1.2 Product Content
1. ROBOT INTRODUCTION
3
1.1 Product Introduction
Congratulations! You are now the master of RoboAttack from Think Gizmos. This super
cool RC robot spins in 360 degrees, features realistic ghting sound eects, dazzling lights,
funky music and is capable of ring long distance missile from its chest. This gives you the
ultimate weapon when ghting other inferior RC robots with your friends.
Robot Remote
IR Receiver Flashing Lights
Missile Launcher
Removable Shield
Arm controlled by RC to
swing up and down.
Wheels on feet
RC Robot RoboAttack x1
Remote Control x1
Missiles x8
Shield x1
Instruction Manual x1
2. INSTRUCTIONS
4
2.1 Battery Installation
1. Before changing batteries, ensure RoboAttack is switched OFF.
2. Using a screwdriver, carefully unscrew the battery cover.
3. For the Robot, insert 4xAA batteries into the compartment making sure you follow the
layout for polarity (g1).
4. For the Remote Control, insert 2xAA batteries into the compartment making sure you
follow the layout for polarity (g2).
5. Carefully replace the battery compartment cover and tighten screw until hand tight.
Fig 1 Fig 2
2.2 Operating Instructions
1. Turning On: On the back-right of the Robot, push the switch to the “on” position. The
lights of the robot will start ashing and the robot will make its starting sound.
2. Controlling: Wait until this sound has nished. The robot will then enter “standby” mode.
You can now take control of the robot using the supplied remote control.
3. Turning O: On the back-right of the robot, push the switch to the “O” position. The
Robot’s lights will turn o and the Robot is now powered o.
Press Key (1): Stride Forward.
Press Key (2): Stride Backward.
Press Key (3): Turn to the Left.
Press Key (4): Turn to the Right.
Press Key (5): Slide Forward.
Press Key (6): Slide Backward.
Press Key (7): Raise arm and re gun.
Press Key (8): Launch Missile.
Press Key (9): Dance.
Press Key (10): Cancel Action.
1
4
2
5
8
6
9
3
Indicator
7
10
RC Receiver LED
3. PRODUCT INFORMATION
5
3.1 Product Description
●Light Eect: Multiple lighting eects can be triggered to show from the Eyes, Gun and
Chest.
●Action Mode: RoboAttack can stride or slide backwards and forwards, plus can turn left
or right. When performing these movements, RoboAttack will emit a “realistic sound
eect.”
●Dance Mode: RoboAttack will emit his favourite dance tune and start dancing &
grooving... Awesome dance moves!
●Fighting Mode: RoboAttack can hold 6 rounds of missiles in his chest, load them up and
watch it spin as he res them, destroying all in his path.
●Energy Saving Mode: After 1 minute of inactivity, the robot will automatically enter power
saving mode. Robot will need to be restarted if this happens.
Problem Reason Solution
Robot doesn’t turn on Batteries may be at or
inserted incorrectly
Check batteries have power
and are inserted correctly
Robot is sluggish, sounds are
weak and lights are dim
Insucient power Please replace batteries
Remote control does not
work properly
Insucient power Please replace batteries
Remote control signal is
obstructed
Point remote control directly
at the robots head
Remote control is too far
away
Ensure you the remote con-
trol is within 3 metres of the
robot
Robot has shut down auto-
matically
Robot has entered energy
saving mode due to 1 minute
of inaction
Turn the robot o and then
on again
3.2 Solutions To Common Queries
Loading the missiles: Insert missiles into the loader as per the image (g3). Push rmly but
not aggressively. When the missile is stuck tight it is ready for launching.
Caution: Although missiles are soft rubber tipped and will not hurt if they hit you or your
child, do not under any circumstances aim at another person’s eyes.
Fig 3
4. BATTERY USAGE WARNINGS
6
1. DO NOT put the battery close to naked ames. Batteries can explode if left in res.
2. DO NOT mix old and new batteries in the robot as this could lead to irregular
functionality.
3. When a battery is out of power, remove the battery to avoid battery leakage that may
cause damaged to this product.
4. This product contains some small parts and is not suitable for children under 3.
Children should seek help of an adult when changing the batteries.
5. Please insert the batteries the correct way round in the compartment.
6. To avoid causing danger. DO NOT make the polarity of the batteries short-circuit.
7. When Robot not in use for an extended period, please remove all the batteries.
CAUTION
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
5. WARRANTY
5.1 Warranty Information
Think Gizmos, Unit 19, Lawson Hunt Industrial Park,
Broadbridge Heath, West Sussex, RH12 3JR
Tel.: +44/(0)203 384 8304
help@thinkgizmos.com ● www.thinkgizmos.com
What is Covered:
This warranty covers any defects in materials or workmanship, with the exceptions stated
below.
How Long Coverage Lasts:
This warranty runs for 1 Year from the date your RoboAttack is delivered.
What is not covered:
Any problem that is caused by abuse, misuse, or an act of God (such as a ood) are not
covered.
What We Will Do:
If the Product proves defective during the warranty period, we will provide you with the
instructions for the return, and we will take one of the following actions: (i) replace the
Product with a product that is the same or equivalent to the Product you purchased; (ii)
repair the Product; or (iii) refund to you the whole of or part of the purchase price of the
Product.
How To Get Service:
To obtain instructions on how to obtain service under this warranty, contact our customer
service by phone or email. You will nd the contact details of our customer service below.
Customer service may ask you questions to determine your eligibility under this warranty,
and if you are eligible you’ll be given instructions for returning the defective Product. If
we send you a replacement or repair your Product, we will pay the cost of delivering the
replacement or repaired Product to you.
Do not return the item to the original place of purchase, please contact Think
Gizmos direct.
7
“CE” marking states that the product is compliant to European Directives
2014J35/EU Low Voltage Directive (LVD)
2004/108/EC EMC Directive
It is possible to request a full copy of Declaration of compliance from the
Distributor:
This product complies with the rules of RoHS Directive(2011/651EU)
This product complies with the rules of Eup Directive(2009/125/EC)
Thinkgizmos is a registered trademark of Paramount Zone Ltd
Meaning of the ‘Dustbin’ Symbol:
To protect our environment, do not dispose of electrical equipment in with domestic waste.
Please return any electrical equipment that you will no longer use to the collection points
provided for their disposal.
This helps to avoid the potential eects of incorrect disposal on the environment and human
health.
This will contribute to the recycling and other forms of reutilisation of electrical and electronic
equipment.
Information concerning where the equipment can be disposed of can be obtained from your
local authority.
