Note: With the siren off, it will still sound in the event the alarm is triggered)
0.5 seconds no Valet mode (see Valet Mode section for details)
2.5 seconds no Turns the shock sensor on/off. (Alarm or Alarm/Starter systems only)
0.5 seconds yes Drive lock. Activates ignition controlled door locks.
0.5 seconds no Activates passive arming (vehicle will arm/lock 30 seconds after the vehicle is disarmed)
Activates timer start mode. Timer start mode has multiple programmable settings:
duration settings, temperature settings and self start settings.
Activates the built in Turbo timer function. Additional installation is required when using
this feature on automatic transmission vehicle’s.
2.5 seconds no Car Check (updates vehicle status on remote pager) / Secure Auxiliary
Button Duration
yes
yes
0.5 seconds
0.5 seconds
Function / Description
9 By Firstech, LLC By Firstech, LLC 8
General System Functions
In order to remote start a manual transmission vehicle, the system must first be set in Reservation Mode. Reservation Mode must be set each and
every time you want to remote start a manual transmission vehicle. The purpose of Reservation Mode is to leave the transmission in neutral before
exiting the vehicle.
IMPORANT
The transmission must be left in the neutral position. The vehicles windows must be rolled up.
The vehicles door pins must be in working order. Do not set reservation mode or remote start with people in the vehicle.
Do not install this remote start on a manual transmission vehicle that has a convertible or removable top.
Activating Reservation Mode
STEP 1:While the vehicle is running, place the transmission in neutral, set the emergency / parking brake, and remove pressure from the foot brake.
STEP 2: Remove the key from the vehicle’s ignition. The vehicle’s engine should remain running even after the key has been removed. If the vehicle
does not remain running make sure your system is not in Valet mode and then contact your local authorized dealer for service.
STEP 3: Exit the vehicle and close the door. The vehicle’s engine should shut off within 10 seconds upon closing the last door. Most motors will shut
off instantly upon closing the last door. If the vehicle’s engine does not shut off, your door trigger may be functioning improperly. Do not use the
remote start feature and take your vehicle to a local authorized dealer for service.
IMPORTANT: By default, the system will lock/arm the vehicle upon setting reservation mode. Take care to not lock your keys inside the vehicle.
Cancelling Reservation Mode
Reservation mode will be cancelled for the following reasons;
You did not activate the parking brake prior to turning off the ignition. You pressed the foot brake after the key was removed from the ignition.
You released the parking brake after the key was removed from the ignition.
You entered valet mode, opened the vehicles door, hood, trunk or set off the alarm.
m@t@r@s@f@Hr@mI
Hold button for 2.5 seconds to release the trunk or hatch. If you are in range, the vehicle’s parking lights will flash once and/or
siren chirp once indicating that the trunk release command has been successfully transmitted.
IMPORTANT: Trunk release is an optional vehicle feature that may require additional parts and labor.
t@r
Upon lock/arm and unlock/disarm, you can eliminate vehicle’s audible confirmation by muting the siren. Normally, the siren will
chirp once to indicate the system is locked/armed and twice to indicate the system is unlocked/disarmed. To mute the siren tap
buttons simultaneously for 0.5 seconds.
IMPORTANT: Even when the siren is muted, it will still go off in the event the alarm is triggered.
s@aOd
Hold buttons simultaneously for 2.5 seconds to turn the shock sensor on and off. The vehicle’s parking lights will flash
once and/or siren chirp once to confirm the shock sensor is on. The vehicle’s parking lights will flash twice and/or siren chirp twice
to confirm the shock sensor is off. IMPORTANT: Turning off the shock sensor also turns off the optional sensor(s).
The shock sensor does not recognize impact for 30 seconds after the system has been armed.
s@s@oOo
11 By Firstech, LLC By Firstech, LLC 10
p@Qw@T@b@rZ
STEP 1: Activate Valet/Programming mode by manually turning the ignition key on and off (between the Acc & On positions) five times within 7
seconds. The vehicle’s parking lights will flash once with the successful completion of this step.
STEP 2: Within 2 seconds after cycling the ignition for the 5th time, press button (I) on 2 way remotes or the (lock) button on 1 way remotes for 0.5
seconds. The parking lights will flash once to confirm the transmitter has been coded.
Exiting Programming: Programming is a timed sequence. The parking lights will flash twice signaling the
end of programming mode.
Programming Multiple Remotes: After the confirmation flash given in step 2, code additional remotes by
pressing button (I) on 2 way remotes or the (lock) button on 1 way remotes. The parking lights will flash once
confirming each additional remote. All systems (except the P2WSSR), can recognize up to three remotes.
IMPORTANT:Every Firstech remote must be coded to the system prior to performing any operations. All remotes must be coded at the same time.
There are lots of advanced features available for your system. Please go to www.compustar.com for more details.
Advanced System Functions
If the remote start fails to start the vehicle, the parking lights will flash three times immediately. Following those three flashes the parking lights will
flash again corresponding to the error table.
Remote Start Error Diagnostic
We recommend that you do not attempt any repairs on your remote starter. Contact your dealer or call us directly.
Number of Parking Light Flashes Remote Start Error
1Motor running
2Key in ignition on position
3Door open (manual transmission only)
4Trunk open
5Foot brake on
6Hood open
7Reservation off (manual transmission only)
8Tach or voltage sensing failure
Remote Coding / Programming Routine (S)
13 By Firstech, LLC By Firstech, LLC 12
Firstech, LLC Warrants to the original purchaser that this product shall be free of defects in material and workmanship under normal use and circumstances for the
period of time that the original owner of this product owns the vehicle in which it is installed; except that the remote controller unit for the period of one year from
the date of installation to the original owner of this product. When the original purchaser returns the product to the retail store where it was purchased or prepaid
postal to Firstech, LLC., 21911 68th Avenue South, Kent, WA 98032, USA within the warranty period, and if the product is defective, Firstech, LLC, will at
its option repair or replace such.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUDED BY THE MANUFACTURER AND EACH ENTITY
PARTICIPATING IN THE STREAM OF COMMERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO, THE EXCLUSION OF ANY
AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL
WARRANTY OF NON-INFRINGEMENT OR PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD. NEITHER THE MANUFACTURER OF
ANY ENTITIES CONNECTED THEREWITH SHALL BE RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED
TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF
ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE
OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE.
Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation on how long an implied warranty will last or the exclusion
or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you may also have other rights, which vary State to State.
Firstech, LLC. is not RESPONSIBLE OR LIABLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL
DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE that may or may not resulted from the operation of Compustar, Compustar Pro, Arctic Start, Vizion, or NuStart. NOT WITH STANDING THE
ABOVE, MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE.
Your Warranty
The product’s warranty is automatically void if the date code or serial number is defaced, missing or altered. This warranty will not be valid unless you have
completed the registration card at www.compustar.com within 10 days of purchase.
Limited Lifetime Warranty
While the alarm is armed, the LED will blink slowly. While the siren is going off, the LED will indicate the specific zone that was triggered. Upon
disarming the alarm after it has been triggered, the amount of siren chirps will indicate the specific zone.
Alarm Diagnostic
Priority Situation LED On Duty Number of Siren Chirps (If Installed)
1Door/Hood/Trunk/Key Triggered 2 flash, rest, then repeat 6
22nd Shock Triggered 3 flash, rest, then repeat 5
3Optional Sensor Triggered 4 flash, rest, then repeat 4
4PANIC 5 flash , rest, then repeat N / A

Navigation menu
