Microwave Oven
Owner’s Manual
MW731
Safety......................................................................................2
Your New Microwave oven...................................................5
Checking Parts ....................................................................5
Warranty and Service Information.......................................5
Setting Up Your Microwave Oven .......................................5
Control Panel Buttons..........................................................6
Operation ...............................................................................7
Setting the Clock .................................................................7
Using the Pause/Cancel Button...........................................7
Using the Instant Cook Buttons...........................................7
Instant Cook Chart...............................................................8
Using the One Minute+ Button ............................................9
Defrosting ............................................................................9
Setting Cooking Times & Power Levels ..............................9
Cooking Instructions ..........................................................10
Cooking Utensils................................................................10
Testing Utensils.................................................................10
Cooking Techniques..........................................................11
General Tips......................................................................11
Cooking Guide...................................................................12
Defrosting Guide................................................................14
Recipes..............................................................................15
Appendix..............................................................................17
Troubleshooting Guide ......................................................17
Care and Cleaning.............................................................18
Specifications ....................................................................18
Warranty...............................................................................19
Guía Rápida ......................................................... Back Cover
Quick Reference................................................. Back Cover
2
S
AVE
T
HESE
I
NSTRUCTIONS
Safety
P
RECAUTIONS TO
A
VOID
P
OSSIBLE
E
XPOSURE TO
E
XCESSIVE
M
ICROWAVE
E
NERGY
:
(a) Do not attempt to operate this oven with the door
open since open-door operation can result in
harmful exposure to microwave energy. It is
important not to defeat or tamper with the safety
interlocks.
(b) Do not place any object between the oven front
face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is
particularly important that the oven door close
properly and that there is no damage to the
1) Door (bent or dented),
2) Hinges and latches (broken or loosened),
3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by
anyone except properly qualified service
personnel.
WARNING
Always observe Safety Precautions when using your
oven. Never try to repair the oven on your own – there
is dangerous voltage inside. If the oven needs to be
repaired, call 1-800-SASUNG for the name of an
authorized service center near you.
I
MPORTANT
S
AFETY
I
NSTRUCTIONS
When using any electrical appliance, basic safety precautions
should be followed, including the following:
WARNING
To reduce risk of burns, electric shock, fire, personal
injury or exposure to excessive microwave energy:
• Read all safety instructions before using the appliance.
• Read and follow the specific “Precautions to Avoid Possible Exposure
to Excessive Microwave Energy” on this page.
• This appliance must be grounded. Connect only to properly grounded
outlets. See “Important Grounding Instructions” on page 4 of this
manual.
• Install or place this appliance only in accordance with the installation
instructions provided.
• Some items, like whole eggs and food in sealed containers, may
explode if heated in this oven.
• Use this appliance only for its intended use as described in the
manual. Do not use corrosive chemicals or vapors in this appliance.
This type of oven is specifically designed to heat, cook, or dry food. It
is not designed for industrial or laboratory use.
3
S
AVE
T
HESE
I
NSTRUCTIONS
Safety
Important Safety Instructions, continued
• As with any appliance, close supervision is necessary when used by
children.
• Do not operate this appliance if it has a damaged cord or plug, if it is
not working properly, or if it has been damaged.
• This appliance should be serviced only by qualified service
personnel. Contact the nearest authorized service facility for
examination, repair, or adjustment.
• Do not cover or block any of the openings on this appliance.
• Do not store this appliance outdoors. Do not use near water – for
example, near a kitchen sink, in a wet basement, or near a swimming
pool, etc.
• Keep the inside of the oven clean. Food particles or spattered oils
stuck to the oven walls or floor can cause paint damage and reduce
the efficiency of the oven.
• Do not immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do not let cord hang over edge of table or counter.
• When cleaning door and oven surfaces, use only mild, nonabrasive
soaps or detergents applied with a sponge or soft cloth.
• To reduce the risk of fire in the oven:
a. Do not overcook food. Watch appliance carefully if paper, plastic,
or other combustible materials are inside.
b. Remove wire twist-ties from plastic cooking bags before placing
bags in oven.
c. If materials inside the oven ignite, keep the oven door closed, turn
the oven off, disconnect the power cord, or shut off the power at
the fuse or circuit breaker panel.
d. Do not use the oven compartment for storage purposes. Do not
leave paper products, cooking utensils, or food in the oven when
not in use.
• Do not try to preheat oven or operate while empty.
• Do not cook without the glass tray in place on the oven floor. Food will
not cook properly without the tray.
• Do not defrost frozen beverages in narrow-necked bottles. The
containers can break.
• Dishes and containers can become hot. Handle with care.
• Carefully remove container coverings, directing steam away from
hands and face.
• Remove lids from baby food before reheating. After heating baby
food, stir well and test temperature by tasting before serving.
• A short power-supply cord is provided to reduce the risk of becoming
entangled in or tripping over a longer cord. Longer cord sets or
extension cords are available and may be used with caution.
• Do not operate any other heating or cooking appliance beneath this
appliance.
• Do not mount unit over or near any portion of a heating or cooking
appliance.
• Do not mount over a sink.
• Do not store anything directly on top of the appliance when it is in
operation.
