SMA Solar Technology MRFB ZigBee Module User Manual MULTI RF BOARD Radio modem module
SMA Solar Technology AG ZigBee Module MULTI RF BOARD Radio modem module
User Manual
Technical Description 1/3 HoMan-MultiRFBoard-eng-T-TBUS113210
1 Information on this Document
Validity
This document is valid for the Multi-RF Board of type HM-MRFB.BG1. You will find the type
designation on the type label on top of the Multi-RF Board.
Purpose
This document is for the certification of the Multi-RF Board. The document summarizes the technical
data of the Multi-RF Board as well as information regarding FCC and IC Compliance of the Multi-RF
Board.
2 Multi-RF Board
The Multi-RF Board is a radio modem module. It allows the data exchange in WPAN radio networks.
The Multi-RF Board contains two radio systems:
• ZigBee radio system in 2.4 GHz ISM band
• 868.3 MHz radio system (automatically deactivated for the USA and Canada)
The Multi-RF Board has its own internal voltage controller. The antennas are integrated and strongly
attached to the printed circuit board. No external antenna can be connected.
Mechanical Data
Voltage supply
Terminals
Communication
Width x height x depth 11⁄4in. x 4 1⁄4in. x 29⁄32 in.
(30mmx108mmx23mm)
Voltage supply via 2 x 5-pole pin header
Input voltage 5 V
Current consumption < 250 mA
Number of 2 x 5-pole pin headers 1
Data transmission via 2 x 5-pole pin header
Interface SPI interface with 3.3 V logic
Pulse frequency of the interface max. 1 MHz
MULTI-RF BOARD
Radio modem module
Version: 1.0
SMA America, LLC Multi-RF Board
Technical Description 2/3 HoMan-MultiRFBoard-eng-T-TBUS113210
ZigBee radio system in 2.4 GHz ISM band
868.3 MHz radio system*
Frequency range 2 405 … 2 480 MHz
Number of frequency channels 16
Distance of frequency channels 5 MHz
Bandwidth of the radio signal 2 MHz
Transmitting power +17 dBm
Standard for radio transmission IEEE 802.15.4
Selection of antenna (antenna diversity) automatically
Selection of the frequency channel automatically
*This radio system is automatically deactivated for the USA and Canada.
Frequency 868.3 MHz
SMA America, LLC FCC and IC Compliance Information
Technical Description 3/3 HoMan-MultiRFBoard-eng-T-TBUS113210
3 FCC and IC Compliance Information
This device complies with Part 15 of the FCC Rules and with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le onctionnement
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications made to this equipment not expressly approved by SMA America, Inc. may
void the FCC authorization to operate this equipment.
RF Exposure Statement
Radiofrequency Radiation Exposure Information:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance of 8 in. (20 cm) between the
radiator and your body.
