Users manual

Mobile Phones Division

Tel. +33 1 40 70 88 44 - Fax +33 1 40 70 66 40 - www.sagem.com

Le Ponant de Paris - 27, rue Leblanc - 75512 PARIS CEDEX 15 - FRANCE

SAGEM SA - Société anonyme à directoire et conseil de surveillance

capital : 36 405 229 € - 562 082 909 RCS PARIS

SAGEM

ENGLISH

*251437828*

251437828-Couv-myX-7-LU-en.qxd 30/01/04 14:28 Page 1

You have just purchased a SAGEM phone, we congratulate you; it is

recommended that you read this handbook carefully in order to use your phone

efficiently and in the best conditions.

Your phone can be used internationally in the various networks (GSM 900 MHz

and DCS 1800 MHz or PCS 1900 MHz, depending on model) depending on the

roaming arrangements with your operator.

We remind you that this phone is approved to meet European standards.

WARNING

Depending on the model, network configuration and associated subscription

cards, certain functions may not be available.

Ensure that your SIM card is a 3 V SIM type that is compatible with your phone.

Inserting an incompatible card will be indicated by a message when your phone

is switched on. Contact your operator.

Your phone is identified by its IMEI number. Write this number down, and do not

keep it with your phone, because you may be asked for it in the event of your

phone being stolen, in order to prevent it from being used, even with a different

SIM card. In order to display the IMEI on your phone's screen, type: *#06#.

SAGEM is a trademark of SAGEM SA.

AT is a registered trademark of Hayes Microcomputer Products Inc.

Hayes is a registered trademark of Hayes Microcomputer Products Inc.

T9 is protected by one or more of the following US patents: 5,818,437,

5,953,541, 5,187,480, 5,945,928, 6,011,554 and other patents are being applied for

worldwide.

Java and all Java based trademarks and logos are trademarks or registered

trademarks of Sun Microsystems, Inc. in the U.S. and other countries.

The WAP navigator is the exclusive property of Openwave. For this reason, it is

forbidden to modify, translate, disassemble or even decompile all or part of the

software that makes up the navigator.

Wellphone™ and SmartCom™ are registered trademarks owned by SmartCom

SARL France.

251437828_myX-7_lu_2e-3ecouv_en.fm Page 1 Vendredi, 30. janvier 2004 9:55 09

Weight: 106 g

Size: 110 x 46 x 22 mm

Original battery: Lithium ion 1000 mAh

Battery life calls/standby: up to 4 h 40 mn/310 h (see page 16 how to increase

the efficiency of your myX-7)

Multimedia objects supported:

Audio formats: iMelody, Midi, wave

Graphic formats: wbmp, bmp, png, gif, animated gif, jpeg, .3gp

Size of memory available for messages:

100 SMS

300 Kb for MMS (inbox, outbox and drafts together; MMS depending on

option)

Size of memory available for the phonenook and the multimedia objects: 4 MB

Maximum size of each message:

SMS < 160 characters

MMS < 100 Kb for outgoing, 100 Kb for incoming messages (depends

on the phone configuration and on the operator reservations)

Using temperature: from - 10°C to + 55°C

251437828_myX-7_lu_2e-3ecouv_en.fm Page 2 Vendredi, 30. janvier 2004 9:55 09

Conformance Document

251437828_myX-7_lu_en.book Page 1 Lundi, 2. février 2004 1:58 13

FCC Conformance Document

FCC Part 24

Network NAPRD03.ver 2.9.1

Health Draft IEEE Std 1528-200x

Exposure to Radio Frequency Signals

- Your wireless handheld portable phone is a low power radio transmitter and receiver. When it is ON, it

receives and also sends out frequency (RF) signals.

- In August, 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with

safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards

previously set by both U.S. and international standards bodies:

ANSI C95.1 (1992)*

NCPR Report 86 (1986)*

ICNIRP (1996)*

(*) American National Standards Institute; National Council on Radiation Protection and Measurements;

International Commission and Non-Ionizing Radiation Protection.

- Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature.

For example, over 120 scientists, engineers, and physicians from universities, government health agencies,

and industry reviewed the available body of research to develop the ANSI Standard (C95.1).

- The design of your phone complies with the FCC guidelines (and those standards).

- For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when used

with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the body.

Use of other accessories may not ensure compliance with FCC RF exposure guidelines.

251437828_myX-7_lu_en.book Page 2 Lundi, 2. février 2004 1:58 13

Menus

Games

WAP

Applications

Delete all

ToDo

Calculator

Converter

Alarm

Timer

Settings

About

Messages

Compose

Inbox

Outbox

Drafts

Options

Memory

Local info.

Call Voice Mail

Camera

Photo Camera

Video Camera

Multimedia

Mes Videos

Mes Pictures

Mes Sounds

Memory

Organiser

Calendar menu

See month

See week

See today

See date

Phonebook

Contacts menu

Settings

Sounds

Display

Camera

Languages

Calls

Security

Networks

Others

Short cuts

Date/Time

Connectivity

Menu Hot-line

251437828_myX-7_lu_en.book Page 3 Lundi, 2. février 2004 1:58 13

Contents

Page 3 MENUS

Page 9 YOUR PHONE PACKAGE - ACCESSORIES

Page 10 DESCRIPTION

Programmable keys and Short cut keys

Strap attachment

Page 12 NAVIGATION PRINCIPLES

Page 13 INITIAL SCREEN

Page 14 ACTIVATING YOUR PHONE

Information on the SIM card

Installing the SIM card and the battery

Page 16 USING YOUR PHONE

Don't obstruct the antenna with your fingers

Increase the efficiency of your phone

Charging the battery

Page 18 PHONEBOOK

Using the phonebook

Contacts menu

Options from a contact saved

Sending a vCard

Receiving a vCard

Page 25 MESSAGES

Compose SMS

Compose MMS

Receiving messages

251437828_myX-7_lu_en.book Page 4 Lundi, 2. février 2004 1:58 13

Contents

Inbox

Outbox

Drafts

Sending options

Memory

Local information

Calling voicemail

Page 36 CAMERA

Take and send a photo

Take a video

Page 39 MULTIMEDIA

My videos

My Pictures

Edit a photo

My Sounds

Memory

Page 43 WAP

The WAP Menu

Configuring WAP parameters

WAP Logging on

Downloading sounds and images

WAP Logging off

GPRS

Page 48 GAMES

251437828_myX-7_lu_en.book Page 5 Lundi, 2. février 2004 1:58 13

Contents

Page 49 APPLICATIONS

Services

ToDo

ToDo menu

ToDo actions menu

Sending a vCal

Receiving a vCal

Exchange of data with a PC

Calculator

Converter

Alarm

Timer

Page 56 ORGANISER

Calendar menu

Sending a vCal

Receiving a vCal

Page 58 SETTINGS

Sounds

Volume and ring tone

Vibrate

Silent mode

Beeps

Recorder

Display

Wallpaper

Screensaver

Operator logo

Camera

251437828_myX-7_lu_en.book Page 6 Lundi, 2. février 2004 1:58 13

Contents

Languages

Calls

Call forward

View last calls

Counters

Display number

Call waiting

Automatic redial

Blacklist

Voicemail

ALS

Security

Keypad locking

PIN number

PIN2 number

Phone code

Confidentiality

Operator

Call barring

Fixed dialling

Cost

Networks

Others

Car kit

Energy saving

Short cuts

Date / Time

Set Date/Time

Automatic update

251437828_myX-7_lu_en.book Page 7 Lundi, 2. février 2004 1:58 13

Contents

Display

Time zone

Summer time

Connectivity

IrDA

Serial Speed

Menu Hot-line

Page 81 CARE AND SAFETY INFORMATION

Safety

SAR

Advice for limiting exposure to radiofrequency (RF) fields

Page 83 WARRANTY

Page 86 TROUBLESHOOTING

Page 90 INDEX

251437828_myX-7_lu_en.book Page 8 Lundi, 2. février 2004 1:58 13

Your phone package

When you open the box, check that all items are present:

1 - Phone

2 - Charger

3 - Battery

4 - User guide

5 - CD

(depending on model)

Accessories

You can also find (as an option) or order the following accessories:

Hands-free kit (*)

Additional battery

Additional charger (*)

USB cable (with associated drivers) and serial cable to connect your phone to a PC

Cigar lighter charger (*)

Colored covers

(*) These accessories are identical to the ones provided for the earlier 3000 series

X-2,

X-5 and

X-6.

251437828_myX-7_lu_en.book Page 9 Lundi, 2. février 2004 1:58 13

Description

Programmable keys

and Short cut keys

Hold down: Switches the phone off

Press briefly: Start phone

In a call context: Reject a call - hang up

In menus: Return to initial screen.

In call context: Call - receiving a call - hands-free mode

Right programmable key:

(Function available depending on model)

In initial screen: Access to certain functions (shortcuts)

In menus: Cancel (or return) as indicated on the screen

During call: Increase volume

Left programmable key:

(Function available depending on model)

In initial screen: Access to certain functions (shortcuts)

In menus: Validate, choose as shown on the screen

During call: Reduce volume

Previous choice / increase value / up

Next choice / reduce value / down

Up input field / move left

Down input field / move right

Hold down: In initial screen: Silent mode

Press briefly + validate (

key) activate or deactivate keypad locking

In call reception mode: Short press stops ring tone

In ring tone setting mode: Activate / deactivate ring tone

Upper case/Lower case

Zoom mode (see

Messages

and

WAP

menus)

WARNING:

do not use the phone in hands-free mode near to your

ear, or you may suffer hearing loss.

Microphone

251437828_myX-7_lu_en.book Page 10 Lundi, 2. février 2004 1:58 13

Description

Strap attachment

Put the strap through the hook inside and at the

bottom of the phone. Pull the strap to lock it into

place.

IrDA Camera

Mirror

251437828_myX-7_lu_en.book Page 11 Lundi, 2. février 2004 1:58 13

Navigation principles

These basic principles bring a great intuitiveness to your phone.