• Precaution for safe use to avoid possible exposure to excessive
microwave oven energy:
Do not attempt to pull any part of the door by hand to open the door.
Open the door only utilizing the push button located at front-right-
bottom side.
4
S
AVE
T
HESE
I
NSTRUCTIONS
Safety
I
MPORTANT
G
ROUNDING
I
NSTRUCTIONS
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electrical current. This
appliance is equipped with a cord that includes a grounding wire
and a grounding plug. The plug must be plugged into an outlet
that is properly installed and grounded. Plug the three-prong
power cord into a properly grounded outlet of standard 115-120
voltage, 60 Hz. Your oven should be the only appliance on this
circuit.
WARNING
Improper use of the grounding plug can result in a risk
of electric shock. Consult a qualified electrician or
servicer if you do not understand the grounding
instructions or if you are not sure if the appliance is
properly grounded.
Use of Extension Cords
A short power-supply cord is provided to reduce the risk of
becoming entangled in or tripping over a longer cord. Longer
cord sets or extension cords are available and may be used if
care is exercised in their use. If a long cord or extension cord is
used:
1. The marked electrical rating of the cord set or extension cord
should be at least as great as the electrical rating of the
appliance.
2. The extension cord must be a grounding-type 3-wire cord and
it must be plugged into a 3-slot outlet.
3. The longer cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on by
children or tripped over accidentally. If you use an extension
cord, the interior light may flicker and the blower may vary
when the microwave oven is on. Cooking times may be
longer, too.
WARNING
Do not cut or remove the third (ground) prong from the
power cord under any circumstances.
5
Your New Microwave oven
Checking Parts
Unpack your microwave oven and check to make sure that you have all
the parts shown here. If any part is missing or broken, call your dealer.
Warranty and Service Information
To help us better serve you, please complete the enclosed registration
card and promptly return it by mail. If the registration card is missing,
you can call Samsung Electronics America, Inc., at 1-800-SAMSUNG
(800-726-7864), or register on-line at WWW.SAMSUNGUSA.COM
When contacting Samsung, please provide the specific model and serial
number information which is usually located on the back or bottom of the
product. Please record these numbers below, along with the other
requested information. Keep this information in a safe place as a per-
manent record of your purchase to aid in identification in case of theft or
loss, and a copy of your sales receipt as a proof of purchase if warranty
service is needed.
MODEL NUMBER ____________________
SERIAL NUMBER ____________________
DATE PURCHASED____________________
PURCHASED FROM____________________
Warranty service can only be performed by a Samsung Authorized Ser-
vice Center. If you should require warranty service, provide the above
information with a copy of your sales receipt to the Samsung Authorized
Service Center.
For service assistance and the location of the nearest service center,
please call 1-800-SAMSUNG (800-726-7864), or go on-line to
WWW.SAMSUNGSUPPORT.COM
Setting Up Your Microwave Oven
1Place the oven on a flat, sturdy surface and plug the cord into a
grounded outlet. Once plugged in, the display on your oven will
show:
Make sure there is adequate ventilation for your oven by leaving at
least four inches of space behind, above, and to the side of the oven.
2Open the oven door by pressing the button below the control panel.
3Wipe the inside of the oven with a damp cloth.
4Place the pre-assembled ring in the indentation in the center of the
oven.
5Place the glass tray on top of the ring so that the three glass tabs in
the center of the tray fit securely into the tabs on the floor of the
oven.
32
1
654
9
87
0
microwave oven
glass tray roller guide ring
instruction
manual registration
card
6
Your New Microwave oven
Control Panel Buttons
1. Instant Cook Buttons p.7
Instant settings to cook popular foods.
2. One Minute+ p.9
Press once for every minute of cooking at High power.
3. Number buttons
Sets cooking times.
4. Defrost p.9
Press to set the defrosting time of the food to be defrosted.
5. Power Level p.9
Sets power to level other than high.
6. Clock p.7
Sets current time.
7. Pause/Cancel p.7
Press to pause oven or correct a mistake.
8. Start
Press to start cooking.
32
1
654
9
87
0
7
Operation
Setting the Clock
1Press the Clock button. The display will show:
2Use the Number buttons to enter the current time. You must press
at least three numbers to set the clock. If the current time is 5:00
enter, 5,0,0
3Press Clock again. A colon will appear, indicating that the time is
set.
If there is a power interruption, you will need to reset the clock.
You can check the current time while cooking is in progress by pressing
the Clock button.
Using the Pause/Cancel Button
The Pause/Cancel button allows you to clear instructions you have
entered. It also allows you to pause the oven’s cooking cycle, so that
you can check the food.
• To pause the oven during cooking: press Pause/Cancel once. To
restart, press Start.
• To stop cooking, erase instructions, and return the oven display to the
time of day: press Pause/Cancel twice.
• To Correct a mistake you have just entered: press Pause/Cancel once,
then re-enter the instructions.
Using the Instant Cook Buttons
1Press the Instant Cook button corresponding to the food you are
cooking (Popcorn, for example). The display shows the first
serving size:
2Press the button repeatedly to select the serving size you want.
The display will cycle through all available serving sizes. Once you
select the correct serving size, the microwave will begin cooking
automatically.
• See next page for Instant Cook Guide.
