Telematics Wireless Ltd. Electric Meter Reader Transmitter ICON Installation Manual

users manual

MM REV 4/30/2007
…………………………………………………………………………………………………………………………
Master Meter, Inc. - 101 Regency Parkway, Mansfield, TX 76063 www.mastermeter.com
Toll Free: 800-765-6518 - Main Line: 817-842-8000 - FAX: 8178428100 info@mastermeter.com
INSTALLATION INSTRUCTIONS
ICON ELECTRICITY METER
Download manual from Master Meter Web site. http://www.mastermeter.com/en/downloads.html
178TTTTTTTTTTTTGGGGGGGGGGGGGGGGGGGGG428100
FCC ID NTAICON240V
The user and the installer should be aware that changes and modifications to the equipment not expressly approved by Master Meter could void warranty and the
user’s authority to operate the equipment. Professionally trained personnel should install the equipment.
NOTE: The antenna used for this transmitter must be installed to normally provide minimum separation distance of at least 20 cm from all persons and
must not be co-located or operating in conjunction with any other antenna or transmitter.
Transmission duty cycle is limited by its design not to exceed 0.12%
For optimum performance
Meter should be installed upright (parallel to the wall) and not on an angle.
Meter should be located at open space or in close box with windows, not in close metal box.
Installed upright parallel to the wall indicate 240 volt version
FIELD PROGRAMABLE PARAMETERS
DEFAULT PARAMETERS
USER CODE 5 DIGITS USER CODE 0
TRANSMISSION INTERVAL 5 DIGITS TRANSMISSION INTERVAL 11 second
TRANSMISSION OFF/ON TRANSMISSION OFF
ATTENTION:
The digital portion of the transceiver has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1.) Reorient or relocate the receiving antenna.
2.) Increase the separation between the equipment and receiver.
3.) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4.) Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
o
p
eration.