Validate

by pressing the

key

Cancel

by pressing the key.

The thumbnails at the bottom of the screen refer to the

keys.

In the menus, a title bar reminds you of the previous level.

The

navigation keys are used to navigate from one menu to

another within the same menu structure.

From the home page, pressing the

keys displays the

icons of the main menus.

The

key

is used to go from a menu to a sub-menu.

The key is used to go from a sub-menu to a menu.

The

key (press briefly) is used to go back to the initial screen (current

function is abandoned).

251437828_myX-7_lu_en.book Page 12 Lundi, 2. février 2004 1:58 13

Initial screen

The initial screen contains the following information:

1 - The title bar icons:

Battery

Calls forwarded

Call (establishing the call)

Call (hands free)

Message (reception of a message, message memory full)

FAX communication

DATA communication

Silent mode

Message in answering machine

WAP (@) communication

GPRS

Home zone

Roaming

Keypad locking

Protected WAP logon

Protected WAP logon icon with certificate

Signal strength level (5 bars).

2 - Date and time, in digital or analog mode

3 - Network provider

4 - Thumbnail centred on bottom line:

the main « Menu » thumbnail shows that the menu can be accessed via

the

keys.

The following information may also be displayed:

« 1 message received »; or « 1 call ».

They can be deleted by pressing key briefly.

Network provider

thu 20 FEB

251437828_myX-7_lu_en.book Page 13 Lundi, 2. février 2004 1:58 13

Activating your phone

To use your phone, you need a card called SIM card. It contains

personal information that you cannot modify:

Secret codes (PIN(s): Personal Identification Numbers), these codes

allow you to protect access to your SIM card and phone.

Phonebook,

Messages,

How special services work.

Your phone is compatible with the SIM 3V cards.

Information on the SIM card

WARNING

This card must be handled and stored with care in order not to be damaged. If you should lose your SIM

card, contact your network provider or your SMC (Services Marketing Company) immediately.

Please keep your SIM card out of reach of young children.

251437828_myX-7_lu_en.book Page 14 Lundi, 2. février 2004 1:58 13

Activating your phone

The SIM card is inserted under the phone's battery. Ensure that the

phone is switched off and the charger disconnected.

Turn the phone back and push lock button upwards.

Remove the back cover by lifting bottom end first.

Take out battery if already installed.

Slide the SIM card, with cut corner as shown on the phone, into the card

holder with fold face down.

Place the battery by positioning first the top of it, as shown on the

battery.

Replace the back cover, clicking in first the upper part then the lower and

pushing the back catch downwards into the lock position.

Installing the SIM card and the battery

251437828_myX-7_lu_en.book Page 15 Lundi, 2. février 2004 1:58 13

Using your phone

The antenna is integrated in your phone, under the back cover at the top.

Avoid putting your fingers on this area when the phone is switched ON.

If your fingers obstruct the antenna, the phone may have to operate with

a higher power level than usual; decreasing its efficiency quickly. It could

also affect the quality of your communications.

Non ionising radiation

To obtain maximum satisfaction from your phone, use it in a vertical

position. Your personal safety can only be improved by doing so.

- Don't press the keys when not necessary: each keypress activates

the backlight, and uses much power.

- Don't activate too often the screensaver: a starting time too high

increases the power consumption.

- Don't obstruct the antenna with your fingers.

Don't obstruct the antenna with your fingers

Increase the efficiency of your phone

251437828_myX-7_lu_en.book Page 16 Lundi, 2. février 2004 1:58 13

Using your phone

Your phone is powered by a rechargeable battery. A new battery must

be charged for 4 hours at least before being used for the first time. It

reaches its optimum capacity after a few cycles of use.

When your battery has been discharged, the phone displays the state

(empty battery icon flashes). In this case recharge your battery for at

least 15 minutes before making any calls in order not to be cut off in the

middle of a call.

To recharge the battery:

Connect the charger to a socket.

Plug the end of the cable into the bottom connector of the phone.

The phone is then charging up. The battery icon is scrolling up and down

to indicate that it is charging. When the battery is fully charged, the

charging stops on its own. Disconnect the cable.

When charging, the battery may warm up, this phenomenon is normal.

Charging the battery

WARNING

There is danger of explosion if the battery is placed in an incorrectly way or if it is exposed to fire.

Do not short circuit it.

The battery does not have any part that you can change.

Do not try to open the battery casing.

Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue.

The use of other types of chargers or batteries may be dangerous or invalidate the warranty.

Used batteries must be disposed of in the appropriate places.

We advise you to take the battery out if you plan not to use the phone for extended periods.

You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery.

251437828_myX-7_lu_en.book Page 17 Lundi, 2. février 2004 1:58 13

Phonebook

The phonebook allows you to store numbers that you call regularly.

These numbers can be stored in the SIM card or in the phone.

Your phone has a vCard phonebook, and the following fields can be

stored in the phone memory exclusively for each contact: last name, first

name, number 1, email, number 2, number 3, call group, company,

comment, photo.

The fields preceded with a star are mandatory.

The storage capacity will depend on the SIM card. Please contact your

network provider to get that information.

In the initial screen, press the

key to access the main menus. The

first menu proposed is

Phonebook

Press the

key

corresponding to the validation key to enter the menu.

The list of your correspondents appears. By default, the cursor is

positioned on the first name in alphabetical order.

If you are using your phone and SIM card for the first time, the

phonebook list will be empty, only the

Contacts menu

function will be

available.

Using the phonebook

251437828_myX-7_lu_en.book Page 18 Lundi, 2. février 2004 1:58 13

Phonebook

Add contact

Select

Add contact

and press the

key

to enter the menu.

Choose the location where you wish to enter the contact (SIM card,

phone or fixed dialling memory – Fixed dialling is available depending

on PIN number 2 options of your SIM card) and enter the contact

information and validate after each entry.

The information needed to store a contact in the phone is first name, last

name, one phone number or an email address.

All other fields are not mandatory. If you do not want to fill them, select

Save

to save the contact created.

Note:

If you want to store a contact in a call group, the ring tone, when

the contact is calling, is the one defined by default in the call group.

To modify the ring tone, select

Phonebook

Contacts menu

Call

Groups

, select the call group,

Options

then

Modify

. Modify the ring

tone and validate.

Contacts menu

251437828_myX-7_lu_en.book Page 19 Lundi, 2. février 2004 1:58 13

Phonebook

Call groups

6 default call groups have already been created. You can create others.

You have the facility to group your contacts into call groups.

It is possible to allocate characteristics to each group (icon, ring tone,

vibrate mode).

Creating new groups:

Do same as above to get the

Contacts menu

and validate.

Press

key to position the cursor on

Call groups

and validate.

By default, the cursor is automatically placed on

Call groups menu,

validate.

Choose one of the options given: Create group or Memory available.

Creating a group

By default, the cursor is placed on

Create group,

validate.

Enter the name and validate.

Choose the

icon

, the

ring tone

and

vibrate mode

that you want to

allocate to this group (validate after each step).

Memory

Select

Memory

and validate.

The screen displays the number of locations available for new groups.

251437828_myX-7_lu_en.book Page 20 Lundi, 2. février 2004 1:58 13

Phonebook

Memory

Select

Memory

and validate. Select SIM or Phone and validate.

The screen displays the locations used on the SIM Card and in the

phone itself. The screen displays the amount of memory used. The

memory capacity is shared between the phonebook and the photo,

pictures, organiser, etc. features. If you lack memory, check if you can

free some space from another function.

My numbers

You can create the entries corresponding to your own numbers in order

to consult them when necessary.

Select

My numbers

and validate. Enter the different details and

validate.

251437828_myX-7_lu_en.book Page 21 Lundi, 2. février 2004 1:58 13

Phonebook

See contact

Select a contact from the list using the

keys. Then press the

key. By directly pressing one character, the phone will display the

first contact saved in the phonebook, starting with it.

The first menu proposed is

See contact

. Validate.

Details of the contact appears (name, phone number, call group, and

some other details).

Further screens display the other details of the contact:

Press the key to view the 3 phone numbers the email address,

company and comment for this contact.

Press the key from any of these screens to call this contact. Press

the key to go back to the phonebook.

The memory number of the contact (for example 21) allows you to call

him directly typing from the initial screen this number followed by *

(example : 21*).

Different icons inform you of the position in the phonebook where the

contact is stored:

contact stored in the SIM card

contact stored in the phone

if the Fixed dialling option is activated, only those contacts may

be called. See

PIN number 2

and

Fixed Dialling

Security

Menu for more details about this activation.

Options from a contact saved

251437828_myX-7_lu_en.book Page 22 Lundi, 2. février 2004 1:58 13

Phonebook

Modify contact

Select the contact desired and validate.

Select

Modify contact

and validate.

Modify what you want and validate then select

Save

once the

modifications completed.

Copy to SIM / Copy to phone

This allows you to copy your phonebook entries from one memory to the

other. Only the name, first phone number and the call group will be

copied.

Select

Copy to SIM

Copy to phone

and validate.

Delete

Select

Delete

and validate.

Validate deletion of entry.

Call

Select

Call

. Press the

key to start the call.

You can also select the party to be called from the phonebook, and

press the key to make the call.

251437828_myX-7_lu_en.book Page 23 Lundi, 2. février 2004 1:58 13

Phonebook

vCards can be sent to another phone supporting vCard.

On a contact in the phonebook, please select the

Send by

option menu

item (SMS, MMS or IrDA).

If the vCard is sent successfully, an information message is displayed.

vCards can be sent as an attachment to an SMS or MMS message. See

Compose MMS

on page 28.

When a vCard is received enclosed to an SMS or MMS message, the

message « You have received 1 message » is displayed.

Open the MMS from the inbox. Go to

Options

by pressing the

key,

and select

Extract

; select the vCard among the list of objects attached

to this MMS, and add this contact to the phonebook by pressing the

key. A message is displayed to confirm the action.

Sending a vCard

It is possible to send a vCard from each contact stored in the phonebook.