8
Operation
Instant Cook Chart Note
The cooking time of 3.0 oz. microwave-popcorn depends on
the contents of butter and brands.
Cooking time is adjustable for desired taste with numeric pads
following package instructions.
Item Weight Remarks
Popcorn 3.5 oz
3.0-3.5 oz • Use one microwave-only bag of popcorn.
• Use caution when removing and opening
hot bag from oven
• To help prevent the popcorn bag from
getting stuck in the oven, fold each end of
the bag up one inch ( ) before placing
the bag in the center of the oven.
• If it still gets stuck, open the door and
reposition the bag, close the door and
press start.
Fresh
Vegetable 1 cup
2 cups
3 cups
4 cups
• Place the vegetable into a casserole and
add some water.
• Cover during cooking and stir before
standing.
Frozen
Dinner 8-10 oz
10-12 oz • Remove package from outerwrapping and
follow package instructions for covering
and standing. After cooking, let stand 1-3
min.
Potato 1 EA
2 EA
3 EA
4 EA
• Prick each potato several times with fork.
• Place on turntable in spoke-like fashion.
• Remove from oven, wrap in foil and let
stand 3-5 min.
• Once during cooking, the oven will beep to
let you know to turn the food over.
Boil Water ½ cup
1 cup
2 cups
• Measure liquid; pour into microwave-safe
container that is 2 times larger than amount
of liquid. Example: For 1 cup liquid use a 2
cup or larger dish.
• Stir well before and after heating to prevent
erupting.
Pizza Reheat 1 Slice
2 Slices
3 Slices
• Put the pizza on a microwave-safe plate
with wide end of slice towards the outside
edge of the plate.
• Do not let slices overlap. Do not cover.
• Before serving, let stand 1-2 min.
9
Operation
Using the One Minute+ Button
This button offers a convenient way to heat food in one-minute incre-
ments at the High power level.
1Press the One Minute+ button once for each minute you wish to
cook the food. For example, press it twice for two minutes. The time
will display, and the oven starts automatically.
Add minutes to a program in progress by pressing the One Minute+
button for each minute you want to add.
Defrosting
The defrost setting is designed for speedy thawing of frozen food and is
one great advantage of the microwave oven. (Power level of 30% is
automatically set for defrosting)
1Press the Defrost button. The display shows “ PL:30”.
2Press the Number buttons to enter the desired defrosting time.
3Press the Start button to begin defrosting.
• See page 14 for the Defrosting Guide.
Setting Cooking Times & Power Levels
The power level lets you control the heating intensity from Warm to High
with the Power Level button.
1Press the Power Level button. The power level is automatically set
to high. If you want to set the power level to something other than
High, press the Power Level button repeatedly.
2Press the Number buttons sequentially to enter the desired
cooking time.
3Press the Start button to begin cooking. If you want to change the
power level, press Pause/Cancel before you press Start, and re-
enter all of the instructions.
You can check the Power Level while cooking is in progress by
pressing the Power Level button.
Pad Touch Display Output
Power
Level Once PL:Hi 700W
Twice PL:90 630W
3 Times PL:80 560W
4 Times PL:70 490W
5 Times PL:60 420W
7 Times PL:50 350W
6 Times PL:40 280W
8 Times PL:30 210W
9 Times PL:20 140W
10 Times PL:10 70W
10
Cooking Instructions
Cooking Utensils
Recommended Use
•Glass and glass-ceramic bowls and dishes — Use for heating or
cooking.
•Microwave browning dish — Use to brown the exterior of small items
such as steaks, chops, or pancakes. Follow the directions provided with
your browning dish.
•Microwavable plastic wrap — Use to retain steam. Leave a small
opening for some steam to escape and avoid placing it directly on the
food.
•Wax paper — Use as a cover to prevent spattering.
•Paper towels and napkins — Use for short-term heating and
covering; they absorb excess moisture and prevent spattering. Do not
use recycled paper towels, which may contain metal and can catch fire.
•Paper plates and cups — Use for short-term heating at low
temperatures. Do not use recycled paper, which may contain metal and
can catch fire.
•Thermometers — Use only those labeled “Microwave Safe” and follow
all directions. Check the food in several places. Conventional
thermometers may be used once the food has been removed from the
oven.
Limited Use
•Aluminum foil — Use narrow strips of foil to prevent overcooking of
exposed areas. Using too much foil can damage your oven, so be
careful.
•Ceramic, porcelain, and stoneware — Use these if they are labeled
“Microwave Safe.” If they are not labeled, test them to make sure they
can be used safely. Never use dishes with metallic trim.
•Plastic — Use only if labeled “Microwave Safe.” Other plastics can melt.
•Straw, wicker, and wood — Use only for short-term heating, as they
can be flammable.
Not Recommended
•Glass jars and bottles — Regular glass is too thin to be used in a
microwave, and can shatter.
•Paper bags — These are a fire hazard, except for popcorn bags that
are designed for microwave use.
•Styrofoam plates and cups — These can melt and leave an
unhealthy residue on food.
•Plastic storage and food containers — Containers such as
margarine tubs can melt in the microwave.
•Metal utensils — These can damage your oven. Remove all metal
before cooking.
