SYMA MODEL AIRCRAFT ABCDEFGABCDEF Remote control aircraft User Manual X8C
SYMA MODEL AIRCRAFT INDUSTRIAL CO.,LTD Remote control aircraft X8C
User manual.pdf
X8C
GYROSCOPE
2.4G
EXPLORERS
4CH 2.4G REMOTE CONTROL QUADCOPTER
INSTRUCTION MANUAL
IMPLEMENT STANDARD: GB/T26701-2011
Main characteristics
Four-axis structure is applied,which makes the quadcopter more flexible and
rapid
when flying.It has the characteristics of wind-resistant and can be flied
indoor or
outdoor.
Built-in 6 axis gyroscope for precise hovering in the sky.
Modular design structure is applied, more simple for assembly and convenient
for
maintenance.
With 360°3D eversion function and throwing flight function .
Newly-increased headless function can recall the aircraft easily.
The materials and specification mentioned in this instruction manual or the parts inside this
package is
for reference only.Our company won’t be responsible for any adaption of the outer package.Nor
shall
we keep our customers informed in advance.Any information updates or changes,please be subject
to
our website .
Safety regulations
1. Please put smaller parts of the quadcopter in the place where children
can’t
reach, avoiding from accidents.
2. Power of this quadcopter is adequate. Therefore, when flying for the first
time, it
should push remote control’s right/left variable-speed joystick slowly,
avoiding
from collisions caused by rising quadcopter rapidly.
3. After flying，please turn off the power of quadcopter and controller, also
take
out the batteries from controller.
4. Please don’t put battery in high-temperature and heated places(such as
fire or
nearby electric heating devices).
5. When the quadcopter flies, it should maintain 2-3 meters from the user
or
others, avoiding from crashing into others’ head, face or body when it lands.
6. When children operate the quadcopter, they should be accompanied with
the
adult and guided by the adult. Ensure that the quadcopter is controlled within
the range of operator’s (or instructor’s) visibility. It is convenient for
controlling.
7. Non-rechargeable battery can’t charge. As installing or changing battery,
please pay attention to the polarity. Don’t use a mixture of old and new
battery
or battery with different types.
8. When it isn’t used, it should turn off power supply of remote controller
and
quadcopter, respectively, and take out the battery in remote controller.
9. Power supply terminal can’t be short circuit.
Maintenance
1. Use clean soft cloth to clean this product frequently.
2. Avoid from exposure or heating in the sun.
3. Don’t put the toy in the water. Otherwise, it’ll damage electronic parts.
4. Please check the plug and other accessories at regular intervals. If there
is any damage, please stop using it immediately until it is repaired
completely.
Contents
Product included following contents:
Quadcopter
2.4G Remote controller
Charge box
Instruction manual
Screwdriver
Blade(4 pieces)
Battery
Four riggers
Four foot stands
Blade lockstitch
Card reader
Iron shaft
Screw(24)
Camera
Get to know your transmitter
Introduction of transmitter:
High/Low speed & Headless mode switch
Left control lever
Photo and video
Left Fine -tuning(Mode 1) Sideward Finetuning(Mode 2)
Power ON/OFF
Mode 1 / 2 switch Sideward Fine-tuning (Mode 1) Left Fine -tuning(Mode 2)
Forward and backward trimmer
Right control lever
3D Eversion
Indicator
Antenna
Battery Cover
4 X AA(LR06)1.5V Batteries（Batteries notincluded）
Installation methods of battery: Open back battery cover of remote control,
and
put 4 No.5 alkaline batteries in the middle place correctly, according to
battery
box's pole indication (battery should be available separately).
1.Install batteries with correct polarity.
2.Do not mix old and new batteries.
3.Do not mix different types of batteries.
Remote control keypad and lcd manual
01.Sideward Fine-tuning :Power-on start in the centering.(Be turn Left/Right
Fine
-tuning in Mode2)
02.Forward/Backward fine-tuning:Power-on start in the middle.
03.Turn Left/Right fine-tuning:Power-on start in centering.(Be Sidewoard
Fly Fine
-tuning in Mode2)
04.Forward shows:Power-on start in the lowest level.(At the center spuare)
05.Backward shows:Power-on start in the lowest level.(At the center spuare)
06.Right sideward fly shows:Power-on start in the lowest level.(At the center
spuare)
07.Left sideward fly shows:Power-on start in the lowest level.(At the center
spuare)
08.Turn left: Pull left function lever to left, it will be higher, than quad
copter turn
left faster.
09.Turn right: Pull left function lever to right, it will be higher, than
quad copter turn
right faster.
10.High/Low speed: Press button “A” for seconds to switch between high speed
mode or low speed mode. “H” means high speed and “L” means low speed.
Headless Mode ：Press button “A” for 3 seconds to enter headless mode or
exit .
11.Power shows:According to the battery's energy for the controller.
12.MODE 1：Default mode when power-on.When change to MODE 2, please
keep pressing button "B" to right than return on the power of transmitter,
the
MODE on LCD displayer will be changed. Same steps to change to MODE 1
again.
13.Signal shows:Normally to full frame.