Receiving a vCard

251437828_myX-7_lu_en.book Page 24 Lundi, 2. février 2004 1:58 13

Messages

From this menu, you are able to send SMS and MMS. MMS is a

Multimedia Message Service, which allows you to enclose audio files,

images and other rich content to your messages; these messages can

even be composed of several slides. MMS are differently invoiced than

SMS are. Please contact your network provider to get more information

on their cost.

This menu has been compiled in collaboration with magic4™.

On the

Messages

menu, please select the

Compose

menu and

validate. Choose the

SMS

option.

The language used is the one selected on the display of the phone (if

the language selected is not compatible with the Easy Message T9™,

the English language will be automatically selected).

When typing a text, a counter showing the number of characters

deducted is displayed at the top of the screen (depending on model).

This counter is not displayed if an icon or sound is inserted into the SMS.

When the text has been entered, the

key (

options

) can also be used

to access the functions offered:

Save

is used to save a draft in memory

Send

is used to send the message by entering the correspondent's

number

T9 options

(see page 26)

Editor mode

(see page 27)

Send options

is used to indicate the message format, the period of

validity, or to activate/deactivate a reply

Cancel

is used to delete all text entered

Activate/deactivate zoom

is used to modify size of characters

Formatting

is used to enrich a text

Insert

to insert an image or sound into your message (see page 28).

Compose SMS

251437828_myX-7_lu_en.book Page 25 Lundi, 2. février 2004 1:58 13

Messages

The Easy Message T9™ mode helps you to easily write your short

messages.

Using T9 Mode

Press once the key corresponding to the letter chosen and make the

word by continuing to press the keys corresponding to the various letters

without paying attention to the display: the word is highlighted.

If you agree on the word proposed on the screen, press the

key to

validate it, and go on writing the next word.

However, the same sequence of keys pressed can correspond to

several words, existing on the dictionary. If the word that appears is not

the word you expected, press the key indicating to scroll through

the words corresponding to this key sequence.

Once you agree on the word proposed on the screen, press the

key to

validate it, add a space and go on writing the next word.

If the word you are expected is not proposed, please add characters until

you get the message

Add the word

? Press

Yes

and validate if the word

displayed suits you or modify this word before adding it in the dictionary.

251437828_myX-7_lu_en.book Page 26 Lundi, 2. février 2004 1:58 13

Messages

In the input screen, the key is used to access other input options.

Input modes

Editor mode

: The

ABC mode

is used to write words that do not exist in

the dictionary. To get a particular character, please press the

corresponding key several times: the characters will scroll down on your

screen.

Mode 123

is used to add numbers.

Insert mode

is used to add symbols, animations, call group icons and

tunes. Images and sounds can be of two types: pre-defined or

customized. Pre-defined images and sounds are smaller, especially

suited to exchanging messages.

Upper case

A short press of the key will display the next letter in upper case.

Two short presses on the key allow you to switch to upper case

editing mode for the whole message.

Punctuation characters

Punctuation characters are obtained thanks to key

(except in

123

mode), or with the help of

Insert

mode (fast access by briefly

pressing the key).

Accented characters

Accented characters are generated automatically in T9 mode.

In ABC mode accented characters are available by pressing the key

supporting the non-accented character in succession.

When composing a message:

The navigation keys assume the

following functions:

key:

Last word

key:

Next word

key:

Previous line

key:

Next line

key:

Deletes last letter

key:

Message options

key (long press):

Zoom mode (changes size of

characters)

key (short press):

Access to symbol table

251437828_myX-7_lu_en.book Page 27 Lundi, 2. février 2004 1:58 13

Messages

On the

Messages

menu, please choose the

Compose

menu and

validate. Select the

MMS

option.

When the text has been entered in the

body

screen, the key

(options)

can also be used to access the functions offered:

The functions offered are:

Slide

to compose a slideshow of the multimedia objects.

Send

Send, Send and receive all, send later.

Warning: some message sendings may fail if the message contents is

too big.

Insert

to insert multimedia objects such as images, videos, animations

and sounds into your message.

Editor Mode

to edit and format the text.

T9 options

(see page 26).

Preview

to see a presentation of the multimedia objects.

When you choose to send your message, the different options are the

following:

Subject:

please write the subject of your MMS.

To:

this option allows you to select the receiver.

Cc:

this option allows you to select the receiver(s) in copy.

Bcc:

this option allows you to select the receiver(s) not visible by the

receivers in copy.

Send options:

there are different options such as:

Priority:

allows you

to assign a priority level to the message.

Request delivery:

allows you

to select the reception of a request delivery.

Compose MMS

251437828_myX-7_lu_en.book Page 28 Lundi, 2. février 2004 1:58 13

Messages

Saving your message

You can save your message as a draft by selecting « Save » from the

options, when editing the Subject or the Body. You will be able to edit it

later from the

Draft

menu.

Sending MMS messages

Once the MMS are sent, you have the option to save them in your

Outbox.

It is recommended not saving them automatically: too many messages

saved will quickly fill up the available memory and no further messages

will be received.

Note:

It is possible that the voice message format (.amr) is not

supported by some PC. See your PC provider.

Receiving MMS messages

Three options are offered to retrieve your MMS: automatic, semi-

automatic and manual options.

The «

automatic retrieval » is automatically programmed in the phone.

If you are using the network of another network provider, you will get a

message informing you that an MMS has been received.

The « semi-automatic retrieval » gives you different options to retrieve

the message.

If you only want to read it once using your own network, please select

« Manual Retrieval ».

Compose MMS

251437828_myX-7_lu_en.book Page 29 Lundi, 2. février 2004 1:58 13

Messages

When you receive a message, the phone will play the ring tone that you

have selected, and the message icon will come on the screen of your

phone.

If you do not read the messages, this icon remains displayed on the

screen. When it flashes, the memory is full.

Receiving icons, backgrounds or tunes can take several seconds. An

icon is blinking when the download of your message is in progress.

Note that you have three different possibilities for receiving MMS:

automatically, semi-automatically or manually; if « manual mode » is

activated, then you will receive only a notification in your Inbox, meaning

that a MMS is available on the MMS Server; select this notification, and

read it when you want to retrieve the MMS from the server.

For more details about automatic and retrieval modes, see « Sending

options » on page 33.

Please contact your network provider to get more information on icons,

backgrounds or tunes downloading.

Receiving messages

251437828_myX-7_lu_en.book Page 30 Lundi, 2. février 2004 1:58 13

Messages

Received messages are stored in the SIM card or in the phone until you

choose to delete them.

On the

Messages

menu, please choose the

Inbox

menu and

Select

Each message shows the presence of any attachments, the time and

date the message was received and its size. Icons are used to describe

the type of message (Multimedia , Remote , SMS ).

Messages are listed in chronological order, the latest one being

displayed first.

The quantity of Not Read and Not Retrieved messages is shown. Not

Retrieved and Not Read messages are shown in bold.

Select a message and press the key. Choose one of the options

given.

Enclosures (pictures or sounds), which you receive, can be saved in

order to be used later on (stored…).

You can consult them in the corresponding menus (WAP bookmarks in

WAP

, ring tones in

Sounds

, wallpapers in

Display

, and icons in

Call

groups

Inbox

251437828_myX-7_lu_en.book Page 31 Lundi, 2. février 2004 1:58 13

Messages

Too many messages saved will quickly fill up the available memory and

no further messages will be received.

On the

Messages

menu, please choose the

Outbox

menu and

Select

For each message, its characteristics (shown with an icon) and the time

(or date) of sending are displayed on the screen.

Select a message and press the key.

Choose one of the options given: Delete sent, Read, Modify, Forward,

Delete, Delete all.

On the

Messages

menu, please choose the

Drafts

menu and

Select

Select a message and press the key. If you do not delete this

message, it will remain as a draft and can be re-used even if you have

already sent it.

Choose one of the options given: Delete all, Visualise, Modify, Details,

Delete.

Outbox

The Outbox is used to store all your sent and waiting messages.

Drafts

When you store a composed message, it is stored among the drafts.

251437828_myX-7_lu_en.book Page 32 Lundi, 2. février 2004 1:58 13

Messages

On the

Messages

menu, please choose

Options

and

Select

Choose one of the options given: SMS or MMS.

The sending options which are proposed are: message centre number,

store sent message, reply given, period of validity (during that period,

the network provider will try to send the message), message format.

The proposed options are:

MMS server:

to select another MMS provider, or set the parameters

of a new MMS provider.

Store sent messages:

(it is highly recommended that you keep this

function deactivated, in order to avoid a full memory),

Retrieval mode:

if you are in a poor coverage area, it may be more

convenient to choose the manual retrieval mode which gives you the

retrieve later option.

Priority:

selection of a priority to send a message.

Delivery report:

request of a delivery report when sending a

message.

Send delivery report:

sending a delivery report when receiving a

message.

MMS reject:

if you want to deactivate the reception of any MMS in

your phone.

Sending options

Several sending options are offered.

251437828_myX-7_lu_en.book Page 33 Lundi, 2. février 2004 1:58 13

Messages

On the

Messages

menu, please select the

Memory

option and

Select

Choose one of the options given: SMS or MMS.

The SMS screen displays the memory available either on the SIM card

or on the phone.

The MMS screen displays how much memory is used in Kbytes.

You can choose whether you want to receive this information or not

(please contact your network provider).

On the

Messages

menu, please select the

Local info.

menu and

Select

Memory

You may know the memory available for saving messages.

Local information

This menu is used to activate reception of local information broadcast by the

network.

251437828_myX-7_lu_en.book Page 34 Lundi, 2. février 2004 1:58 13

Messages

On the

Messages

menu, please select the

Call Voice Mail

option and

Select

Note:

if your voicemail number has not been entered yet, you must enter

it in the menu

Settings/Calls/Voicemail

Calling voicemail

This function allows you to call your voicemail.

251437828_myX-7_lu_en.book Page 35 Lundi, 2. février 2004 1:58 13

Camera

This menu allows you to take photos or videos and use them for different

purposes. For instance, you can send them to another phone or an

Internet address, store them, use them as wallpapers or screen

savers…

Before taking a picture, some features need to be set. See the

Settings/Camera

menu.

