SYM Technology V248919 Bi-Directional Amplifier User Manual Updated Vision24

SYM Technology, Inc. Bi-Directional Amplifier Updated Vision24

Users Manual

Usermanualforsoftwaredefinablerepeater
Network Vision
PassionfortheMission
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential1
User Manual for Vision24
<SoftwareDefinableRepeater>
Copyright©2012SYMTechnologyIncorporated.Allrightsreserved.
ThisproductisintendedonlyforinstallationinaRESTRICTEDACCESSLOCATIONandisdesigned
tooperatewithintheNormalOperating(typicaloperating)rangesorconditionsspecifiedinthis
document.Operationofthisequipmentbeyondthespecifiedrangesinthisdocumentmaycause:
1.Spuriousemissionsthatviolateregulatoryrequirements.
2.Theequipmenttobeautomaticallyremovedfromservicewhenmaximumthresholdsare
exceeded.
3.Theequipmenttonotperforminaccordancewithitsspecifications.
Itistheoperator'sresponsibilitytoensurethisequipmentisproperlyinstalledandoperated
withinSYMTechnologyoperatingspecificationstoobtainproperperformancefromthe
equipmentandtocomplywithregulatoryrequirements.
ForPERMANENTLYCONNECTEDEQUIPMENT,areadilyaccessibledisconnectdeviceshallbe
incorporatedinthebuildinginstallationwiring.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
2
Warnings,Cautions,andNotes
Warnings,Cautions,andNotesarefoundthroughoutthismanualwhereapplicable.Theassociated
iconsareusedtoquicklyidentifyapotentialconditionthatcouldresultintheconsequencesdescribed
belowifprecautionsarenottaken.Notesclarifyandprovideadditionalinformationtoassisttheuser.
WARNING:Thiswarningsymbolmeansdanger.Youareinasituationthatcouldcause
bodilyinjury.Beforeyouworkonanyequipment,beawareofthehazardsinvolved
withelectricalandRFcircuitryandbefamiliarwithstandardpracticesforpreventing
accidents.
Toreducetheriskoffireorelectricshock,donotexposethisappliancetorainor
moisture.Workingwiththerepeaterwhileinoperation,mayexposethetechnicianto
RFelectromagneticfieldsthatexceedFCCrulesforhumanexposure.
CAUTION:Thiscautionsymbolmeansusertobecareful.Inthissituation,theusermight
dosomethingthatcouldresultinequipmentdamageorlossofdata.
Usetheattachedspecifiedpowersuplycord.Ifanyanotherunapprovedcordisused,it
maycauseinterferencetotheequipment.Topreventelectricshock,donotuseother
plugwithanextensioncord.
NOTE:Thisnotesymbolmeansusertotakenote.Notescontainhelpfulsuggestionsor
referencestomaterialnotcoveredinthedocument.Proceduresarenotcontainedin
notes.
Informationinthisdocumentissubjecttochangewithoutnotice.
Pleasesendcommentsto:
EMail:support@symtechnology.com
Phone:(626)3560817
Fax:(626)3569087
Address:SYMTechnology,Inc.
234E.ColoradoBlvd.,Suite410
Pasadena,CA91101,USA
http://www.symtechnology.com
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential3
RevisionHistory
DateVersionApprovalDescription
FEB.3,20121.0DocumentRelease
FEB.22,20121.1WebGUIchange
APR.1,20122.0EnclosureandServiceCardhardwarechange
July18,20122.1UsermanualtitlechangedintoVision24
July24,20122.2Safetyinstructionadded
Aug17,20122.3Photosarereplaced


Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
4
TableofContents
Warnings,Cautions,andNotes......................................................................................................2
RevisionHistory..............................................................................................................................3
1.Introduction.............................................................................................................................8
1.1ProductDescription......................................................................................................................8
1.2ContentsofBox.............................................................................................................................9
1.3GlanceattheVision....................................................................................................................11
1.4SystemConfigurationandTechnical...........................................................................................11
2.Installation.............................................................................................................................18
2.1UnpakingandInspection............................................................................................................18
2.2InstallationConsiderations.........................................................................................................18
2.3WallMountingProcedure...........................................................................................................21
2.4RackMountingProcedure...........................................................................................................22
2.5ElectricalInstallation...................................................................................................................25
2.5.1Grounding............................................................................................................................25
2.5.2ConnectionoftheAntennaCables......................................................................................26
2.5.3ACPowerConnection..........................................................................................................27
2.5.4EthernetConnection............................................................................................................27
3.Operation...............................................................................................................................29
3.1SystemIndicators........................................................................................................................29
3.1.1SystemStatusIndicators......................................................................................................29
3.1.2ControllerStatusIndicators.................................................................................................30
3.2Initialstartupandpowersettingprocedures............................................................................31
3.2.1800/900MHzPowerSettingProcedures.............................................................................31
3.2.21900MHzPowerSettingProcedures..................................................................................32
3.3WebbasedGUIoperation..........................................................................................................33
3.3.1NetworkConnection............................................................................................................34
3.3.1.1LocalNetworkConnection ........................................................................................... 34
3.3.1.2SprintPrivateNetwork ................................................................................................. 35
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential5
3.3.2WebbasedGUILogin...........................................................................................................35
3.3.3MenuList.............................................................................................................................36
3.3.4Status...................................................................................................................................37
3.3.4.1Gauge ............................................................................................................................ 37
3.3.4.2Band&GainControl ..................................................................................................... 38
3.3.5Health..................................................................................................................................38
3.3.5.1AlarmStatusMonitoringforServiceCard .................................................................... 39
3.3.5.2SettingAlarmThreshold ............................................................................................... 39
3.3.5.3EventLog ...................................................................................................................... 40
3.3.5.4SNMPTestAlarm .......................................................................................................... 40
3.3.5.5Input&OutputGraph .................................................................................................. 40
3.3.6Setup....................................................................................................................................41
3.3.6.1Network ........................................................................................................................ 41
3.3.6.2Install&Update ............................................................................................................ 43
3.3.7Account................................................................................................................................46
3.3.7.1UserList ........................................................................................................................ 46
3.3.7.2NewAccount ................................................................................................................ 48
3.3.8MemoPad............................................................................................................................48
3.3.9OtherMiscellaneousFeatures.............................................................................................49
4.Maintenance..........................................................................................................................50
4.1Troubleshooting..........................................................................................................................50
4.2ReplacementofComponents.....................................................................................................52
4.2.1FieldReplaceableUnits(FRU)..............................................................................................53
4.2.2800/900MHzServiceCard...................................................................................................53
4.2.31900MHzServiceCard........................................................................................................54
4.2.4Rectifier................................................................................................................................55
4.2.5Controller.............................................................................................................................56
4.3ReturnforServiceProcedures....................................................................................................57
5.Specifications.........................................................................................................................59
5.1800/900MHzServiceBand.........................................................................................................59
5.21900MHzServiceBand..............................................................................................................60
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
6
ListofFigures
[Figure11]PartsListforVision................................................................................................................10
[Figure12]GlanceattheVision...............................................................................................................11
[Figure13]BlockDiagramforVision........................................................................................................12
[Figure14]MechanicaldimensionforVisionplatform...........................................................................13
[Figure15]800/900MHzServiceCardview............................................................................................14
[Figure16]1900MHzServiceCardview.................................................................................................14
[Figure17]Rectifierview.........................................................................................................................15
[Figure18]Controllerview.......................................................................................................................16
[Figure19]Filter&Combinerviews..........................................................................................................16
[Figure110]MainFramefrontandrearviews........................................................................................17
[Figure21]WallMountBracketDimension.............................................................................................20
[Figure22]RackMountDimensionDrawings..........................................................................................20
[Figure23]Wallmountinginstallation.....................................................................................................22
[Figure24]Rackmountinginstallation....................................................................................................23
[Figure25]Groundingcableconnection..................................................................................................25
[Figure26]AntennaportontheVision...................................................................................................26
[Figure27]ACpowerinputsocketontheVision....................................................................................27
[Figure28]EthernetportontheVision...................................................................................................28
[Figure29]WANportconnectiontoanUWMS01.................................................................................28
[Figure31]FrontPanel..........................................................................................................................29
[Figure32]ControllerFrontPanelControlsandIndicators.....................................................................30
[Figure33]LocalAreaConnectionProperties..........................................................................................34
[Figure34]InternetProtocolProperties..................................................................................................35
[Figure35]WebGUILogin.......................................................................................................................35
[Figure36]WebGUIMainMenu.............................................................................................................36
[Figure37]ServiceBandStatus................................................................................................................37
[Figure38]StatusPage.............................................................................................................................38
[Figure39]HealthPage............................................................................................................................39
[Figure310]EventLogPopup.................................................................................................................40
[Figure311]NetworkPage.......................................................................................................................41
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential7
[Figure312]Install&Upgradepage.........................................................................................................43
[Figure313]InstallationWizardviaStep1..............................................................................................44
[Figure314]InstallationWizardviaStep2..............................................................................................44
[Figure315]InstallationWizardProcessviaStep3.................................................................................45
[Figure316]FirmwareUpdate.................................................................................................................45
[Figure317]FactorySet...........................................................................................................................46
[Figure318]UserListPage.......................................................................................................................47
[Figure319]NewAccountPage...............................................................................................................48
[Figure320]MemoPage..........................................................................................................................49
[Figure41]800/900MHzServiceCardReplacement...............................................................................54
[Figure42]1900MHzServiceCardReplacement....................................................................................55
[Figure43]RectifierReplacement............................................................................................................56
[Figure44]ControllerReplacement.........................................................................................................57
ListofTables
[Table11]PartsListforVision24(VS24FKIT)...........................................................................................9
[Table12]MechanicalandEnvironmentalCharacteristics......................................................................13
[Table21]Toolsneededforinstallation(notsupplied)............................................................................19
[Table31]SystemStatusIndicators..........................................................................................................29
[Table32]ControllerStatusIndicators.....................................................................................................30
[Table33]DLGainsettingofDownlinkinputpowerincaseofV2489(24dBmmodel).........................32
[Table34]DLGainsettingofDownlinkinputpowerincaseofV2419(24dBmmodel).........................33
[Table35]WebGUIAccessID/Password..................................................................................................36
[Table36]WebGUIMainMenu...............................................................................................................36
[Table37]AlarmStatusforHealthPage...................................................................................................39
[Table38]EventLogDescription..............................................................................................................40
[Table39]UserGroupAccessAuthority...................................................................................................47
[Table41]LEDIndicatorsTroubleshootingguide.....................................................................................50
[Table42]SystemAlarmontheWebGUITroubleshootingguide...........................................................51
[Table43]FieldReplaceableUnits...........................................................................................................53
[Table51]800/900MHzServiceBandSpecifications...............................................................................59
[Table52]1900MHzServiceBandSpecifications....................................................................................60
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
8
1. Introduction
Thismanualcontainsinformationandproceduresforinstallation,operation,andmaintenanceofthe
Visionindoorsystem.