Testing Utensils
If you are not sure whether a dish is microwave-safe or not, you can per-
form this test:
1Fill a 1 cup glass measuring cup with water and put it inside your
oven, next to the dish you want to test.
2Press the One Minute+ button once to heat them for one minute at
High power.
The water should be warm and the dish you are testing should be cool. If
the dish is warm, then it is absorbing microwave energy and is not
acceptable for use in the microwave.
11
Cooking Instructions
Cooking Techniques
Stirring
Stir foods such as casseroles and vegetables while cooking to distribute
heat evenly. Food at the outside of the dish absorbs more energy and
heats more quickly, so stir from the outside to the center. The oven will
turn off when you open the door to stir your food.
Arrangement
Arrange unevenly shaped foods, such as chicken pieces or chops, with
the thicker, meatier parts toward the outside of the turntable where they
receive more microwave energy. To prevent overcooking, place thin or
delicate parts toward the center of the turntable.
Shielding
Shield food with narrow strips of aluminum foil to prevent overcooking.
Areas that need shielding include poultry wing-tips, the ends of poultry
legs, and corners of square baking dishes. Use only small amounts of
aluminum foil. Larger amounts can damage your oven.
Turning
Turn foods over midway through cooking to expose all parts to micro-
wave energy. This is especially important with large items such as
roasts.
Standing
Foods cooked in the microwave build up internal heat and continue to
cook for a few minutes after the oven stops. Let foods stand to complete
cooking, especially foods such as roasts and whole vegetables. Roasts
need this time to complete cooking in the center without overcooking the
outer areas. All liquids, such as soup or hot chocolate, should be shaken
or stirred when cooking is complete. Let liquids stand a moment before
serving. When heating baby food, stir well and test the temperature
before serving.
Adding Moisture
Microwave energy is attracted to water molecules. Food that is uneven
in moisture content should be covered or allowed to stand so that the
heat disperses evenly. Add a small amount of water to dry food to help it
cook.
General Tips
• Dense foods, such as potatoes, take longer to heat than lighter foods.
Foods with a delicate texture should be heated at a low power level to
avoid becoming tough.
• Altitude and the type of cookware you are using can affect cooking time.
When using a new recipe, use the minimum cooking time and check the
food occasionally to prevent overcooking.
• Foods with a non-porous skin or shell, such as potatoes, eggs, or hot
dogs, should be pierced to prevent bursting.
• Frying with heating oil or fat is not recommended. Fat and oil can
suddenly boil over and cause severe burns.
• Some ingredients heat faster than others. For example, the jelly inside a
jelly doughnut will be hotter than the dough. Keep this in mind to avoid
burns.
• Home canning in the microwave oven is not recommended because all
harmful bacteria may not be destroyed by the microwave heating
process.
• Although microwaves do not heat the cookware, the heat is often
transferred to the cookware. Always use pot holders when removing food
from the microwave and instruct children to do the same.
12
Cooking Instructions
Cooking Guide
GUIDE for Cooking Meat in Your Microwave
• Place meat on a microwave-safe roasting rack in a microwave-safe dish.
• Start meat fat-side down. Use narrow strips of aluminum foil to shield any
bone tips or thin meat areas.
• Check the temperature in several places before letting the meat stand
the recommended time.
• The following temperatures are removal temperatures. The temperature
of the food will rise during the standing time.
GUIDE for Cooking Poultry in Your Microwave
• Place poultry on a microwave-safe roasting rack in a microwave-safe
dish.
• Cover poultry with wax paper to prevent spattering.
• Use aluminum foil to shield bone tips, thin meat areas, or areas that start
to overcook.
• Check the temperature in several places before letting the poultry stand
the recommended time.
Food Cook Time/Power Level Directions
Roast
Beef
Boneless
Up to 4 lbs.
Cooking Time:
8-11 min. / lb. for 115° F - Rare
9-12 min. / lb. for 120° F - Medium
10-15 min. / lb. for 145° F - Well Done
Power Level: High(Hi) for first 5
min., then Medium(50).
Place roast fat-side down on
roasting rack. Cover with
wax paper. Turn over when
cooking time is half up. Let
stand 10 min.
Pork
Boneless
or bone-
in
Up to 4 lbs.
Cooking Time:
9-13 min. / lb. for 160° F Well Done
Power Level: High(Hi) for first 5
min., then Medium(50).
Place roast fat-side down on
roasting rack. Cover with
vented plastic wrap. Turn
over when cooking time is
half up. Let stand 10 min.
Bacon
2-6 slices
Cooking Time:
2 slices: 1½- 2½ min.
4 slices: 2½- 4 min.
6 slices: 4-6 min.
Power Level: High(Hi).
Arrange slices on roasting
rack or a dish lined with
paper-towel. Cover with
paper towel. Microwave
until crisp.
Food Cook Time/Power
Level Directions
Whole
Chicken
Up to 4
lbs.
Cooking Time:
9-12 min. / lb. 170° -180°F
Power Level: High(Hi).
Place chicken breast-side down on
roasting rack. Cover with wax paper.
Turn over when cooking time is half up.
Cook until juices run clear and meat
near the bone is no longer pink. Let
stand 5-10 min.
Chicken
Pieces
Up to 2
lbs.
Cooking Time:
7-10 min. / lb.
