Skspruce Technologies Inc. Smart Access Control SAC700 Series Datasheet

Contents

Users Manual Part One

SKSpruce Technologies, Inc.
SAC700 SERIES ——SAC700
WIRELESS ACCESS CONTROLLER
S
KSpruce SAC700 wireless access controller
adopts the advanced modular hardware and
software design and uses powerful multi-core and
multi-thread processors. Therefore, SAC700 delivers
good scalability and blazing data processing perfor-
mance. Besides, SAC700 boasts rich wireless user access
and fit access point (AP) management functions and
features.
SAC700 can be deployed with SKSpruce SAP series to
construct a wireless network where SAC700 delivers
all AP configuration, control, and management com-
mands. APs are connected to the network without any
configuration and are plug-and-play. Compared with a
wireless network consisting of independent fat APs, such
a network integrates more QoS, security, and roaming
features, delivers much higher service quality and makes
services more stable. SAC700 can monitor and control AP radio
frequencies in real time. Based on the real-time monitoring data,
SAC700 can offer features such as automatic power adjustment
and dynamic channel assignment, as well as load balancing by
traffic or user quantity. These features minimize interference on
wireless signals, as well as balance and stabilize workload.
Besides the previously mentioned features, SAC700 also pro -
vides features such as L2/L3 roaming, secure user access, and
role-based user management. Applying to various networks of a
enterprise, SAC700 is an ideal choice for enterprise users who
want to deploy wireless networks.
SKSpruce Technologies, Inc.
SMART MANAGEMENT
SAC700A centrally configures and manag-
es all APs under its control. No configura-
tion needs to be done on APs. This greatly
simplifies large-scale wireless network
deployment and management. SAC700A
provides two service traffic forward-
ing modes, central forwarding and local
forwarding to adapt to different networks
and to improve network resource utiliza-
tion.
SRM
The Smart RF Management (SRM) feature
monitors the wireless network environ-
ment in real time. Based on the monitor
data, the feature automatically configures
RF parameters of all APs and adjusts the
power or channel of one or more APs,
which makes users avoid interference
from wireless devices nearby. Besides, the
SRM feature can implement wireless net-
work self-healing. Once an AP fails, the
feature automatically increases the power
of APs around to shrink or even eliminate
the blind area.
SMART LOAD BALANCING
In a WLAN that wireless users determine
the AP to connect, this will lead to some
APs are overloaded while some other APs
are quite idle. Therefore, network resource
utilization is unbalanced. This feature can
balance workload among APs by user
quantity or traffic to improve network
resource utilization.
HIGH RELIABILITY
The SAC700A supports 1：1 backup. In
a network that SAC700A 1：1 backup is
implemented, when the active SAC700A
access controller fails，all the APs con-
nected to the failed one will be switched
to the backup SAC700A immediately. The
wireless users under the failed device will
get in service or network access in a very
short time.
END-TO-END SECURE FEA-
TURES
SAC700A provides powerful secure fea-
tures to present good user experience.
• Wireless user access control: various
access authentication modes (such as
802.1X-based and portal) and strict
user access control policies
• Data encryption: 802.11i standards
• Application security: role-based ap-
plication permission control
ROAMING ANYTIME AND
ANYWHERE
With the unique wireless roaming tech-
nology and dedicated data processing
mechanism for roaming, SAC700A sup-
ports cross-controller or cross-network
seamless L2/L3 roaming.
Features
SKSpruce Technologies, Inc.
Item Description
Layer 2 function VLAN
Broadcast suppression
Layer 3 function
DHCP Server, DHCP Snooping
Static routing, OSPF protocol
VRRP protocol
WLAN
AP management and control
CAPWAP
Performance monitoring and statistics (with SKSpruce network management system)
Seamless roaming
Redundancy 1:1 redundancy; active-standby
Security
Authentication types
• Web portal authentication
• MAC authentication
• RFC 3576 RADIUS authentication
• RFC 3580 IEEE 802.1X RADIUS
• EAP authentication, including EAP-TLS, EAP-FAST, EAP-SIM/AKA
Authentication client
• RADIUS Client
• LDAP/ SSL Secure LDAP
Encryption
• WEP: 64 and 128 bit
• TKIP, AES
• SSL,TLS: RC4 128-bit, RSA1024 and 2048bit
Access control
System
management
Configuration based on CLI and WebUI
Login through console or Telnet
Syslog system monitor SNMP v1, v2c
License-based capacity (AP and user quantity) control
Product Functions
SKSpruce Technologies, Inc.
Product Model SAC700
Software parameters
12,000 DHCP users
16 DHCP pools
16,000 ARP table entries
16,000 bridge table entries
256 static routes
2000 dynamic routes
16 NAT pools
Perfor-
mance pa-
rameters
802.11 Throughput 8 Gbit/s
Max. number of managed APs in distrib-
uted mode 512
Max. number of managed APs in cen-
tralized mode 128
Max. number of managed users in dis-
tributed mode 18,432
Max. number of managed users in cen-
tralized mode 4608
VLAN 4094
Chassis
Dimensions 440 mm x 311 mm x 44.5 mm
Number of line card or RTM slots None
Chassis kit None
Line card
Model SA700A
Data interface 8 x GE (RJ45/SFP Combo)
CPU Dual-core, 800 MHz frequency
Memory 4 GB DDR3
RTM Interface 1 None
Interface 2 None
Weight (fully-loaded) 4.0 kg
Power pa-
rameters
Voltage 90 V to 264 V AC
Power frequency 50 Hz
Rated power consumption (fully-loaded) 60 W
Parameters
SKSpruce Technologies, Inc.
SKSpruce Technologies, Inc.
http://www.skspruce.com
Marketing Center：+86 10 62668369
Service Hotline：+86 4006267656
Chengdu
Level 2, A5, Tianfu Software Park,
Tianfu Avenue, Hi-tech Zone,
Chengdu.
TEL: +86 28 85231119
Beijing
Room 517, B2, Silicon Valley
Bright City, No. 1, Nongda South
Road, Haidian District, Beijing
TEL: +86 10 62667150
FAX: +86 10 82605230
Hongkong
Room 2, Level 19, Henan Build-
ing, No. 90-92, Jaffe Road, Wan-
chai District, Hongkong.
TEL: +852 28619883
Ordering Information
Name Configuration Remark
SAC700
System Standard configuration
License Management
64 APs authorized for initial purchase Standard configuration
Additional 64 APs authorized for a
new license
If you want to increase the number of managed
APs after purchase, apply for a license for up-
grade with desired AP quantity. The number of
APs that an SAC700A manage more APs is based
on the combination of licenses.