Thesystemisfutureproof,readyforevolutiontoadvancedmodulationschemeslikeEVDO
(evolutiondataoptimized)andLTE(LongTermEvolution).ServiceCardsareavailableinsingle‐ormulti
bandconfigurationforavarietyoffrequencycombinations(3frequencybandssimultaneously),power
classes,andsystemdesigns.
1.1 ProductDescription
TheVisionplatformisaplugandplayrepeatersolutionthatutilizesthemediumpowerand
performanceforaonesectormulticarriersolution.TheVisionprovidesadjustabledownlink
power/gain,adjustableuplinkpower/gain,downlinkanduplinksignalconditioning,optionalremote
systemstatusmonitoringandremotesystemconfigurabilityviaexternalwirelessmodem.
TheVisionisaninbuildingRFrepeatersystemandcoversSMR800MHz/900MHzandCDMA/LTE
1900MHzbandssimultanelosuly.TheVisioncanprovidesignalcoverageandhighquality,fastdata
transmission.
TheVisionhastwoservicecardswhichare800/900MHzcardand1900MHzcard.Thesecardsarebi
directionalamplifierunitsforeachband.AndtheVisionhasrectifierandcontrollercardaswell.All
servicecardsaremountedthroughbackboardwhichislocatedinthemainframeenclosure.AllRF
cablesarepreinstalledbetweenbackboardandfilter&combinerunits.Filter&combinerunitsprovide
commonantennacableconnectionforallsignals.
800/900MHzservicecardand1900MHzservicecardincludedigitalfiltertoselectmultiplesub
bands(orblocks)easily.WhenprovidingLTEserviceinsteadofiDEN/CDMA,VisoncanprovideLTE
servicewithoutanyhardwarechangeasitonlyrequiresnewbandwithselectionforLTEsignal.The
Visionplatformisdesignedtoaccommodateavarietyandamixtureofdifferentandupcoming
technologies.
TheControllerofVisionsystemhasthelocalmanagementabilitytocontrolandmonitorthestatusof
therepeaterandalsoprovidesremotemonitoringandcontrollingcapabilityviaexternalwireless
modem.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential9
HerearethekeyfeaturesoftheVision.
TripleBandConfigurationwithSelectableMultipleSubbands(800/900/1900MHz)
ModularDesignwithHotSwappableCards(accommodatingupto2cards)
DigitalFilteringusingHighPerformanceDSP
Multistandardplatformistechnologyagnostic(iDEN/CDMA/LTE)
InstallationWizard:AutomaticInstallationandOptimization
Filter&CombinerUnitsforCommonDonorandSeviceAntennas
WirelessSetupviaWiFi
DownlinkInput&OutputPowerTrendDisplay(48hours)
UserFriendlyWebbasedGUI
ConvectionCooling(NoFAN)
SlimBodyStructure
1.2 ContentsofBox
[Table11]PartsListforVision24(VS24FKIT)
NoItemPartNumberQty
1VisionMainFramewithFilter,RF
CablesandwallmountbracketVSMF1
2EthernetCable6.6ft(2m)VSEC011
3PowerCord5.9ft(1.8m)VSPC011
4GroundCable6.6ft(2m)VSGC011
5WallMountingScrewsVSMB016
6RectifierVSRET1
7ControllerVSCTR1
824dBm,800/900MHzServiceCardV24891
924dBm,1900MHzServiceCardV24191
10Filter&CombinerforDonorAntenaFC891926L1
11Filter&CombinerforServiceAntenaFC891926R1
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
10
[Figure11]PartsListforVision
(1)(2)(3)
(4)
(6)(7) (8)(9)
(5)
(10)(11)
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential11
1.3 GlanceattheVision
[Figure12]GlanceattheVision
1.4 SystemConfigurationandTechnical
ThephysicalsizeandenclosureofVisionplatformhasbeenoptimizedforeaseofinstallation.The
systemissuppliedwithaheatsinktodissipateheatfromthesystem.Thesystemisdesignedto
withstanditsweightwhenperformingwallmountinginstallationandalsoprovidesrackmountbrackets
toaccommodateinstallationonstandard19”rack.TheVisionenclosureincludesonerectifier(120VAC
/60Hz),onesystemcontroller,andfilter&combinerunits.TheIP20indoorratedenclosurehasasturdy
aluminumframeasshownin[Figure12].
TheVisionplatformisdesignedwithseparateservicecardswheretheusercanservicealltwocards
800/900MHzServiceCard
1900MHzServiceCard
RectifierController
Donor(BTS)
AntennaPort
Service(MOBILE)
AntennaPort
Handle
+12VDCPower
On/Offswitch
ACPower
On/Offswitch
+12VDCOutputPort
ACInputPort
EarthGroundLug
EthernetPorts
forLAN/WAN
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
12
tosimultaneously(iDENandCDMA/LTEnetwork)ormayjustserviceoneparticularnetwork.Each
servicecardhasonemodularizeddownlinkanduplinkconverterwithpoweramplifiertominimizethe
physicalsizeandincreaseefficiency.
DET
LNA
FIR1
SAW
Server
Port
HPA DET
DET
LNA
FIR1
Digital
LNA
FIR1
HPA
DET
DET
Digital
800/900
SAW
SAW LNA
HPA
DET
SAW
Quad-band
VisionTM Series
Donor
Port
DL
UL
DL
UL
DL
UL
DL
UL
DHCP, Web server, SNMP
Ethernet USB LEDs
CONTROLLER
DL Input
UL Output
FIR2
FIR2
DET
SAW
SAW
HPA
DET
DET
DET
AC IN
Craft
Rectifier
(POWER SUPPLY UNIT)
DET
DET
DET
DET
LO2 LO2
LO1 LO1
Fix LO1 Fix LO1
Fix LO2 Fix LO2
Fix LO3 Fix LO3
Fix LO4 Fix LO4
FIR2
FIR3
FIR1
FIR2
FIR3
1900
MPX MPX
UL Input
DL Output
WiFi
[Figure13]BlockDiagramforVision
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential13
[Figure14]MechanicaldimensionforVisionplatform
[Table12]MechanicalandEnvironmentalCharacteristics
ItemDescription
Dimenstions(W*H*D)17.4*19.6*10inch(442*498*254mm)
Weight90.6lbswhenfullyloadedwithan800/900card(15.4lbs)
and1900card(12.6lbs)
CoolingConventionalCooling(NoFAN)
ACPower110~125VAC,60Hz
OperatingTemperature+14°Fto+122°F(10°Cto+50°C)
RelativeHumidity5%to95%noncondensing
RFconnectorsNtypefemale(BTSandMOBILEports)
EthernetInterfaceRJ45jack(LANandWAN)
12VDCOutputConnectorCircularReceptacle(2064301)
EarthGroundLugCopperCompressionTerminal(7/8”twohole)
MountingMethodWallMountand19”RackMount
CertificatesUL609501,FCCpart15,part90andpart24
EnvironmentalRoHScompliant(EUDirective2002/95/EC)
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
14
1.4.1. 800/900MHzServiceCard
[Figure15]800/900MHzServiceCardview
The800/900MHzservicecardconsistsofup/downconverterwithinternalpoweramplifier,digital
filtermodulebasedonhighperformanceFPGA.
Thefollowingarethekeyfeaturesof800/900MHzservicecard.
VeryflexibleBandwidth:0.25MHzto18MHz(by0.25MHzstep)
OneClickFrequencyShifting:200kHzBandShifting
Support2NoncontiguousSubbands
CenterFrequencyisadjustableby25KHzstepforEachSubband
1.4.2. 1900MHzServiceCard
[Figure16]1900MHzServiceCardview
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential15
The1900MHzservicecardconsistsofup/downconverterwithinternalpoweramplifier,digitalfilter
modulebasedonhighperformanceFPGA.
Thefollowingarethekeyfeaturesof1900MHzservicecard.
VeryflexibleBandwidth:1.25MHzto20MHz(by1.25MHzstep)
Support3NoncontiguousSubbands
CenterFrequencyisadjustableby50kHzstepforEachSubband
MaximumInstantaneousBandwidth:upto60MHz
1.4.3. Rectifier
TheRectifierisdesignedtotakeACpowerandsupplyallnecessarypowerthroughoutthesystemand
usesonlyindustrialgradecomponents.