180°F dark meat
170°F light meat
Power Level: High(Hi).
Place chicken bone-side down on dish,
with the thickest portions towards the
outside of the dish. Cover with wax
paper. Turn over when cooking time is
half up. Cook until juices run clear and
meat near the bone is no longer pink.
Let stand 5-10 min.
13
Cooking Instructions
Guide for Cooking Seafood in Your Microwave
• Cook fish until it flakes easily with a fork.
• Place fish on a microwave-safe roasting rack in a microwave-safe dish.
• Use a tight cover to steam fish. A lighter cover of wax paper or paper
towel provides less steaming.
• Do not overcook fish; check it at minimum cooking time.
Guide for Cooking Eggs in Your Microwave
• Never cook eggs in the shell, and never warm hard-cooked eggs in the
shell; they can explode.
• Always pierce whole eggs to keep them from bursting.
• Cook eggs just until set; they become tough if overcooked.
Guide for Cooking Vegetables in Your Microwave
• Vegetables should be washed just before cooking. Often, no extra water
is needed. If dense vegetables such as potatoes, carrots and green
beans are being cooked, add about ¼ cup water.
• Small vegetables (sliced carrots, peas, lima beans, etc.) will cook faster
than larger ones.
• Whole vegetables, such as potatoes, acorn squash or corn on the cob,
should be arranged in a circle on the turntable before cooking. They will
cook more evenly if turned over after half the cooking time.
• Always place vegetables like asparagus and broccoli with the stem ends
pointing towards the edge of the dish and the tips toward the center.
• When cooking cut vegetables, always cover the dish with a lid or vented
microwavable plastic wrap.
• Whole, unpeeled vegetables such as potatoes, squash, eggplant, etc.,
should have their skin pricked in several spots before cooking to prevent
them from bursting.
• For more even cooking, stir or rearrange whole vegetables halfway
through the cooking time.
• Generally, the denser the food, the longer the standing time. (Standing
time refers to the time necessary for dense, large foods and vegetables
to finish cooking after they come out of the oven.) A baked potato can
stand on the counter for five minutes before cooking is completed, while
a dish of peas can be served immediately.
Food Cook Time/Power
Level Directions
Steaks
Up to 1.5
lbs.
Cooking Time:
6-9 min. / lb.
Power Level: Medium-
High(70).
Arrange steaks on roasting rack with meaty
portions towards the outside of rack. Cover
with wax paper. Turn over and rearrange
when cooking time is half up. Cook until
fish flakes easily with a fork. Let stand 3-5
min.
Fillets
Up to 1.5
lbs.
Cooking Time:
3-7 min. / lb
Power Level:
High(Hi).
Arrange fillets in a baking dish, turning any
thin pieces under. Cover with wax paper. If
over 1/2 inch thick, turn over and rearrange
when cooking time is half up. Cook until
fish flakes easily with a fork. Let stand 2-3
min.
Shrimp
Up to 1.5
lbs.
Cooking Time:
3-6 min. / lb.
Power Level:
High(Hi).
Arrange shrimp in a baking dish without
overlapping or layering. Cover with wax
paper. Cook until firm and opaque, stirring
2 or 3 times. Let stand 5 min.
14
Cooking Instructions
Defrosting Guide
• Unwrap food. Place food on microwave-safe rack, plate or shallow dish.
• After first half of defrosting time: remove any remaining wrap, break food
apart or separate pieces if possible, remove any thawed food, if possible,
shield tips, thin meat or warm areas of food with foil.
• When defrosted, food should be cool, but softened in all areas. If still
slightly icy, return to microwave oven very briefly, or let stand a few
minutes.
• Poultry and fish may be placed under running cool water until defrosted.
Food Microwave Time at
Defrost Level Procedure
Beef
Chuck
Roast
up to 5 lbs
Steaks
up to 5 lbs
Ground
Beef
up to 3 lbs
Microwave Time: 7-10
min / lb
Let Stand: 5-10 min.
Microwave Time: 6-10
min / lb
Let Stand: 5-10 min
Microwave Time: 8-11
min / lb
Let Stand: 5-10 min.
Place on plate or rack. Microwave
until a wooden pick can be easily
inserted in center. Turn over twice.
Place on plate or rack. Microwave
until pliable, then separate steaks and
rearrange. Turn over twice.
Place on plate or rack. Microwave
until pliable, then break apart and
remove defrosted portions at halftime.
Turn over twice.
Pork
Spareribs
up to 3 lbs
Pork
Chops
up to 3 lbs
Microwave Time: 6-9
min / lb
Let Stand: 5-10 min.
Microwave Time: 6-9
min / lb
Let Stand: 5-10 min.
Place on plate or rack. Microwave
until pliable, then separate and
rearrange. Turn over twice.
Place on plate or rack. Microwave
until pliable, then separate and
rearrange. Turn over twice.
Poultry
Whole
Chicken
up to 5 lbs
Pieces
up to 2 lbs
Microwave Time: 7-10
min / lb
Let Stand: 5-10 min.
Microwave Time: 9-12
min / lb
Let Stand: 5-10 min.
Place on plate or rack. Microwave
until pliable, then break apart and
rearrange portions at half time. Rinse
cavity with cool water. Remove
giblets.
