SMC Networks RT359333DB5 5GHz 802.11n 3T3R wifi module User Manual Revised
SMC Networks Inc 5GHz 802.11n 3T3R wifi module Revised
User Manual Revised
JI5-RT359333DB5
User Manual
802.11 a/n Wireless Mini PCIE
SMC Networks
20 Mason
Irvine, CA 92618
U.S.A.
Copyright © 2013 SMC Networks
All Rights Reserved
Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no
responsibility is assumed by SMC for its use, or for any infringements of patents or other rights of third parties
which may result from its use. No license is granted by implication or otherwise under any patent or patent rights
of SMC. SMC reserves the right to change specifications at any time without notice
No part of this publication may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying and recording, or stored in a database or retrieval system for any purpose
without the express written permission of SMC.
Microsoft and Windows are registered trademarks of Microsoft Corporation. Apple and Macintosh are registered
trademarks of Apple, Inc. All other brands, product names, trademarks, or service marks are property of their
respective owners.
iii
SMCD3GNV5 Administrator Manual
Compliance
Federal
Communication Commission
Interference
Statement
This equipment has been tested and found to comply with the limits for a
Class
B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are
designed to provide reasonable protection
against harmful interference in
a
residential installation. This equipment generates uses and can
radiate
radio
frequency energy and, if not installed and used in accordance with
the
instructions, may
cause harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a
particular
installation. If this equipment does cause harmful
interference to radio
or
television reception, which can be determined by turning the equipment off
and
on, the user is encouraged to try to correct the interference by one of
the
following
measures:
- Reorient or relocate the receiving
antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different from
that
to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the
following two
conditions: (1) This device may not cause harmful
interference,
and (2) this device must accept any
interference received,
including interference
that may cause undesired
operation.
FCC Caution: Any changes or modifications not expressly approved by
the
party responsible for
compliance could void the user's authority to operate
this equipment
.
iv
JI5-RT359333DB5 User Manual
IMPORTANT
NOTE
:
FCC
Radiation Exposure
S
t
ateme
n
t:
This equipment complies with FCC radiation exposure limits set forth for
an
uncontrolled environment.
This equipment should be installed and
operated
with minimum distance 20cm between the radiator &
your
body.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
IEEE 802.11 a/n operation of this product in the U.S.A.
is
firmware-limited to channels 1 through
11.
This device is
intended
only for OEM
integrators
under the
following condition
s:
The antenna must be installed such that 20 cm is maintained between
the
antenna and users,
and
The transmitter module may not be co-located with any other transmitter
or antenna.
As long as the above two conditions are met, further transmitter test will not
be
required. However, the
OEM integrator is still responsible for testing
their
end-product for any additional compliance
requirements required with
this
module installed (for example, digital device emissions, PC
peripheral
requirements,
etc.).
IMPORTANT NOTE: In the event that these conditions can not be met
(for
example certain laptop
configurations or co-location with another
transmitter),
then the FCC authorization is no longer
considered valid and the FCC ID
can
not be used on the final product. In these circumstances, the OEM
integrator
will be responsible for re-evaluating the end product (including the
transmitter)
and obtaining
a separate FCC
authorization.
注意
!
依據
低功率電波輻射性電機管理辦法
第十二條
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用
者均不得擅自
變更頻率、加大功率或變更原設計之特性及功能。
第十四條
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現
有干擾現象時，
應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信規定作業之無線電信。
低功率射頻電機
須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干
擾。
v
SMCD3GNV5 Administrator Manual
End Product
Labeling
This transmitter module is authorized only for use in device where the
antenna
may be installed such
that 20 cm may be maintained between the antenna
and
users. The final end product must be labeled
in a visible area with the
following:
“Contains TX FCC ID: JI5-359333DB5
”.
Manual
Information
That Must be
Included
This module must be properly installed in an approved device to function properly.Installation should be
performed only at the factory or by a qualified service technician.The module should be inserted into the
mini-PCIE connector. Once installed into the mini-PCIE card slot, carefully attach the Wi-Fi antennas
to the connectors on the card.
The OEM integrator has to be aware not to provide information to the end
user
regarding how to install
or remove this RF module in the user manual of
the
end product which integrates this
module.
The user manual for OEM integrators must include the following information
in
a prominent location
“IMPORTANT NOTE: To comply with FCC RF
exposure
compliance requirements, the antenna used
for this transmitter must
be
installed to provide a separation distance of at least 20 cm from all persons
and
must not be co-located or operating in conjunction with any other antenna
or transmitter.
For all the model ship to USA market, OEM integrator shall limit the accessible
channel
to US channel
36-48 and 149-165 only during the manufacturing process by special firmware
setting
which is not
available to the end
user.
vi
JI5-RT59333DB5 User Manual
Contents
Compliance ............................................................................................................. iii
Contents .................................................................................................................. vi
About this Manual .................................................................................................... 7
1 Introduction ........................................................................................................... 8
Features ........................................................................................................................ 8
What is Wireless LAN ................................................................................................... 9
Wireless LAN Modes .................................................................................................. 10
Notes on Wireless LAN
Configuration
.................................................................. 11
7
SMCD3GNV5 Administrator Manual
About this Manual
This User’s Manual describes how to install and operate your 802.11a/n
Wireless
LAN Module. Please read this manual before you install the
product.
