SSK SSM-F200 Portable Smart Storage User Manual SSM F200
SSK CORPORATION Portable Smart Storage SSM F200
SSK >
User Manual
Quick settings
Thank you for purchasing SSK Cloud SSM-F200.
Please read the manual carefully before using:
Product interfaces and LED indicators
RJ45 Ethernet port
Power
Power indicator
WiFi indicator
How to charge the product
Charge it by PC/Mac
Charge it by USB adapter
Ways to connect PC to SSM-F200 Access to the product by SAMBA
Open my computer, and input \\10.10.10.254 in the
address bar
Visit the product on WEB
Open IE explorer, and enter 10.10.10.254 into the
address bar
Connect SSM-F200 to PC by the wire–
High-speed HDD mode Remote accessing mode
1.First, connect SSK Cloud to Internet
2.Then click on the remote access icon and login
TIPS AND FAQ of SSK
What is “SSM-F200 SSK Cloud”?
“SSM-F200 SSK Cloud” is a solution for the
storage, backup and management of personal
data, the system of which can keep the privacy and
stability of the data effectively, make the complex
backup and management of data become simpler
and easier.
How about its features?
How to connect it with mobile
Can videos stored in it be played directly?
Wireless transmission rate
SSK Cloud adopts 2.4G network output 802.11n
wireless protocol standards, its max transmission
rate can be 300Mbps, with 2.4G network, signal
coverage of which is broad and its signal
penetrability is strong.
The system of SSK Cloud
The Linux of the SSK Cloud uses is developed by SSK, and it
has a good security rate and high efficiency. And it can be
more intelligent and stable by periodical OTA update.
The HDD and Format of SSK Cloud
Please do not shake or drop it when it is powered in order to
make sure its normal work, because of the build-in 2.5” 1TB
HDD. The partition and format of the product has been done
already, so it can be used directly after setup.
The warranty and DATA
One year warranty service is provided after sales, and the HDD can
be changed freely if there is malfunction or damage which is
comply with the warranty regulations during the warranty period.
*And all data in the SSK Cloud will not be saved or recovered when
its HDD need to be changed or repaired, so synchronize backup
your data to the public cloud is recommended.
The dormancy of the product
In order to make sure its efficiency and stability, the HDD of the
product will shift work/dormancy status automatically, to reduce
power consumption and a better protection for the HDD.
RESET
（Factory reset)
Wireless connection
Wired connection
USB3.0 typeB port
3
②
Built-in 2.5 inch 1TB storage, with USB3.0Hi-transmission rate;
Built-in 4000mAh Lithium polymer battery, portable and
convenient to use;
High-gain WiFi antenna, 300Mbps wireless connecting and
transmitting rate;
Simple APP remote management, multiple fast backup modes;
Support remote access and manage, you can read and store the
data anywhere anytime;
Support multiple platforms using, such as IOS, Android,
Windows, Mac OS.
1.
2.
3.
4.
5.
6.
Connect the WIFI hotspot of SSKCLOUD showed in your
mobile phone, and then click the APP to visit the cloud.
No matter what kind of your device is, Apple or Android, can
play the main stream format video directly by SSKCLOUD
client-side software.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without RF striction.