Place on plate or rack. Microwave
until pliable, then break apart and
rearrange portions at half time.
Seafood
Steaks
up to 3-5 lbs
Fillets
up to 3-5 lbs
Shrimp
up to 3 lbs
Microwave Time: 6-10
min / lb
Let Stand: 5-10 min.
Microwave Time: 4-8
min / lb
Let Stand: 5-10 min.
Microwave Time: 4-8
min / lb
Let Stand: 5-10 min.
Place on plate or rack. MIcrowave
until a wooden pick can be easily
inserted in center, break apart and
rearrange at half time.
Place on plate or rack. Microwave
until a wooden pick can be easily
inserted in center, break apart and
rearrange at half time.
Place on plate or rack. Microwave
until pliable, then separate and
rearrange at half time.
Food Microwave Time at
Defrost Level Procedure
15
Cooking Instructions
Recipes
Beef and Barley Stew
1½ lbs. beef stew cubes, cut into ½-inch pieces
½ cup chopped onion
2 Tbs. all-purpose flour
1 Tbs Worcestershire sauce
1 can (13.75-14.5 oz.) beef broth
2 medium carrots, cut into ½-inch slices (about 1 cup)
½ cup barley
1 bay leaf
¼ tsp. pepper
1 pkg. (9-10 oz.) frozen peas, thawed
1. In a 2-quart casserole, combine beef, onion, flour, and Worcestershire;
mix well. Cover with lid. Cook at High for 7 to 9 minutes until beef is no
longer pink, stirring once.
2. Stir in beef broth, carrots, barley, bay leaf, and pepper. Cover with lid.
Cook at Medium for 45 to 50 minutes until carrots and beef are tender,
stirring 2 to 3 times.
3. Stir in peas. Cover with lid. Cook at Medium for 10 minutes. Let stand for
10 minutes. Remove bay leaf before serving. Makes 6 servings.
Broccoli and Cheese Casserole
¼ cup butter or margarine
¼ cup chopped onion
1½ Tbs. flour
½ tsp. salt
¼ tsp. dry mustard
1/8 tsp. pepper
1½ cups milk
¼ cup chopped red pepper
8 oz. (2 cups) cheddar cheese, shredded
1 pkg. (9-10 oz.) frozen chopped broccoli, thawed
4 cups cooked spiral shaped pasta (8 oz. dry)
1. In a 2-quart casserole, cook butter and onion at High for 3 to 4 minutes
until onion is soft, stirring once.
2. Add flour, salt, mustard, and pepper; mix well. Cook at High for 60 to 90
seconds until mixture boils. Stir in milk until smooth.
3. Stir in red pepper. Cook at High for 2 to 3 minutes until mixture boils and
thickens slightly, stirring twice. Stir in cheese until melted.
4. Add broccoli and pasta, mix well. Cover with lid. Cook at High for 5 to 6½
min until heated through, stirring once. Stir before serving. Makes 6
servings.
16
Cooking Instructions
Warm Potato Salad
2 lbs. small red potatoes, cut into ½-inch pieces
4 slices bacon (uncooked), cut into ½-inch pieces
¼ cup chopped onion
2 tsp. sugar
1 tsp. salt
1 tsp. flour
½ tsp. celery seed
1/8 tsp. pepper
2½ Tbs. apple cider vinegar
1. In a 2-quart casserole, combine potatoes and ¼ cup water. Cover with
lid. Cook at High until potatoes are tender (10-12 min.); stir twice. Drain
and set aside to cool slightly.
2. In a medium bowl, cook bacon at High until crisp (3-5 min.); stir once.
Place bacon on a paper towel. Reserve 1 Tbs. drippings.
3. Combine drippings and onion. Cover with plastic wrap; turn back a
corner to vent steam. Cook at High until tender (3-4 min.); stir once.
4. Stir in sugar, salt, flour, celery seed, and pepper. Cook at High until
mixture boils (30-40 sec.). Stir in vinegar and ½ cup water. Cook at High
until liquid boils and thickens slightly (1-2 min.); stir once. Add bacon to
dressing. Pour dressing over potatoes. Stir well. Makes 6 servings.
Black Bean Soup
1 cup chopped onion
1 clove garlic, minced
2 cans (15 oz. each) black beans, drained
1 can (14-16 oz.) stewed tomatoes, chopped
1 can (13.75-14.5 oz.) chicken broth
1 can (7-8.5 oz.) corn
1 can (4 oz.) chopped green chilies
1-2 tsp. ground cumin, or to taste
1. Place onion and garlic in a 3-quart casserole. Cover with lid. Cook at
High for 4 to 5½min until tender.
2. Add one can of beans, mash beans with a fork. Add remaining
ingredients; mix well.
3. Cook uncovered, at High for 10 minutes; stir. Reduce power to Medium
and cook for 6 minutes. Stir before serving. Makes about 2 quarts.
17
Appendix
Troubleshooting Guide
Before you call a repair person for your oven, check this list of possible
problems and solutions.
Neither the oven’s display nor the oven operate.
• Properly insert the plug into a grounded outlet.
• If the outlet is controlled by a wall switch, make sure the wall switch is
turned on.
• Remove the plug from the outlet, wait ten seconds, then plug it in again.