Ittakesin110~125VACandconvertsto3.5VDC,6.5VDC,12VDCand28VDCanddistributes
necessaryDCpowertoeachmoduleofthesystem.
[Figure17]Rectifierview
ACMainPower
Switch
+12VDCOuput
PowerSwitch
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
16
1.4.4. Controller
[Figure18]Controllerview
ThemainfunctionalityofControlleristomonitorthestatusandcontroleachmoduleofthesystem
viaLANport(RJ45jack).TheLEDsonfrontpaneloftheControllordisplaytheoperationstatusofeach
servicecard.AndithasaWiFiAPmoduleinthecontroller,sothenitcansupportwirelesssetup
withoutconnectingactualEthernetconnection.
CAUTION:
LithiumBattery:Riskofexplosionifbatteryisreplacedbyanincorrecttype.Disposeof
usedbatteriesaccordingtotheinstructions.
1.4.5. Filter&Combiner
Filter&CombinerforDonorAntennaFilter&CombinerforServiceAntenna
[Figure19]Filter&Combinerviews
Therearenoantennaportsoneachservicecardofthesystem.Instead,allservicecardsarecombined
throughfilter&combinerunitsfordownlinkanduplink.ThismeanstheVisionsystemallowsyoutoput
amultibandcombinerunittobeabletousemultibandantennathroughonecombinedport.There
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential17
areoneFilter&CombinertotakesignalinputfromBTSviadonora`ntennaandtheother
Filter&CombinertodistributesignalstopassiveDAS(DistributionAntennaSystem)orserviceantenna.
1.4.6. MainFrame
[Figure110]MainFramefrontandrearviews
TheMainFrameincludesbackboardwhichcanhaveinterfacewithallservicecards,rectifier,controller
andfilter&combinerunits.RFcablesareprewiredontherearofthebackboard.Thishelpsuserinstall
allunitswithoutconnectinganyRFcablesexceptantennacables.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
18
2. Installation
Thischaptercontainsunpacking,inspection,installationinstructions,andrecommendationsfor
installingtheVisionindoorsystem.
Itisimportanttoperformthefollowing:
Carefullyreadallmaterialinthischapterpriortoequipmentinstallation.
Reviewanygovernmentandlocalcodesastheyapplytoyourinstallation.
Beforeoperating,readtheinstructionsinchapter3.
SYMTechnologyrecommendsthatasitesurveybeperformedbyaqualifiedindividualorfirmprior
toequipmentorderingorinstallation.Performingadetailedsitesurveyreducesoreliminates
installationandturnupdelays.PayparticularattentiontoACpoweravailability,spaceandRFcabling
required.
2.1 UnpakingandInspection
Thisequipmenthasbeenoperated,testedandcalibratedatthefactory.Carefullyopenthe
containersandremovetheequipment.Retainallpackingmaterialthatcanbereassembledintheevent
thattheunitmustbereturnedtothefactory.Pleaseperformthefollowingsteps:
Visuallyinspectfordamagethatmayhaveoccurredduringshipment.Ifpossible,inspectthe
equipmentinthepresenceofthedeliveryperson.
Checkforevidenceofwaterdamage,bentorwarpedchassis,loosescrewsornuts,or
extraneouspackingmaterialinconnectors.
Iftheequipmentisdamaged,thecarrieristhefirstareaofrecourse.Determinetheextentof
damageandthenfileaclaimwiththecarrier.
Iftheequipmentmustbereturnedtothefactory,pleaserefertochapter4.3forinformation
concerningaReturnMaterialAuthorization(RMA).
2.2 InstallationConsiderations
Environmentalconditionsoftheinstallationlocationshouldbewithinthesystemoperational
specifications.Ingeneral,areaswithgoodairflow,thusprovidingnaturalventilation
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential19
Normalinstallationrequires120VACsinglephaseinput.Specialconsiderationshouldbegivento
lightningprotectionofallsystemsinviewofthevulnerabilityofmosttransmittersitestolightning.
Lightningarrestorsarerecommendedintheserviceentrance.Straight,shortgroundrunsare
recommended.Theelectricalservicemustbewellgrounded.
TheVisionisdesignedforinstallationinlocationsthatpermitaccesstothebottomoftheenclosure
forconnectionofACinputpower,DCoutputpowerandRFcables.
[Table21]liststhetoolsthattheinstallerneeds.Referto[Figure23]and[Figure24],formounting
examplesandmountingbrackets.
[Table21]Toolsneededforinstallation(notsupplied)
ToolsneededWhereused
CrimptoolGroundcables
Electrician’sknifeEarthground
CableCutterGroundcables
RotoHammerWallMountingBracket
DrillBitWallMountingBracket
20mmOpenendwrenchTighteningandlooseningNconnectors
SlottedScrewdriverMountingBracketandEnclosure
SpectrumAnalyzer(800to3,000MHz)Systemperformancechecksandsettingoutputpower
30dB;50wattAttenuatorsSpectrumAnalysis
DigitalVoltOhmMeterVerifypower
RFCablesTestsetup
Mounttheenclosureontoitsdesignatedlocation.Verifythatsufficientspacetoslidethemodulesin
andoutisavailableandthattheairintakeandexhaustventsarenotblocked.Aminimumof8inches
(203mm)offreespaceisrequiredatboththetopandbottomoftheenclosuretoproperlycoolthe
system.Themountingdimensionwithboltsizerequirementsisshownin[Figure21]and[Figure22].
CAUTION:Donotinstalltheservicecarduntiltheenclosureiscompletelyinstalledata
permanentlocation.
WARNINGS:Thumbscrewsshouldbetightenedwithatoolafterbothinitialinstallation
andsubsequentaccesstothepanel.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
2
0
[Figure21]WallMountBracketDimension
[Figure22]RackMountDimensionDrawings
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential21
2.3 WallMountingProcedure
Eightmountingholesareprovidedonthewallmountingbrackettoattachittothewall.Thewall
bracketmustbesecurelyattachedtosufficientlycarrytheweightoftheVisionenclosure,whichis
boltedtothewallbracketthroughfouralignedmountingholes.
ThefollowingstepsshouldbefollowedwhilemountingtheVisionenclosure:
(1) TaketheVisionenclosureoutofthebox
(2) TaketheallServiceCardsoutoftheenclosure
(3) DetachthemountingbracketfromtheVisionenclosurebyunscrewingthe8screwsonthe
bracket.(4oneachside)
(4) Usingthefouranchorbolts,mountthebracketonthewall
(5) Makesurethebracketissecurelymounted
(6) SlightlytilttheVisionenclosureandmounttheenclosureontothewallasshowninthe
picture.Hooktheupper2guardscrewsfirstandthenslide/pushinthelower2guard
screwsintotheplace.
(7) MakesuretheVisionenclousreissecurelyplacedontothewallbracket
(8) Fastenthe8bracketscrewsbackproperly
(9) SlideeachServiceCardintotheslotandmakesuretheyarepushedinalltheway
Note:InspectServiceCardrear15pinDSubconnector.Verifyallpinsarestraight,not
recessed,andalignmentshieldisnotbent.
CAUTION:WheninstallingtheServiceCard,donotuseexcessiveforce.Forcingthe
ServiceCardintotheenclosurewillcausethepinsonthe15pinDSubconnectorofthe
ServiceCardtobecomerecessedorbroken.
(10) AfterslidingServiceCardsintoenclosure,tosecureServiceCards,tightentopandbottom
fourcaptivescrews.
(11) Inspecteverythingissecure
(12) Refertochapter3.2forinitialturnon,checkout,andpowersettingprocedures.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
2
2
 

 
[Figure23]Wallmountinginstallation
2.4 RackMountingProcedure
Eightmountingholesareprovidedontherackmountingbrackettoattachittothe19”rack.Therack
bracketmustbesecurelyattachedtosufficientlycarrytheweightoftheVisionenclosure,whichis
boltedtotherackbracketthrougheightalignedmountingholes.
ThefollowingstepsshouldbefollowedwhilemountingtheVisionenclosure:
(1) TaketheVisionenclosureandrackmountbracketsoutofthebox
(2) TaketheallServiceCardsoutoftheenclosure
(3) DetachthewallmountingbracketandhandlesfromtheVisionenclosurebyunscrewingthe
8screwsonthebracket.(4oneachside)
(4) AttachtherackmountingbrackettotheVisionenclosurebyscrewingtheeighteenflathead
screwsonthebracket.(9oneachside)
(8)(9)(10)
(3)(4)(6)
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential23
(5) IdentifytheexactlocationforVisionenclosureandusethe8mountboltstostabilizethe
Visionencousure.(4oneachside)
(6) Makesurethebracketissecurelymounted
(7) SlideeachServiceCardintotheslotandmakesuretheyarepushedinalltheway.
Note:InspectServiceCardrear15pinDSubconnector.Verifyallpinsarestraight,not
recessed,andalignmentshieldisnotbent.
CAUTION:WheninstallingtheServiceCard,donotuseexcessiveforce.Forcingthe
ServiceCardintotheenclosurewillcausethepinsonthe15pinDSubconnectorofthe
ServiceCardtobecomerecessedorbroken.
(8) AfterslidingServiceCardsintoenclosure,tosecureServiceCard,tightentopandbottomfour
captivescrews.
(9) Inspecteverythingissecure
(10) Refertochapter3.2forinitialturnon,checkout,andpowersettingprocedures.