Installation steps of quadcopter’s safety guard
1. Pull out decorating parts as shown in Figure (1).
2. Press down decorating parts as shown in Figure(2) and insert blade
protective frame into fuselage interface.
3. Twist two screws of every parts as shown in Figure（3）.
Note: Without rigger, blade protective frame effect in flight
will be better.
Installation steps of quadcopter’s stands
1.Insert stands into the quadcopter body as figure(1).
2.Twist the wide screws to locking the stands as figure(2).
Install camera
Installation steps of X8C camera:
1.Push the camera and tight it as figure (1).
2.Connect the camera power line into the socket on quadcopter body as figure
(2).
Disassembly steps of X8C camera:
1. Pull out power supply cable of the camera as shown in Figure (3).
2. Press down safe lock of lower main body as shown in Figure (4).
3. Push forward the camera and take it out as shown in Figure (5).
Note: After turning on quadcopter’s power supply, it forbids
to
insert or pull out the camera’s plug connecting to the aircraft.
Photography/Video instructions
1.Methods:1 Make sure the power line of camera is inserted to
the quadcopter.
2.Turn the quadcopter power on,the camera works normally when
the RED indicator change form flashing to green and keep light
on.lf the RED indicator just light on and light off seconds later,
it means the SD card is not in the camera.please insert the SD
card,than the indicator light on GREEN.
2.Get to know take photo and video:
① Turn on the transmitter and pull left lever up and down
to connect signal between quadcopter and transmitter.
② Take Photo : Make sure camera normally work, when
push the button “C” up, camera will take a photo after
a beep from transmitter and the GREEN indicator on
camera will be RED and flash on time.
Take Video : Make sure camera normally work , when pull the button “C”
down ,camera starts to take video after a beep from transmitter and the
GREEN indicator on camera will change to RED than keep flashing.
Press the button “C” slightly again , another beep from transmitter means
video stopped and the RED flashing light on camera will be GREEN and
keep light on.
Controller modes & instructions
The transmitter built-in two modes, Mode 1 & Mode 2, in line with different
customer’s usage pattern. Keep pushing button B to right, than turn on the
transmitter power to change Mode 1 or Mode 2.
MODE 1
Operating direction
Hover up and down
Push the throttle up or down, the quadcopter flies upward or downward.
Forward and backward
Push the direction lever up or down,the quadcopter flies forward or backward.
Turn Left and Right
Pull the throttle left or right, the quadcopter turns to left or right.
Sideward fly
Pull the direction lever left or right, the quadcopter flies to left side
or right
side.
Fine-tuning operation
Forward/Backward fine-tuning
When the quadcopter keeps flying forward /backward, you can correct it by
pressing fine-tuning button down / up.
Sideward fly fine-tuning
When the quadcopter keeps flying to left / right side, you can correct it
by pressing the fine-tuning button right / left.
Turn left/right fine-tuning
When the quadcopter keeps rotating to left /right, you can correct it by
pressing the finetuning button right / left.
MODE 2
Operating direction
Hover up and down
Push the throttle up or down, the quadcopter flies upward or downward.
Forward and backward
Push the direction lever up or down, the quadcopter flies forward or backward.
Turn Left and Right
Pull the direction lever left or right, the quadcopter turns to left or right.
Sideward fly
Pull the throttle left or right, the quadcopter flies to left side or right
side.
Fine-tuning operation
Forward/Backward fine-tuning
When the quadcopter keeps flying forward /backward, you can correct it by
pressing fine-tuning button down / up.
Sideward fly fine-tuning
When the quadcopter keeps flying to left / right side, you can correct it
by pressing the fine-tuning button right / left.
Turn left/right fine-tuning
When the quadcopter keeps rotating to left /right, you can correct it by
pressing the finetuning button right / left.
Ready to fly your quadcopter
1.Press the ON/OFF power switch up.
2.Open battery cover,and connect battery connector with dash receiver.
3.Enclose battery into the fuselage, after closing battery cover,turn on
the switch on the bottom of aircraft.
4.Push the throttle lever to the highest position,and then pull it back to
the lowest position.There will be one clear sound from the transmitter,this
shows that the quadcopter has entered into the pre-fly state.
Function introduction
1.Low-voltage protection:
If four indicator lights in the bottom of aircraft start to twinkle, it means
that the aircraft is short of electricity and is not able to roll. At that
time, a return voyage shall immediately be made to the aircraft.
2.Over-current protection:
In the condition of rotating aircraft’s fan blade, when being crashed or
stuck, aircraft’s circuit will conduct over-current protection.
3.Horizontal correcting function:
Place the quadcopter on a horizontal postion,then push transmitter both left
and right lever
to lowest right conner for about 2-3 second ,indicator on the quadcopter
changed from
normal lights up to quickly flashing ;After 2-3 second ,the indicator changed
to normal lights,it means the quadcopter restarted /reset successfully.
4.3D eversion:
When you are familiar with the basic operation,you can do some awesome&
exciting tricks and stunts! First of all,fly the aircraft to a height of
more than 3 meters, press the 3D Eversion switch on the rear right side of
the transmitter,then push the right rudder(in any direction)to make 360
degree flip.