This manual includes the
following
topics:
Product description and
features.
8
JI5-RT359333DB5 User Manual
1 Introduction
The JI5-RT359333DB5, which is based on the RT35933 solution, is a dual-band mode
802.11a/n wireless LAN embedded Mini-PCI module for Wireless Cable Gateway Router.
JI5-RT359333DB5 will be a RF module of AP
board.
Additionally, provide new feature to
existing Wireless Cable Gateway Router
products.
Features
Embedded to any AP with Mini-PCI type -B
slot.
•
IEEE 802.11 a/n
compatible.
•
Backward compatible with IEEE 802.11a
standard.
•
Wire-free access to networked resources from anywhere beyond the
desktop.
•
Delivers data rate up to 450
Mbps.
•
801.11 a/n: Dynamically shifts between 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
network
speed,
based on signal strength, for maximum availability and reliability
of
connection.
•
Uses 5GHz frequency band, which complies with worldwide
requirement
•
Ensures great security by providing the 64/128/256 Wired Equivalent Privacy (WEP)
and WPA/PWA2.
•
802.11i standards
support.
•
WMM
support.
9
SMCD3GNV5 Administrator Manual
What is Wireless LAN
Wireless Local Area Network (WLAN) systems offer a great number
of
advantages over
traditional wired systems. WLAN is flexible and easy to
setup
and manage. They are also
more economical than wired LAN
systems.
Using radio frequency (RF) technology, WLAN transmit and receive data
through
the air.
WLAN combine data connectivity with user mobility. For example,
users
can roam from a
conference room to their office without being disconnected
from
the
LAN.
Using WLAN, users can conveniently access-shared information, and
network
administrators can configure and augment networks without installing or
moving
network
cables.
WLAN technology provides users with many convenient and cost saving
features:
Mobility:
WLAN provide LAN users with access to real-time
information
anywhere in
their organization, providing service opportunities that
are
impossible with wired
networks.
Ease of
Installation:
Installing is easy for novice and expert users
alike,
eliminating the
need to install network cables in walls and
ceilings.
Scalability:
WLAN can be configured in a variety of topologies to adapt
to
specific
applications and installations. Configurations are easily
changed
and range from
peer-to-peer networks suitable for a small number of
users
to full infrastructure networks of
thousands of users roaming over a
broad area.
10
JI5-RT359333DB5 User Manual
Wireless LAN Modes
Wireless LANs can be configured in one of two
ways:
1.
Ad-hoc Networking
Also known as a peer-to-peer network, an
ad-hoc
network is one that allows all workstations
and
computers in the network to act as servers to all
other
users on the network. Users on the
network can
share
files, print to a shared printer, and access the
Internet
with a shared modem.
However, with
ad-hoc
networking, users can only communicate with
other
wireless LAN
computers that are in the wireless
LAN
workgroup, and are within
range.
2.
Infrasture Networking
Infrastructure networking differs from
ad-hoc networking
in that it includes an access point.
Unlike
the ad-hoc structure where users on the LAN
contend
the shared bandwidth, on an
infrastructure network
the
access point can manage the bandwidth to
maximize
bandwidth
utilization.
Additionally, the access point enables users on
a
wireless LAN to access an existing wired
network,
allowing wireless users to take advantage of the
wired
networks resources, such as
Internet, email,
file
transfer, and printer
sharing.
Infrastructure networking has the following
advantages
over ad-hoc
networking:
Extended range: each wireless LAN
computer
within the range of the access point
can
communicate with other wireless LAN
computers
within range of the access
point.
Roaming:
the access point enables a
wireless
LAN computer to move through a building
and
still
be connected to the
LAN.
Wired to
wireless
LAN
connectivity:
the
access
point bridges the gap between wireless
LANs
and
their wired
counterparts.
11
SMCD3GNV5 Administrator Manual
Notes on Wireless LAN
Configuration
When configuring a wireless LAN (WLAN), be sure to note the following
points:
Optimize the performance of the WLAN by ensuring that the
distance
between
access points is not too far. In most buildings, WLAN
Adapters
operate within a
range of 100 ~ 300 feet, depending on the thickness
and
structure of the
walls.
Radio waves can pass through walls and glass but not metal. If there
is
interference
in transmitting through a wall, it may be that the wall
has
reinforcing metal in its
structure. Install another access point to
circumvent
this
problem.
Floors usually have metal girders and metal reinforcing struts that
interfere with
WLAN transmission.
12
JI5-RT59333DB5 User Manual
20 Mason
Irvine, CA. 92618
U.S.A.
http://na.smc.com
Document number: JI5-RT359333DB5
