Brief Introduction

This product is a multifunctional wireless door sensor. Integrate functions of

emergency button and door sensor , with a design of low power consumption chip

and of low voltage fault monitoring report, anti-tamper and anti-destruction.

Compatible with 1527 coding format, long emission distance. Typically apply to all

kinds of anti-theft doors & windows of households and commerces.

Transmitter

Magnetic bar

Emergency button

The sensor is installed onto the moving door(picture 2).

place for installation, take out the sensor the

adhesive tape on back; Please take notice of the below:

First,

and put

clean

up the 2-sided

1, PartA, the transmitter(sensor body) and Part B, the magnetic bar should

be installed separately, that is, the body should be installed on the fixed

frame and the magnetic bar should be installed on the mobile door.

(Notes: magnetic bar is on the left of the transmitter as picture 1. ).

2, Magnet and transmitter is facing up and down.

3, After installation, the indicator light flashes once while opening the door

which means installation is available.

4, Door sensor indicator light flashes once which means the hints of alarm;

indicator flashes twice means the low power of the battery.

5, Part A and Part B can be consolidated with screws, (take out bottom

cover of the transmitter, fix with screws, then fit the front cover onto the

bottom cover.)

6, The metal door would affect the signal; if installed onto the metal door,

should raise the transmitter bottom of the transmitter with insulating

material

Electrical Property

No. Item Technical Index Unit Remarks

Working voltage

Static current

Emission current

Emission distance

Trigger distance

Under-voltage

point

Coded format

Emission

Frequency

(in open air)

(Picture1)

Structure diagram and

installation requirements

(Picture1) (Picture2)

door

Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttotheconditionthatthis

devicedoesnotcauseharmfulinterference(1)thisdevicemaynotcauseharmfulinterference,

and(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause

undesiredoperation.

Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould

voidtheuser'sauthoritytooperatetheequipment.

NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital

device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable

protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,

usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe

instructions,maycauseharmfulinterferencetoradiocommunications.However,thereisno

guaranteethatinterferencewillnotoccurinaparticularinstallation.

Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,

whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotryto

correcttheinterferencebyoneormoreofthefollowingmeasures:

‐‐Reorientorrelocatethereceivingantenna.

‐‐Increasetheseparationbetweentheequipmentandreceiver.

‐‐Connecttheequipmentintoanoutletonacircuitdifferent

fromthattowhichthereceiverisconnected.

‐‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

FCCID:2AIT9-PB67R


