SEIKAKU TECHNICAL GROUP DMT-300HD Wireless Microphone User Manual

SEIKAKU TECHNICAL GROUP LIMITED Wireless Microphone Users Manual

Users Manual

WIRELESS MICROPHONE
SYSTEM
DMT-300HD
TMTM
INSTRUCTION
MANUAL
NF01293-1.1
SEIKAKU TECHNICAL GROUP LIMITED
UNIT 1107 BLK.A2,YAU TONG INDUSTRIAL CITY .NO.17,KO FAI ROAD,KOWLOON,HONG KONG.
http://www.dmtmic.com Tel: 886-4-22313737
email: alto@altoproaudio.com Fax: 886-4-22346757
All rights reserved to DMT. All features and content might be changed
without prior notice. Any photocopy, translation, or reproduction of part of this
manual without written permission is forbidden.
Copyright 2004 SEKAKU ELECTRON INDUSTRY (H.K.) CO., LTD.
GRILLE HOLDER
TAIL TUBE
TUBE
22
DMT-300HD
BATTERY INGORMATION:
NOTE: Make sure the power switch is in the "OFF" position when changing or installing new bat-
tery. Average life on an alkaline battery is 10 hours. Be sure to use good quality long life
1.5V 2 alkaline battery only.
1. This microphone has a 3-level power switch design.
2. In using first turn on the receiver and then the transmitter.
3. New battery the power light is in "OFF".
The light is "ON". It indicates the ba needs to be replaced.
4. Remember to turn the switch "OFF".
When the microphone is not in use in order to save power. In "STAND
set the switch to the center.
ttery
-BY"
NO.
1
2
3
5
4
7
6
9
8Frequency Response
Current
Carrier Frequency Range
RF Radiation
Total Harmonic Distortion
Oscillation Mode
Modulation Mode
Frequency Stability
Spurious Emission
ELECTRIC PARAMETER
75mA
50Hz-13KHz 3dBm
VHF Band 174~216MHz
FM(F3E)
10mW
45dBm
0.005%/25
Quartz controlled fixed frequency
1.0%
SPECIFICATION
INSTRUTION:
3.
1. After operation the microphone must be switched off as well. Otherwise the batteries will soon be
exhausted. in order to avoid untune consumption of the inner battery: if pilot lamp of the wireless
microphone (1)remains lighted, it means that the battery has no more power: (2)the lamp must
flash only for the time of the switching -on; this indicates that the microphone works well.
2. INSTALL BATTERY:
PLS. make sure the positive/negative before you replacement batteries.
We congratulate you for the choice of this excellent professional apparatus microphone which
will give you outstanding results at the high fidelity. the microphone suit for school speech,
meeting speech, teachers and performer on the stage. to avoid of problem like wireless
microphone.
When switches the power switch to "on" position, then the power indicator lights, indicate the
apparatus is on.
When switches the power switch to "off"position, then the power indicator lights, indicate the
apparatus is off.
FEATURES:
"STAND-BY" funciton.
Steel net based to prevent from rolling.
SPECIFICATION
TRANSMITTER PERFORMANCE SPECIFICATION:
10
11
12
13
Power Supply
Operating Temperature
Dimensions
Weight
DC 3V
10 ~50
246 (L) mm (9.68 in.)
208 grams (7.3oz.)
TMTM
ON OFF PWR
W
E
I
R
N
E
O
L
H
E
P
S
O
S
C
MI
R
300HD
POWER LED LIGIHT
PSWITCH
11
Caution:
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