Open the shutter at the back of your phone.

Click on the camera button on the initial screen,

select the

Camera

menu. Choose the


Camera

option and press

The camera is now on. Look into your phone display and position your

subject. Move your phone to position your photo.

To activate one of the four available zoom levels, use the

keys.

You can set the photo layout (landscape or portrait) using the

key.

You can set the luminosity using the

key:

: to avoid backlighting, : outdoor, : low luminosity.

Press

Take

, the photo is taken and stays on the phone display.

Warning: if you press the key, you will go back to the previous screen

and lose the photo you have just taken.

Briefly press the key to save your photo. You may have to choose

the photo format, depending on your settings.

If there is not enough memory to save the photo, a warning message

appears, prompting you to confirm whether you want to go on.

Take and send a photo

BackSave

251437828_myX-7_lu_en.book Page 36 Lundi, 2. février 2004 1:58 13

Camera

Once taken, the photo appears on the phone display. The name is made

up with a number.

Note:

using the camera during a call may disturb the call quality.

The

Options

menu appears, giving you the option to choose between:

New photo

: allows you to take a new photo,

Modify the name

: allows you to modify the name of a photo,

Send

: allows you to send the photo by MMS (see the

Message

menu).

Editor

: various options to modify a photo (see chapter

Multimedia

part

Edit a photo

Select one of the options with the

keys and validate.

NB:

photos that have been taken can be saved onto a PC through a

cable or IrDA using the MPAS (My Pictures And Sounds) utility which

can be downloaded from www.planetsagem.com.

251437828_myX-7_lu_en.book Page 37 Lundi, 2. février 2004 1:58 13

Camera

Open the shutter at the back of your phone.

Select the

Camera

menu. Choose the

Video

Camera

option and press

Press the left key (

Record

) to record then press again the left key (

Stop

)

when you want to stop recording.

Note: the phone automatically stops recording when the maximum size

available is reached.

Press

Options

- you can display the video: select

Play

- then you can save it: select

Save

. Modify the name if you want and

press

Warning

A message informs you that the storing and the compression of the

video are in progress. It will take a few seconds.

During this time, you have two choices:

- either you select

Cancel

, the compression is interrupted and when

you display the video later, the phone will resume the compression.

- or you select

Hide

, the compression is not interrupted and you can

use your phone but some functions are not available (taking a video

or photo, sending a MMS).

See chapter

Multimedia

My videos

for the options on a video saved.

Note:

the videos are saved in the phone with a .3gp format.

Take a video

251437828_myX-7_lu_en.book Page 38 Lundi, 2. février 2004 1:58 13

Multimedia

This menu gives you easy access to your favourite photos, videos,

pictures and sounds.

From the

Multimedia

menu, please select the

My Videos

menu and the

Select

label (left key).

The names of the videos stored in memory are displayed on the screen.

Please use the

keys to select one of them.

Once you have selected a video, press

Play

The video is now displayed. After a few seconds an

Options

button appears at the bottom of the screen . Press the

Options

button.

Select one of the options in the list with the

keys and press

Send by

: to send the video by MMS or IrDA (see

Messages

chapter).

Thanks to My Pictures And Sounds (MPAS) software available from

www.planetsagem.com, you can import videos (.3gp format) or export

videos (MPAS converts .3gp format into mpeg4 format readable on

PC).

Delete

: to delete the video.

Rename

: to modify the name of the video.

Play

: to display the video again.

Properties

: properties of the video selected.

Video

: allows you to delete all the videos saved or to take a new

video.

My videos

This menu gives you access to your videos.

251437828_myX-7_lu_en.book Page 39 Lundi, 2. février 2004 1:58 13

Multimedia

On the

Multimedia

menu, please select the

My Pictures

menu and

Select

The pictures stored are displayed on the screen. Please, use the

keys to select one of them.

Once you have selected a picture, press the key to validate the

Options

menu.

Select one of the options in the list with the

keys and validate.

Use as

: allows you to use the picture as a wallpaper or screen saver,.

Delete

: allows you to delete a picture,

Delete all

: allows you to delete all pictures,

Rename

: allows you to rename a picture,

Send by

: makes it possible to transmit a picture (NB: you may not

send any copyrighted picture).

You can import or export pictures to or from a computer using My

Pictures And Sounds (MPAS), available from www.planetsagem.com.

Editor

: allows you to retouch the photo.

My Pictures

This menu gives you access to your pictures.

251437828_myX-7_lu_en.book Page 40 Lundi, 2. février 2004 1:58 13

Multimedia

Edit a photo

On the

Multimedia

menu, please select the

My Photos

menu and

Select

. Select a photo and the

Edit

option, the

Photo editor

appears.

Select one of the edit functions with the

keys and validate:

Sepia

: allows you to change colors into sepia,

Zoom

: allows you to magnify certain parts of your photo,

Adjustment

: allows you to improve contrast,

Emboss

: allows you to modify a photo with an embossed grey tint,

Negative

: allows you to change a photo into negative,

Grey Scale

: allows you to change color into black and white,

Add mark

: allows you to add special characters or drawings to your

photo,

Add frame

: allows you to surround your photo with a frame,

Contrast

: allows you to increase or decrease the contrast of your

photo,

Sharpen

: allows you to sharpen a photo,

Blur

: allows you to add blur to a photo.

251437828_myX-7_lu_en.book Page 41 Lundi, 2. février 2004 1:58 13

Multimedia

To access your sounds, use the same procedure as for your pictures

(see the

My Pictures

menu).

You can import or export sounds to or from a computer using My

Pictures And Sounds (MPAS), available from www.planetsagem.com.

On the

Multimedia

menu, please select the

Memory

menu and

Select

Use the

keys to select the different features using memory. You

can see the memory capacity used by each individual feature.

My Sounds

This menu gives you access to your sounds.

Memory

This menu indicates the memory size used by the different features of

your phone.

251437828_myX-7_lu_en.book Page 42 Lundi, 2. février 2004 1:58 13

WAP

WAP (Wireless Application Protocol): a protocol that translates the

Internet language into WML language that can be read by a phone. The

WAP function allows you to log onto certain Internet sites. You can log

onto sites that allow you to download tunes, icons or animated

screensavers to your phone.

The

Services

menu, a dropdown menu, can be accessed at all times

when navigating through WAP pages pressing the key.

Consult the Services Menu using the key. It contains the following

sub menus:

Welcome:

logs onto the home page.

(carries the name of your access provider)

Bookmarks:

is used to save in a phonebook the names and addresses

of Internet sites in order to make the access easy.

You can receive bookmarks from messages and add them to this list

(see chapter on SMS).

You can also send messages by SMS: select a bookmark, press the

key

(Options)

, then select

Send by message

Go to URL:

this menu allows you to input an Internet address directly.

Inbox:

this menu allows you to check the messages sent by the Internet

site.

Save items:

is used to save a WAP site items.

Snapshots:

takes a snapshot of the currently displayed page.

History:

backward and forward navigation of the pages displayed are

kept in memory.

Reload:

refreshes the current page.

Reset cache:

clears the stored information on previous connections.

The WAP Menu

The WAP navigator is unde

licence:

The WAP navigator is the

exclusive property of Openwave.

For this reason, it is forbidden to

modify, translate, disassemble o

even decompile all or part of the

software that makes up the

navigator.

You can activate the

magnifying glass to increase

the size of the characters by

holding down the

key.

251437828_myX-7_lu_en.book Page 43 Lundi, 2. février 2004 1:58 13

WAP

Advanced…:

choose one of the following advanced settings

- Settings

-Show URL

- Disconnect

- Circuit prompt (if user wants to confirm each logon)

- Security (is used to access information on making WAP connections

secure).

About…:

information on the browser.

Exit:

returns to the phone's home page.

Select the

Advanced…

menu, then the

Settings

menu.

Choose from the proposed sub-menus:

Connection settings

is used to select or modify your access provider's

logon parameters or configure the parameters of other access providers.

The active access service is preceded with a star.

Configuration of WAP and GPRS parameters:

All information to be entered in the parameters are provided by your

operator or access provider.

- Choose the access service, then press

Options

- Enter the title and validate.

- Enter Internet address of home page and validate.

- Enter parameters of preferred connections:

GSM if not GPRS (by default): the logon to WAP services uses the

GPRS as a priority. However, in the event of unavailability of the

GPRS network, the GSM network is used to establish the link.

GPRS: the logon to WAP services uses the GPRS network

exclusively.

GSM: the logon to WAP services uses the GSM network exclusively.

Configuring WAP parameters

251437828_myX-7_lu_en.book Page 44 Lundi, 2. février 2004 1:58 13

WAP

The

GSM parameters

to be entered are:

- Login

- Password

- IP address of WAP gateway

- Port type (secure or insecure)

- Dial-up number

- Mode (digital, analog or automatic)

In automatic mode access can be gained to the operator's network by a

digital link and an analog link to a different network (in roaming).

The

GPRS parameters

to be entered are:

- Login

- Password

- IP address of WAP gateway

- Port type (secure or insecure)

- APN: if no APN has been defined, press the key

(Options)

then

the APN menu. Select or add an APN.

Once all the settings have been entered, you can activate the chosen

access provider. Select him from the list. Validate your choice.

Linger timer

is used to choose the time after which the call is

automatically disconnected if you have forgotten to log off from a

service.

251437828_myX-7_lu_en.book Page 45 Lundi, 2. février 2004 1:58 13

WAP

Using the

Welcome

menu, you can log onto your access provider's

WAP site by pressing the

key.

If you are logging onto the GSM network, the @ symbol flashes, the

metering of the cost of the call starts as soon as it stops flashing.

Some WAP sites allow you to download tunes, icons or animated

screensavers. Once downloaded, they are stored in your phone's

memory. You can then save them in your phone (same operation as

used for downloading using messages).