 
 
[Figure24]Rackmountinginstallation
(3)(4)(5)
(6)(7)(8)
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
2
4
WARNINGS:
A)ElevatedOperatingAmbient‐Ifinstalledinaclosedormultiunitrackassembly,the
operatingambienttemperatureoftherackenvironmentmaybegreaterthanroom
ambient.Therefore,considerationshouldbegiventoinstallingtheequipmentinan
environmentcompatiblewiththemaximumambienttemperature(Tma)specifiedbythe
manufacturer.
B)ReducedAirFlow‐Installationoftheequipmentinarackshouldbesuchthatthe
amountofairflowrequiredforsafeoperationoftheequipmentisnotcompromised.
C)MechanicalLoading‐Mountingoftheequipmentintherackshouldbesuchthata
hazardousconditionisnotachievedduetounevenmechanicalloading.
D)CircuitOverloading‐Considerationshouldbegiventotheconnectionofthe
equipmenttothesupplycircuitandtheeffectthatoverloadingofthecircuitsmighthave
onovercurrentprotectionandsupplywiring.Appropriateconsiderationofequipment
nameplateratingsshouldbeusedwhenaddressingthisconcern.
E)ReliableEarthing‐Reliableearthingofrackmountedequipmentshouldbemaintained.
Particularattentionshouldbegiventosupplyconnectionsotherthandirectconnections
tothebranchcircuit(e.g.useofpowerstrips)."
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential25
2.5 ElectricalInstallation
ReadtheWarnings,Cautions,andNotes.
TheVisionisdesignedforinstallationinlocationsthatpermitaccesstothebottomoftheenclosure
forconnectionofACinputpower,+12VDCoutputpower(forexternalwirelessmodem,UWMS01)and
RFcables.
WARNINGS:Thisunituseddangerousvoltages.Lossoflife,severepersonalinjuryor
propertydamagecanbetheresultiftheinstructionscontainedinthismanualarenot
followed.Itiscompulsorytogroundtheunitbeforeconnectingpowersupply.A
groundingcable(yellowgreen,10AWG)isprovidedontheenclosuretoconnectthe
earthgroundcable.
2.5.1 Grounding
Groundingmustbecarriedout.Connectanearthbondingcabletothegroundingconnection
providedatthebothsidepanelsoftheVisionenclosure.Donotusethegroundingconnectionto
connectexternaldevices.

[Figure25]Groundingcableconnection
Connectthegroundcable,providedintheVisionenclosurebox,withPH5*8mmpanheadbolts.
CAUTION:ThePEcablesmusthaveaminimumcrosssectionof5.5mm2.Thelocal
groundcablerequiresanadequateearfortheM5GNDbolt.
Positionof
Groundlug
10AWG(YellowGreen)
Groundingcable
Connections
Washer
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
2
6
2.5.2 ConnectionoftheAntennaCables
TheconnectionsforantennasarelocatedatthefrontoftheTheVision.
[Figure26]AntennaportontheVision
CAUTION:TightentheNconnectorsonlybyhandortorquewrench.Theuseofpliers
maycausedamagetotheconnectorandimpairtheperformanceoftheVision.
WARNINGS:ExposuretoRadioFrequencyRadiation
TheradiatedoutputpowerofthisdeviceisfarbelowtheFCCradiofrequencyexposure
limits.Nevertheless,thisdeviceshouldbeusedinsuchamannerthatthepotentialfor
humancontactduringnormaloperationisminimized.Inordertoavoidthepossibilityof
exceedingtheFCCradiofrequencyexposurelimits,theminimumseparationdistanceof
7.9inches(20cm)mustbemaintainedbetweenhumanbodyandantennaoftheVision
tosatisfyFCCRFexposurerequirements.FormoreRFexposureinformation,pleasevisit
theFCCwebsiteatwww.FCC.gov
Note:SeparationbetweenDonor(BTS)antennaandService(MOBILE)antennais
necessarytopreventoscillation.Oscillationoccurswhenthesignalenteringthesystem
continuallyreenters,duetothelackofseparationbetweentheDonorandService
antennas.Asaresult,thenoiselevelrisesabovethesignallevel.Topreventfeedback,the
DonorandServiceantennasmustbeseparatedbyanappropriatedistancetoprovide
sufficientisolation.Thisdistanceisdependentonthegainoftherepeater.Asufficient
isolationvalueis15dBgreaterthanthemaximumgainoftheVision.
Donor(BTS)
AntennaPort
Service(MOBILE)
AntennaPort
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential27
2.5.3 ACPowerConnection
Beforeconnectingelectricalpowertotheunit,thesystemmustbegroundedasdescribedinthe
previouschapter(2.5.1).
ThemainACpowerinputsocketislocatedonthebottomofVisionenclosure.Mainpowermustbe
connectedatthemainsconnector.ThepowercableisincludedwiththeVisionenclosurepackingbox.

[Figure27]ACpowerinputsocketontheVision
CAUTION:Aminimumcrosssectionof0.83mm2isrequiredforthepowersupply
connection.Eachwiremustobservetheapplicablenationalregulationsregardingloop
impedance,voltagedrop,andmethodsofinstallation.
CAUTION:DonotconnectordisconnectthepowercordattheACmainconnectorwhile
powerison.TurnoffACpowerswitchbeforeconnectingthepowercordattheunit,
thenturnonACswitchagain.
2.5.4 EthernetConnection
TheEthernetportsarelocatedonfrontoftheVisioncontrollerasshownbelowinError! Reference
source not found.8].
LANEthernetPort(forlaptopconnection)
TheVisioncanbeconfiguredlocallywiththebuiltinwebbasedgraphicaluserinterface.Usinga
providedstandardEthernetcable,connectyourlaptoptothe“LAN”portontheVisioncontroller.The
LANconnectioniseasytosetupandmuchfasterinoperation.TheLANconnectionshouldbeusedfor
initialsetupandwhenevertheoperatorisatsite.
However,beforeyouconnectyourlaptoptotheLANport,verifyyourlaptop’sLocalAreaConnection
ACPowercable
Connections
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
2
8
setting.Formoredetailinformation,pleasereferto“3.3.1networkconnection”.
Aftertheconnectionismadeproperly,theredandgreenLEDsneartheVisionsEthernetconnector
willflash.Thenetworkhardwarewilldeterminethehighestspeedsupportedbybothdevices.With
mostPCs,theoperatingsystemwillautomaticallyestablishthehardwareandsoftwarenetwork
connection.
[Figure28]EthernetportontheVision
WARNINGS:EthernetInstructions:Thisequipmentisforindooruseandallthe
communicationwiringislimitedtoinsideofthebuilding.
WANEthernetPort(forexternalwirelessmodem,UWMS01)
ThisportisusedforconnectionofVisionandexternalwirelessmodemforremoteaccess.Thisport
shouldbeselectedifaCDMA/EVDOmodembox(UWMS01)isbeinginstalledalongwiththeVision.
AnIPaddressoftheWANportisconfiguredwith192.168.1.2,staticaddress.
LAN(Local)
Ethernetport
WAN(Remote)
Ethernetport
WAN Ethernetport
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential29
[Figure29]WANportconnectiontoanUWMS01
3. Operation
ThischaptercontainsadescriptionoftheSYMTechnologyVisionindoorSystemcontrolsandindicators,
initialstartupandoperatingprocedures,andpowersettingprocedures.
3.1 SystemIndicators
WheninstallationoftheVisionenclosure,ServiceCards,groundingcable,antennaconnectionandAC
powercordiscompleted,turnontheACpowerswitchonthefrontpaneloftherectifier,asshownon
[Figure31]below.
3.1.1 SystemStatusIndicators
Thesystemfrontpanelstatusindicatorsareshownin[Figure31]anddescriptionsarelistedin[Table
31].TherectifierpowersupautomaticallywhensystemACpowerissetto“ON.
[Figure31]FrontPanel
[Table31]SystemStatusIndicators
LEDIndicatorsDescriptions
800/900MHzServiceCard‐POWER(SolidGreen):Poweron
‐ALARM(SolidRed):Alarm&shutdown
1900MHzServiceCard‐POWER(SolidGreen):Poweron
‐ALARM(SolidRed):Alarm&shutdown
Rectifier ‐POWER(SolidGreen):Poweron
‐ALARM(SolidRed):Alarm(ServiceCardoff)
Note:TheVisionplatformisaplugandplayandthepowerwillbesuppliedtoservicecards,onceAC
ACMainPower
On/OffSwitch
+12VDCOutput
PowerSwitch
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
3
0
powerswitchissetto“ON.ThereisnoseparateDCswtichforservicecards.
3.1.2 ControllerStatusIndicators
ThelocationandfunctionoftheVisioncontrolsandindicatorsisshownin[Figure32]anddescribed
intheparagraphsthatfollow.ThecontrolsandindicatorsfortheControllerconsistoftheLANport,
WANport,Debugport,Boot/ResetbuttonandstatusindicatorLEDasshownin[Figure32].Thestatus
indicatorLEDhastwocolorcapability:Green,Red,andindicatesthestatusofthecontrolleraslisted
anddescribedin[Table32].
 
[Figure32]ControllerFrontPanelControlsandIndicators
[Table32]ControllerStatusIndicators
ItemDescriptions
LED
Indicators
POWER ‐SolidGreen:Poweron
CPU‐SolidGreenorOff:Abnormalstatus
‐BlinkingGreen:Normalstatus
Ethernet
Interface
LAN‐LaptopConnection
WAN‐ExternalWirelessModemconnect
USBDebug‐CPUDebugport
ResetControllerReboot
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential31
3.2 Initialstartupandpowersettingprocedures
BeforestartupVision,pleasereadchapter3.3ifyouarenotfamiliarwithVisionwebGUI.