• Reset the circuit breaker or replace any blown fuse.
• Plug another appliance into the outlet; if the other appliance doesn’t
work, have a qualified electrician repair the outlet.
• Plug the oven into a different outlet.
The oven’s display works, but the power won’t come on.
• Make sure the door is closed securely.
• Check to see if packing material or other material is stuck to the door
seal.
• Check for door damage.
• Press Cancel twice and re-enter all cooking instructions.
The power goes off before the set time has elapsed.
• If there has not been a power outage, remove the plug from the outlet,
wait ten seconds, then plug it in again. If there was a power outage, the
time indicator will display “88:88” Reset the clock and any cooking
instructions.
• Reset the circuit breaker or replace any blown fuse.
The food is cooking too slowly.
• Make sure the oven is on its own 15 amp circuit line. Operating another
appliance on the same circuit can cause a voltage drop. If necessary,
move the oven to its own circuit.
You see sparks or arcing.
• Remove any metallic utensils, cookware, or metal ties. If using foil, use
only narrow strips and allow at least one inch between the foil and
interior oven walls.
The turntable makes noises or sticks.
• Clean the turntable, roller ring and oven floor.
• Make sure the turntable and roller ring are positioned correctly.
Using your microwave causes TV or radio interference.
• This is similar to the interference caused by other small appliances, such
as hair dryers. Move your microwave further away from other appliances,
like your TV or radio.
18
Appendix
Care and Cleaning
Follow these instructions to clean and care for your oven.
• Keep the inside of the oven clean. Food particles and spilled liquids can
stick to the oven walls, causing the oven to work less efficiently.
• Wipe up spills immediately. Use a damp cloth and mild soap. Do not use
harsh detergents or abrasives.
• To help loosen baked on food particles or liquids, heat two cups of water
(add the juice of one lemon if you desire to keep the oven fresh) in a four-
cup measuring glass at High power for five minutes or until boiling. Let
stand in the oven for one or two minutes.
• Remove the glass tray from the oven when cleaning the oven or tray. To
prevent the tray from breaking, handle it carefully and do not put it in
water immediately after cooking. Wash the tray carefully in warm sudsy
water or in the dishwasher.
• Clean the outside surface of the oven with soap and a damp cloth. Dry
with a soft cloth. To prevent damage to the operating parts of the oven,
don’t let water seep into the openings.
• Wash the door window with very mild soap and water. Be sure to use a
soft cloth to avoid scratching.
• If steam accumulates inside or outside the oven door, wipe with a soft
cloth. Steam can accumulate when operating the oven in high humidity
and in no way indicates microwave leakage.
• Never operate the oven without food in it; this can damage the
magnetron tube or glass tray. You may wish to leave a cup of water in
the oven when it is not in use to prevent damage if the oven is
accidentally turned on.
If you have a problem you cannot solve,
please call our service line:
1-800-SAMSUNG
(1-800-726-7864)
Specifications
Model Number MW731
Oven Cavity 0.7cuft
Controls 10 power levels, including defrost
Timer 99 minutes, 99 seconds
Power Source 120 VAC, 60 Hz
Power Output 700 Watts
Power Consumption 1100 Watts
Outside Dimensions 191/4”(W) X 1013/16”(H) X 1313/16”(D)
Oven Cavity Dimensions 13(W) X 729/32”(H) X 1215/16”(D)
Net/Gross Weight 26.5/28.5 lbs
19
Warranty
SAMSUNG MICROWAVE OVEN
This SAMSUNG brand product, as supplied and distributed by
SAMSUNG ELECTRONICS AMERICA, INC. (SAMSUNG) and
delivered new, in the original carton to the original consumer
purchaser, is warranted by SAMSUNG against manufacturing
defects in materials and workmanship for a limited warranty period
of:
One (1) Year Parts and Labor, Eight (8) Years Parts Warranty for
Magnetron
This limited warranty begins on the original date of purchase, and is
valid only on products purchased and used in the United States. To
receive warranty service, the purchaser must contact SAMSUNG for
problem determination and service procedures. Warranty service
can only be performed by a SAMSUNG authorized service center.
The original dated bill of sale must be presented upon request as
proof of purchase to SAMSUNG or SAMSUNG’s authorized service
center. Transportation of the product to and from the service center
is the responsibility of the purchaser.
SAMSUNG will repair or replace this product, at our option and at no
charge as stipulated herein, with new or reconditioned parts or
products if found to be defective during the limited warranty period
specified above. All replaced parts and products become the
property of SAMSUNG and must be returned to SAMSUNG.
Replacement parts and products assume the remaining original
warranty, or ninety (90) days, whichever is longer.
This limited warranty covers manufacturing defects in materials and
workmanship encountered in normal, non-commercial use of this
product and shall not apply to the following, including, but not limited
to: damage which occurs in shipment; delivery and installation;
applications and uses for which this product was not intended;
altered product or serial numbers; cosmetic damage or exterior
finish; accidents, abuse, neglect, fire, water, lightning or other acts of
nature; use of products, equipment, systems, utilities, services,
parts, supplies, accessories, applications, installations, repairs,
external wiring or connectors not supplied or authorized by
SAMSUNG which damage this product or result in service problems;
incorrect electrical line voltage, fluctuations and surges; customer
adjustments and failure to follow operating instructions, cleaning,
maintenance and environmental instructions that are covered and
prescribed in the instruction book; product removal and
reinstallation; problems caused by pest infestations, and overheating
or overcooking by user; glass tray or turntable; reduced magnetron
power output related to normal aging. SAMSUNG does not warrant
uninterrupted or error-free operation of the product.