To log off, press the

key. The logoff happens automatically after a

few seconds of inactivity if you forget to log off. This period is defined by

the linger time setting.

WAP Logging on

Downloading sounds and images

WAP Logging off

The connection to a WAP service

on the GPRS network is not cut i

an incoming call is received. You

can answer the call.

251437828_myX-7_lu_en.book Page 46 Lundi, 2. février 2004 1:58 13

WAP

A flashing icon indicates that the phone is logging onto a GPRS network.

A non-flashing icon indicates that the GPRS network is available; if the

icon is dark, it indicates that the phone is logged onto the GPRS

network: see page 44 for the attachment options.

This icon is not displayed if the GPRS network is not available or if the

SIM card inserted in your phone does not include the GPRS service. It

may also disappear when accessing WAP services if the connection

uses the GSM network instead of the GPRS network.

GPRS

251437828_myX-7_lu_en.book Page 47 Lundi, 2. février 2004 1:58 13

Games

The games being designed by Java™, many compatible games can be

downloaded in your phone.

With the

Games

menu you can use the two games already installed

(depending on model) and install others. For that, display the

MoreGames menu: it gives access to the WAP portal from which you

can download games connecting on internet sites.

Settings/Connection menu:

this menu allows you to save sites

addresses from which you can dowload games.

Delete all menu:

deletes all the games you have downloaded.

251437828_myX-7_lu_en.book Page 48 Lundi, 2. février 2004 1:58 13

Applications

The Java™ function allows you to download applications and utilities in

your phone.

Downloading is done through the WAP function.

Please go to the

Applications

menu to use the applications already

installed or install others.

This item may not be present on your phone’s menu, as it depends on

your SIM.

ToDo menu

This menu allows you to add ToDo’s, access category-based Todo

management and delete all the ToDo’s.

On the

Applications

menu, please select the

ToDo

menu and confirm

your choice.

Select one of the actions in the list with the

keys and validate.

Memory

: allows you to view the memory used by the different

functions of your ToDo.

Categories

: allows you to see the different event categories, assign

a specific ring tone to each individual category, know the number of

events in each category and see them.

Memory

: allows you to view the memory capacity used by the

different functions of your diary.

Clean-up:

allows you to schedule the deletion of events that took

place more than one day, week or month ago.

Delete all :

allows you to delete all the events from your diary.

Add events:

allows you to add events according to their categories.

Select one type of event and validate. Fill in the different items. Save

the event.

251437828_myX-7_lu_en.book Page 56 Lundi, 2. février 2004 1:58 13

Organiser

You can send vCals to another phone using MMS or IrDA depending on

your phone and the recipient’s phone.

On the See today list, please select an event and in theTodo event

actions menu list, select Send.

Then choose between MMS, IrDA or serial link for the type of sending

and confirm.

For MMS deliveries, you should in addition select your contact

information (phone number or Email address) before confirming.

If you receive a call while you are sending a vCal, the call will have

precedence.

The vCal receipt mode differs with the type of delivery:

- By MMS, you receive a message you have to open to extract the vCal.

You cannot add the event to your diary until you have saved it.

- By IrDA or serial link, you receive a message and when the download

is completed, a message appears on your phone display, asking you

what you want to do with the vCal (save it, delete it…).

You can assign a different beep to each diary event.

You can also assign a different ring tone to each diary event category.

Sending a vCal

You can send a vCal from each diary event. Yet, this function is available only

on certain models of phone.

Receiving a vCal

251437828_myX-7_lu_en.book Page 57 Lundi, 2. février 2004 1:58 13

Settings

This menu allows you to set your phone.

Volume and ring tone

This menu allows you to allocate a ring tone to each type of event.

On the

Sounds

menu, please select the

Ring tones

menu and

Select

Select one of the events given: Alarm, Calls, Messages, Local Infos and

Fax and validate.

Select the

ring tone

from the proposed list and validate.

Adjust the

volume

using the

keys and validate.

You can deactivate the sound by pressing the key.

Voice Calls: the ring tone selected here will be played only when

receiving a call from a contact stored without any call group.

Otherwise, the ring tone selected for this call group will be played.

Vibrate

This menu allows you to activate the vibrate mode for calls.

On the

Sounds

menu, please select the

Vibrate

menu and

Select

Select the vibrate mode from the proposed choices (ring tone and

vibrate, vibrate only, vibrate inactive or vibrate plus ring tone) and

validate.

Sounds

This menu allows you to customize the ring tones on your phone and to

activate beep and vibrate modes.

251437828_myX-7_lu_en.book Page 58 Lundi, 2. février 2004 1:58 13

Settings

Warning: vibrate mode is not a priority regarding the ring tone selected

on the call group. To make vibrate mode apply in general, switch to

Silent mode.

Silent mode

This menu allows you to switch to Silent mode.

On the

Sounds

menu, please select

Silent mode

and

Select

Activate

deactivate

Silent mode and validate.

Silent mode can also be accessed via the initial screen by holding down

the key.

When the phone is in silent mode, the relevant icon appears on the

initial screen.

In this mode, the ring tone will not function, except for the alarm clock.

Note

: if you have activated the silent mode, it does not remain after

switching off your phone.

Beeps

This menu allows you to activate a beep for each type of event.

On the

Sounds

menu, please select the

Beeps

menu and

Select

Select the type of beep you want to allocate from the proposed choices

(Key beep, Network beep or Battery beep) and validate. Activate or

deactivate the beep and validate.

If you select key beeps, different options are given.

251437828_myX-7_lu_en.book Page 59 Lundi, 2. février 2004 1:58 13

Settings

Recorder

These menu allows you to record you own melody.

On the

Sounds

menu, please select the

Recorder

menu and

Record

Record your melody or your voice by means of the microphone then

save it.

Give it a name and validate. The new tone is saved in the list of ringtones

and in

Multimedia/My Sounds

If you select the recorder by means of a programmable key, the sound

is saved in the

Assistant/Memo

menu.

This menu allows you to choose the skin of your phone, i.e. define its

look (text font, colors, default animation, background image…).

On the

Display

menu, please select

Skins

Select the desired skin and validate.

Skins are not downloadable but you can download screensavers and

boot mode animations without changing those included by default with

the skin.

Display

This menu allows you to customize your screen by choosing a different

presentation.

251437828_myX-7_lu_en.book Page 60 Lundi, 2. février 2004 1:58 13

Settings

Wallpaper

This menu allows you to display the background picture you want on

your phone.

On the

Display

menu, please select the

Wallpaper

menu and

Select

Select the Wallpaper and

Visualise

. The picture appears in the

background of the screen.

Press the

key to validate this choice, or the

key to go back to

choice.

Screensaver

This menu allows you to display an animation when the phone is in

standby mode.

On the

Display

menu, please select the

Screensaver

menu and

Select

Select one of the screensavers given and

Visualise

The chosen screensaver appears on the screen, validate it.

Adjust the screensaver display time (more than 60 seconds) and

validate. The screensaver comes on the screen each time the display

time that has been selected runs off.

NB:

the selected screensaver is active only if the

Eco.

mode is de-

activated on the

Energy saving

menu.

251437828_myX-7_lu_en.book Page 61 Lundi, 2. février 2004 1:58 13

Settings

Operator logo

This menu allows you to display your operator's logo on the initial

screen.

On the

Display

menu, please select the

Operator logo

menu and

Select

Activate

Deactivate

and press

251437828_myX-7_lu_en.book Page 62 Lundi, 2. février 2004 1:58 13

Settings

On the

Settings

menu, please select the

Camera

menu and

Select


Timer:

this menu enables you to take a photo with a 5, 10 or 15 second

time delay. During preview of the photo, activate the delayed exposure

by pressing on the button . (NB: if you want to take the photo

immediately, then press on the Photo button).

Click sound:

This menu allows you to select the sound you will hear

when taking a photo.

Photo format:

This menu allows you to choose the format in which your

photo will be saved. There are several options:

- either you systematically set the photo format to one of the following:

High resolution

Mobile format

- or you can choose the photo format on a case-by-case basis.

Video

Video size restriction:

This menu allows you to choose a video size.

Video sound:

This menu allows you to select or not the sound when

recording a video.

Camera

This menu allows you to set the camera and video features of your phone.

251437828_myX-7_lu_en.book Page 63 Lundi, 2. février 2004 1:58 13

Settings

On the

Settings

menu, please select the

Languages

menu and

Select

Select your language and validate.

If you select

Automatic

, the language used will be the one relative to

your SIM card.

The

Calls

menu allows you to manage all the calls functions (call

forward, displaying numbers, call waiting, voicemail number, etc.).

Languages

This menu allows you to choose your phone's display language.

Calls

251437828_myX-7_lu_en.book Page 64 Lundi, 2. février 2004 1:58 13

Settings

Call forward

Depending on your subscription, this service allows you to forward

incoming calls to a different number or to the voice mailbox.

On the

Calls

menu, please select the

Call forward

menu and

Select

Choose the type of forwarding you want from the options available.

View last calls

This menu allows you to access the list of last numbers used.

On the

Calls

menu, please select the

View last calls

menu and

Select

For every phone call are displayed on the screen:

- its characteristics (shown with an icon),

- the time (or date),

- its duration.

Select a call from the list and validate.

Select one of the options given: Call, Store in your phonebook, Send a

message, Delete, Delete all.

You can also make the call by pressing the key.

251437828_myX-7_lu_en.book Page 65 Lundi, 2. février 2004 1:58 13

Settings

Fast access to the list of calls from the initial screen: press the key.

Counters

This menu allows you to consult the duration of the up calls.

It can also be used to check the volume of data exchanged in GPRS.

On the

Calls

menu, please select the

Counters

menu and

Select

Select one of the options given.

Display number

This menu allows you to modify the status of the display number

function.

On the

Calls

menu, please select the

Display number

menu and

Select

Select one of the options given: Anonymous mode, My number, Callers’

number.

Anonymous mode

You have the facility to mask your number on the phone of the person

you are calling.

Preset: network default mode.

No: you choose not to activate anonymous mode and then to display

your number.

