SHENGLAI TECHNOLOGY VU50012BT Bluetooth Headphones User Manual Print
SHENZHEN SHENGLAI TECHNOLOGY CO.,LIMITED Bluetooth Headphones Print
User Manual
HEADPHONES
BLUETOOTH
VU50012BT
USER’S MANUAL
COLLECTION
™
ANSWER CALLS
RECHARGEABLE
BATTERY
BRIGHT
LED LIGHTS
WIRELESS
Important Safety Precautions
When using your Vivitar Bluetooth Headphones, basic safety precautions should always be followed, including the
following:
1. READ ALL INSTRUCTIONS BEFORE USING YOUR HEADPHONES.
2. Do not use your headphones near water. Clean using a dry or slightly moist cloth.
3. Do not place your headphones on any wet surfaces.
4. Do not allow children or the infirm to play with your headphones without adult supervision.
5. Do not expose your headphones to excessive heat, flames or fire.
6. Always press all buttons carefully. Do not manhandle your headphones.
7. Do not use in extremely dry environments, as this can lead to static discharge during usage.
8. Do not expose your headphones to temperatures above 40°C. Keep out of direct sunlight.
9. Do not attempt to repair this product yourself. Contact a qualified service center if your headphones
are in need of service.
10. Do not drop, puncture or expose your headphones to excessive trauma.
11. Your headphones are not intended for commercial use.
12. Do not place near objects that generate a strong magnetic field.
13. Unplug this device when not in use for long periods of time or during lightning storms.
BATTERY WARNING:
-The device is equipped with an integrated lithium ion battery. The
battery cannot be replaced. Do not attempt to remove the battery
from the device.
-Do not dispose of in fire or expose to excessive heat.
-Do not crush, puncture, incinerate, or short circuit external contacts.
-Please recycle or dispose of the battery properly. Contact your local
recycling facilities and/or the manufacturer for further information.
CAUTION
Introduction
Thank you for purchasing your Vivitar Bluetooth Headphones, item VU50012BT. You can use your
headphones with iPads, iPhones, iPods and many other types of smartphones and Bluetooth
devices to stream music and enjoy hands-free calling. In addition, once powered on, your
headphones light up in an exciting array of colors and patterns. In order to get the best results
when using your headphones, please read this manual prior to using.
Package Contents
-Vivitar VU50012BT Bluetooth Headphones
-User’s Manual with Warranty Information
Specifications
Bluetooth Specification: V4.2
Bluetooth Range: Up to 33 Feet (10 Meters)
Charging Input: DC5V
Battery Type: 320mAh, Lithium Ion Battery
Charge Time: Approximately 2 Hours
Play Time: Approximately 7 Hours*
*Applicable at 40% of maximum volume. Results will be lower when volume is higher.
A Quick Look at Your Device
Front View RearView
1. Mode/Answer
2. Play/Pause
3. Next Track / Volume +
4. Previous Track / Volume –
5. ON/OFF Switch
6. Microphone
7. LED Indicator Light
8. Charging Port
9. Auxiliary Port
1
5
6
789
2
3
4
Charging Your Headphones
Your headphones have a built-in, rechargeable lithium ion battery. To avoid damage, do not
attempt to remove the battery. The full performance of the battery is only achieved after a few
charging-discharging cycles. Charge the battery fully before first use. To do so, follow the steps
below:
1. Connect one end of the included USB charging cable to the charging port on your headphones.
Then plug the other end of the USB charging cable into a USB port on your computer or a
suitable power adapter in order to recharge the internal rechargeable battery.
NOTE: The internal battery of your headphones takes approximately two hours to charge when
completely drained.
2. When the battery is charging, the LED indicator light will turn red. The LED indicator light will
turn off when the battery is fully charged. Unplug when charging is complete.
NOTE: Overcharging could reduce the life of the battery. A charged battery will lose its capacity
if it is not used on a regular basis.
Important!
To avoid a complete discharge of the battery, charge your headphones at least once every six
months.
Pairing Your Headphones with a Bluetooth
Device
Your headphones can be paired with most Bluetooth devices including iPads, iPhones, iPod
Touches, and most smartphones, laptops and tablets. In order to pair your headphones with a
phone, follow the steps below:
1. Slide the ON/OFF Switch to the ON position to turn on your headphones. The LED indicator
light will start alternately flashing red and then blue repeatedly. This indicates that your
headphones are in pairing mode.
2. Go to the Bluetooth Manager of your Bluetooth device.
3. Search Bluetooth devices and select your headphones (most frequently listed as “Light up
headphone”) to start connecting.
4. Enter “0000” if your device asks for the PIN code.
5. Once paired, the LED indicator light will blink blue.
Auxiliary Input Mode
To use your headphones with devices that are not Bluetooth enabled, plug one end of a standard
3.5mm audio cable into the Auxiliary Port on your headphones. Plug the other end into the
headphone jack on your audio device. If the ON/OFF Switch is in the ON position while playing
music from a device connected to the Auxiliary Port your headphones will light up in an exciting
array of colors and patterns.
Using Your Headphones
Powering Your Headphones On and OFF
1. Slide the ON/OFF Switch to the ON position to turn on your headphones. If you have already
paired your headphones to your Bluetooth device, they will automatically remain paired each
time you power on your headphones.