Note:TheVisionmustbewarmedupforaminimumof10minutespriortosetting
powerlevels.FailuretoproperlywarmtheVisionmayresultinloweroutputpower,once
theVisionreachesoperatingtemperature.
Toperformtheinitialstartup,proceedasfollows:
(1) VerifythatallDonor(BTS)andService(MOBILE)antennaportcablesareproperlyconnected.
(2) ChecktheconnectionstatusbetweenPowercableandGroundcable.
CAUTION:DonotoperatetheVisionwithoutaloadattached.Excessiveinputpower
maydamagetheservicecard.
(3) Checktomakesurethe120VACpowercordisproperlyconnectedtothesystem.
(4) Checktheantennaconnections.
(5) TurnontheACpowerswitchontherectifierfrontpanel.
(6) AccesswebbasedGUIthroughwebbrowserandLANport
(7) Checkthelevelofinputpowerofeachservicecard.Andchangetheantennapositionincase
ofinputoverdrivealarmistriggered.
(8) CheckthesystemalarmonhealthwindowsofWebbasedGUI.Ifanysignaldoesn’tcome
fromdonorRSSIinputwhenthesystemisturnedon,InputLowalarmsarises.ButtheVision
isnormal.
(9) Refertochapter3.2.1forthepowersettinginstructions.Howtosetupthegainisexplained
inchapter3.3.4.2.
3.2.1 800/900MHzPowerSettingProcedures
(1) Ensurethecompositedownlinkinputpowertothe800/900MHzservicecardis<‐27dBm.
(2) WhenDownlinkinputpowertothe800/900MHzservicecardisataproperlevel,turnonthe
DLHPAusingWebbasedGUI.
(3) AdjusttheDLgainsettingtogeneratemaximumoutputpowerusingWebbasedGUI.Referto
[Table33]below.
(4) DeterminetheoutputpowerlevelattheService(MOBILE)antennaport.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
3
2
[Table33]DLGainsettingofDownlinkinputpowerincaseofV2489(24dBmmodel)
DLInputPowerDLGainDLOutputPower
57dBm81dB24dBm
47dBm71dB24dBm
37dBm61dB24dBm
27dBm51dB24dBm
Note:Downlinkanduplinkgainisfactorypresenttominimumgain.Refertosystem
specificationsinchapter5.
CAUTION:IftheoutputpowerlevelatthefrontoftheServiceantennaportexceedsthe
Visionsspecifiedcapability,reducetheDLgainuntiltheVisionoutputpowerratingis
met.
(5) AdjustDL/ULAGCLimitLevelbelowtheSystemmaximumoutputpower,ifAGCoperation
needed.
(6) AdjusttheULGainlevelequaltoorbelowDLGainlevel.
Note:WhenusingULGainTrackinginWebGUI,ULGainwillbeautomaticallysetbased
onDLGainsetting.
(7) TurnontheULHPAaftersettingULGainorULGainTracking.
(8) Whenallsettingiscompleted,checktomakesuresystemgainandoutputpowerareat
properlevel.
(9) CheckthesystemalarmonhealthwindowsofWebbasedGUI
(10) MeasuretheDownlinkouputpowerandspurioustomakesuretheyareproperlyset.
3.2.2 1900MHzPowerSettingProcedures
(1) Ensurethecompositedownlinkinputpowertothe1900MHzservicecardis<‐30dBm.
(2) WhenDownlinkinputpowertothe1900MHzservicecardisataproperlevel,turnontheDL
HPAusingWebbasedGUI.
(3) AdjusttheDLgainsettingtogeneratemaximumoutputpowerusingWebbasedGUI.Referto
[Table34]below.
(4) DeterminetheoutputpowerlevelattheService(MOBILE)antennaport.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential33
[Table34]DLGainsettingofDownlinkinputpowerincaseofV2419(24dBmmodel)
DLInputPowerDLGainDLOutputPower
60dBm84dB24dBm
50dBm74dB24dBm
40dBm64dB24dBm
30dBm54dB24dBm
Note:Downlinkanduplinkgainisfactorypresenttominimumgain.Refertosystem
specificationsinchapter5.
CAUTION:IftheoutputpowerlevelatthefrontoftheServiceantennaportexceedsthe
Visionsspecifiedcapability,reducetheDLgainuntiltheVisionoutputpowerratingis
met.
(5) AdjustDL/ULAGCLimitLevelbelowtheSystemmaximumoutputpower,ifAGCoperation
needed.
(6) AdjusttheULGainlevelequaltoorbelowDLGainlevel.
Note:WhenusingULGainTrackinginWebGUI,ULGainwillbeautomaticallysetbased
onDLGainsetting.
(7) TurnontheULHPAaftersettingULGainorULGainTracking.
(8) Whenallsettingiscompleted,checktomakesuresystemgainandoutputpowerareatproper
level.
(9) CheckthesystemalarmonhealthwindowsofWebbasedGUI
(10) MeasuretheDownlinkouputpowerandspurioustomakesuretheyareproperlyset.
3.3 WebbasedGUIoperation
WebBasedGUIisprovidedforeaseofmanagementandmaintenanceoftheVisionsystem.This
chapterexplainsWebbasedGUIoftheVisionplatform.
Note:WebGUIisaccessiblethroughtheInternetExplorer6,7,8,9,GoogleChromeand
FireFox.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
3
4
3.3.1 NetworkConnection
BeforeusingWebGUI,makesuretheEthernetconnectionbetweenuserslaptop(orPC)andthe
Controller,LANportoftheVisionisestablished.
3.3.1.1 LocalNetworkConnection
Tonetworkconnection,proceedasfollows:
(1) ConnecttheVision,ControllerLANporttoLaptop(orPC)usingEthernetCable(RJ45).
(2) SelectTCP/IPinLocalNetworkProperties.
[Figure33]LocalAreaConnectionProperties
(3) IPSetting
UnderInternetProtocol(TCP/IP)properties,makesuretoselectObtainanIPaddress
automatically”. OrwhenselectingUsethefollowingIPaddress”,besuretouse192.168.2.XXX
(onlyexcept1)andtherecommendedIPaddressis192.168.2.200.
So,assigntheIPaddressesasfollows:
IPaddress:192.168.2.200,Subnetmask:255.255.255.0,Defaultgateway:Leaveitblank
(4) OpenInternetExplorerandtypeinhttp://192.168.2.1
(5) Onceloginscreencomesup,logintotheVision.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential35
 
Automatically(Dynamic)IPassignment Manually(Static)IPassignment
[Figure34]InternetProtocolProperties
3.3.1.2 SprintPrivateNetwork
InordertoconnecttotheSprintPrivateNetwork,theWANportoftheVisionneedstobeconnected
toanexternalmodembox,UWMS01asshownin[Figure29].UWMS01,universalmodemboxisalso
providedbySYMTechnology,andrefertoUWMSmanualatwww.symtechnology.com
3.3.2 WebbasedGUILogin
Forsecuritypurpose,onlytheauthorizedusercanlogintotheWebGUI.
(1) Openawebbrowser,suchasInternetExplorer,googlechrome,FireFoxandSafari.
(2) IntheURLfield,enterhttp://192.168.2.1andpressEnter.
The Login Window displays.
[Figure35]WebGUILogin
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
3
6
Authorizeduser(s)mayloginwithdefaultIDandPasswordasshownin[Table39]below.
[Table35]WebGUIAccessID/Password
AccessLevelIDPassword
Administratoradminadmin
Uservisionvision
Onceloggedin,statuspagewillbedisplayed.
3.3.3 MenuList
TherearefourmainmenusintheWebGUI.
[Figure36]WebGUIMainMenu
[Table36]WebGUIMainMenu
NoMainMenuSubMenuDescription
1Status
800/900
‐Input/Gain/OutputLeveldisplay
‐Subbandselection
‐GainSetting
‐HPAON/OFF
‐Summaryalarmstatus
1900
2Health‐
‐AlarmcheckforeachServicecard
‐SetThresholdlevelforeachServicecard
‐EventLogDisplay
‐TestSNMPAlarm&Clear
‐ProvideInput&OutputGraphforeachServicecard
3Setup
Network
‐SetCascadeandHeartbeatIntervalforeachService
card
‐SetIPAddressofWANPort
‐SetlocationInformaitonofwheretheDeviceisinstalled
‐SetSNMPDestinationIPofSNMPTrap/InformData
‐SetDeviceSystemTime
Install&Update
‐ProvideeachServicecardsInstallation
‐DeviceFirmwareUpdate
‐EachServicecardsFactorySet
‐RebootfunctionalityofServiceCardsincluding
Controller
4Account
UserListDisplayofregisteredaccounts
NewAccountRegisternewUser(s)andAdministrator(s)
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential37
3.3.4 Status
Thestatuspageisdesignedtoprovideacomprehensivestatusofthesystemataglance.Thestaus
updateindisplayedingaugeandisupdatedeveryfiveseconds.
[Figure37]ServiceBandStatus
3.3.4.1 Gauge
ThestatusofeachServiceCardismonitoredanddisplayedinthegaugeandanalarmmessagewillbe
shownwhenalarmistrigged,asshowninError! Reference source not found.8]below.Statusalsohassub
menusfor800/900and1900bandsanddisplaysinputpower,gain,outputpowerofdownlink/uplinkof
eachServiceCard.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
3
8
[Figure38]StatusPage
3.3.4.2 Band&GainControl
StatusPageprovidesaninterfacewhereusercansetandadjustFrequency,Gain,AGC,Uplink
Tracking,andHPAOn/Offofeachcard.ThisInterfaceisavailableonlywhenthecardispluggedin.When
servicecardisnotpluggedin,submenuwillbeinactive.