Yes: you choose to active anonymous mode and then not to display your

number.

251437828_myX-7_lu_en.book Page 66 Lundi, 2. février 2004 1:58 13

Settings

During a call, you may be informed that a caller is trying to reach you:

you hear a special tone. The caller's identity is displayed on the screen

(name or number).

Call waiting

(Operator-dependent service)

On the

Calls

menu, please select the

Call waiting

menu and

Select

You can

activate, deactivate,

consult the status

of the call waiting

service in order to check if it is active or not.

During a call, if a second caller tries to contact you, the screen displays

the call warning.

Automatic redial

This menu allows you to call back a caller you have not managed to

reach.

On the

Calls

menu, please select the

Auto redial

menu and

Select

You can set the redial function to inactive, on request or systematic.

If you choose

On demand

, your phone will offer to redial your caller

automatically if his number is busy.

251437828_myX-7_lu_en.book Page 67 Lundi, 2. février 2004 1:58 13

Settings

Blacklist

The blacklist is used to limit failures on automatic calls (calls generated

by the automatic redial function or by applications: data, fax for

example).

On the

Calls

menu, please select the

Blacklist

menu and

Select

When several automatic calls failed with a number (number busy or

unknown), this number is put in the blacklist and no automatic call will

be done with this number any more until you delete it from the blacklist.

Note:

this function does not apply to the calls performed manually.

Voicemail

This function is used to record your answer phone number.

This number will be used during a call to the voice mailbox using the

programmable keys.

On the

Calls

menu, please select the

Voicemail

menu and

Select

Enter your answer phone number and validate.

ALS

The ALS (Alternate Line Service) function allows you, depending on

your subscription, to have two phone lines.

The number of the line selected (1 or 2) for the calls appears on the initial

screen.

251437828_myX-7_lu_en.book Page 68 Lundi, 2. février 2004 1:58 13

Settings

Keypad locking

This menu allows you to lock the keypad to avoid unwanted key presses.

On the

Security

menu, please select the

Keypad locking

menu and

Select

Activate

deactivate

and validate

The lock icon appears on the initial screen.

This function is also available in the initial screen pressing the

and keys.

PIN number

This menu allows you to activate and modify your phone's PIN.

On the

Security

menu, please select the

PIN number

menu and

Select

To modify the PIN, select

Modify

and

Select

Enter old PIN and validate.

Enter new PIN twice and validate.

To activate or deactivate the PIN, select the

Check PIN

menu and

Select.

Enter PIN and validate.

Select

Activate

Deactivate

and validate.

Security

This menu allows you to configure your phone's security settings.

251437828_myX-7_lu_en.book Page 69 Lundi, 2. février 2004 1:58 13

Settings

PIN2 number

You have a second PIN number to allow you to access certain

functions*.

* These functions may or may not be available depending on your SIM

card.

Proceed as above in order to activate, deactivate or modify PIN number

2 of your phone.

Phone code

The Phone code menu allows you to activate the phone code so that it

is requested and checked whenever the phone is switched on if a

different SIM card is used. This code is automatically linked to the SIM

card installed when the phone is activated, for example to protect the

phone if stolen.

To activate or deactivate the phone code, select the

Phone code

and validate.

Enter 0000 (the factory code, by default) and validate.

Select

Activate

Deactivate

and validate.

To modify the phone code, select

Modify

and validate.

Enter old phone code and validate.

Enter new phone code and validate.

Enter phone code again to confirm it and validate.

251437828_myX-7_lu_en.book Page 70 Lundi, 2. février 2004 1:58 13

Settings

The Confidentiality function is used to delete numbers stored in View

last calls and the SMS stored in the memory when a new SIM card is

inserted into the phone.

Confidentiality

This menu allows the activation of automatic deletion, after power off/on,

for messages and/or calls stored in the phone.

On the

Security

menu, please select the

Confidentiality

menu and

Select

Activate

Deactivate

and validate.

Operator

This menu allows you to modify the call barring.

On the

Security

menu, please select the

Operator

menu and

Select

Access to this service depends on your type of subscription.

251437828_myX-7_lu_en.book Page 71 Lundi, 2. février 2004 1:58 13

Settings

Call barring can be applied to ALL calls (incoming and outgoing), to all

incoming calls when you are away from your home country (if roaming

available).

Call barring

This menu allows you to block the sending or reception of certain calls.

Before you can use this service, a password will be provided by your

operator when you take out your subscription.

On the

Security

menu, please select the

Call barring

menu and

Select.

Select

Activate

Deactivate

and validate.

Access to this service depends on your subscription type.

Fixed dialling

This menu allows you to restrict the outgoing calls.

The availability of this menu depends on your SIM.

On the

Security

menu, please select the

Fixed dialling

menu and

Select

Enter PIN2 number and validate.

Select

Activate

Deactivate

and validate.

Proceed as for any other phonebook.

When activating this function, only the numbers stored in the phonebook

can be called.

This phonebook is linked to the SIM card, and its size depends on the

card's capacity.

251437828_myX-7_lu_en.book Page 72 Lundi, 2. février 2004 1:58 13

Settings

Cost

This menu allows you to control the cost of your calls (*).

On the

Security

menu, please select the

Cost

menu and validate.

The

Cost

menu (*) lets you check the cost of the last call you made and

of all the calls you made since you last deleted them.

The

Delete costs

menu (*) lets you delete the cost of your last call and

reset the cost counter after entering your PIN 2 code.

(*) WARNING

Depending on how the networks and associated subscription cards are

configured, some functions may be unavailable (these are marked out

with *).

On the

Settings

menu, please select the

Networks

menu and

Select

Choose

Preferred

to view all the pre-registered networks.

Choose

Selection

to activate (automatically or manually) one of the

networks accessible in the area in which your are located.

Choose

Network type

to select your network: GSM-DCS or PCS

(depending on model).

Choose

GPRS

to select the way you want to be attached on the GPRS

network: always, or only when needed (when launching a data

connection).

Networks

This menu allows you to configure network preferences.

251437828_myX-7_lu_en.book Page 73 Lundi, 2. février 2004 1:58 13

Settings

Car kit

This menu allows you to configure your phone with a car kit.

On the

Others

menu, please select the

Car kit

menu and

Select

Choose one of the options given: Automatic response, Switch off, Kit

volume.

Energy saving

This function is used to deactivate the screen backlight and to select the

economic mode.

On the

Others

menu, please select the

Energy saving

menu and

Select

Backlight:

choose one of the options given: Deactivate, Full backlight,

Screen only, and validate.

By deactivating the screen backlight, you increase the battery life of your

phone. Warning: display legibility is reduced.

Economic mode

: choose one of the options given: Partial, Deactivate,

Complete, and validate.

When choosing the economic mode, the screen goes out (standby mode).

To quit economic mode, press the key.

NB:

if you selected an animation in the

Display/Screensavers

menu and

activated the economic mode, this will be activated as the priority and the

screensaver will not appear.

Others

251437828_myX-7_lu_en.book Page 74 Lundi, 2. février 2004 1:58 13

Settings

(Function available depending on model)

This menu allows you to customize the settings of your phone to make

it as convenient as possible for you to use.

On the

Settings

menu, please select the

Short cuts

menu and

Select

Select the key that you wish to modify and validate.

Choose the function that you want to allocate to this key and validate.

Short cuts

This menu allows you to allocate functions to the programmable keys.

251437828_myX-7_lu_en.book Page 75 Lundi, 2. février 2004 1:58 13

Settings

Set Date/Time

This menu allows you to set the date and time of your phone.

On the

Date / Time

menu, please select

Set Date/Time

and validate.

Date:

set the date by entering it directly in digital form or by using the

keys.

Use the

(or

) key to access the next (or previous) entry field.

Once the date is correct, validate it.

Time:

same procedure as for setting the date.

Automatic update

This menu allows you to choose manual or automatic updating of date

and time (after switch off of your phone or when going abroad for

instance) (service depending on the operator).

From the

Date / Time

menu, please select

Automatic upd.

and press

Please select Automatic, Manual or On demand and press

Date / Time

251437828_myX-7_lu_en.book Page 76 Lundi, 2. février 2004 1:58 13

Settings

Display

This menu allows you to select the date and time display type.

On the

Date / Time

menu, please select

Display

and validate.

In the list that appears, select the desired display type between:

- Analog,

-Digital,

- None,

by using the

keys and validate.

Time zone

This menu allows you to change time in relation to the GMT time.

On the

Date / Time

menu, please select

Time zone

and validate.

Choose the time of the country desired by calculating the time from the

GMT time.

251437828_myX-7_lu_en.book Page 77 Lundi, 2. février 2004 1:58 13

Settings

Summer time

This menu allows you to set your phone to the summer/winter time.

On the

Date / Time

menu, please select 1 h, 2 h

Summer time

Winter time

depending on the season, and validate.

251437828_myX-7_lu_en.book Page 78 Lundi, 2. février 2004 1:58 13

Settings

IrDA

This menu is used to configure the data exchange with another device

(Personal Digital Assistant, PC, etc.).

On the

Connectivity

menu, please select the

IrDA

parameters menu

and validate.

You may then:

- send or receive images, sounds etc either using a different

compatible phone or from a PC installed with "My Pictures and

Sounds" (available from www.planetsagem.com), or

- exchange contacts, events and tasks with your PC by means of the

Wellphone software (page 53).

Serial Speed

On the

Connectivity

menu, please select the

Serial Speed

parameters

menu and validate.

The

Speed

menu enables you to select the speed to be used for data

exchanges via your phone's serial port. Except for specific

requirements, it is advisable to stick to the default setting:

Automatic

Connectivity

You can also connect it to your computer in order to receive data or fax

through GSM or GPRS network (depending on subscription): configure the

connection parameters of your computer using the Wellphone CD supplied

as an accessory.

251437828_myX-7_lu_en.book Page 79 Lundi, 2. février 2004 1:58 13

Settings

On the

Settings

menu, please select the

Menu Hot-line

parameters

menu and validate.

