DRAFT

TULIP

Congratulation! You have joint the exclusive client group of

Ituran, U.S.!

Our system allows for the location of vehicles in open area, urban

and metropolitan area.

For efficient and useful operation of the TULIP, please follow the

instructions.

DRAFT

Installation instructions

1. Install the unit in hidden location in the vehicle

Use the Mounting Legs to screw the unit or to tie it up with

strips.

11 22

2. Connect the main power (12 V) to the D25 connector (1)

to pins No 1/14 (+) and pins No.3/16 (-)

3. Connect the RF- Antenna to the TNC connector (2).

3. Call Ituran operating center for unit remote initialization.

We will be happy to assist you at customer support center