2. Slide the ON/OFF Switch to the OFF position to power off your headphones.
Listening to Music
• Play/Pause Button: Press to play or pause a track.
• Quickly tap the “NEXT TRACK/VOLUME +” button to advance to the next song in a playlist.
• Quickly tap the “PREVIOUS TRACK/VOLUME -” button to go back to the last song in a playlist.
• Press and hold the “NEXT TRACK/VOLUME +” button to increase the volume.
• Press and hold the “PREVIOUS TRACK/VOLUME -” button to decrease the volume.
Note: You can also adjust volume and playback settings on your phone or connected audio
device.
Using the Phone Function
• Last Number Re-dial: Press the MODE/ANSWER button twice to re-dial the last number called.
• Answering a Call: Quickly press the MODE/ANSWER button to answer an incoming call.
• Reject an Incoming Call: Press and hold the MODE/ANSWER button for a few seconds to reject
an incoming call.
• Ending a Call: Quickly press the MODE/ANSWER button to end a call.
Maintenance and Care
-Before using your headphones, examine the ear cups to make sure that they are clean. Similarly,
inspect the ports and jacks of your headphones to make sure that they are clear of dust and
debris before charging or inserting an AUX cable.
-Use a soft, moist cloth to clean the cushions of your ear cups. Do not allow moisture to get inside
the ear cups. If necessary, use a small amount of dish soap diluted with water to clean more
stubborn stains. Never use any harsh chemicals or detergents. Make sure your headphones are
dry before using.
-When your headphones are not in use, they should be stored in a cool, dry place.
-Never tug or yank on the USB cable or AUX cable while they are connected to your headphones.
Connect and disconnect these cables as carefully as possible.
-Never expose your headphones to high temperatures, extreme cold, high humidity or excessive
moisture or water.
-Please recycle or dispose of your headphones properly based on the laws and rules of your
municipality. Contact local recycling facilities and/or the manufacturer of your headphones for
further information.
FCC Statement
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Vivitar One Year Warranty
This warranty covers the original consumer purchaser only and is not transferable.
This warranty covers products that fail to function properly UNDER NORMAL USAGE, due to
defects in material or workmanship. Your product will be repaired or replaced at no charge for
parts or labor for a period of one year.
What Is Not Covered by Warranty
Damages or malfunctions not resulting from defects in material or workmanship and damages or
malfunctions from other than normal use, including but limited to, repair by unauthorized parties,
tampering, modification or accident.
To Obtain Warranty Service and Troubleshooting Information:
Call 1-800-592-9541 in the U.S. or 0-800-917-4831 in the UK or visit our website at
www.vivitar.com.
To receive Warranty service along with the name and address of an authorized product service
center, the original consumer purchaser must contact us for problem determination and service
procedures. Proof of purchase in the form of a bill of sale or receipted invoice, evidencing that the
product is within the applicable Warranty period(s), MUST be presented in order to obtain the
requested service. It is your responsibility to properly package and send any defective products
along with a dated copy of proof of purchase, a written explanation of the problem, and a valid
return address to the authorized service center at your expense. Do not include any other items
or accessories with the defective product. Any products received by the authorized service
center that are not covered by warranty will be returned unrepaired.
Vivitar One Year Warranty (continued)
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
OTHER THAN THOSE EXPRESSLY DESCRIBED ABOVE SHALL APPLY. DISTRIBUTOR FURTHER
DISCLAIMS ALL WARRANTIES AFTER THE EXPRESS WARRANTY PERIOD STATED ABOVE. NO
OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR ENTITY WITH
RESPECT TO THE PRODUCT SHALL BE BINDING ON DISTRIBUTOR. REPAIR, REPLACEMENT,
OR REFUND OF THE ORIGINAL PURCHASE PRICE - AT DISTRIBUTOR’S SOLE DISCRETION
-ARE THE EXCLUSIVE REMEDIES OF THE CONSUMER. IN NO EVENT WILL DISTRIBUTOR, ITS
MANUFACTURERS, OR SAKAR INT. BE LIABLE FOR ANY INCIDENTAL, DIRECT, INDIRECT,
SPECIAL, PUNITIVE OR CONSEQUENTIAL DAMAGES (SUCH AS, BUT NOT LIMITED TO,
DAMAGES FOR LOSS OF PROFITS, BUSINESS, SAVINGS, DATA OR RECORDS) CAUSED BY THE
USE, MISUSE OR INABILITY TO USE THE PRODUCT. EXCEPT AS STATED HEREIN, NO OTHER
WARRANTIES SHALL APPLY. NOTWITHSTANDING THE FOREGOING, CONSUMER’S RECOV-
ERY AGAINST DISTRIBUTOR SHALL NOT EXCEED THE PURCHASE PRICE OF THE PRODUCT
SOLD BY DISTRIBUTOR. THIS WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN
THE ORIGINAL CONSUMER WHO PURCHASED THE PRODUCT AND IS NOT TRANSFERABLE.
Some countries, states or provinces do not allow the exclusion or limitation of incidental or
consequential damages or allow limitations on warranties, so limitation or exclusions may not
apply to you. This warranty gives you specific legal rights, and you may have other rights that
vary from state to state or province to province. Contact your authorized retailer to determine
if another warranty applies. This product is manufactured, distributed and sold by SAKAR
International, Inc. All other trademarks are the property of the respective owner, who has not
sponsored, endorsed or approved this product.
.
™
