ST Engineering Telematics Wireless 2W4GB1 4G INTERPRETER User Manual 4G INTERPRETER

Telematics Wireless Ltd. 4G INTERPRETER 4G INTERPRETER

User Manual

_____________________________________________________________________________________

Master Meter, Inc. 101 Regency Pkwy, Mansfield, TX 76063 T: 817-842-8000 F: 817-842-8100 MasterMeter.com
4G
INTERPRETER
Installation
Instructions
FCC ID: NTA2W4GB1
Rev 1.0
April, 2013
_____________________________________________________________________________________

Master Meter, Inc. 101 Regency Pkwy, Mansfield, TX 76063 T: 817-842-8000 F: 817-842-8100 MasterMeter.com
CAUTION
The User and the Installer should be aware that changes and modifications to the equipment not
expressly approved by Master Meter could void warranty and the user's authority to operate the
equipment.
Professionally trained personnel should install the equipment.
The antenna used for this transmitter must be installed to normally provide minimum separation
distance of at least 20 cm from all persons and must not be co-located or operating in conjunction
with any other antenna or transmitter
ATTENTION
The digital portion of the transceiver has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 90 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
1.) Reorient or relocate the receiving antenna.
2.) Increase the separation between the equipment and receiver.
3.) Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4.) Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 90 of FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
_____________________________________________________________________________________

Master Meter, Inc. 101 Regency Pkwy, Mansfield, TX 76063 T: 817-842-8000 F: 817-842-8100 MasterMeter.com
MULTI-JET METER INSTALLATION INSTRUCTIONS
The installation instructions detailed below are consistent with recommendations by the American
Water Works Association in AWWA Manual M6, Water Meters-Selection, Installation, Testing, and
Maintenance.
WE RECOMMEND IN THE DESIGN OF THE INSTALLATION:
1. The installation should include a high quality, low pressure loss shutoff valve
upstream of the meter to prevent water damage to the customer property when service
is required, a downstream shutoff valve is likewise recommended.
2. The meter should be installed in a horizontal plane, with the register upright, in a
location accessible for reading, service and inspection.
3. The installation should be leak-tight, with properly sized gaskets. When meter
connections are ordered from Master Meter, gaskets are provided. Appropriate gaskets
and couplings also are available from a qualified waterworks distributor. Whenever a
meter is pulled from the line, discard and replace the old gaskets.
4. Although AWWA opposes the grounding of electrical systems to potable water
delivery lines, such practices do exist. To prevent accidental harm to service personnel,
make certain that an electrical grounding strap is installed around the meter.
_____________________________________________________________________________________

Master Meter, Inc. 101 Regency Pkwy, Mansfield, TX 76063 T: 817-842-8000 F: 817-842-8100 MasterMeter.com
AT THE TIME OF INSTALLATION:
1. Thoroughly flush the service line upstream of the meter to remove dirt and debris.
2. Remove meter spud thread protectors. Note: To protect the meter spud threads, sore
the meter with the thread protectors in place.
3. Set the meter in the line. Arrows on the side of the meter and above the outlet spud
indicate the direction of flow.
4. Do not over-tighten connections; tighten only as required to seal. Do not use pipe
sealant or Teflon tape on meter threads.
5. With upstream shutoff valve only: Open the shutoff valve slowly, to remove air from
meter and service line. Open a consumer faucet slowly to allow entrapped air to escape.
Close the customer Faucet.
5.1. With upstream and downstream shutoff valves installed:
A. To test the installation for leaks: Close the outlet (downstream) shutoff valve.
Open the inlet (upstream) shutoff slowly until the meter is full of water.
B. Open the outlet (downstream) valve slowly until air is out of the meter and
service line. Open a customer faucet slowly to allow entrapped air to escape.
Close the customer faucet.
