SMC SMM-112-T Wireless Microphone User Manual SMM 112 Instruction Manual lab test
International SMC (HK) Ltd. Wireless Microphone SMM 112 Instruction Manual lab test
SMC >
Users Manual
SMM-112
Instruction Manual
PROFESSIONAL WIRELESS
MICROPHONE
Please read before using this unit.
Ò
The Singing Machine is a registered trademark of The Singing Machine Co., Inc.
0678
Contents
1. Headset Wireless Microphone x 1
2. Microphone Receiver x 1
3. Microphone Transmitter x 1
Congratulations on your purchase of a Singing Machine Wireless
Microphone. We at the Singing Machine know that it will provide you and
your friends with endless hours of entertainment. Inside you will find
instructions on how to use and maintain this unit.
Microphone Transmitter Details
Settings
The switch on the transmitter of your Singing Machine Wireless
Microphone has three settings:
1. ON - The switch is set to ON position. The microphone will function. The
red indicator light is on. The microphone will use battery power.
2. STANDBY - The switch is set to STANDBY position. The microphone will
not function. The red indicator light is on. The microphone
will use battery power.
NOTE: The purpose of this setting is to maintain a connection between the
microphone and the receiver when moving around the area in
which it is being used.
3. OFF - The switch is set to OFF position. The microphone will not function.
The red indicator light is off. The microphone will not use battery
power.
Important Note: When the microphone transmitter switch is set to OFF,
noise may be generated from the karaoke machine. Please make sure to
reduce both the MASTER VOLUME and MIC VOLUME to the low level OR
switch off the receiver before turning off your microphone.
1
123
Instructions for Use
1. Insert one (1) active DC 9-Volt battery into the slot located at the
bottom of the transmitter.
2. Insert one (1) active DC 9-Volt battery into the slot located in the back
of the receiver.
3. Plug the Æ3.5mm microphone cord into the transmitter input jack.
4. Hold the transmitter on the belt by attached clip.
5. Properly wear the wireless headset microphone and adjust the mic
head by its flexible cord to appropriate position.
6. Set the switch on the transmitter to the STANDBY position.
7. Plug the receiver into the Microphone Input Jack of your Singing
Machine karaoke machine.
8. Set the switch on your Singing Machine karaoke machine to the ON
position.
9. Adjust the Master Volume and Mic Volume Controls of your Singing
Machine to a comfortable level.
10. Set the switch on the receiver to the ON position.
11. Set the switch on the transmitter to the top ON position.
Your Singing Machine Wireless Microphone set is now ready for use!
Maintenance
!To ensure long battery life, please make sure that both the Receiver and
the Transmitter are set to the OFF position when not in use. To be
absolutely certain, we advise you to remove the 9-Volt batteries from
both the Receiver and the Transmitter when they are not in use.
!Please remove the Receiver from the Microphone Input Jack of your
Singing Machine karaoke machine when not in use. This will reduce the
possibility of damage to the Receiver.
2
3
1.PROBLEM: The Transmitter indicator light is on, but there is no sound
when I sing.
a) Is the Transmitter switch set to ON?
b) Is the Singing Machine karaoke machine correctly plugged in and
switched on?
c) Are the Microphone Volume and Master Volume controls of your Singing
Machine set to a high enough level?
d) Does the Receiver contain one (1) 9-volt battery, is it properly connected
to your Singing Machine, and is it turned on?
2.PROBLEM: The Receiver indicator light is on, but there is no sound when
I sing.
a) Is the Receiver properly connected to the Singing Machine?
b) Is the Transmitter switch set to ON?
c) Does the Transmitter contain one (1) 9-volt battery?
d) Is the Singing Machine karaoke machine correctly plugged in and
switched on?
e) Are the Microphone Volume and Master Volume controls of the Singing
Machine karaoke machine set to a high enough level?
3.PROBLEM: The Singing Machine karaoke machine I am using is
switched on, but there is no sound when I sing.
a) Is the Transmitter switch set to ON?
b) Does the Transmitter contain one (1) 9-volt battery?
c) Are the Microphone Volume and Master Volume controls of your Singing
Machine set to a high enough level?
d) Does the Receiver contain one (1) 9-volt battery, is it properly connected
to your Singing Machine, and is it turned on?
Troubleshooting
Troubleshooting
CAUTION: Two of same microphones should not be used in same location
unless with one wireless and one wired microphone.
Please call Customer Service at (866) 670-6888 if the Troubleshooting
Guide information does not correct your problem.
Servicing of a Singing Machine by an unauthorized repair facility will void
your warranty. The Singing Machine cannot guarantee future repairs on
machines that have been tampered with by unauthorized personnel.
4
NOTE:
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER AUTHORITY
TO OPERATE THE EQUIPMENT.
PRINTED IN CHINA
The Singing Machine Company, Inc.
6601 Lyons Road, Bldg. A7, Coconut Creek, FL33073-9902, USA.
TEL: (954) 596-1000 FAX: (954) 596-2000
VISIT OUR WEBSITE www.singingmachine.com
