SMC SMM-106 Wireless Microphone User Manual SMM 106 OW 21 Novt 02
International SMC (HK) Ltd. Wireless Microphone SMM 106 OW 21 Novt 02
SMC >
User Manual
Maintenance
!To ensure long battery life, please make sure that both
the Receiver and the Microphone are set to the OFF
position when not in use. To be absolutely certain, we
advise you to remove the AA batteries from both the
Receiver and the Microphone when they are not in
use.
!Please remove the Receiver from the Microphone
Input Jack of your Singing Machine karaoke machine
when not in use. This will reduce the possibility of
damage to the Receiver.
Troubleshooting
1.PROBLEM: The Microphone indicator light is
on, but there is no sound when I sing.
a) Is the Microphone switch set to ON?
b) Is the Singing Machine karaoke machine correctly
plugged in and switched on?
c) Are the Microphone Volume and Master Volume
controls of your Singing Machine set to a high enough
level?
d) Does the Receiver contain one (1) AA battery, is it
properly connected to your Singing Machine, and is it
turned on?
Troubleshooting
2.PROBLEM: The Receiver indicator light is on,
but there is no sound when I sing.
a) Is the Receiver properly connected to the Singing
Machine?
b) Is the Microphone switch set to ON?
c) Does the Microphone contain one (1) AA battery?
d) Is the Singing Machine karaoke machine correctly
plugged in and switched on?
e) Are the Microphone Volume and Master Volume
controls of the Singing Machine karaoke machine set to
a high enough level?
3.PROBLEM: The Singing Machine karaoke
machine I am using is switched on, but there is no
sound when I sing.
a) Is the Microphone switch set to ON?
b) Does the Microphone contain one (1) AA battery?
c) Are the Microphone Volume and Master Volume
controls of your Singing Machine set to a high enough
level?
d) Does the Receiver contain one (1) AA battery, is it
properly connected to your Singing Machine, and is it
turned on?
Troubleshooting
Please call Customer Service at (954)-596-1110 if the
Troubleshooting Guide information does not correct your
problem.
Servicing of a Singing Machine by an unauthorized repair
facility will void your warranty. The Singing Machine
cannot guarantee future repairs on machines that have
been tampered with by unauthorized personnel.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Warning: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
Instructions for Non-Wireless Use
1. Plug Cannon Jack into the Microphone, making
sure that the three holes line up with the three
prongs in the base of the Microphone.
2. Plug the Microphone Cord into the Microphone
Input Jack of your Singing Machine karaoke
machine.
3. Set the switch on your Singing Machine karaoke
machine to the ON position.
4. Set the switch on the Microphone to the MIC
position.
Your Singing Machine SMM-106 Wireless Microphone is
now ready for non-wireless use!
NOTE: For best non-wireless performance, please
remove batteries from the Microphone prior to
non-wireless use.
The Singing Machine Company, Inc.
6601 Lyons Road, Bldg. A7, Coconut Creek, FL33073-9902, USA.
TEL: (954) 596-1000 FAX: (954) 596-2000 PRINTED IN CHINA
VISIT OUR WEBSITE www.singingmachine.com
4 5 6
SMM-106
OWNER’S MANUAL
Please read before using this unit.
The Singing Machine is a registered trademark of The Singing Machine Co., Inc.
WIRELESS MICROPHONE
Contents
1. Wireless Microphone x 1
2. Microphone Receiver x 1
3. Microphone Antenna x 1
4. Microphone Cord with Cannon Jack and ∅6.3 mm
Jack x 1
5. ∅3.5 mm Jack adapter x 1
Congratulations on your purchase of a Singing Machine
SMM-106 Wireless Microphone! We at the Singing Machine know
that it will provide you and your friends with endless hours of
entertainment. Inside you will find instructions on how to use and
maintain your SMM-106.
In the unlikely event that you will be using your SMM-106 Singing
Machine Wireless Microphone in an area of high radio frequency
interference, you may need to temporarily make use of the non-
wireless option by attaching it to the included microphone cord.
Microphone Details
!Settings
The switch on your Singing Machine SMM-106 Wireless
Microphone has three settings:
1. ON - The switch is in the top position. For wireless
use, the microphone will function. The red indicator
light is on. The microphone will use battery
power.
2. MIC - The switch is in the middle position. For non-
wireless use, the microphone will function. If the
battery is removed from the microphone, the red
indicator light will not be turned on.
3. OFF - The switch is in the bottom position. The
microphone will not function. The red
indicator light is off. The microphone will not use
battery power.
Important Note: When the microphone switch is set to
OFF, noise may be generated from the karaoke machine.
Please make sure to reduce both the MASTER VOLUME
and MIC VOLUME to the low level OR switch off the
receiver before turning off your microphone.
Instructions for Wireless Use
1. Insert one (1) AA battery into the Microphone.
2.Plug the Antenna into the bottom of the
Microphone.
3. Insert one (1) AA battery into the slot located in
the back of the Receiver.
4. Set the switch on the Microphone to the middle
MIC position.
5. Plug the Receiver into the Microphone Input Jack of
your Singing Machine karaoke machine.
6. Set the switch on your Singing Machine karaoke
machine to the ON position.
7. Set the switch on the Receiver to the ON position.
8. Set the switch on the Microphone to the top ON
position.
Your Singing Machine SMM-106 Wireless Microphone is
now ready for wireless use!
NOTE: If you encounter minor interference during
wireless use, please adjust the tuning screw on the
Receiver, and roll up the plastic Receiver Antenna.
Excessive interference will require temporary non-
wireless use.
1 2 3
1 2
345