InBandSelectionpart,usercansetuptotwobandsfor800/900serviceanduptothreebandsfor
1900service.
CAUTION:Anerrormessagewillbedisplayedwhenthereisanoverlapinfrequencyin
settingbands.Theremustbe0.5MHzfrequencyoffsetinbandsselectionfor800/900and
1900service.Youcannotgoontothenextstepinsettingwhenthereisanerrormessage.
GainSelectionpartallowsusertosetDL/ULAGClimit,ULGainTracking,DLGain,ULGain,DLHPA
andULHPA.InputPower,UsedGainandOutputPowerdisplayedintheGainSelectionareautomatically
updatedaccordingtotheguage.
3.3.5 Health
Healthpagedisplayseachservicecard’salarmstaus,alarmthresholdlevelsetting,eventlog,SNMP
testalarmtransmission,downlinkinputpowerandoutputpoweringraph.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential39
[Figure39]HealthPage
3.3.5.1 AlarmStatusMonitoringforServiceCard
HealthPagechecksandmonitorsmodule’salarmstatusinrealtime.Therearefourdifferentcolorsof
displaydependingontheseverityofalarmsasshownbelow.
[Table37]AlarmStatusforHealthPage
GreenNORMAL
YellowMinorAlarm
RedMajorAlarm
GrayServiceCardnotinserted
Note:HealthPageprovideshelpnotesonalarmstatus.Whenplacingyourmouseonthe
alarm,aballonhelpnotewillpopup.
3.3.5.2 SettingAlarmThreshold
HealthPageprovidesanInterfacewhereusercansetAlarmThresholds.UsercandefineAlarm
thresholdsorusethedefaultthresholdsprovidedbysystem.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
40
3.3.5.3 EventLog
HealthPageallowsusertosaveandvieweventlog.Clickonthe“EventLog"toseethePopup
Messageasshownbelow.UsercaneithersaveoropentheEventLog.
[Figure310]EventLogPopup
ThefollowingarethedescriptionsofEventLog.
[Table38]EventLogDescription
MessageParameterDescription
Date&TimeMM/DD/YYhh:mm‐
CascadeCodeUpperlettersSiteIDofServiceCard
LevelSystem,800/900,1900FieldReplaceableUnits
StatusEvent,Trap,Alarm,ClearStatusInformation
DescriptionEventNameAlarmInformation
3.3.5.4 SNMPTestAlarm
HealthPageprovidesaninterfaceforusertochecktheconnectionstatusofthedevicebysending
testalarm.TestalarmtransmitsSNMPTraptotheIPaddresssetinSetupPage‐>Network’sSNMP
ManagerIP.
3.3.5.5 Input&OutputGraph
HealthPagedisplayseachservicecard’sInputPowerandOutputPowerinGraph.Eachdotis
displayedeveryfiveminutesandsystemkeepsanddispalyslast48hoursofdata.Clickon800/900and
1900tabstomoveovertoitsserviceband’sgraph.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential41
3.3.6 Setup
3.3.6.1 Network
NetworkPageallowsusertosetDevice’sNetworkenvironment,systeminstalledlocationandtime.
[Figure311]NetworkPage
3.3.6.1.1 Cascade&Heartbeat
Upto3cascadecodescanbeassignedbasedoninsertedservicecards.Eachcascadecodeshould
beuniguegivenbySprint.Duplicatedcascadecodewon’tbeassignedonthewebGUI.Usercanputin
upto23capitallettersasCascadeCodeandsettheHeartbeatintervalfrom1to120minutes.Heartbeat
canbeoffaswell.Heartbeattimesetat20minutesbydefault.
Ifheartbeatintervalissetto1to5minutesforconnectingUWMS01,thisheartbeatintervalwillbe
automaticallysetto20minutesafter30minuteslater.
3.3.6.1.2 Location
LatitudeandLongitude:TypeintheGPSinformationofthesitewheretheVisionisinstalled.
Withoutthelocationinformation,heartbeatswillnotbegenerated.ThelatitudeformatisN+
ddd.dddddd,e.g.,N+39.006957.ThelongitudeformatisWddd.dddddd,e.g.,W94.532306.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
42
3.3.6.1.3 EthernetConfiguration
ThisEthernetsetupisforWANportincaseofexternalwirelessmodem,UWMS01orT1/DSL
connectioniftheVisionsendsoutalarmtothepublicnetwork).ThisportcanworkatDHCPclient
(ObtainIPaddressautomatically)orStaticIPaddressmode.Bydefault,StaticIPaddressisassignedto
beconnectedtoanUWMS01asfollows:
IPaddress:192.168.1.2,Subnetmask:255.255.255.0,Defaultgateway:192.168.1.100.
3.3.6.1.4 SNMPDestinationIP
ThisisthetargetIPaddressestowhichtheVisionsdataisdirected.Use10.22.25.15(defaultvalue)
(or192.168.1.100whenUWMS01isconnected)astheSNMPDestinationIP.
WhentheVisionisconnectedtothepublicnetwork,theSNMPDestinationIPaddressshouldbe
changedtoproperone.
3.3.6.1.5 Date&TimeSetting
AssigncorrectDateandTimeinformation.Eventlogwillrecodalleventbasedonthisdateandtime.
3.3.6.1.6 WiFiSetting
TheVisionincludes802.11b/g/nwirelessUSBmodule,whichoperatesinthe2.4GHzfrequency
spectrum.ThismeanstheVision24/30canworkasWiFiAP.Usercanconnectalaptoporsmartphone
wirelesslyviaWiFi.ThiswillletusernottoclimbupaladdertoconnectalaptoptotheVisonwhenitis
locatedonthehighlevel.
WARNINGS:ExposuretoRadioFrequencyRadiation
Theradiatedoutputpowerofthisdevicerequirestheminimumseparation
distanceof7.9inches(20cm)mustbemaintainedbetweenhumanbodyand
antennaoftheVisiontosatisfyFCCRFexposurerequirements.FormoreRF
exposureinformation,pleasevisittheFCCwebsiteatwww.FCC.gov
Bydefault,WiFiisenabled.VisionsdefaultWiFiSSIDisVisionrepeaterandpasswordisvisionsym
Note:ThisWiFiAPdoesn’thaveactualinternetconnection.Itwilhelponlywireless
connectiontotheVisiontoaccessitswebGUIwirelessly.
ToaccessVisionWebGUIthroughWiFi,usebelowURLafterconnectingVisonrepeater.
(1) OpenawebbrowserofLaptoporSmartPhone,suchasInternetExplorer,google
chrome,firefox,Safari.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential43
(2) IntheURLfield,enterhttp://192.168.3.254andpressLoginButton.
3.3.6.2 Install&Update
Install&UpgradepageisprovidedforeaseofSystem’sinitialsepup.ThispageprovidesInstallation
Wizard,Firmwareupdates,FactorySetandReboot.
[Figure312]Install&Upgradepage
3.3.6.2.1 InstallationWizard
InstallationWizardprovidesaninterfaceforaneasysetup.Selecttheservicebandtobeinstalled
andthenclickon“Start”buttontoseethenextstepsshownbelow.(Thischapterwillshow800/900
servicecardinstllationasanexample).
Step1.BandSelection
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
44
[Figure313]InstallationWizardviaStep1
InBandSelection,usersetsFrequencytobeservicedandhasBlockNameandFrequencyValue.Block
NamehasBandwidthandBlock,andFrequencyValuehasBandwidthandcenterfrequencytobe
selected.
CAUTION:Anerrormessagewillbedisplayedwhenthereisanoverlapinfrequencyin
settingbands.Theremustbe0.5MHzfrequencyoffsetinbandsselectionfor800/900and
1900service.Youcannotgoontothenextstepinsettingwhenthereisanerrormessage.
Step2.GainSelection
[Figure314]InstallationWizardviaStep2
GainSelectionPageallowsusertosetthegainofservicecardbasedonuserdefinedoutput.
Ifautogain(AGC)needed,pleaseselectAGClimitlevel.AGClimitlevelshouldbehigherthantarget
outputpower.Ifuplinkgaintrackingneeded,pleaseselectuplinkoffsetdB.Uplinkgaintracking
maintainsthedifferencetheoffsetdBfromthedownlinkgain.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential45
Step3.InstallationProcess
InstallationProcessillustratesthepocessofinstallation.Intheeventofanerror,thealarmwillbe
displayedinalarmstatusandinstallationwillfail.Insuchcase,allsetvalueswillberesettotheprevious
values.
[Figure315]InstallationWizardProcessviaStep3
3.3.6.2.2 FirmwareUpdate
PerformFirmwareUpdateoftheVision.
(1) ChecktheslotorcontrollertobeupdatedontheFirmwareUpdateblock.
(2) Click“Browse”button.
(3) SelectthefileneededtoupdatefromtheDialogue.
WhencompletingFirmwareUpdate,theWebGUIwillcloseautomaticallyandthesystemwillreboot.
[Figure316]FirmwareUpdate
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
46
3.3.6.2.3 FactorySet
ThisfeatureresetsallparameterstoFactorydefaultsetting.Thecheckboxforfeatureisonlyavailable
toinstalledservicecard(s).
[Figure317]FactorySet
3.3.6.2.4 Reboot
Thisfeaturerebootsselectedservicecard(s)andthecheckboxforfeatureisonlyavailabletoinstalled
servicecard(s).Whenselectingthisfeature,theWebGUIwillcloseautomaticallyandthesystemwill
reboot.
3.3.7 Account
3.3.7.1 UserList
ThisfeaturedisplaysauthorizedoperatorsforWebGUIaccess.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential47
[Figure318]UserListPage
UserGrouphasAdministratorandUserandtheiraccessauthorityisshownbelow.
