SENTRY >
Manual
Bluetooth stereo Headset
(EH-03L)
User’s manual
SPECIFICATION
MODEL NO EH-03 Version BLUETOOTH V3.0+EDR
Bluetooth profiles HSP,HFP,A2DP,AVRCP Effective
range
10 meters
Music Time 7 hours Talk time 9 hours
Standby time Up to 250 hours input DC:5V/380mAh
Charge Time 2 hours dimensions 145*165*45 mm
Battery life may vary depending on usage.
Specifications may change without notice due to continuous product enhancement.
About the EH-03
EH-03 is a stereo headset with Bluetooth technology. it supports the following
Bluetooth profiles:
HSP—headset profile
HFP—hands-free-profile
A2DP—Advanced Audio distribution profile
AVRCP—Audio/Video remote control profile
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING
THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE
Overview:
1． Retractable string
2． ,<key: last song
3． >key: next song
4． Multifunction button (MFB): a) Answer; b): end; c) reject call; d) Pause; e) Play
5． LED indicator
6． + key: volume up
7． -key: volume down
8． Charging port
9． Build-in microphone
Re-mark:
1. the battery is rechargeable
2.first time charging: before using the Bluetooth headset, please charge the battery of headset
fully.
How to use
1) Switching on /off the headset
Function Operation LED indicator
Switch on Press and hold the MFB for 3 second Blue LED is flashing 1 or 2 second
Switch off Press and hold the MFB for 3 second Blue LED is flashing 1 or 2 second
2) Pairing the headset with Bluetooth device
2.1 how to enter pairing mode
be sure the headset is in power off status first. Press and hold the MFB for 5-6 seconds until
red and blue LED blink alternately, then release the MFB, the unit is becoming pairing mode.
2.2 Pairing the headset with Bluetooth mobile phone:
Make sure your mobile phone with Bluetooth function. Then, turn on its Bluetooth function
and searching Bluetooth device.
2.3 Keep the headset and mobile within 0.8 meter when pairing.
2.4 Make the Bluetooth headset in pairing mode, after searched, select the model No “EH-03L” in
the Bluetooth device list.
2.5 After successful pairing ,the red LED of headset will be quickly blinks.
Wearing the headset
The string of headset is retractable, the user could be adjust it until feel comfortable.
Making calls with the headset
Function Status of headset Operation
Answer calling Ringing Press MFB shortly
Volume up Conversation model Press +key
Volume down Conversation model Press - key
Warning: Excessive pressure on the headset would cause hearing loss.
TROUBLESHOOTING GUIDE
Symptom Possible Problems Solution
The headset
does not turn
on.
- No power.
- Power Switch is not set to “ON”
correctly
- Recharge batteries enough time with
cable .
Press MFB( Power switch) on about 3
second again.
There’s no
music from the
headset
- The headset hasn’t pair the
Bluetooth device.
- Too Long distance between the
headset and device
-
- turn of the headset and turn on it
again. And make the Bluetooth device
in the status mode.
- short the distance between the
device..
-
90 DAY LIMITED WARRANTY AND SERVICE
VALID IN THE COUNTRY ONLY
SENTRY INDUSTRIES INC warrants this unit to be free from defective materials or factory
workmanship for a period of 90 days from the date of original customer purchase and provided
the product is utilized within the COUNTRY . This warranty is not assignable or transferable.
Our obligation under this warranty is the repair or replacement of the defective unit or any part
thereof, when it is returned to the Service Department, accompanied by proof of the date of
original consumer purchase, such as a duplicated copy of a sales receipt. You must pay all
shipping charges required to ship the product to THE SERVICE CENTER for warranty service.
This warranty is valid only in accordance with the conditions set forth below:
1. The warranty applies to the SENTRY product only while:
a. It remains in the possession of the original purchaser and proof of purchase is
demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service, usage outside
the descriptions and warnings covered within the owner’s manual
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by owner’s manual
specifications, or failure to provide reasonable care and necessary maintenance as
outlined in the owner’s manual.
3. Warranty of the headset applies to residential use only and is void when products are used
in a nonresidential environment or installed outside the United States.
To register your product, visit the link below on the website to enter your information.
http://www.sentryindustries.com
FCC Statement:
This equipment has been tested and found to comply with the limits for Part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Note: Modifications to this product will void the user’s authority to operate this equipment.
IC Statement :
This device complies with Industry Canada licence-exempt RSS standard(s). Operation
is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device."
IC Déclaration:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil
doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.
Remarque: Toute modification de ce produit annule l'autorité de l'utilisateur à utiliser cet
équipement.
