Salto Systems S L AEB AElement BLE Mifare with Bluetooth technology Electronic Lock Series including all mechanical variants. User Manual 12 User 20manual

Salto Systems S.L AElement BLE Mifare with Bluetooth technology Electronic Lock Series including all mechanical variants. 12 User 20manual

Users manual

220511-ED. 21/10/2013 All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any
item in this catalog, its design, construction, and/or materials.
©2013 SALTO Syst ems S.L.
Installation guide AELEMENT
1/2
t*
*
Outside
Exterior
Inside
Interior
* Only for doors > 2-9/16" thickness
*Solo para puertas > 65mm de espesor
*Uniquement pour portes > 65 mm d' épaisseur
1
2
3
4
6
7
10
9
8
5
Only SALTO spindle
ANSI Lock
EXTERIOR
EXTERIEUR
INTERIOR
INTERIEUR
INSIDE
OUTSIDE
11
4-9/16"
(116)
2-9/16"
(65)
2-5/8"
(67)
1-25/32"
(45)
1"
(25.5)
(mm)
The mounting with other spindles voids the guaranty.
El montaje de otros cuadradillos anula la garantia.
Le montage d'autres carrés annulera le garantie.
NOTE: Screws and spindles are included in the box of the reader.
NOTA:Los tornillos y cuadradillos estan incluidos en la caja del lector.
NOTE: Les vis et les carrés sont inclus dans la boite du lecteur.
Solo cuadradillos SALTO
Seulement carrés SALTO
Eng
F
E
Installation guide
Guía de instalación
Guide d'installation
*****
AE i 0 xxx... series
(NO electronic privacy )
Recommendation for Customer’s lever set installation on SALTO AElement.
See : 4MO01300
Recomendaciones para la instalación de manillas Cliente en SALTO AElement.
Ver: 4MO01300
Recommandation pour l’installation des béquilles client sur Salto AElement.
Voir: 4MO01300
11/16"
(17,5)
220511-ED. 21/10/2013 All contents current at time of publication.
SALTO Systems S.L. reserves the right to change availability of any
item in this catalog, its design, construction, and/or materials.
©2013 SALTO Syst ems S.L. 2/2
Only SALTO spindle
123
46
Solo cuadradillos SALTO
Seulement carrés SALTO
INSIDE
Installation guide AELEMENT
ANSI Lock
CUT
*
*
CORTE
The groove must be on the same side than the grub screw.
La ranura en el lado del prisionero.
La rainure doit être du côté de la vis
INTERIOR
INTERIEUR
Metal door
Puerta metalica
Porte metallique
Wood door
Puerta madera
Porte en bois
OUTSIDE INSIDE
EXTERIOR
EXTERIEUR
INTERIOR
INTERIEUR
REMOVE
QUITAR
RETIRER
Screw driver
PZ2
1
Aligned
OUTSIDE & INSIDE
2
Alinear
EXTERIOR - INTERIOR
=
=
READER CABLE
LOCK CABLE
WIRELESS CABLE
(OPTIONAL)
CABLE LECTOR
CABLE CERRADURA
b
a
Screw driver
Torx T10 TAMPER
AT THIS POINT D O NOT
CLOSE THE DOOR
PROGRAM THE LOCK FIRST
follow user manual