[Table39]UserGroupAccessAuthority
WebGUIpageItem
UserGroup
AdministratorUser
Status 800/900 O O
1900 O O
Health
SDR Alarm (SNMP) O O
Alarm Threshold O
Default Threshold O
Event Log O O
Test Alarm (SNMP) O
Power History O O
Setup Network O
Install & Upgrade O
Account User List O X
New Account O X
*: View only, X: Access not allowed
Administratoraccountislimitedto5only.Useraccount(s)canbeaddedordeletedby
Administrator(s).
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
48
3.3.7.2 NewAccount
NewAccountPageallowsoperatortoregisterUserandAdministratorintheGroup.Useraccountand
passswordupto35alphanumericcharacters,upperandlowercaseareallowed.
[Figure319]NewAccountPage
3.3.8 MemoPad
TheMemopadisavailableontheupperrighthadcornerofWebGUIforoperatorand/orSystem
Managertotakenotes.ClickontheMemoandaMemobrowserwillbedisplayedasshownbelow.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential49
[Figure320]MemoPage
Makesuretoclickon"Save",otherwisenoteswillbelost.
3.3.9 OtherMiscellaneousFeatures
System’smanualisavailablefordownloadontheupperrightcornerofWebGUI.LogoutMenuallows
operatortologoutfromtheWebGUI.WhenclickingLogout,aLoginwindowwillbedisplayed.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
5
0
4. Maintenance
ThissectioncontainsperiodicmaintenanceandperformancetestproceduresfortheVision.
Note:Checkyourorderandequipmentwarrantybeforeattemptingtoserviceorrepair
theVision.Donotbreakthesealsonequipmentunderwarrantyorthewarrantywillbe
nullandvoid.Donotreturnequipmentforwarrantyorrepairserviceuntilproper
shippinginstructionsarereceivedfromthefactory.
Intheeventofamalfunction,theusershouldcheckthestatusoftheantennas,feedercables,
connectors,andmainspowerbeforereplacinganycompoents.
4.1 Troubleshooting
TheHealthwindowintheGUIindicateswhenandhowoftenfaultshaveoccurred.SeeError!
Reference source not found.]formoreinformation.ThePOWERandALARMLEDslocatedontheeach
servicecard,controllerandtherectifierfrontpaneldisplaythecurrentoperatingconditionoftheVision
(refertochapter3.1).IftheLEDsindicateaproblem,suggestionsarelistedin[Table41]and[Table42].
CAUTION:Themanualcontainsinformationandproceduresforinstallation,operation,
andmaintenanceoftheVision.Itishighlyrecommendedtoreadthemanualthoroughly
beforebeginningtroubleshooting.SYMTechnologyrecommendsthatmaintenancebe
performedbyaqualifiedindividualorfirmpriortoequipmentinstallationorreplacement.
[Table41]LEDIndicatorsTroubleshootingguide
ProblemSuggestedAction
NorectifierLEDsarelit
1.Checktoseewhetherproperpowerisbeingsupplied
throughACpowercord.
2.SetrectifierfrontpanelACPowerswitchtoONposition.
3.Defectiverectifierreplace.
NoservicecardLEDsarelit
1.SetrectifierfrontpanelACPowerswitchtoON(I)position.
2.ChecktoseeifServiceCardisinsertedproperly.
3.Defectivecontrollerreplace.
NocontrollerLEDsarelit
1.SetrectifierfrontpanelACPowerswitchtoON(I)position.
2.Push‘Resetbuttononcontrollerfront
3.Defectivecontrollerreplace.
NotcommunicationEthernet1.Verify suppliedEthernetcable
2.SetTCP/IPpropertiesofPC:“ObtainanIPaddress
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential51
automatically
3.ConfirmifIPaddressis192.168.2.200incaseof“Usethe
followingIPaddress”ofTCP/IPproperties
4.MakesureifalaptopisconnectedtoaLANport
5.Push‘Resetbuttononcontrollerfrontpanelandthen
rebootlaptopPC.
6.Defectivecontrollerreplace
RectifieralarmLEDredonat
rectifierfrontpanel.
1.OutofrangeofACpowervoltage(105to125VAC)orDC
powervoltage
2.SetrectifierfrontpanelACPowerswitchtoON(I)position
3.Defectiverectifierreplace.
1900LEDredonatservice
cardfrontpanel
1.Analarmhasbeendetectedin1900servicecard.Check
healthwindowintheWebGUI.
2.Followtroubleshootingprocedureof[Table42].
800/900LEDredonatservice
cardfrontpanel
1.Analarmhasbeendetectedin800/900servicecard.Check
healthwindowintheWebGUI.
2.Followtroubleshootingprocedureof[Table42].
CPULEDsolidgreenonorOff
atcontrollerfrontpanel
1.ControllerisinSleepMode.
2.Push‘Resetbuttononcontrollerfront
3.Defectivecontrollerreplace
[Table42]SystemAlarmontheWebGUITroubleshootingguide
ProblemSuggestedAction
CommunicationFailredalarm
1.ChecktoseeiftheServiceCardisinsertedproperly.
2.SelectRebootinWebGUIsetup>install&upgradewindow
andclickonApply.
3.Defectiveservicecardreplace.
LowInputyellowalarm
1.CheckdownlinkinputpowerlevelonBTS(donor)port.
SystemwillstilloperatenormallyeventhereislowInput
power.
2.Trytiltingthedonorantenna.
InputOverdriveredalarm
1.Checkdownlinkinputpowerlevel onBTS(donor)port.
2.Verifyhighlimitthresholdlevelofinputoverdrive
3.Trytiltingthedonorantennatoadjusttotheproperinput
powerlevel.
4.OscillationduetolackofisolationbetweentheAntennas.Try
relocatingortiltingtheantennas.
VSWRredalarm
1.CheckthecableconnectedtoMOBILE(service)port.
2.ReconnectRFCabletoMOBILEport
3.VerifyhighlimitthresholdlevelofVSWR.
4.TurnontheDLHPA.
5.Defectiveservicecardreplace.
GainDropyellowalarm
1.Checkdownlinkinputpowerandoutputpowerlevel.
2.VerifyGainDropthresholdlevelandthendowngradelow
powerthresholdlevel.
3.Defectiveservicecardreplace.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
5
2
OverPowerredalarm
1.Checkforcorrectsettingoftheoverpowerthresholdlevel
2.SetminimumgainandthenturnontheDLHPAorULHPA.
3.Adjustthegainnottoexceedtheoverpowerthresholdlevel.
4.Defectiveservicecardreplace.
LNAredalarm
1.SelectRebootinWebGUIsetup>install&upgradewindow
andclickonApply.
2.Defectiveservicecardreplace.
PLLUnlockredalarm
1.ResetServicefrequency.
2.SelectRebootinWebGUIsetup>install&upgradewindow
andclickonApply.
3.Defectiveservicecardreplace.
DSPModuleredalarm
1.SelectRebootinWebGUIsetup>install&upgradewindow
andclickonApply.
2.Defectiveservicecardreplace.
ModuleOverTemp.redalarm
1.Checkforblockedairvents(insufficientclearance).
2.Checkforambienttemperatureover+50°C(122°F)
3.VerifyhighlimitthresholdlevelofOvertemperature.
4.SelectRebootinWebGUIsetup>install&upgradewindow
andclickonApply.
5.Defectiveservicecardreplace.
RectifierOverTemp.redalarm
1.Checkforblockedairvents(insufficientclearance).
2.Checkforambienttemperatureover+50°C(122°F)
3.SelectRebootinWebGUIsetup>install&upgradewindow
andclickonApply.
4.Defectiverectifierreplace.
RectifierDCFailureredalarm
1.SelectRebootinWebGUIsetup>install&upgradewindow
andclickonApply.
2.TurntheACPowerswitchtoOFFlocatedontheRectifier
frontpanel,andthenturniton.
3.Defectiverectifierreplace.
SystemUndercurrentred
alarm
1.ChecktoseeifallHPAareOn.
2.Checksystemcurrent.
3.VerifylowlimitthresholdlevelofUndercurrent
4.2 ReplacementofComponents
MaintenanceoftheVisionshouldbeperformedonafieldreplaceableunit(FRU)basisonly.Donot
damagethewarrantylabelsonthecomponentsasthisvoidsthewarranty.
Thesparepartslistcontainsonlyunitthatcanbereplacedwithouttuningorsolderingwork.Itisnot
recommendedtoreplaceanycomponentsinsidetheVisionitself,exceptofrectifierandcontroller.
CAUTION:Defectpartsshouldonlybereplacedbyoriginalpartsfromthesupplier.All
interventionsinsidethehousingareatone'sownrisk.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential53
4.2.1 FieldReplaceableUnits(FRU)
Thepartslistedin[Table43]canbereplacedinthefieldonsitebyaqualifiedtechnicianwith
experiencemaintainingRFpoweramplifiersandsimilarequipment.
[Table43]FieldReplaceableUnits
CategoryPartItemNo.
Common
RectifierVSRET
ControllerVSCTR
DonorCombiner&
ServerCombiner
FC891926
Vision24
800/900MHzServiceCardV2489
1900MHzServiceCardV2419
4.2.2 800/900MHzServiceCard
Toreplacean800/900MHzservicecard,referto[Figure41]andproceedasdescribedinthesteps
thatfollow:
(1) SettheDLHPAandULHPAtoOFFattheWebbasdedGUI.
(2) Usingascrewdriver,loosenthefourcaptivescrewssecuringtheservicecardtotheVision
enclosure.
