SHARPVISION DW132671CAI 7 inch Digital Wireless System User Manual CGZ3140823 00959 EF DW671
SHARPVISION CO.,LTD. 7 inch Digital Wireless System CGZ3140823 00959 EF DW671
User Manual
Image Device
TV S
y
stem PAL NTSC
Effective Pixels
Sensin
g
Area
Scannin
g
S
y
stem
S
y
nc. S
y
stem
Horizontal Sync Frequency 15.625 kHz 15.734 kHz
Vertical Sync Frequency 50 Hz 60 Hz
Video Output
Gamma Consumption
AGC
S/N Ratio
White Balance
Electronic Shutter
BLC
Operation Frequency:
Line of Sight Range:
Receiving Sensitivity:
V
ideo Codec:
Frame Rate:
Output Power:
Spread SPECTRUM:
Delay:
RF Bit Rate:
Operating Temperature
Stora
g
e Temperature
Minimum Illumination
Power Supply
Night vision distance
Waterproof rating
Audio
Viewing Angle
0Lux
DC10~32V
□8~10m □12~15m
Auto pairing:
1. Choose the channel that needs to be set up, and the monitor display the message
“PAIRING START 50” and a counter that counts down 50s.
2. Within the countdown, power the camera.
3. The monitor and cameras will synchronize themselves with each other after the
camera is powered for 5s.
For successful auto pairing, the picture appears. If pairing isunsuccessful, the
monitor displays the message “No Signal”. Repeat the pairing procedure. Manually pairing:
1. Choose the channel that needs to be set up, and the monitor display the message
“PAIRING START 50” and a counter that counts down 50s.
2. Press the pairing button on the power-on camera.
3. The monitor and cameras will synchronize themselves with each other.
For successful auto pairing, the picture appears. If pairing isunsuccessful, the
monitor displays the message “No Signal”. Repeat the pairing procedure.
IP69K
□ Yes □ No
□ 120° □ 92°
4Mbps
–20℃ ~ 70℃, RH95%MAX.
–
30℃ ~ 80℃, RH95%MAX.
17dBm
FHSS
120ms
-89dBm
MPEG4
PAL: 25f/s NTSC: 30f/s
Auto
2400-2483.5MHZ
120M
Better than 48dB
Auto
Auto:1/60(NTSC)/1/50(PAL)～1/100,000 Seconds
1.0Vp-p, 75Ohm
0.45
Auto
4.6228mm×3.6112mm
2:1 Interlace
Internal
CAMERA USER MANUAL
1/3" CMOS PC1089
728×488 pixels
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should
be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
FCC Statement:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: Modifications to this product will void the user’s authority to operate this equipment.