Menu Hot-line

This menu is used to provide information to your operator if an intervention

on your phone is necessary.

251437828_myX-7_lu_en.book Page 80 Lundi, 2. février 2004 1:58 13

Care and safety information

Safety

Use of your phone is subject to safety measures designed to protect users and their environment.

Do not use your phone in damp areas (bathroom, swimming pool…). Protect it from liquids and other moisture.

Do not expose your phone to extreme temperatures from - 10°C to + 55°C.

The physicochemical processes created by chargers impose temperature limits when charging the battery. Your phone

automatically protects the batteries in extreme temperatures.

Do not leave your phone within the reach of small children (certain removable parts may be accidentally ingested).

Electrical safety

Only use the chargers listed in the manufacturer’s catalogue. Using any other charger may be dangerous; it would also

invalidate your warranty. Line voltage must be exactly the one indicated on the charger’s serial plate.

Aircraft safety

When travelling by plane, you will need to switch your phone off when so instructed by the cabin crew or the warning signs.

Using a mobile phone may be dangerous to the operation of the aircraft and may disrupt the phone network.

Its use is illegal and you could be prosecuted or banned from using cellular networks in the future if you do not abide by these

regulations.

Explosive materials

Please comply with warning signs at petrol station asking you to switch your phone off. You will need to comply with radio

equipment usage restrictions in places such as chemical plants, fuel depots and at any location where blasting operations are

under way.

Electronic medical equipment

Your phone is a radio transmitter which may interfere with electronic medical equipment or implants, such as hearing aids,

pacemakers, insulin pumps, etc. It is recommended that a minimum separation of 15 cm be maintained between the phone and

an implant. Your doctor or the manufacturers of such equipment will be able to give you any advice you may need in this area.

Hospitals

Always make sure that your phone is switched off in hospitals when so instructed by warning signs or by medical staff.

Road safety

Except in emergencies, do not use your phone when driving unless you have a hands-free kit enabling you to manoeuvre freely.

In order to give your full attention to driving, stop and park safely before making a call. You must comply with any current legislation.

Ensure that no part of your body is permanently close to the aerial unless there is a metal screen (e.g.: a vehicle roof, …).

251437828_myX-7_lu_en.book Page 81 Lundi, 2. février 2004 1:58 13

Care and safety information

SAR

This phone complies with European requirements governing exposure to radio waves. Your phone is a transmitter/receiver. It

has been designed and manufactured to comply with radiofrequency energy exposure limits recommended by the Council of

the European Union and the ICNIRP for the entire population. These limits were established by independent scientific agencies

on the basis of in-depth and regular evaluations of scientific studies. The limits include a large safety margin that is intended to

guarantee the safety of all, irrespective of age or state of health.

The exposure standard for phones uses a unit of measure called the SAR, or Specific Absorption Ratio. The SAR limit

recommended by the Council of the European Union and the ICNIRP is 2 W/kg (*). Tests were conducted on a standardised

usage position basis, with the phone transmitting at its maximum level certified in all its frequency bands. Although the

standardised measurement is done at maximum power, the real SAR of the phone in use is generally very far below the

maximum value.

The phone was designed to operate at the power level strictly neces-sary to ensure communication with the network. In general,

the closer you are to a base station, the lower the power at which the phone will transmit.

Validation of conformity with European directive 1999/5 (directive R&TTE) is a pre-requisite for introducing any model of phone

onto the market. Protection of health and the safety of the public and the user are a vital requirement of this directive. This

model's maximum SAR value measured at the compliance test for use at the ear was 0.57 W/kg. Although differences may exist

from one phone to the other and depending on position, all comply with European regulations.

Advice for limiting exposure to radiofrequency (RF) fields

For individuals concerned about limiting their exposure to RF fields, the World Health Organization (WHO) provides the following

advice:

Precautionary measures: Present scientific information does not indicate the need for any special precautions for the use of

mobile phones. If individuals are concerned, they might choose to limit their own or their children’s’ RF exposure by limiting the

length of calls, or using "hands-free" devices to keep mobile phones away from the head and body.

Further information on this subject can be obtained from the WHO home page http://www.who.int/peh-emf WHO Fact sheet

193: June 2000.

(*) The SAR limit for phones used by the general public is 2 watts/kilogram (2 W/kg) on average for 10 g of tissue. This value

includes a large safety margin to increase protection and to take account of the variations in measurements. The SAR

information may vary in different parts of the world, depending on declared national requirements and the frequency

bands used by the network.

251437828_myX-7_lu_en.book Page 82 Lundi, 2. février 2004 1:58 13

Warranty

The software program developed by SAGEM remains the exclusive property of SAGEM SA. It is therefore highly prohibited to

modify, translate, de-compile or disassemble this software program or any part thereof.

Usage precautions

Your phone allows you to download ring tones, icons and animated screensavers. Some of these items may contain data that

may cause malfunctions of your phone or data losses (virus for example).

For this reason, SAGEM SA rejects all responsibility concerning (1) the reception of downloaded data or losses of the said data,

(2) the impact on the operation of the phone and (3) damages resulting from receiving the said downloaded data or loss of said

data. In addition, SAGEM SA states that a failure caused by receiving downloaded data that do not comply with the

specifications set by SAGEM SA is excluded from the warranty. Consequently, the diagnosis and repair of a phone infected by

the said downloaded data will be at the expense of the customer.

Warranty conditions

Whenever you wish to make use of the warranty, please contact your vendor and present him with the purchasing paperwork

that he gave you.

If a fault occurs, he will advise you.

The new phone (excluding consumables), including new accessories bundled with the phone, are guaranteed by SAGEM SA,

parts and labour (apart from travel) against any manufacturing fault for a period of twelve (12) months with effect from the sale

of the phone by SAGEM SA to the customer, on presentation of the paperwork stating the purchase date of the phone.

Phones that have been repaired or replaced as standard during the warranty period stated above are guaranteed (parts and

labour) until the later of these two dates:

Expiry of the guarantee period of twelve (12) months stated above or three (3) months with effect from the support provided by

SAGEM SA.

In any disputes, the phone is covered by the legal warranty against the consequences of faults or hidden defects in compliance

with articles 1641 and subsequent of the French civil code.

All faulty phones under warranty will be replaced or repaired free of charge at SAGEM SA's option (with the exclusion of repair

of any other damage), once it has been specified that the work required for the application of the warranty will be done in a

workshop and that the return costs (transport and insurance) of the phone to the address to be indicated to it by the SAGEM SA

after-sales service, whose phone number will appear on the delivery note, will be charged to the customer.

Subject to essential legal provisions, SAGEM SA does not accept any warranty, explicit or implicit, other than the warranty

provided expressly in this chapter, nor shall SAGEM SA accept responsibility for any immaterial and/or indirect damages (such

as loss of orders, loss of profit or any other financial or commercial damage) under the warranty or not.

251437828_myX-7_lu_en.book Page 83 Lundi, 2. février 2004 1:58 13

Warranty

The acceptance of a phone under warranty demands that a purchase document that is legible and without modi-fication, stating

vendor's name and address, date and place of purchase, type of phone and IMEI, are attached to the warranty, and that the

information on the phone identification label is legible and that this label or any other seal has not been tampered with.

The warranty applies in normal conditions of use.

Prior to sending the phone for repair, it is the customer's responsibility to backup at his expense the customized data stored in

the phone (phonebook, settings, wallpapers). A list of backup facilities can be provided by SAGEM SA on request. The

responsibility of SAGEM SA cannot be invoked if damage occurs to customer files, programs or data. The information or

operating elements and the contents of files will not be re-installed in any case in the event of loss.

SAGEM SA may decide, at its option, to repair the phone with new or reconditioned parts, replace the phone with a new phone

or, in any dispute, a phone in good working condition. During its work SAGEM SA reserves the facility to make, where

necessary, any technical modifications to the phone where these modifications doe not adversely affect its initial purpose.

Faulty parts to be replaced during a repair under warranty will become the property of SAGEM SA.

The phone repair and standstill time during the warranty period may not lead to an extension of the warranty period as stated

in article 1 above, provided no other vital provisions have been agreed.

The application of the warranty is subject to the full payment of the sums due for the phone when the request for support is made.

The following are excluded from the warranty:

Breakdowns or malfunctions due to non-compliance with the installation and use instructions, to an external cause of the phone

(shock, lightning, fire, vandalism, malice, water damage of any type, contact with various liquids or any harmful agent, unsuitable

electric current...), to modifications of the phone made without the written consent of SAGEM SA, to a servicing fault, as described

in the documentation supplied with the phone, to lack of supervision or care, to poor environmental conditions of the phone

(especially temperature and hygrometry, effects of variations in electric voltage, interference from the mains network or earth) or

even due to a repair, a call-out (opening or trying to open the phone) or to servicing done by personnel not approved by SAGEM SA.

Damage resulting from inadequate packaging and/or poor packing of the phone sent back to SAGEM SA.

Normal wear and tear of the phone and accessories.

Communication problems linked with a poor environment, especially:

Problems accessing and/or logging onto the Internet, such as breakdowns of the access network, the failure of the subscriber's

or his correspondent's line, transmission fault (poor geographic coverage by radio transmitters, interference, disturbance, fai-

lure or poor quality of phone lines...), a fault inherent to the local network (cabling, file server, user phone) and/or transmission

network fault (interference, disturbance, failure or poor quality of the network...).

Change of parameters of the cellular network made after the phone was sold.

Supply of new software versions.

Current servicing work: delivery of consumables, installation or replacement of these consumables...

Call-outs for phone or software modified or added without the written consent of SAGEM SA.

251437828_myX-7_lu_en.book Page 84 Lundi, 2. février 2004 1:58 13

Warranty

Faults or disruptions resulting from the use of products or accessories not compatible with the phone.

Phones returned to SAGEM SA without having complied with the return procedure specific to the phone cove-red by this

warranty.

The opening or closing of a SIM operator key and call-outs resulting in the non-operation of the phone resulting from the opening

or closing of SIM operator key done without the agreement of the original operator.