(3) Usethe800/900MHzservicecard’sfronthandlestopulltheservicecardoutoftheenclosure.
CAUTION:Whenremovingtheservicecardfromtheenclosure,supporttheservicecard
sotherearoftheservicecarddoesnotsuddenlydropanddamagetherearDsub
conector.Theservicecardweightisapproximately7kg(15.4lbs).
(4) Installthereplacement800/900MHzservicecardinreverseorder.
(5) AligntheguiderailsonthetopandbottomoftheservicecardwithguiderailsintheVision
enclosureandthenslidetheservicecardgentlyintoplace.
CAUTION:Ensuretheservicecardisintheproperorientationbeforeattemptingto
installintotheVisionenclosure.Damagetotherearconnectorscouldoccurifimproperly
installed.
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
5
4
[Figure41]800/900MHzServiceCardReplacement
4.2.3 1900MHzServiceCard
Toreplacea1900MHzservicecard,referto[Figure42]andproceedasdescribedinthestepsthat
follow:
(1) SettheDLHPAandULHPAtoOFFattheWebbasdedGUI.
(2) Usingascrewdriver,loosenthefourcaptivescrewssecuringtheservicecardtotheVision
enclosure.
(3) Usethe1900MHzservicecard’sfronthandlestopulltheservicecardoutoftheenclosure.
CAUTION:Whenremovingtheservicecardfromtheenclosure,supporttheservicecard
sotherearoftheservicecarddoesnotsuddenlydropanddamagetherearDsub
conector.Theservicecardweightisapproximately5.7kg(12.6lbs).
(4) Installthereplacement1900MHzservicecardinreverseorder.
(5) AligntheguiderailsonthetopandbottomoftheservicecardwithguiderailsintheVision
enclosureandthenslidetheservicecardgentlyintoplace.
CAUTION:Ensuretheservicecardisintheproperorientationbeforeattemptingto
installintotheVisionenclosure.Damagetotherearconnectorscouldoccurifimproperly
installed.
Captive
Screws(4)
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential55
[Figure42]1900MHzServiceCardReplacement
4.2.4 Rectifier
Toreplacearectifier,referto[Figure44]andproceedasdescribedinthestepsthatfollow:
(1) SettherectifierACPowerswitchestooFF.
(2) ACmainpowerturnsoffordisconnecttoACpowercord.
(3) Usingascrewdriver,loosenthefourcaptivescrewssecuringtherectifiertotheVision
enclosure.
(4) Usetherectifiersfronthandlestopulltherectifieroutoftheenclosure.
CAUTION:Whenremovingtherectifierfromtheenclosure,supporttherectifiersothe
rearoftherectifierdoesnotsuddenlydropanddamagetherearDINconector.The
rectifierweightisapproximately5.2kg(11.4lbs).
(5) Installthereplacementrectifierinreverseorder.
(6) AligntheguiderailsonthetopandbottomoftherectifierwithguiderailsintheVision
enclosureandthenslidetherectifiergentlyintoplace.
Captive
Screws(4)
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
5
6
CAUTION:Ensuretherectifierisintheproperorientationbeforeattemptingtoinstall
intotheVisionenclosure.Damagetotherearconnectorscouldoccurifimproperly
installed.
[Figure43]RectifierReplacement
4.2.5 Controller
Toreplaceacontroller,referto[Figure44]andproceedasdescribedinthestepsthatfollow:
(1) SettherectifierACPowerswitchestooFF.
(2) Usingascrewdriver,loosenthetwocaptivescrewssecuringtherectifiertotheVision
enclosure.
(3) Pullthecontrolleroutoftheenclosure.
CAUTION:Whenremovingthecontrollerfromtheenclosure,supportthecontrollerso
therearofthecontrollerdoesnotsuddenlydropanddamagetherearDINconector.
(4) Installthereplacementcontrollerinreverseorder.
(5) AligntheguiderailsonthetopandbottomofthecontrollerwithguiderailsintheVision
enclosureandthenslidethecontrollergentlyintoplace.
CAUTION:Ensurethecontrollerisintheproperorientationbeforeattemptingtoinstall
intotheVisionenclosure.Damagetotherearconnectorscouldoccurifimproperly
installed.
Captive
Screws(4)
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential57
 
[Figure44]ControllerReplacement
4.3 ReturnforServiceProcedures
WhenreturningproductstoSYMTechnology,thefollowingprocedureswillensureoptimumresponse.
ManufacturersLimitedWarranty
SYMTechnology,Inc.offersalimitedwarrantythattheVisionwillbefreefromdefectsinmaterialor
workmanshipasfollows:
TWO(2)YEARLIMITEDWARRANTY:Foraperiodoftwo(2)yearsfromthedateoforiginalpurchase,
SYMTechnologywill,atitsoption,eitherrepairorreplaceadefectiveVision(withneworrebuilt
parts/replacement).
LIMITEDWARRANTYONREPAIRED/REPLACEDPRODUCTS:AfterSYMTechnologyrepairsorreplaces
theVision,therepairedorreplacedVisionshallbecoveredbywarrantyfortheremainingtimeofthe
originalwarrantyperiodorforninety(90)daysfromthedateofrepair,whicheverislonger.Repairor
replacementmayincludetheuseoffunctionallyequivalentreconditionedunits.Replacedfaultypartsor
componentswillbecomethepropertyofSYMTechnology.
Thislimitedwarrantydoesnotcoverandisvoidwithrespecttothefollowing:(i)Visionwhichhave
beenimproperlyinstalled,maintained,modified,orrepaired;(ii)Visionwhichhavebeensubjectto
outdooruse,misuse,physicaldamage,abnormaluseoroperation,improperhandlingorstorage,
exposuretofire,water,excessivemoistureorextremetemperature;(iii)Visionoperatedoutside
publishedmaximumratings;(iv)Visiononwhichwarrantysealsorproductserialnumbershavebeen
Captive
Screws(2)
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
58
removed,broken,oraltered;(v)costofinstallation,setup,removalorreinstallation;(vi)signal
receptionproblemsornetworkproblems;(vii)damageasaresultoffire,flood,powersurge,lightening,
actsofGodorotheractswhicharenotthefaultofSYMTechnologyandwhichtheVisionisnot
specifiedtotolerate;and(viii)anyVisionwhichhavebeenopened,modified,orrepairedbyanyone
otherthanSYMTechnologyoraSYMTechnologyauthorizedservicecenter.
ObtaininganRMA
AReturnMaterialAuthorization(RMA)numbermustbeobtainedpriortoreturningequipmenttothe
factoryforservice.PleasecontactourRepairDeparentat(626)3560817toobtainthisnumber,orFAX
yourrequestto(626)3569087.FailuretoobtainthisRMAnumbermayresultindelaysinreceiving
repairservice.
The user that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
UsermanualforSoftwareDefinableRepeater
ProprietaryandStrictlyConfidential59
5. Specifications
5.1 800/900MHzServiceBand
[Table51]800/900MHzServiceBandSpecifications
ItemDownlinkUplinkDescription
FrequencyBand851869/935940MHz806824/896901MHzBW:18&5MHz
AirInterfaceiDEN
BandSelection2noncontiguousblockssimultaneously
Bandwidth0.25to18MHz/250kHzstep
(Addition:4.6,4.8,6.6,6.8,17.6,17.8MHz)Fcshifting:25kHzstep
OutputPower24dBm
Gain/AdjustmentRange5181dB/30dB
BandGainRipple±1.5dBpeaktopeak
RollOffatBandEdge65dBcat500kHz
SystemDelay7.5us
AdjacentChannelPower>50dBcat25kHz,>55dBcat50kHz,
>65dBcat500kHz,>65dBcat1MHz@singlechannel
OutofbandEmission‐13dBm(Inband),65dBc(OutofBand)>FCCrequirements
WaveformQualitySQE10%
FrequencyError≤±0.05ppm(±40Hz)
VSWR<1.4:1 
UplinkNoiseFigure<5dBatmaximumgain
<12dBatminimumgain
Document No.:
Date:
August 17, 2012 Version: 2.3
UserManual forVision24
Copyright2012SYMTechnology,Inc.Allrightsreserved.
60
5.2 1900MHzServiceBand
[Table52]1900MHzServiceBandSpecifications
ItemDownlinkUplinkDescription
FrequencyBand19301995MHz18501915MHz BW:65MHz
AirInterfaceCDMA/LTE
BandSelection3noncontiguousblockssimultaneously
Bandwidth1.25to20MHz/1.25MHzstepFcshifting:50kHzstep
OutputPower24dBm
Gain/AdjustmentRange5484dB/30dB
BandGainRipple±1.5dBpeaktopeak
RollOffatBandEdge50dBcat1MHz
SystemDelay7.5us
AdjacentChannelPower>45dBcat885kHz,>55dBcat1.98MHz,
<‐13dBmat±2.25MHz(1MHzRBW)@singlechannel
OutofbandEmission<‐13dBm>FCCrequirements
WaveformQualityRho0.96
FrequencyError≤±0.05ppm(±90Hz)
VSWR<1.4:1 
UplinkNoiseFigure<5dBatmaximumgain
<12dBatminimumgain
ACLR>45dBcat±5MHz
>45dBcat±10MHz LTEsignal(ETM1.1)
EVM/FrequencyError5%differencefromreferencesource/<±0.05
ppm+12HzLTEsignal(ETM3.1)
Operatingband
UnwantedEmission
<‐10dBmat±2.557.55MHz(100kHzRBW)
<‐14dBmat±7.5512.55MHz(100kHzRBW)
<‐15dBmat±1315MHz(1MHzRBW)
LTEsignal(ETM1.1)

Navigation menu
