SHUOYING DV181SB DIGITAL VIDEO CAMERA User Manual K929 V181SB00101 B
SHUOYING INDUSTRIAL (SHENZHEN) CO., LTD. DIGITAL VIDEO CAMERA K929 V181SB00101 B
SHUOYING >
User Manual
1
4
What’s Included 2Parts of the Camera 3Initial Setup
1. AV Out Port
2. Wrist Strap Connector
3. Tripod Socket
4. USB Connector
5. USB Lever
6. LED Indicator Light
7. Microphone
8. Lens
9. Speaker
10. Mode Button
11. Menu Button
12. Left / Resolution Button
13. Shutter / OK Button
14. LCD Screen
15. Up / Zoom In Button
16. SD Memory Card Slot
17. Power Button
18. Delete Button
19. Right Button
20. Down / Zoom Out Button
21. Battery Compartment
Installing the Battery Installing the Memory Card
Turning On the Camera Using the Camera
SD Memory Card
(up to 16 GB) needed
for normal use.
Insert 3 x AAA (1.5V) batteries.
Alkaline batteries recommended
(not inlcuded).
Photo Capture Mode
Video Capture Mode
Playback Mode (Photos & Videos)
Use this mode to capture photos with your camera.
After powering on your camera, press the MODE button once to
open the Photo Capture mode. To take a photo, aim your camera as
desired and press the “Shutter” button. The photo will be
automatically saved to the memory card.
To access the various menus for the Photo Capture mode, press the
MENU button while in the Photo Capture mode. For more
information, please refer to the camera’s User Manual in the
software or online.
Your camera has dierent modes for the various camera
functions.
You can switch modes by pressing the MODE button on your
camera after the camera has been powered ON.
Use this mode to capture videos with your digital camera. This is
the default mode when the camera is powered ON. To take a
video, aim your camera as desired and press the “Shutter” button
to start the recording. A red recording indicator will appear while
the recording is in progress. To stop the recording, press the
“Shutter” button again. The video will be automatically saved to
the memory card.
To access the various menus for the Video Capture mode, press the
MENU button while in the Video Capture mode. For more
information, please refer to the camera’s User Manual in the
software or online.
Use this mode to view and manage the videos and photos saved
to the SD memory card.
After powering on your camera, press the MODE button twice to
open the Playback mode. You can scroll through the videos and
photos that you captured with your camera to view or delete as
desired.
To access the various menus for the Playback mode for videos and
photos, press the MENU button while in the Playback mode. For
more information, please refer to the camera’s User Manual in the
software or online.
Main Camera Modes
1. Digital Camcorder
2. AV Cable
3. Installation CD
4. Wrist Strap
5. Built-in USB Connector (not shown)
SD Memory Card not included Accessing
the menu
Selecting
the modes
1
16
21
321
14
15
11
12
13 20
19
10
5
4
6
9
17
18
8
7
2
3
4
尺寸：360x290mm 105克铜版纸黑白双面印刷
1. warning:
Warning: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
2．Class B digital device or peripheral or cordless phone,Note:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Shielded cables must be used with this unit to ensure compliance with the Class B FCC limits.