Tips:3D eversion goes better when battery power is enough.
5.Headless function:
1. Forward definition
1. Turn on power switch of remote control.
2. After aircraft connects with power supply, place the switch in “ON”
position, adjust the direction pointed by aircraft’s handpiece and regard
it as the dead ahead in headless situation.
3. Push the accelerator’s push rod of remote control to the highest point
and pull back to the lowest point.When remote control pops, it indicates
that frequency
modulation and forward definition have already finished.
2. Switch to headless function and general function
1. After frequency modulation, the aircraft defaults to general pattern.
The indicator light on aircraft is long bright state. After pressing down
headless function switch on the top left of master remote controller for
2 seconds, remote control will give out “DDD...”, it means that it enters
into headless state. After pressing for 2 seconds and hearing long “D”, it
means that it exits headless state.(In headless mode, four indicators on
the
aircraft flicker slowly for once within four seconds)
2. In headless state, the operator has no need torecognize the position of
aircraft’s headpiece, and he just needs to control the aircraft in accordance
with the direction of remote control’s operating rod.
3. Correcting forward direction
1. When the aircraft is in the headless condition, if there is any deviation
in the fixed-head direction, it is necessary to re-fix the right direction
of the aircraft and stir the
accelerator and direction lever to the bottom left side.Long-time shining
of indicator lights on the aircraft after slow flashing for 3 seconds shows
that adjustment is
Completed.
Battery replacement and charging method
Steps of battery replacement:
1. Turn off aircraft’s power supply, and push the switch to “OFF”.
2. Open aircraft’s battery cover backward.
3. Connect battery interface with dash receiver.
4. After battery replacement, fasten the battery cover again.
Steps of battery charge:
1. Connect battery switch with charger.
2. Connect charger to power supply socket.
Balanced charger:
1. Insert adapter’s DC outlet into import socket of balanced charger. Red
light
of balanced charger will light on.
2. Insert three-position balanced plug of power battery to output end of
charger.
Green light of balanced charger will light on. When green light extinguishes,
it means the end of battery charging.
(Charging time is less than 200 minutes)
Note: if power battery inserts into the charger, the light has no change.
It
indicates that this battery is full energy. There is no need to recharge.
Charging time: about 200 minutes Flying time: about 7 minutes!
Cautions when charging:
1.When charging, please put this product on a dried or ventilated area and
keep
it far away from heat source or explosive product.
2.When charging, please remove the batteries from the quadcopter. Then
charging process should be supervised by an adult so as not to cause an
accident.
3.When finish flying, please do not charge the battery if the surface
temperature
is still not cool. Otherwise it may cause a swollen battery or even a fire
hazard.
4.Please make sure that you use the original USB charging cable provided.
When the battery has been used for a long time, or appears to be swollen,
please replace them.
5.A battery when not in use for a long time will lose its charge automatically.
Charging or discharging too often may reduce the life of the battery.
Steps of fan blade’s installation/disassembly of
aircraft
Steps of fan blade’s disassembly:
1. Rotate and back out fan blade cover in anti-clockwise direction as shown in Figure (1) .
2. Rotate blade lockstitch for about 90° in the anti-clockwise as figure(2) till the iron shaft
point to the
opening of blade lockstitch.
3. Get iron shaft out and pull blade lockstitch upward as figure (3) shows.
4. Pull out fan blade upward as shown in Figure (4).
Installation steps of fan blade:
1. Insert fan blade into principal axis pipe as shown in Figure (1)
2. Install the blade lockstitch inside the quill as figure (2) shows to ensure that the gap
of blade
lockstitch aligns at the hole on the quill.
3. Install the iron shaft inside and rotate blade lockstitch for about ninety degrees in the
clockwise
direction shown in figure (3).
4. Rotate and twist fan blade cover in clockwise direction as shown in Figure (4).
Maintenance procedure
Problems Causes
Solutions
Aircraft has no response
1. Aircraft enters into low-voltage protection.
2. Electric quantity of remote control is insufficient, power indicator light will flicker.
3. Channel selection of remote control is inconsistent with aircraft’s match codes.
1. Charge the aircraft.
2. Change remote control’s battery.
3. Adjust channels of remote control and aircraft, and make them become consistent.
Aircraft’s flying response is insensitive
1.The remote-control unit suffers low battery or the quality of battery is not good enough.
2. Remote control with the same frequency is transmitting interference.
1.Change battery with better quality.
2. Change the place where has no transmitting interference of the same frequency.
When hovering, side flight is formed
1. Have no horizontal correction.
1. Conduct horizontal correction, as shown in p.8(3)(correcting function)
In headless state, it deviates to dead ahead
1. Head deflection is caused by multiple collisions.
2.Long time usage of headless mode.
1. Define forward again, as shown in p.9(5)(headless function)
Spare parts
FCC statement
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Hereby,SYMA MODEL AIRCRAFT INDUSTRIAL CO.,LTD,declares that this Remote control
aircraft is in compliance with the essential requiremetnts and other relevant provisions of Directive
1995/5/EC.