In the cases of warranty exclusion and of expiry of the warranty period, SAGEM SA shall draw up an estimate to be given to the

customer for acceptance before any call-out. The repair and carriage costs (there and back) given in the accepted estimate will

be charged to the customer.

These provisions are valid unless a special written agreement has been made with the customer. If one of the provisions turns

out to infringe a legally essential rule that consumers could have the benefit of under the national legislation, this provision will

not be applied, but all other provisions will remain valid.

251437828_myX-7_lu_en.book Page 85 Lundi, 2. février 2004 1:58 13

Troubleshooting

ROBLEM

- S

ITUATION

CTIONS

It is impossible to switch

the phone on

Remove and replace the battery.

If you still cannot switch the phone on, charge the battery:

- Put it on charge for at least 15 minutes before switching it back on again.

- Check if the battery icon is scrolling up and down.

- If so, the phone is charging.

- If not, please take the charger out and put it back on again. Please check

that the charging icon is scrolling up and down.

- If you still cannot switch the phone on, please disconnect the charger, put

it back on again and please repeat that manipulation several times.

- If the charging icon is still not scrolling up and down, please contact your

after-sales services.

- When the charging icon has stopped scrolling up and down, the battery is

charged.

Battery status unknown

The phone does not recognize the battery. Please check the position of the

battery.

LOW BATTERY

This message is displayed when the battery becomes too weak. The phone

switches itself off automatically. Put the phone on charge.

SIM not present

Check if the SIM card is present and properly positioned / inserted.

Check the condition of the SIM card. If damaged, please go back to the

operator's shop for advice. Contact your after-sales service if the message

persists.

Incorrect PIN code

An incorrect PIN code has been entered. Be careful! Three incorrect PIN

codes will block the SIM Card.

SIM BLOCKED

You have entered three incorrect PIN codes.

Enter your PUK code to unblock your SIM Card.

You must enter: **05*PUK*PIN*PIN#

You must enter the PUK code (Personal Unblocking Key) given by your

network provider.

10 errors will permanently block your SIM Card. You must then contact your

network provider to get a new one.

251437828_myX-7_lu_en.book Page 86 Lundi, 2. février 2004 1:58 13

Troubleshooting

SIM LOCKED

On network providers’ request, the handset can only be used with some

types of SIM cards. This message means that the SIM card you are using

does not fit with the phone. Take the SIM card out, and switch it back on. If

the message

SIM not present

appears on the screen, you will need to

check its compatibility next to the place where you bought it. If not, please

contact your after-sales service.

No call connection

Check that the number you have dialled is correct.

If the letter R is displayed on the top right corner of the screen, without any

network name displayed, only emergency services can be called.

Check the status of your credit.

Check that the SIM Card you are using offers the service you are requesting

; check if its validity has not expired.

Check and deactivate the outgoing calls restriction when necessary.

The network could be saturated. Try later.

If the problem persists, please contact your Technical Helpdesk.

No receiving calls

Try to make a call in order to check that the phone and the networks are

operational.

Check and deactivate the permanent call forwarding (permanent call

forwarding icon displayed on the screen).

Check and deactivate the incoming calls restriction when necessary.

If the problem persists, please contact your Technical Helpdesk.

Quality reception when calling

Avoid placing your fingers on the top of the phone, where the aerial is

integrated: the phone will have to use full strength to establish a quality

transmission.

Impossible to send message

Check that the message centre number is correctly entered.

To do so, please select the menu

Messages

, select

Options

, select

MSG

centre n°

and check the number entered. Please contact your network

provider to get this number.

ROBLEM

- S

ITUATION

CTIONS

251437828_myX-7_lu_en.book Page 87 Lundi, 2. février 2004 1:58 13

Troubleshooting

No answer phonebox

Check that the SIM card does offer this service.

Program the call to be forwarded to answer phoneusing the information

provided by the operator.

Check that the SIM card used offers this service. Try to make a call to check

that phone and network are operational.

Check if the answer phone number is properly configured. To do so, go to

the

Calls

menu, select

Voicemail

and check the number. Otherwise, enter

your operator’s answer phone centre number.

If answer phone icon flashing

Call the answer phone and listen to the new messages to make it disappear.

Wrong ring tone is played on call

reception

Check the call group of the contact who has called: check the ring tone

selected for this group.

Backlight does not work

Go into the

Settings / Others

menu, select the

Energy saving

menu and

activate backlight.

In WAP context:

SERVER NOT ANSWERING

message

Switch off and then switch phone back on.

Logon to home page impossible

In the

WAP

menu,

Clear the cache

Operator name does not appear on

screen

Go into the

Settings

menu, select

Networks

, then

Selection

. Wait until the

operator appears, select it and validate.

If the Operator logo is present (depending on model), activate the display

(

Settings/Display/Operator logo

How do I (un)lock the keypad?

Press the key, then the

key (validate).

How do I switch to silent mode?

Hold the key down unless ring tone sounds, when a short touch is

enough.

How do I activate zoom?

Can be activated only in SMS and WAP screens; hold down the key.

How do I delete the envelop that

appears on the screen?

If you have received a voice mail, please call your voice mailbox and follow

the instructions given.

How do I delete the answer phone

that appears on the screen?

This answer phone means that you have received a voice mail: please call

your voice mailbox and listen to it. Please follow the instructions given.

How do I remove the written

message at the bottom of the home

page (1 call)

Press the

key to go back to the initial page without messages.

ROBLEM

- S

ITUATION

CTIONS

251437828_myX-7_lu_en.book Page 88 Lundi, 2. février 2004 1:58 13

Troubleshooting

How do I download ring tones?

Logon to one of the following site via your computer:

www.planetsagem.com. These site offer to send ring tones to your phone in

the form of an SMS. You can also logon to your operator's site. Once the

SMS has been received, all you have to do is save it: validate the option

« Save messages », the tune will then be added to your list. In addition, you

can logon to some sites by phone.

How do I free up memory to

download my objects (sounds,

images)

Go into the

Multimedia

menu, select

My Videos, My Pictures

Sounds

then delete some objects.

How do I free up memory to receive

new messages?

Manage your Outbox carefully. It is recommended not saving them

automatically: too many messages saved will quickly fill up the available

memory and no further messages will be received. To delete them, please

go into the

Messages

menu, select

Outbox

then delete some messages.

Manage your

Inbox

carefully also.

How do I free up memory to store

new contacts in my Phonebook?

It is highly recommended to manage your Phonebook carefully.

If you have received pictures enclosed to a Vcard, please save or delete

them.

How can I increase the efficiency of

my phone?

The most efficient actions are as follows:

You can deactivate the backlight (in the menu

Settings /

Others / Energy

Saving

), or please keep your phone safely in order to avoid pressing the

keys unnecessarily: every time a key is pressed the screen lights up.

You can deactivate the screensaver or select the activation time to be more

than every 300 s (the screensaver uses processing power).

Make sure that you don’t obstruct the antenna with your fingers when using

the phone (see page 16).

ROBLEM

- S

ITUATION

CTIONS

251437828_myX-7_lu_en.book Page 89 Lundi, 2. février 2004 1:58 13

Index

Accessories p9

Activating your phone p14

Alarm p55

Anonymous mode p66

Battery

Charging the battery p17

Installing the battery p15

Beeps p59

Calculator p53

Call barring p72

Calls (menu)

Automatic redial p67

Call forward p65

Call waiting p67

Counters p66

Display number p66

View last calls p65

Camera p36

Car kit p74

Changing cover p15

Charger p9

Confidentiality p71

Contact p19

Add contact p19

Delete p23

Modify contact p23

See contact p22

Converter p54

Currencies p54

Date / Time p76

Description p9

Display p60

Energy saving p74

Fax p79

Fixed dialling p72

Games p48

GPRS p44, p45, p47

GSM p45

Icon p13

Initial screen p13

Input modes p27

IP address p45

IrDA p79

Keypad locking p10, p69

Languages p64

Local information p34

Lock keypad p69

251437828_myX-7_lu_en.book Page 90 Lundi, 2. février 2004 1:58 13

Index

Memory p23, p34

Menus p3

Messages

Compose p25

Drafts p32

Inbox p31

MMS p29

Receiving messages p30

Sending options p33

Navigation principles p12

Networks p73

Operator p71

Phone code p70

Phonebook

Phonebook menu p19

Using the phonebook p18

PIN number p69

PIN2 number p70

Programmable keys p10

Ring tones p58

Safety information p81

Screensaver p61

Security p69, p70, p71, p72, p73

Sending options p33

Serial Speed p79

Short cut keys p10, p75

Silent mode p59

SIM card p14, p15

Skins p60

SMS p25

Sounds p58, p59

T9 p26

Text p28, p29, p30

Timer p55

Troubleshooting p86, p87, p88, p89

vCard p24

Vibrate p58

Video p38, p39

Voicemail p68

Volume p58

Wallpaper p61

WAP p43, p44, p45, p46, p47

Configuring WAP parameters p44, p45

Downloading sounds and images p46

Services menu p43, p44

WAP logging off p46

WAP logging on p46

Warranties p83

Your phone package p9

251437828_myX-7_lu_en.book Page 91 Lundi, 2. février 2004 1:58 13



251437828_myX-7_lu_en.book Page 93 Lundi, 2. février 2004 1:58 13



251437828_myX-7_lu_en.book Page 94 Lundi, 2. février 2004 1:58 13



251437828_myX-7_lu_en.book Page 95 Lundi, 2. février 2004 1:58 13



251437828_myX-7_lu_en.book Page 96 Lundi, 2. février 2004 1:58 13



251437828_myX-7_lu_en.book Page 97 Lundi, 2. février 2004 1:58 13

Sagem Wireless 95H03R3 Triple Band GSM/PCS Mobile Phone 900/1800/1900 MHz User Manual Users manual

Sagem Wireless Triple Band GSM/PCS Mobile Phone 900/1800/1900 MHz Users manual

Users manual

Navigation menu

Namespaces

Views

Navigation
