User Manual
CONTROL LOCATIONS
WIRELESS MICROPHONE
48. ON Position 51. STANDBY Position
49. Battery Compartment 52. OFF Position
50. LED Indicator
E11
ENGLISH
49
50
51
52
48
RADIO AND OTHER OPERATIONS
SING ALONG - RADIO
1. Follow operating instructions for AM/FM radio.
2. Connect the supplied Microphone to either one of the Mic input jacks.
3. Adjust Master Volume and Mic Volume. Your voice will be combined with the radio
station output and will be heard through the speaker.
Note: Echo effect cannot be activated in radio mode.
PUBLIC ADDRESS - USING A MICROPHONE
The unit can be used as a PA (Public Address System).
Public Address (PA) Operation Procedures
1. Connect the supplied Microphone to either one of the MIC input jacks.
2. Press the ON/OFF button to turn the unit on.
3. Set the Function Selector to AUX. Move the MIC VOLUME control to central position.
4. Move the ON/OFF switch located on the Microphone to ON position and speak or sing
to the Microphone. The Microphone sensitivity and loudness could be adjusted as
required by turning the MIC VOLUME control and/or MASTER VOLUME control.
5. To add depth or ambiance to your voice, adjust the ECHO control until the desired effect
is obtained.
Note: To prevent feedback or whistling from occurring, please be sure that the
microphone is not too close to the unit.
1) Lift up the battery compartment cover at the front of the handle.
2) Place a 9V battery in the compartment as indicated by the polarity symbols (+ and -) marked
inside the compartment of the wireless microphone.
3) Replace the cover.
4) The switch on wireless microphone has three settings:
1. ON - The switch is in the top position. The microphone will function. The red indicator
light is on.
2. STANDBY - The switch is in the middle position. The microphone will not function. The
red indicator light is on.
NOTE: The purpose of this setting is to maintain a connection between the microphone
and the Singing Machine when moving around the area in which it is being used.
3. OFF - The switch is in the bottom position. The microphone will not function. The red
indicator light is off.
NOTE: To ensure long battery life, please make sure that the wireless microphones is set to the
OFF position when not in use. When not in use for a long period of time, we recommend
that you remove the DC 9-V battery.
SMM-107 WIRELESS MICROPHONE OPERATIONS
E18
ENGLISH
WIRELESS MICROPHONE INFORMATION
Warning: Modifying, tampering and adjustment to this unit or replacement of any
transmitter component (crystal, semiconductor, etc.) to this unit that could result in a
violation of the rules.
FCC NOTICE
This wireless microphone system complies with Part 90 of FCC Rules. There is one frequency
available for the system. You must get a licence for the frequency you plan to use before you use
the system.
Please look for this website http://wireless.fcc.gov/uls/ to apply the licence or phone to the
nearest FCC offices and contact them to get the necessary application. Licensibility depends on
how you will use the system.
For RF exposure
“IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no
change to the antenna or the device is permitted. Any change to the antenna or the device could
result in the system exceeding the RF exposure requirements.”
SAFETY INFORMATION
Your wireless microphone contains a low power transmitter. When the EUT is power on and it
sends out radio frequency (RF) signals. In August 1996, the Federal Communications
Commissions (FCC) adopted RF exposure guidelines with safety levels for wireless devices.
IMPORTANT
To maintain compliance with the FCC's RF exposure guidelines hold the transmitter and
antenna at least 1 inch (2.5 centimetres) from your face and speak in a normal voice, with the
antenna pointed up and away from the face. Ensure that the antenna is at least 1 inch (2.5
centimetres) from your body when you using your wireless microphone.
Use only the supplied antenna. Unauthorised antennas, modifications, or attachments could
damage the transmitter and may violate FCC regulations.
E19
ENGLISH
NOTE:
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER AUTHORITY
TO OPERATE THE EQUIPMENT.
