Samsung Electro Mechanics SWP-TT100 Wireless Charger Tx Pad User Manual
Samsung Electro Mechanics Wireless Charger Tx Pad
User Manual
·
·
D
User’s Manual
H
·
·
Please
read this manual thoroughly before use to ensure that
Please
read
this
manual
thoroughly
before
use
to
ensure
that
you use the product safely and properly.
The images in this manual may be different from the actual product,
and the contents are subject to change without notice for performance
improvement.
D
evice layout
Wireless charging Surface
Indicator light Multipurpose jack
H
ow to use
(Micro USB 5-Pin)
Connect a Micro USB 5-Pin Adaptor to the Slim Wireless Charger.
Micro USB 5-Pin Adaptor is not included, and the adaptor must be
certified for 5V/2A.
Place a wireless device on top of the Slip Wireless Charger, and
charging begins when the LED light flashes in green. (Charging in
progress)
progress)
The wireless device should be placed on the right position for optimum
performance.
LED Status Display
LED
Status
Display
Status LED Display
Green Red
Standby Off
Charging Flashing -
Charging Complete
On
Charging
Complete
On
-
Abnormal -On
Impurities (Metal) - Flashing Fast
Insufficient Power Flashing in Orange
※In case of abnormal status: Adjust the position of wireless device.
※In case of impurities (metal): Please check if there is an impurity (metal)
between the wireless device and Slim Wireless Charger.
※In case of insufficient power: Use a certified 5V/2A adaptor.
Considerations
Considerations
Please read the included user’s manual thoroughly before using this
product.
The receiver pad required to use this product, besides the wireless device
with Qi feature, is not included.
Do not touch the product with wet hands.
Protect the product from severe impact, e.g. dropping the product.
Use the product between 5˚C~35˚C, and avoid temperatures that are too
low or too high when storing the product.
Protect the connection parts (connection port and plug) from conductive
impurities (liquid, dust, metal powder, lead, etc).
Keep out of the reach of children or pets as they may suck
or chew the
Keep
out
of
the
reach
of
children
or
pets
as
they
may
suck
or
chew
the
product.
Do not randomly renovate, disassemble, or repair the product.
Items that contain information in magnetic strips such as credit cards,
phone cards, bank books, and tickets may be damaged by the product’s
magnetic force.
SPECS
SPECS
· Product Name: SLIM WIRELESS CHARGER
· Model Name: SWP-TT100
· Dimensions: 66 x 96 x 6mm (not including Non-Slip Pads)
· Rated Input: 5.0V---2A
· Manufacturer : Samsung Electro-Mechanics Co.,Ltd.
Md
i
K
·
M
a
d
e
i
n
K
orea
Product Warranty
Product
Name SLIM WIRELESS CHARGER Model Name SWP-TT100
Date of
Purchase S/N
Place of
Purchase Warranty
Period 1 year
Name of Customer’s