LIMITED WARRANTY TO ORIGINAL PURCHASER
20
Warranty
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE
LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES
WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT
LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY
PERIODS STATED ABOVE, AND NO OTHER EXPRESS
WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR
CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE
BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR
LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE
SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE
USE, MISUSE OR INABILITY TO USE THIS PRODUCT,
REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM
IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL
RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN
AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT
SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE.
WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES
ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO
PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS
AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR
INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT
CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS
LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER
THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS
NONTRANSFERABLE AND STATES YOUR EXCLUSIVE
REMEDY.
Some states do not allow limitations on how long an implied warranty
lasts, or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to
you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
To obtain warranty service, please contact: SAMSUNG
ELECTRONICS AMERICA, INC. - WWW.SAMSUNGUSA.COM
SAMSUNG CUSTOMER SERVICE
400 VALLEY RD., SUITE 201, MT. ARLINGTON, NJ 07856
Tel: 973-601-6000, Fax: 973-601-6001
1-800-SAMSUNG (1-800-726-7864)
WWW.SAMSUNGSUPPORT.COM
21
Warranty
SAMSUNG ELECTRONICS
Subject to the requirements, conditions, exclusions and limitations of the
Original Limited Warranty supplied with Samsung Electronics (SAM-
SUNG) products, and the requirements, conditions, exclusions and limi-
tations contained herein, SAMSUNG will additionally provide Warranty
Repair Service in the United States on SAMSUNG products purchased
in Canada, and in Canada on SAMSUNG products purchased in the
United States, for the warranty period originally specified, and to the
Original Purchaser only.
The above described warranty repairs must be performed by a SAM-
SUNG Authorized Service Center. Along with this Statement, the Origi-
nal Limited Warranty Statement and a dated Bill of Sale as Proof of
Purchase must be presented to the Service Center. Transportation to
and from the Service Center is the responsibility of the purchaser.
Conditions covered are limited only to manufacturing defects in material
or workmanship, and only those encountered in normal use of the prod-
uct.
Excluded, but not limited to, are any original specified provisions for, in-
home or on-site services, minimum or maximum repair times,
exchanges or replacements, accessories, options, upgrades, or con-
sumables.
For the locations of a SAMSUNG Authorized Service Center in the
United States and Canada, please contact SAMSUNG at:
1-800-SAMSUNG (1-800-726-7864)
Or on-line at:
WWW.SAMSUNGUSA.COM and WWW.SAMSUNGCANADA.COM
Note
NORTH AMERICAN LIMITED WARRANTY ADDENDUM
22
Note
23
Note
Guía Rápida Quick Reference
Feature Operation
Programar el Reloj 1. Presione CLOCK.
2. Use los botones numéricos para ingresar la
hora del día.
3. Presione nuevamente CLOCK.
Cocinando con Un
Minuto Más 1. Presione el botón ONE MINUTE + una vez por
cada minuto de cocción.
2. Se mostrará el tiempo en la pantalla y el horno
comenzará.
Botones Cocción
Instantánea 1. Presione el botón que corresponda al alimento
que va a cocinar. (Por ejemplo POPCORN).
2. Presione repetidamente el botón para
seleccionar la porción.
Descongelar 1. Presione DEFROST.
2. Presione en secuencia los botones numéricos
(del 0 al 9) para ingresar el tiempo deseado de
descongelado.
3. Presione START.
Para programar el
Tiempo de Cocción
y los Niveles de
Potencia
1. Presione el botón POWER LEVEL. Si usted
desea programar un nivel de potencia diferente
a ALTO, entonces presione repetidamente el
botón POWER LEVEL.
2. Use los botones numéricos para programar el
tiempo de cocción.
3. Presione START para comenzar a cocinar.
Feature Operation
Set Clock 1. Press CLOCK.
2. Use the Number buttons to enter the current
time.
3. Press CLOCK again.
One Minute+
Cooking 1. Press the ONE MINUTE + button once for each
minute of cooking.
2. The time will display and the oven will start.
Instant Cook
Buttons 1. Press button that corresponds to the food you
are cooking (for example, POPCORN).
2. Press the button repeatedly to select serving
size.
Defrost 1. Press DEFROST.
2. Press the buttons(0-9) sequentially to enter the
desired defrosting time.
3. Press START.
Set Cooking Time
and Power Levels 1. Press the POWER LEVEL button. If you wnat to
set the power level to something other than
High, press the POWER LEVEL button
repeatedly.
2. Use NUMBER buttons to set cooking time.
3. Press START to begin cooking.
ELECTRONICS
SAMSUNG ELECTRONICS AMERICA, INC.
HEADQUARTERS
105 CHALLENGER ROAD
RIDGEFIELD PARK, NEW JERSEY 07660-0511
Samsung Electronics Co., Ltd.
June 2002
Printed in Malaysia
